BYD G3. Service Instruction - part 4





BYD G3 AUTO Owner’s Instruction





46

Left Information Display



 Fuel Gauge





When  power  supply  is  at  ON,  this
gauge

indicates

remaining

fuel

amount in the fuel tank.

Almost Full

– all eight grids are lighted.

Almost Empty

– the last grid is flashing.

Generally the fuel shall be more than 1/4
full.

In braking, accelerating and turning, the
indicator  may  flash  quickly,  which  is
caused by shaking fuel in the tank.

When the fuel  level is  near to ―E‖ mark
with  the  information  screen  displaying
―Please refill fuel‖, you shall add fuel as
soon as possible.
On slope road or in turning, the shaking
fuel  in  the  tank  may  cause  the  fuel
indicator  flashing  or  ―Please  refill  fuel‖
displayed  on  information  screen  before
the normal refilling time.

 Engine  Cooling  Fluid Temperature

Gauge







When  power  supply  is  at  ON,  this
gauge  indicates  the  temperature  of
engine  cooling  fluid.  The  engine
temperature  varies  with  climate  and
engine load.


If  the  main  warning  light  is  on  with
―Cooling Fluid Overheated‖ displayed on
the  right  information  screen,  it  means
the  engine  cooling  fluid  is  overheated.
When  the  engine  is  overheated,  you
shall  stop  the  car  to  cool  down  the
engine.
The  engine  may  get  overheated  in  the
following cases:

● Driving uphill in hot days;
● When the car is stopped frequently in
driving, the AC device is turned on with
the engine running in idle state for a long
time.
● When the care is used to tow a trailer.


Note

 Do not remove the thermostat

in  the  engine  cooling  system,
otherwise  the  engine  may  run
abnormally.



When

the

engine

is

overheated,  do  not  continue
driving.




-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





47

 Odometer and Dual Short Mileage

Odometer







This  screen  displays  the  following
information.

1.  Odometer

–  displays  the  total  travel

mileage of the car.
2.  Dual  Short  Mileage  Odometer

–

display  the  travel  mileage  after  the  two
short  mileage  odometers  are  reset  to
zero respectively.

You can use one to calculate remaining
fuel amount (TRIP A) and use another to
record the mileage of each trip (TRIPB).
3.  Trip/Reset  button  (ODO  TRIP  button
on  the  left)

–  reset  the  dual  short

mileage  odometers  and  change  the
display mode.







To  change  the  display  mode,  press
down and then quickly release the ODO
TRIP  button.  Pressing  the  button
repeatedly, the odometer will display the
following  information  in  cycle:    Total
Mileage

(ODO)

–  Short  Mileage

Odometer  (TRIPA)

–  Short  Mileage

Odometer  (TRIP  B)  -  Total  Mileage
(ODO).
To  reset  a  short  mileage  odometer,
switch  the  information  displayed  on  the
screen  to  the  reading  of  it  firstly,  then
press  TRIP  button  for  over  2  seconds
and release the button after it is reset to
zero.

Tachometer






Tachometer  displays  the  engine
speed  in  rpm  (round  per  minute)  by
multiply  the  reading  by  1000.  Make
gear

shift

according

to

the

tachometer  reading  can  prevent
engine from over speed running.


Driving  at  over  high  engine  speed  will
lead  to  excessive  wear  of  the  engine
and higher fuel consumption.


Note

Do not  allow the  pointer  to enter
read  area,  which  means  the
engine may severely damaged.




-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





48

Maintenance of Indicator Lights & Warning Buzzer



In driving, if any indicator light is on or

information is displayed on the right screen

or the buzzer gives out warning tone

Solution

(a)



Parking brake indicator
Possible  cause:  low  braking  fluid  level,  braking  system  failure,  parking  brake  is  not
released.
Stop driving and contact BYD service station immediately.

(b)



Indicator for unfastened seat belt.

Wear driver’s seat belt.

(c)



Indicator for charging system fault.
Stop driving and contact BYD service station immediately.

(d)



Warning indicator for low engine oil pressure.
Stop driving and contact BYD service station immediately.

(e)



Indicator for engine fault
Send the car to BYD service station for a check.

(f)



Smart key, key position indicator

(g)



Indicator for ABS fault
Send the car to BYD service station for a check. If the parking brake indicator is also
on, stop driving and contact BYD service station immediately.

(h)



Service Indicator
Send the car to BYD service station for a check.

(i)



Indicator for opened door.
Check and make sure all doors are closed.

(j)



Indicator for airbag fault
Send the car to BYD service station for a check.

(k)



Main warning indicator
Pay attention to information displayed on the right screen.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





49

Right Information Display

Information  switch  button  (DISP  button
on  the  right)

–  used  to  switch  between

and set up information.




Time Adjustment

Clock  setting  is  realized  through
combination of DISP button on the right
and ODO TRIP button on the left of the
combination instrument.


①

Switch  to  clock  interface  through

DISP  button,  and  press  ODO  TRIP
button on the combination instrument to
enter  clock  setting  interface,  and  the
hour value on the screen begins flashing.
At this time, press DISP button once to
increase the hour value by 1; press and
hold  the  button  the  value  will  be
displayed from 00 to 23 in cycle.


②

Press  ODO  TRIP  button  again,  the

hour value stop flashing and the minute
value begins flashing. At this time press
DISP button once to increase the minute
value by 1; press and hold the button the
value  will  be displayed from 00 to 59 in
cycle.


3

  Press  ODO  TRIP  button  again,  the

minute  value  stop  flashing  and  the
single  digit  and  tens  digit  of  year  value
begins flashing. At this time press DISP
button once to increase the minute value
by 1; press and hold the button the value
will be displayed from 09 to 49 in cycle.




 The order of value adjustment is hour

value-  minute  value

–  tens  digit  and

single digit of year value

– month value-

day value

– hour value.



  When  finishing  adjustment  of  day

value, long press ODO TRIP button for 2
seconds  to  exit  clock  setting  and  the
interface  will  shift  to  clock  interface
automatically;  press  ODO  TRIP  button
again to go to step 1.



  During  operation,  if  you  long  press

ODO  TRIP  button  for  2  seconds,  the
interface  will  switch  to  clock  interface
automatically.

During  setting,  if  you  stop  operation
before adjustment  is  finished,  the  clock
setting  will  be  regarded  as  completed
and  the  current  time  value  will  be
accepted after 10 seconds.


-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





50

 Driving Information Display

Press TRIP button to switch driving

information,  and  available  items  and
display  order  are  shown  in  the  table
below:



Display item

Description

Clock

When  the  power  supply  is  at  ON,  the clock  will
always be displayed.

Date

When the power supply is at ON, the date will be
displayed by default.

Fuel consumption

The  total  fuel  consumption  since  the  last

resetting,  press  ―DISP‖  button  for  2  seconds  to
reset this item.

Average fuel consumption

The  average  fuel  consumption  /  100  km  since

the  last  resetting;  press  ―DISP‖  button  for  2
seconds to reset this item.

Instant fuel consumption

Instant fuel consumption amount.

Oil mileage

The  expected  travel  mileage  of  the  remaining
fuel,  which  is  calculated  by  a  combination  of
average  fuel  consumption  and  instant  fuel
consumption.  The  actual  mileage  may  be
different from this value.

Average speed

The  average  vehicle  speed  since  the  last

resetting;  press  ―DISP‖  button  for  2  seconds  to
reset this item.

Clock setting

Clock and date adjustment is in increment cycle

mode.

Driving time

The  time  after  engine  starting  or  the  last

resetting;  press  ―DISP‖  button  for  2  seconds  to
reset this item.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





51

 Prompt Information Display


Display description or buzzer tone

Description

Key is not detected

If key is not detected, this information will be displayed after pressing starting switch.

Low key battery

This information prompts key battery is running low. Please change battery.

Parking braking is not released.

When vehicle speed is over 5km/h and the parking braking is not released, this

information will be displayed with buzzer warning.

Please refill fuel

When remaining fuel is low, this information will be displayed with buzzer warning.


 Fault Information Display


Display description or buzzer tone

Description

Cooling fluid temperature is over high

This information will be displayed when the cooling fluid temperature is over high. Stop
the car immediately and contact BYD service station.

Low engine oil pressure

The  engine  oil  is  not  sufficient.  Stop  driving  and  contact  BYD  service  station
immediately.

Check charging system

This  information  indicates  that  there  is  fault  with  charging  system.  Stop  the  car
immediately and contact BYD service station.

Check brake system

This  information  indicates  that  brake  fluid  level  is  low  or  there  is  fault  with  braking
system. Stop the car immediately and contact BYD service station.

Check ABS system

This  information  will  be  displayed  when  there  is  fault  with  ABS  or  braking  system.
Contact BYD service station for a check immediately.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





52

(a) Braking System Warning Light

When  ignition  switch  is  at  ON,  the
indicator  will  be  on  in  the  following
cases:

● When Braking Fluid Level is low…


Tips

When  braking  fluid  level  is  low,
continued driving is dangerous.



The  car  shall  be  checked  by  BYD
service station in the following cases.

● When ignition switch is at ON, the light

is not on even when the parking brake
is applied.

●  When  the  parking  brake  is  released,

even if ignition switch is turned on, the
light is not on.

During  operation  if  the  light  is  on
temporally it does not mean that there is
fault.









Tips

If any of the following cases, park
the car in a safe place and contact
BYD service station immediately.
● When engine is running, even if

the  parking  brake  is  released,
the light remains on.

In  this  case  the  brake  may  be
abnormal,  which  means  the
brake  stopping  distance  is
longer. Step on the brake pedal
forcibly for emergency cut-off.


● Braking system warning light is

still on when ABS warning light
is on.

In this case, the anti-lock brake
system  does  not  function  and
the  car  will  be  extremely
unstable.










(b) Seat Belt Indicator

The light  will remind the driver to fasten
seat belt.

When ignition switch is at ON or START,
if  the  driver’s  seat  belt  is  not  fastened,
this indicator will be turned on. The seat
belt will remains on until the driver’s seat
belt is fastened.

(c) Discharging Warning Indicator

This light remind  you that the battery in
discharging state.

If this indicator is on during driving, there
may be fault in charging system.

The  engine  can  start  up  normally  until
the  battery  is  depleted.  Turn  off  all
electrical  appliances,  such  as  AC,  fan
and  radio,  and  drive  the  car  to  the
nearest BYD service station for repair.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





53

(d) Low Engine Oil Warning Indicator

This indicator warns you that engine oil
pressure is low.

In  driving,  if  this  indicator  flashes  or
remains on, stop your car away from the
road  and  stop  the  engine  immediately.
Contact BYD service station for help.

When the engine is in idle running, this
indicator  will  flash  occasionally  or  turns
on after emergency braking. In this case,
if the indicator goes out in acceleration,
it means this system is normal.

When  the  engine  oil  level  is  low,  this
light  will also be turned on. This  light is
not intended to indicate engine oil level.
Engine  oil  level  shall  be  checked  by
dipstick.


Note

Do not continue driving when the
warning light is on

– even a short

distance may damage the engine.



(e) Engine Fault Indicator
This  indicator  will  be  turned  on  when
there is fault with engine EFI system.
When  the  light  is  turned  on,  please
contact

BYD

service

station

for

repair/check as soon as possible.

(F) Low Fuel Level Warning Indicator
This indicator will turn on  when the fuel
in the tank is running low. You shall refill
the tank as soon as possible.
On slope or in turning, the shaking fuel
in the tank may cause the indicator to be
turned on earlier.

(g) ABS Warning Indicator
When ignition switch is at ON, this  light
will  be  turned  on.  If  the  anti-lock  brake
system is normal, the light will be turned
off  after  several  seconds.  Later  if  the
system gets it trouble, this light  will turn
on again.
When  ABS  warning  light  is  turned  on
and braking system warning indicator is
turned  off,  anti-lock  braking  system  is
disabled  but  the  braking  system  still
functions normally.
In this case the wheels may be locked in
braking  in  emergency  braking  and  on
slippery road.

If  any  of  the  following  cases,  parts
monitored  by  the  indicator  system
may  have  problem,  and  please
contact BYD  service station  as  soon
as possible.

●  When  ignition  switch  is  at  ON,  this
light never turns on or is always on.
● This light is turned on in driving.
During  operation  if  the  light  is  on
temporally it does not mean that there is
fault.


Tips

When  braking  system  warning
indicator  is  on,  if  ABS  warning
indicator  is  still  on,  please  park
the car at a safe place and contact
BYD service station immediately.
In  this  case,  the  anti-lock  brake
system does not function and the
car will be extremely unstable.




(h) Door Open Warning Indicator
This  light  will  remains  on  until  all  doors
are closed.


-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





54

(i) SRS Warning Light

When ignition switch is at ON, this  light
will be turned on. And it will be turned off
after  some  5  seconds.  It  means  the
airbag system functions normally.
This  warning  indicator  is  intended  to
monitor  airbag  ECU,  impact  sensor,  air
charging

device,

warning

light,

connecting wire and power supply.
If  any  of  the  following  cases,  it  means
there  is  fault  with  parts  monitored  by
warning

indicator

system.

Please

contact BYD service station for a check
as soon as possible.
●  When  ignition  switch  is  at  ON,  this

light never turns on or is always on.

●  This  light  is  turned  on  or  flashes  in
driving.

(j) Buzzer Light Indicator
When width-indicator lights or headlights
are turned on, if you open driver’s door,
the buzzer will give out warning tone.


Check Maintenance Indicators

1. Apply parking brake.
2. Open a door.

Door open indicator shall be turned

on.
3. Close the door.

Door  open  indicator  shall  be  turned

off.
4. Turn ignition switch to ON, but do not
start the engine.

All maintenance indicators shall be
turned on except door open indicator.
ABS indicator shall be turned off after
several seconds. SRS indicator shall
be turned off after some 6 seconds.

If  any  maintenance  indicator  or  buzzer
does  not function  as  per  the  procedure
above,  please  have  the  car  checked  in
BYD  service  station  as  soon  as
possible.



Note

In  driving,  if  the  red  warning
indicator  (such  as  indicator  for
discharging,  braking,  engine  oil,
water

temperature)

on

the

instrument  panel  is  turned  on,
you

shall

stop

the

car

immediately  and  check  for  fault
as per instructions in this instruction.
If  necessary,  please  call  for  help
for BUD service station.

















-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





55

Chapter 1

Section 6



Operation of Instruments and Controllers


Parking System


Parking System .................................................................................................. 56





-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





56

Parking System







When  parking  the  car,  apply  the
parking  handle  firmly  to  avoid
random move of the car.

Setting:  pull  up  parking  handle.  To  get
better  holding  force,  step  on  and  hold
the  brake  pedal  firstly  until  the  parking
handle is pulled up.
Releasing:  pull  up  parking  handle  (1)
slightly,  press  down  lock-releasing
button (2) and then release (3).
To remind you that the parking handle is
applied, the parking system indicator on
the instrument panel will remain on until
the parking handle is released.




Tips

Before  driving,  make  sure  that
parking  handle  is  released  fully
and the  parking  system  indicator
goes out.







-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





57

Chapter 1

Section 7



Operations of Instruments and Controllers


Automobile Multimedia System



Multimedia System (optional) ............................................................................ 58





-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





58

Multimedia System (optional)








Digital preset keys

Power/Volume

USB button

Sound effect

adjusting button

AUX button

Instruction station

selecting button

Mute button

Disc exit button

Auto station

selecting button

Radio button

Scanning and

previewing button

CD button

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





59

Multimedia System

FM/AM Radio
Multimedia  system  on  your  BYD
auto  can  receive  AM  and  FM  band
clearly. Meanwhile, digital preset key
makes it easy for you to select your
favorite radio station.

Operations of Radio
Only in the position of ACC (I) or ON
(II),  can  you  operate  the  sound
system.  Press  power/volume  button
(PWR/VOL)  or  FM/AM  button,  you
can  start  the  Multimedia  system.
Turn

power/volume

knob

(PWR/VOL),  you  can  adjust  the
volume.

At  last,  the  received  waveband  and
frequency  will  be  displayed.  To
change  the  waveband,  just  press
FM/AM button. Every time you press
FM/AM button, waveband will switch
from  FM1  to  FM2,  FM3,  AM1  and
AM2.If you listen to the stereo radio
station,  "ST‖  will  appear  on  the
screen.  If  you  drive  through  the
place  with  weak  radio  signal,  ―ST‖
will flicker on the screen.

Radio Selection

Five  ways  are  available  for  you  to
search  radio  station  on  the  selected
waveband  as  follows:  instruction  station
selection (TUNE), auto station selection
(SEEK),

scanning

and

previewing

(SCAN),  auto  station  scanning  and
saving  (long  press  SCAN)  or  digital
preset button.

Instruction Station Selection (TUNE)

Using  instruction  station  selection  button
(TUNE),  you  can  receive  your  desired
broadcasting frequency. Press the top of
TUNE, you can adjust to high frequency;
press  the  bottom  of  TUNE,  you  can
adjust  to  low  frequency.  When  your
desired  frequency  appears  on  the
screen, just stop pressing.

Auto Station Selection (SEEK)
Auto  station  selection  is  available  to
search radio station with a strong signal
on  certain  waveband  automatically.  To
enable  this  function,  press  the  top  or
bottom of SEEK button and then release
it.  Sound  system  will  scan  up  or  down
from  the  current  frequency  according
the  place  you  press. When  it  searches
certain  station  with  strong  signal,  it  will
stop searching.

Scanning and Previewing (SCAN)

Scanning and previewing is available to
play  all  the  saved  radio  stations  on  all
the  wavebands  for  previewing.  To
enable this function, press SCAN button
and then release it.

―SCAN‖ will appear

on  the  screen.  Multimedia  system  will
play  all  the  saved  radio  stations  on  all
the  wavebands  for  about  5  seconds.
Without  any  operation  at  the  moment,
system  will  continue  to  play  the  next
radio station; when it plays your desired
station,  just  press  SCAN  and  then  you
can listen to it.
Preset (PRESET)
You  can  store  the  frequency  of  your
favorite  radio  stations  under  the  six
digital  preset  keys.  Digital  preset  keys
are  available  to  save  radio  stations  in
AM1 and AM2 on the AM waveband well
as  FM1,  FM2  and  FM3  on  FM
waveband respectively.
In saving frequency, you shall follow the
steps below:

1.  Select  your  desired  waveband
(AM or FM).
2.  Use  instruction  station  selection
(TUNE),

auto

station

selection

(SEEK), or scanning and previewing
(SCAN) to receive your desired radio
station.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





60

3. Select the preset number (1~
6) for saving your desired station,
press this key for 2 seconds and
then  the  station  will  be  saved
under  the  corresponding  preset
number.
4.  Repeat  the  operations  above
from 1 to 3, you can save 12 AM
radio  stations  and  18  FM  radio
stations.

Once  the  frequency  of  radio station
is

saved,

simply

press

the

corresponding digital preset key and
you can listen to this radio station.
If  storage  batteries  on  the  car  are
detached or used up or fuse of radio
is  taken  down,  the  preset  channel
will be cancelled.

Auto Station Scanning and Saving
(long press SCAN)
Long  press  SCAN  for  about  2
seconds,  system  will  automatically
search  the  radio  station  with  strong
signal  and  save  them  to  FM1,  FM2
and  FM3  or  AM1  and  AM2.Press
auto  station  scanning  and  saving
button  (SCAN),  you  can  enable  this
function.  Then

,  ―SCAN‖  on  the

screen will flicker at the frequency of
1Hz.Altogether,  12  AM  and  18  FM
radio  stations  can  be  saved  under

the digital preset keys (1~6).Then, you
can  select  the  preset  radio station  with
these  digital  preset  keys  (1~6).If  you
don’t  like  to  listen to the channel saved
through auto scanning, you can use the
digital  preset  key  to  save  other
frequencies.  First,  search  your  desired
frequency  by  instruction  station  selection
(TUNE),  auto  station  selection  (SEEK)
or  scanning  (SCAN),  and  then  save
them  under  the  selected  digital  preset
key as mentioned above.

Volume Adjustment
Bass,  treble,  balance  and  fader  are
adjustable.  Press  the  sound-effect
adjustment  button  (AUDIO),  you  can
select  your  desired  mode.  Every  time
you press AUDIO button, the mode  will
switch from BAS to TRE, BAL, and FAD
in  order;  after  one  circle,  short  press
―AUDIO‖ button, the interface of screen
will  return  to  the  current  mode.  If  the
mode  is  changed,  corresponding  mode
name  will  be  displayed  on  the  screen
one by one.

Balance/Fader
Sound intensity of each speaker can be
adjusted  by  these  two  modes.  Left  &
right sound intensity can be adjusted by
Balance  while  front  &  rear  sound
intensity  can  be  adjusted  by  Fader.
Press AUDIO button and you can select
Balance or Fader. Turn the volume knob
and you can adjust Balance or Fader to
a  satisfied  level.  The  displayed  number
is what you set currently.

Treble/Bass
By  using  these  modes,  you  can  adjust
the  timbre  to  a  favorite  level.  Press
AUDIO button and you can select treble
(TRE)  or  bass  (BAS)  mode.  Turn  the
volume  knob  and  you  can  adjust  the
timbre to a favorite level. The displayed
number  is  what  you  set  currently.  After
you  stop  using  the  volume  knob  to
adjust  the  mode  for  three seconds,  the
system will get back to the current mode
automatically.

Mute

If  a  quiet  environment  is  needed
temporarily, you can quickly  turn off the
sound of speaker by mute button.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

BYD G3 AUTO Owner’s Instruction





61

Playing Compact Disc
To  play  compact  disc,  the  ignition
switch

must

be

turned

to

ACCESSORY (I) or ON (II).You can
operate

CD

player

with

the

controlling device which can also be
used to operate the radio. To select
CD player, please press DISC button.
You w

ill see "CD‖ and the number of

ongoing  program  displayed  on  the
screen. System will continue to play
CD  until  you  change  the  mode.
Insert a CD into the CD slot and the
driver will absorb it and start playing.
After  the  system  finishes  playing,  it
will return to the very beginning and
play the CD again.

Notes
:
Please do not use the disk with any
adhesive label. As the label may curl,
it may lead to the disc to be locked in
the device or cause other faults.
Please do not play the 8cm (3 inch)
disc. You are only allowed to play the
standard  round  disc.  Deformed  disc
may be locked in the driver or cause
other faults.

To  achieve  the  best  effect  for  playing
CD-R,  please  only  use  the  high-quality
disc  with  the  mark  of  ―

―.Making  a

CD-R  shall  be  completely  closed.  By
doing so, the disc can be played on the
CD  player.  This  device  is  not  designed
for CD-RW.
When  playing  the  CD,  press  FM/AM
button and you can switch to radio mode.
Press  DISC  button  again  and  the
system  returns  to  CD  mode  and  starts
playing from the point where it stops last
time.

During playing, if you turn off this system
by pressing PWR/VOL button or shutting
down  the  ignition  switch,  the  disc  will
remain  in  the  driver.  Start  this  system
again  and  the  player  will  start  playing
from  the  point  where  it  stops  last  time.
Press Exit button and you can take out
the disc from the driver.

If the disc is released out but  not taken
away from the disc slot for ten seconds,
it  will  enter  again  automatically.    To
start  playing  this  disc,  just  press  DISC
button.
During  playing  the  disc,  you  can  select
music  and  change  program  by  SEEK
button.

To  fast  move  the  disc  in  the  same
program,  just  long  press  SEEK  button.
Long press the top of ―SEEK‖ button to
fast forward and its bottom to fast rewind.
When  it  reaches  your  desired  position,
just  release  the  button.  Short  press  the
top  of  ―SEEK‖  button,  the  system  will
skip  forward  to  the  beginning  of  next
program.  Shot  press  the  bottom  of
―SEEK‖  button,  the  system  will  skip
backward  to  the  beginning  of  current
program.
Press it again and the system will skip to
the  beginning  of  last  program.  During
playing, you can achieve such functions
as  pause,  repeat  (RPT),  preview  (INT)
or random play (RDM).

Pause
In CD mode, press 1 to pause. Play-time
of  the  current  track  will  flicker  on  the
screen for reminding. Press 1 again and
it can get back to normal playing.

Repeat (RPT)
To  enable  this  function,  just  press  2  in
CD  mode.

―RPT‖  will  appear  on  the

screen  for  reminding.  The  system  will
replay the current program continuously.
Press 2 again and you can disable  this
function.

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     2      3      4      5     ..
