Lincoln Zephyr (2006 year). Instruction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Seating and Safety Restraints

Seating

Safety restraints

Tires, Wheels and Loading

Traction Control™/AdvanceTrac

威

170

Transmission operation

171

Roadside Emergencies

175

Getting roadside assistance

175

Hazard flasher switch

176

Fuel pump shut-off switch

Customer Assistance

196

Reporting safety defects (U.S. only)

202

Table of Contents

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Cleaning

203

Maintenance and Specifications

Lubricant specifications

All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from Ford Motor Company. Ford may change the contents without
notice and without incurring obligation.

Table of Contents

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to

the State of California to cause cancer and birth defects or other
reproductive harm. In addition, certain fluids contained in vehicles and
certain products of component wear contain or emit chemicals known
to the State of California to cause cancer and birth defects or other
reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Lincoln. Please take the time to
get well acquainted with your vehicle by reading this handbook. The
more you know and understand about your vehicle, the greater the
safety and pleasure you will derive from driving it.

For more information on Ford Motor Company and its products visit the
following website:
• In the United States: www.ford.com
• In Canada: www.ford.ca
• In Mexico: www.ford.com.mx
• In Australia: www.ford.com.au
Additional owner information is given in separate publications.

This Owner’s Guide describes every option and model variant available
and therefore some of the items covered may not apply to your
particular vehicle. Furthermore, due to printing cycles it may describe
options before they are generally available.

Remember to pass on the Owner’s Guide when reselling the vehicle. It
is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the
safety switch will automatically cut off the fuel supply to the

engine. The switch can also be activated through sudden vibration (e.g.
collision when parking). To reset the switch, refer to the Fuel pump
shut-off switch in the Roadside Emergencies chapter.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In
this guide, answers to such questions are contained in comments
highlighted by the warning triangle symbol. These comments should be
read and observed.

Warning symbols on your vehicle

When you see this symbol, it is
imperative that you consult the
relevant section of this guide before
touching or attempting adjustment
of any kind.

Protecting the environment

We must all play our part in
protecting the environment. Correct
vehicle usage and the authorized
disposal of waste, cleaning and
lubrication materials are significant
steps towards this aim. Information in this respect is highlighted in this
guide with the tree symbol.

BREAKING-IN YOUR VEHICLE

Your vehicle does not need an extensive break-in. Try not to drive
continuously at the same speed for the first 1,000 miles (1,600 km) of
new vehicle operation. Vary your speed frequently in order to give the
moving parts a chance to break in.

Do not add friction modifier compounds or special break-in oils during
the first few thousand miles (kilometers) of operation, since these
additives may prevent piston ring seating. See Engine oil in the
Maintenance and Specifications chapter for more information on oil
usage.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SPECIAL NOTICES

New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by
your vehicle’s New Vehicle Limited Warranty, refer to the Warranty
Guide that is provided to you along with your Owner’s Guide.

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic
controls.

Please read the section Supplemental restraint system (SRS)
in the Seating and Safety Restraints chapter. Failure to follow

the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should
NEVER be placed in front of an active passenger airbag.

Service Data Recording

Service data recorders in your vehicle are capable of collecting and
storing diagnostic information about your vehicle. This potentially
includes information about the performance or status of various systems
and modules in the vehicle, such as engine, throttle, steering or brake
systems. In order to properly diagnose and service your vehicle, Ford
Motor Company, Ford of Canada, and service and repair facilities may
access vehicle diagnostic information through a direct connection to your
vehicle when diagnosing or servicing your vehicle.

Event Data Recording

Other modules in your vehicle — event data recorders — are capable of
collecting and storing data during a crash or near crash event. The
recorded information may assist in the investigation of such an event.
The modules may record information about both the vehicle and the
occupants, potentially including information such as:
• how various systems in your vehicle were operating;
• whether or not the driver and passenger seatbelts were buckled;
• how far (if at all) the driver was depressing the accelerator and/or the

brake pedal;

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

• how fast the vehicle was traveling; and
• where the driver was positioning the steering wheel.
To access this information, special equipment must be directly connected
to the recording modules. Ford Motor Company and Ford of Canada do
not access event data recorder information without obtaining consent,
unless pursuant to court order or where required by law enforcement,
other government authorities or other third parties acting with lawful
authority. Other parties may seek to access the information
independently of Ford Motor Company and Ford of Canada.

Cell phone use

The use of Mobile Communications Equipment has become increasingly
important in the conduct of business and personal affairs. However,
drivers must not compromise their own or others’ safety when using
such equipment. Mobile Communications can enhance personal safety
and security when appropriately used, particularly in emergency
situations. Safety must be paramount when using mobile communications
equipment to avoid negating these benefits.

Mobile Communication Equipment includes, but is not limited to cellular
phones, pagers, portable email devices, in-vehicle communications
systems, telematics devices and portable two-way radios.

A driver’s first responsibility is the safe operation of the vehicle.
The most important thing you can do to prevent a crash is to

avoid distractions and pay attention to the road. Wait until it is safe to
operate Mobile Communications Equipment.

Middle East/North Africa vehicle specific information

For your particular global region, your vehicle may be equipped with
features and options that are different from the ones that are described
in this Owner’s Guide; therefore, a supplement has been supplied that
complements this book. By referring to the pages in the provided
supplement, you can properly identify those features, recommendations
and specifications that are unique to your vehicle. Refer to this
Owner’s Guide for all other required information and warnings.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

See Owner’s Guide

Fasten Safety Belt

Airbag - Front

Airbag - Side

Child Seat

Child Seat Installation
Warning

Child Seat Lower
Anchor

Child Seat Tether
Anchor

Brake System

Anti-Lock Brake System

Brake Fluid -
Non-Petroleum Based

Powertrain Malfunction

Speed Control

Master Lighting Switch

Hazard Warning Flasher

Fog Lamps-Front

Fuse Compartment

Fuel Pump Reset

Windshield Wash/Wipe

Windshield
Defrost/Demist

Rear Window
Defrost/Demist

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle Symbol Glossary

Power Windows
Front/Rear

Power Window Lockout

Child Safety Door
Lock/Unlock

Interior Luggage
Compartment Release
Symbol

Panic Alarm

Engine Oil

Engine Coolant

Engine Coolant
Temperature

Do Not Open When Hot

Battery

Avoid Smoking, Flames,
or Sparks

Battery Acid

Explosive Gas

Fan Warning

Power Steering Fluid

Maintain Correct Fluid
Level

MAX

MIN

Emission System

Engine Air Filter

Passenger Compartment
Air Filter

Jack

Check Fuel Cap

Low Tire Pressure
Warning

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Introduction

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may
become serious enough to cause extensive repairs. A warning light may
illuminate when a problem exists with one of your vehicle’s functions.
Many lights will illuminate when you start your vehicle to make sure the
bulbs work. If any light remains on after starting the vehicle, refer to the
respective system warning light for additional information.

Check engine: The Check Engine
indicator light illuminates when the
ignition is first turned to the ON
position to check the bulb. Solid
illumination after the engine is started indicates the On Board
Diagnostics System (OBD-II) has detected a malfunction. Refer to On
board diagnostics (OBD-II) in the Maintenance and Specifications
chapter. If the light is blinking, engine misfire is occurring which could
damage your catalytic converter. Drive in a moderate fashion (avoid
heavy acceleration and deceleration) and have your vehicle serviced
immediately by your authorized dealer.

Under engine misfire conditions, excessive exhaust temperatures
could damage the catalytic converter, the fuel system, interior

floor coverings or other vehicle components, possibly causing a fire.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Check fuel cap: Illuminates when
the fuel cap may not be properly
installed. Continued driving with
this light on may cause the Check
engine warning light to come on,
refer to Fuel filler cap in the
Maintenance and Specification chapter.

Brake system warning light: To
confirm the brake system warning
light is functional, it will
momentarily illuminate when the
ignition is turned to the ON position
when the engine is not running, or in a position between ON and START,
or by applying the parking brake when the ignition is turned to the ON
position. If the brake system warning light does not illuminate at this
time, seek service immediately from your authorized dealer. Illumination
after releasing the parking brake indicates low brake fluid level or a
brake system malfunction and the brake system should be inspected
immediately by your authorized dealer.

Driving a vehicle with the brake system warning light on is
dangerous. A significant decrease in braking performance may

occur. It will take you longer to stop the vehicle. Have the vehicle
checked by your authorized dealer.

Anti-lock brake system: If the
ABS light stays illuminated or
continues to flash, a malfunction has
been detected, have the system
serviced immediately by your
authorized dealer. Normal braking is still functional unless the brake
warning light also is illuminated.

Airbag readiness: If this light fails
to illuminate when ignition is turned
to ON, continues to flash or remains
on, have the system serviced
immediately by your authorized dealer. A chime will also sound when a
malfunction in the supplemental restraint system has been detected.

BRAKE

ABS

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Safety belt: Reminds you to fasten
your safety belt. A BeltMinder

威

chime will also sound to remind you
to fasten your safety belt. Refer to
the Seating and safety restraints
chapter to activate/deactivate the BeltMinder

威 chime feature.

Charging system: Illuminates when
the battery is not charging properly.

Engine oil pressure: Illuminates
when the oil pressure falls below the
normal range, refer to Engine oil in
the Maintenance and
Specifications chapter.

Traction Control

娂: Illuminates

when the Traction Control

娂 is

active. If the light remains on, have
the system serviced immediately,
refer to the Driving chapter for
more information.

Speed control: Illuminates when
the speed control is engaged. Turns
off when the speed control system
is disengaged.

Anti-theft system: Flashes when
the SecuriLock

娂 Passive Anti-theft

System has been activated.

Throttle Control/Transmission:
Illuminates when a powertrain fault
has been detected. Contact your
authorized dealer as soon as
possible.

Turn signal: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators flash faster, check for a burned out bulb.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

High beams: Illuminates when the
high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the
ignition in the OFF/LOCK or ACCESSORY position and the driver’s door
is opened.

Headlamps on warning chime: Sounds when the headlamps or parking
lamps are on, the ignition is off (the key is not in the ignition) and the
driver’s door is opened.

Parking brake ON: Sounds when the parking brake is left ON and
driven. If the warning stays on after the park brake is off, contact your
authorized dealer as soon as possible.

GAUGES

Speedometer: Indicates the
current vehicle speed.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is
running or hot.

Fuel gauge: Indicates
approximately how much fuel is left
in the fuel tank (when the ignition
is in the ON position). The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.

The FUEL icon and arrow indicates
which side of the vehicle the fuel
filler door is located.

Refer to Filling the tank in the Maintenance and Specifications
chapter for more information.

Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.

Odometer: Registers the total miles
(kilometers) of the vehicle.

Refer to Message Center in the
Driver Controls chapter on how to
switch the display from Metric to
English.

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Instrument Cluster

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AUDIO SYSTEMS

AM/FM In-dash Six CD/MP3 Sound system (if equipped)

Accessory delay: Your vehicle is equipped with accessory delay. With
this feature, the window controls, radio and moon roof (if equipped) may
be used for up to ten minutes after the ignition is turned off or until
either front door is opened.

THX: Your vehicle may be equipped
with the THX

威 II certified premium

audio system. This system creates
optimal acoustic quality for all
seating positions and road
conditions. The system offers an
advanced speaker system,
amplifiers, subwoofer and
equalization.

1. Memory presets: To set a
station: Select frequency band
AM/FM1/FM2; tune to a station,
press and hold a preset button until

2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)

Entertainment Systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Lincoln Zephyr (2006 year). Instruction - part 1
