Chapter 1
Table 1-5. Additional Certified Munitions Table
DODIC
NSN
Item
FM/TO
Type of
Airdrop
1340-J143
1340-01-118-2838
5” Rocket Motor, Mk22, Mod
FM 10-555
Low-Velocity
4
TO 13C7-3-401
Platform
1375-M913
1375-01-237-5933
Linear Demolition Charge
FM 10-555
Low-Velocity
TO 13C7-3-401
Platform
1375-
1375-01-380-1350
Selectable Lightweight Attack
FM 4-20.103/
Low-Velocity
MM15
Munition (SLAM), M2, in
MCRP 4-11.3C/
A-22
reusable environmental
TO 13C7-1-11,
plastic packs or in PA19
Chapter 9, Sec I
ammunition container
1375-
1375-01-380-1378
Demolition Attack Munition
FM 4-20.103/
Low-Velocity
MM16
(DAM), M3, in reusable
MCRP 4-11.3C/
A-22
environmental plastic packs
TO 13C7-1-11,
or in PA19 ammunition
Chapter 9, Sec I
container
*1375-MM15
1375-01-380-1350
Selectable Lightweight Attack
FM 4-20.103/
High-Velocity
Munition (SLAM), M2, in
MCRP 4-11.3C/
A-22
PA19 ammunition container
TO 13C7-1-11,
Chapter 9, Sec II
*1375-MM16
1375-01-380-1378
Demolition Attack Munition
FM 4-20.103/
High-Velocity
(DAM), M3, in PA19
MCRP 4-11.3C/
A-22
ammunition container
TO 13C7-1-11,
Chapter 9, Sec II
1375-
1375-01-380-1350
Selectable Lightweight Attack
FM 4-20.103/
Low-Velocity
MM15
Munition (SLAM), M2, in
MCRP 4-11.3C/
A7A/A-21
reusable environmental
TO 13C7-1-11,
plastic packs or in PA19
Chapters 3-6,
ammunition container
Sec I & II
1375-
1375-01-380-1378
Demolition Attack Munition
FM 4-20.103/
Low-Velocity
MM16
(DAM), M3, in reusable
MCRP 4-11.3C/
A7A/A-21
environmental plastic packs
TO 13C7-1-11,
or in PA19 ammunition
Chapters 3-6,
container
Sec I & II
1375-
1375-01-380-1350
Selectable Lightweight Attack
FM 4-20.103/
High-Velocity
MM15
Munition (SLAM), M2, in
MCRP 4-11.3C/
A7A/A-21
PA19 ammunition container
TO 13C7-1-11,
Chapters 4 & 6,
Sec III
1375-
1375-01-380-1378
Demolition Attack Munition
FM 4-20.103/
High-Velocity
MM16
(DAM), M3, in PA19
MCRP 4-11.3C/
A7A/A-21
ammunition container
TO 13C7-1-11,
Chapters 4 & 6,
Sec III
1-36
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
General
Table 1-5. Additional Certified Munitions Table (continued)
DODIC
NSN
Item
FM/TO
Type of
Airdrop
1375-ML45
1375-01-415-1229
Holder, Blasting Cap, M9
FM 4-20.103/
Low-Velocity
1375-ML47
1375-01-415-1232
Cap, Blasting, Nonelectric, 30 foot
MCRP 4-11.3C/
A-22
Shock Tube, M11 (1.4B) Cap,
TO 13C7-1-11,
1375-MN02
1375-01-415-1230
Blasting, Nonelectric, 500 foot
Chapter 9, Sec I
Shock Tube, M12 (1.4S)
1375-MN03
1375-01-415-1231
Cap, Blasting, Nonelectric, 1000
foot Shock Tube, M13 (1.4S)
1375-MN06
1375-01-415-1233
Cap, Blasting, Nonelectric, Delay,
M14 (1.4S)
1375-MN07
1375-01-415-1234
Cap, Blasting, Nonelectric, Delay,
M15
1375-MN08
1375-01-415-1235
Ignitor, Time Blasting Fuze, M81,
w/Shock Tube Capability (1.4S)
1375-MN39
1375-01-449-9601
Cap Blasting, Non-Electric, M16
1375-MN41
1375-01-449-9602
Cap, Blasting, Non-Electric, M18
1375-MN86
1375-01-494-6939
Cap, Blasting, Dual, In-Line
Initiator, Non-Electric, 200-ft
Minitube, M19
1375-MN87
1375-01-494-6929
Trainer, Inert (for M19), M20
1375-MN88
1375-01-494-6945
Cap, Blasting, In-Line Initiator,
Non-Electric, 500-ft Minitube, M21
1375-MN89
1375-01-494-6934
Trainer, Inert (for M21 and M23),
M22
1375-MN90
1375-01-494-6941
Cap, Blasting, In-Line Initiator,
Non-Electric, 1000-ft Minitube, M23
1375-ML45
1375-01-415-1229
Holder, Blasting Cap, M9
FM 4-20.103/
Low-Velocity
1375-ML47
1375-01-415-1232
Cap, Blasting, Nonelectric, 30 foot
MCRP 4-11.3C/
A7A/A-21
Shock Tube, M11 (1.4B) Cap,
TO 13C7-1-11,
1375-MN02
1375-01-415-1230
Blasting, Nonelectric, 500 foot
Chapters 3-6,
Shock Tube, M12 (1.4S)
Sec I & II
1375-MN03
1375-01-415-1231
Cap, Blasting, Nonelectric, 1000
foot Shock Tube, M13 (1.4S)
1375-MN06
1375-01-415-1233
Cap, Blasting, Nonelectric, Delay,
M14 (1.4S)
1375-MN07
1375-01-415-1234
Cap, Blasting, Nonelectric, Delay,
M15
1375-MN08
1375-01-415-1235
Ignitor, Time Blasting Fuze, M81,
w/Shock Tube Capability (1.4S)
1375-MN39
1375-01-449-9601
Cap Blasting, Non-Electric, M16
1375-MN41
1375-01-449-9602
Cap, Blasting, Non-Electric, M18
1375-MN86
1375-01-494-6939
Cap, Blasting, Dual, In-Line
Initiator, Non-Electric, 200-ft
Minitube, M19
1375-MN87
1375-01-494-6929
Trainer, Inert (for M19), M20
1375-MN88
1375-01-494-6945
Cap, Blasting, In-Line Initiator,
Non-Electric, 500-ft Minitube, M21
1375-MN89
1375-01-494-6934
Trainer, Inert (for M21 and M23),
M22
1375-MN90
1375-01-494-6941
Cap, Blasting, In-Line Initiator,
Non-Electric, 1000-ft Minitube, M23
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
1-37
Chapter 1
Table 1-5. Additional Certified Munitions Table (continued)
DODIC
NSN
Item
FM/TO
Type of
Airdrop
1375-ML45
1375-01-415-1229
Holder, Blasting Cap, M9
FM 4-20.153/
Low-Velocity
1375-ML47
1375-01-415-1232
Cap, Blasting, Nonelectric, 30 foot
MCRP 4-11.3B/
A-22
Shock Tube, M11 (1.4B) Cap,
TO 13C7-18-41,
1375-MN02
1375-01-415-1230
Blasting, Nonelectric, 500 foot
Figure 3-90
Shock Tube, M12 (1.4S)
and
1375-MN03
1375-01-415-1231
Cap, Blasting, Nonelectric, 1000
FM 4-20.103/
foot Shock Tube, M13 (1.4S)
MCRP 4-11.3C/
1375-MN06
1375-01-415-1233
Cap, Blasting, Nonelectric, Delay,
TO 13C7-1-11,
M14 (1.4S)
Chapter 9, Sec II
1375-MN07
1375-01-415-1234
Cap, Blasting, Nonelectric, Delay,
M15
1375-MN08
1375-01-415-1235
Ignitor, Time Blasting Fuze, M81,
w/Shock Tube Capability (1.4S)
1375-MN39
1375-01-449-9601
Cap Blasting, Non-Electric, M16
1375-MN41
1375-01-449-9602
Cap, Blasting, Non-Electric, M18
1375-MN86
1375-01-494-6939
Cap, Blasting, Dual, In-Line
Initiator, Non-Electric, 200-ft
Minitube, M19
1375-MN87
1375-01-494-6929
Trainer, Inert (for M19), M20
1375-MN88
1375-01-494-6945
Cap, Blasting, In-Line Initiator,
Non-Electric, 500-ft Minitube, M21
1375-MN89
1375-01-494-6934
Trainer, Inert (for M21 and M23),
M22
1375-MN90
1375-01-494-6941
Cap, Blasting, In-Line Initiator,
Non-Electric, 1000-ft Minitube, M23
1375-ML45
1375-01-415-1229
Holder, Blasting Cap, M9
FM 4-20.153/
High-Velocity
1375-ML47
1375-01-415-1232
Cap, Blasting, Nonelectric, 30 foot
MCRP 4-11.3B/
A7A/A-21
Shock Tube, M11 (1.4B) Cap,
TO 13C7-18-41,
1375-MN02
1375-01-415-1230
Blasting, Nonelectric, 500 foot
Figure 3-55
Shock Tube, M12 (1.4S)
and
1375-MN03
1375-01-415-1231
Cap, Blasting, Nonelectric, 1000
FM 4-20.103/
foot Shock Tube, M13 (1.4S)
MCRP 4-11.3C/
1375-MN06
1375-01-415-1233
Cap, Blasting, Nonelectric, Delay,
TO 13C7-1-11,
M14 (1.4S)
Chapters 4 & 6,
1375-MN07
1375-01-415-1234
Cap, Blasting, Nonelectric, Delay,
Sec III
M15
1375-MN08
1375-01-415-1235
Ignitor, Time Blasting Fuze, M81,
w/Shock Tube Capability (1.4S)
1375-MN39
1375-01-449-9601
Cap Blasting, Non-Electric, M16
1375-MN41
1375-01-449-9602
Cap, Blasting, Non-Electric, M18
1375-MN86
1375-01-494-6939
Cap, Blasting, Dual, In-Line
Initiator, Non-Electric, 200-ft
Minitube, M19
1375-MN87
1375-01-494-6929
Trainer, Inert (for M19), M20
1375-MN88
1375-01-494-6945
Cap, Blasting, In-Line Initiator,
Non-Electric, 500-ft Minitube, M21
Trainer, Inert (for M21 and M23),
1375-MN89
1375-01-494-6934
M22
1375-MN90
1375-01-494-6941
Cap, Blasting, In-Line Initiator,
Non-Electric, 1000-ft Minitube, M23
1-38
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
General
Table 1-5. Additional Certified Munitions Table (continued)
DODIC
NSN
Item
FM/TO
Type of
Airdrop
***1375-MM50
1375-01-325-6826
Clipped Demolition Shaped
FM 4-20.103/
Low-Velocity
Charge M221, in the M2A1
MCRP 4-11.3C/
A-22
Shipping and Storage
TO 13C7-1-11,
Container
Chapter 9, Sec I
***1375-MM50
1375-01-325-6826
Clipped Demolition Shaped
FM 4-20.103/
High-Velocity
Charge M221, in the M2A1
MCRP 4-11.3C/
A-22
Shipping and Storage
TO 13C7-1-11,
Container
Chapter 9, Sec II
***1375-MM50
1375-01-325-6826
Clipped Demolition Shaped
FM 4-20.103/
Low-Velocity
Charge M221, in the M2A1
MCRP 4-11.3C/
A7A/A-21
Shipping and Storage
TO 13C7-1-11,
Container
Chapters 3-6, Sec
I & II
***1375-MM50
1375-01-325-6826
Clipped Demolition Shaped
FM 4-20.103/
High-Velocity
Charge M221, in the M2A1
MCRP 4-11.3C/
A7A/A-21
Shipping and Storage
TO 13C7-1-11,
Container
Chapters 4 & 6,
Sec III
Remote Activation Munitions
FM 4-20.103/
Low-Velocity
System Packed in PA108
MCRP 4-11.3C/
A7A/A-21
Shipping and Storage
TO 13C7-1-11,
Container
Chapters 3-6, Sec
1375-MN80
1375-01-482-0476
Receiver, Radio, Firing,
I & II
Non-electric, Blasting Cap,
M17
5895-01-431-1160
Receiver, Radio, Firing,
Electric, Blasting Cap, M16
1375-01-431-1156
Firing Device, Demolition,
Radio Type, M152
* These munitions must be encased in honeycomb when rigged for high-velocity airdrop.
** The following restrictions apply to the Modernized Demolition Initiators (MDI), when rigged for low-
velocity airdrop.
The containers (wooden crates) may be broken down into smaller packaging units.
Individual corrugated cardboard boxes.
Individual foil wrapped items.
MDI items may be rigged for airdrop up to their smallest unit of package.
MDI items in their smallest unit of packaging must be encased in a honeycomb bin.
No container may be rigged on top of a honeycomb bin except another honeycomb bin.
Only honeycomb bins and corrugated cardboard boxes may be rigged on top of corrugated
cardboard boxes.
Wooden crates can only be stacked on top of other wooden crates.
Corrugated cardboard boxes containing spools of shock tubing (M12, M13) must be positioned
so the spools are lying flat on their base.
Center the load in the A7A/A-21 or A-22 container. Place honeycomb on all four sides of the
bundle and secure the honeycomb with Type III nylon cord. Place a piece of honeycomb over
the top of the load and position a piece of 3/4-inch plywood on top of the honeycomb. Close
and secure the container.
*** These munitions must be encased in honeycomb when rigged for airdrop. Place a 3/4 by 12 by 6 1/4-inch
piece of plywood between the bottom of the M2A1 Shipping and Storage Container and the bottom piece of
honeycomb encasing the munitions. Secure the honeycomb encasing the munitions with tape.
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
1-39
This page intentionally left blank.
Chapter 2
Preparing Low-Velocity A-22 Cargo Bag Loads
RIGGING THE A-22 CARGO BAG
2-1. Prepare the A-22 cargo bag according to FM 4-20.103/MCRP 4-11.3C/TO 13C7-1-11. Position the
loads in the A-22 cargo bags as shown in Figures 2-1 through 2-75.
SPECIAL INSTRUCTIONS
2-2. Follow these special instructions when rigging A-22 cargo bags for low-velocity airdrop.
The ammunition loads are positioned in the A-22 cargo bag for low-velocity airdrop according
to the figures listed in this section.
A-22 cargo bags rigged for airdrop must NOT be more than 83 inches high, including the
parachute, for C-130 aircraft and 101 inches for C-17 aircraft without prior Air Force approval.
Any load that overhangs the edge of the standard 1- by 48- by 48-inch low-velocity A-22 skid
must be placed lengthwise in the aircraft.
Note: If the length of the load exceeds 48 inches but is too short for a double A-22 cargo bag,
use the rigging procedures for the stretch A-22 cargo bag in FM 4-20.103/MCRP 4-11.3C/TO
13C7-1-11 along with the skid and honeycomb layout in this manual.
When using the CVR system, the first layer of honeycomb must be 2 inches from all sides of the
skidboard.
Note: If the load is smaller than the length of the skidboard, place honeycomb filler sheets
vertically inside the A-22 container. The length of the A-22 container should equal the length of
the skidboard. This prevents the A-22 containers from shifting when the loads are restrained
inside the aircraft.
CAUTION
Steel strapping MUST NOT be used to bind a load below the second
layer of honeycomb. Steel strapping MUST NOT be used to bind
honeycomb layers to the skid.
The A-22 cargo bag must be closed and secured according to FM 4-20.103/MCRP 4-11.3C/TO
13C7-1-11.
PARACHUTE REQUIREMENTS
2-3. Select the correct parachute from Table 1-1. Attach the parachute to the rigged load according to
FM 4-20.103/MCRP 4-11.3C/TO 13C7-1-11.
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-1
Chapter 2
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-1.
5.56-Millimeter Ammunition
Cartridge, 5.56-mm, Ball, M855, (DODIC 1305-A059)
Cartridge, 5.56-mm, Tracer, M856, (DODIC 1305-A063)
Cartridge, 5.56-mm, Tracer, M196, (DODIC 1305-A068)
Cartridge, 5.56-mm, Ball, M193, (DODIC 1305-A071)
7.62-Millimeter Ammunition
Cartridge, 7.62-mm, Blank, M82, (DODIC 1305-A111)
Note: M82 boxes must be oriented with the long side sitting vertically.
Cartridge, 7.62-mm, Ball, M59 and M80, (DODIC 1305-A122)
Cartridge, 7.62-mm, Tracer, M62, (DODIC 1305-A124)
Cartridge, 7.62-mm, Ball, Tracer, Linked with M13 Link, M80,
(DODIC 1305-A127)
Cartridge, 7.62-mm, 5-rd Clip, M80, (DODIC 1305-A130)
Cartridge, 7.62-mm, Ball, Tracer, Linked with M13 Link, M62,
(DODIC 1305-A131)
Cartridge, 7.62-mm, Ball, Tracer, M80/1 Linked, M62, (DODIC 1305-A131)
Cartridge, 7.62-mm, Match, M118, (DODIC 1305-A136)
Cartridge, 7.62-mm, Tracer, M62, (DODIC 1305-A140)
Cartridge, 7.62-mm, Ball, M80, Linked, (DODIC 1305-A143)
Cartridge, 7.62-mm, Tracer, M62, Clipped, (DODIC 1305-A145)
Cartridge, 7.62-mm, Tracer, M62, Linked, (DODIC 1305-A146)
Figure 2-1. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-2
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
9-Millimeter Ammunition
Cartridge, 9-mm, Ball, M882, (DODIC 1305-A363)
.30-Caliber Ammunition
Cartridge, Cal .30, AP, API, 8-rd Clip, Grade R, (DODIC 1305-A205)
Cartridge, Cal .30, AP, API, M2, Linked with M1 Link, Grade MG,
(DODIC 1305-A207)
Cartridge, Cal .30, AP, API, Linked with Tracer, (DODIC 1305-A209)
Cartridge, Cal .30, Ball, M2, (DODIC 1305-A212)
Cartridge, Cal .30, Ball, M2, Clipped, (DODIC 1305-A216)
Cartridge, Cal .30, Tracer, M1 or M25, Clipped, (DODIC 1305-A234)
Cartridge, Cal .30, Tracer, M25, Linked, (DODIC 1305-A236)
.45-Caliber Ammunition
Cartridge, Cal .45, Ball, M1911, (DODIC 1305-A475)
.50-Caliber Ammunition
Cartridge, Cal .50, API, M8, (DODIC 1305-A531)
Cartridge, Cal .50, API, M8, Linked, (DODIC 1305-A533)
Cartridge, Cal .50, API-T, M1/M17 Linked, (DODIC 1305-A540)
Cartridge, Cal .50, API-T, M20, (DODIC 1305-A541)
Cartridge, Cal .50, API-T, M20, Linked with M2 Link, Grade AC,
(DODIC 1305-A543)
Cartridge, Cal .50, API-T, M20, Linked with M2 Link, Grade MG,
(DODIC 1305-A544)
Cartridge, Cal .50, Tracer, M17, Grade MG, (DODIC 1305-A571)
Cartridge, Cal .50, Tracer, M17, Linked with M2 Link, Grade AC,
(DODIC 1305-A572)
Cartridge, Cal .50, Spotter-Tracer, M48A2, (DODIC 1305-A574)
Cartridge, Cal .50, Linked, 4 API, M8, API-T, M20, (DODIC 1305-A576)
Cartridge, Cal .50, Linked, 4 API, M8, API-T, M20, (DODIC 1305-A577)
Cartridge, Cal .50, API-T, M20, Linked, (DODIC 1305-A585)
Cartridge, Cal .50, Linked, 4 API, M8, 1 API-T, M20, (DODIC 1305-A587)
Cartridge, Cal .50, Linked, 4 API, M8, 1 API-T, M20, (DODIC 1305-A589)
Cartridge, Cal .50, API Lowlite, Linked, 1 Tracer, M257, 2 MK 263, 2 MK211, 1
M20 Tracer, 4 M20, (DODIC 1305-AA50)
Incendiary Item
Burster, Incendiary, Field, M4 without Fuze, (DODIC 1345-K010)
Figure 2-1.
Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop (continued)
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-3
Chapter 2
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-2.
Shotgun Ammunition
Cartridge, 12-gauge Shotgun, No. 00 Buckshot, M162, (DODIC 1305-A011)
Incendiary Items
Smoke Pot, Hexachloroethane, M5, (DODIC 1365-K866)
Figure 2-2. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-4
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
LAYERS1 & 2
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-3.
7.62-Millimeter Ammunition
Cartridge, 7.62-mm, Linked, 9-ball, M80, 1 Tracer, M62, (DODIC 1305-A165)
Cartridge, 7.62-mm, Linked, 9-Ball, M80, 1Tracer, M276 (DODIC 1305-A257)
.30-Caliber Ammunition
Cartridge, Cal .30, AP, API, Carton, Grade R, (DODIC 1305-A201)
Cartridge, Cal .30, AP, API, Carton, Grade MG, (DODIC 1305-A202)
.50-Caliber Ammunition
Cartridge, Cal .50, API-T, M20, Carton, Grade MG, (DODIC 1305-A542)
Figure 2-3. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-5
Chapter 2
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-4.
.30-Caliber Ammunition
Cartridge, Cal .30, Ball, M2, Clipped, (DODIC 1305-A214)
Cartridge, Cal .30, Tracer, M1, Clipped, (DODIC 1305-A232)
.32-Caliber Ammunition
Cartridge, Cal .32, Ball, Auto, 71 Grain, (DODIC 1305-A350)
.38-Caliber Ammunition
Cartridge, Cal .38, Special, Ball, M41, (DODIC 1305-A400)
.50-Caliber Ammunition
Cartridge, Cal .50, API, M8, Carton, Grade MG or API-T, M20,
(DODIC 1305-A532)
Cartridge, Cal .50, API, M8, Linked with M2 Link, Grade MG, (DODIC 1305-
A534)
40-Millimeter Ammunition
Cartridge, 40-mm, HEI-T, SD, M3, (DODIC 1310-B559)
Demolition Item
Dynamite, Military, M1, (DODIC 1375-M591)
Figure 2-4. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-6
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
LOAD SPREADER
(3/4-IN PLYWOOD)
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-5.
20-Millimeter Ammunition
Cartridge, 20-mm, Linked, 4 HEI/TP-T, (DODIC 1305-A653)
Cartridge, 20-mm, Linked, 7 HEI, M56A3-1, M220, (DODIC 1305-A655)
Cartridge, 20-mm, Linked, HEAT-SD, M246, (DODIC 1305-A792)
Figure 2-5. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-7
Chapter 2
HONEYCOMB
FILLERS
HONEYCOMB
LAYERS
AMMUNITION
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-6.
25-Millimeter Ammunition
Cartridge, 25-mm, M791, (DODIC 1305-A974)
Cartridge, 25-mm, HEI-T, M792, w/ M758 Fuze, (DODIC 1305-A975)
Cartridge, 25-mm, M919, (DODIC 1305-A986)
Figure 2-6. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-8
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
HONEYCOMB
FILLERS
HONEYCOMB
AMMUNITION
LAYERS
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-7.
30 Millimeter Ammunition
Cartridge, 30-mm, Target Practice, M788 (DODIC1305-B118)
Cartridge, 30-mm, HE, Dual Purpose, M789, (DODIC 1305-B129)
Cartridge, 30-mm, HE, Dual Purpose, M789, (DODIC 1305-B130)
Figure 2-7. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-9
Chapter 2
LAYERS1 & 3
LAYER 2
HONEYCOMB
LAYERS
AMMUNITION
BOXES
HONEYCOMB
SKID
FILLERS
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-8.
40-Millimeter Ammunition
Cartridge, 40-mm, HEDP, Linked, M430, (DODIC 1310-B542)
Cartridge, 40-mm, TP, M918, (DODIC 1310-B584)
Figure 2-8. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-10
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
HONEYCOMB
BOXES
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-9.
40-Millimeter Ammunition
Cartridge, 40-mm, HEDP, M33, (DODIC 1310-B470)
Cartridge, 40-mm, HEDP, Linked, M430, (DODIC 1310-B542)
Cartridge, 40-mm, HE, Linked, M383E1, (DODIC 1310-B571)
Cartridge, 40-mm, HE, Linked, M384, (DODIC 1310-B572)
81-Millimeter Ammunition
Cartridge, 81-mm, HE, M362, (DODIC 1315-C222)
Cartridge, 81-mm, HE, M372, (DODIC 1315-C223)
Cartridge, 81-mm, HE, M43A1, (DODIC 1315-C225)
Cartridge, 81-mm, HE, M374A2, (DODIC 1315-C236)
Cartridge, 81-mm, HE, M374A2 with Fuze M524A5, (DODIC 1315-C256)
Cartridge, 81-mm, HE, M374A2 with Fuze M524A6, (DODIC 1315-C256)
Cartridge, 81-mm, HE, M374A2 with Fuze M567, (DODIC 1315-C256)
Cartridge, 81-mm, HE, M374A2 with Fuze M716, (DODIC 1315-C256)
Cartridge, 81-mm, Smoke, WP, M375A2 with Fuze PD 524A6,
(DODIC 1315-C276)
Grenade
Grenade, Hand, Fragmentation, M26 or M26A1, (DODIC 1330-G890)
Antipersonnel and Antitank Mines
Mine, Antipersonnel, MN, M14, (DODIC 1345-K121)
Mine, Antitank, HEAT, Heavy M15 with Fuze M603, (DODIC 1345-K180)
Figure 2-9. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-11
Chapter 2
Demolition Items
Charge, Demolition, Chain, M1, Eight 2 1/2-lb Telrytol Charge Strung on
Detonating Cord, (DODIC 1375-M035)
Charge, Demolition, Block, M2, (DODIC 1375-M036)
Figure 2-9. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop (continued)
HONEYCOMB
LAYERS
AMMUNITION
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-10.
40-Millimeter Ammunition
Cartridge, 40-mm, Illuminating, M583A1, (DODIC 1310-B535)
Grenades
Cartridge, Grenade, Rifle, NATO, 7.62-mm, M64, (DODIC 1330-G839)
Grenade, Hand, Incendiary, TH-3, AN-M14 with Fuze M201A1,
(DODIC 1330-G900)
Antipersonnel and Antitank Mines
Mine, Antipersonnel, M16A1 with Fuze M605, (DODIC 1345-K092)
Mine, Antipersonnel, M18A1 with Accessories, (DODIC 1345-K143)
Demolition Items
Charge, Demolition Block, Comp C4, 1 1/4-lb, M112, (DODIC 1375-M023)
Firing Device, Demolition, M3, Pull-Release Type, (DODIC 1375-M629)
Figure 2-10. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-12
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
HONEYCOMB
LAYERS
AMMUNITION
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-11.
40-Millimeter Ammunition
Cartridge, 40-mm, Illuminating, M661, (DODIC 1310-B504)
Cartridge, 40-mm, Illuminating, M662, (DODIC 1310-B505)
Cartridge, 40-mm, Red Smoke, M713, (DODIC 1310-B506)
Cartridge, 40-mm, Green Smoke, M715, (DODIC 1310-B508)
Cartridge, 40-mm, Yellow Smoke, M716, (DODIC 1310-B509)
Cartridge, 40-mm, HEDP, M433, (DODIC 1310-B546)
60-Millimeter Ammunition
Cartridge, 60-mm, HE, M49A4, (DODIC 1310-B632)
Figure 2-11. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-13
Chapter 2
HONEYCOMB
LAYERS
AMMUNITION
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-12.
40-Millimeter Ammunition
Cartridge, 40-mm, AP-T, M81, (DODIC 1310-B552)
Cartridge, 40-mm, HE-T, SD, M3, MK11, MK2, (DODIC 1310-B562)
Demolition Items
Charge, Demolition, Roll Type, M-186, (DODIC 1375-M060)
Cap, Blasting, Special Electric, M6, (DODIC 1375-M130)
Figure 2-12. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-14
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
HONEYCOMB
BOXES
FILLERS
LAYERS 1 & 3
HONEYCOMB
HONEYCOMB
LAYERS
FILLERS
LAYER 2
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-13.
60-Millimeter Ammunition
Cartridge, 60-mm, Illuminating, M83A3, (DODIC 1310-B627)
Cartridge, 60-mm, Smoke, WP, M302A1, (DODIC 1310-B630)
Flare and Signal Items
Signal, Illuminating, A/C, Single Star, AN-M43A2, Red, (DODIC 1370-L231)
Signal, Illuminating, A/C, Single Star, AN-M45A2, Green, (DODIC 1370-L233)
Demolition Items
Charge, Demolition, Shaped, 40-lb, M3, (DODIC 1375-M421)
Figure 2-13. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-15
Chapter 2
AMMUNITION
BOXES
LAYERS 1, 3, 5, & 7
HONEYCOMB
LAYERS
LAYERS 2, 4, 6, & 8
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-14.
81-Millimeter Ammunition
Cartridge, 81-mm, Illuminating, M301A3, (DODIC 1315-C226)
Figure 2-14. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-16
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-15.
81-Millimeter Ammunition
Cartridge, 81-mm, Smoke, WP, M57, (DODIC 1315-C230)
Figure 2-15. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-17
Chapter 2
AMMUNITION
BOXES
STEEL
STRAPPING
LOAD SPREADER
(¾-IN PLYWOOD)
HONEYCOMB
STACKS
(12” X 12”)
SKID
HONEYCOMB
STACKS
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-16.
84-Millimeter Ammunition
Cartridge, 84-mm, M136 with Launcher (AT4), (DODIC 1315-C995)
Figure 2-16. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-18
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-17.
90-Millimeter Ammunition
CAUTION
The 90-millimeter ammunition will contaminate the area if a parachute
malfunctions.
Cartridge, 90-mm, WP, M313C, (DODIC 1315-C258)
Cartridge, 90-mm, HE, M71, (DODIC 1315-C265)
Cartridge, 90-mm, HE, M71, (DODIC 1315-C266)
Cartridge, 90-mm, HE, M71, (DODIC 1315-C267)
Cartridge, 90-mm, Smoke, WP, M313, (DODIC 1315-C273)
Figure 2-17. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-19
Chapter 2
Cartridge, 90-mm, APERS-T, M580, (DODIC 1315-C275)
Cartridge, 90-mm, HE-T, M71A1 with Fuze PD M557, (DODIC 1315-C280)
Cartridge, 90-mm, AP-T, M318 or M318A1, (DODIC 1315-C285)
Cartridge, 90-mm, HEP-T, T142E3, (DODIC 1315-C292)
Cartridge, 90-mm, HEAT, M431A1, (DODIC 1315-C294)
Cartridge, 90-mm, Canister, M377, (DODIC 1315-C601)
105-Millimeter Ammunition
Cartridge, 105-mm, HE, M1, (DODIC 1315-C443)
Cartridge, 105-mm, HE, M1, (DODIC 1315-C444)
Cartridge, 105-mm, HE, M1, (DODIC 1315-C445)
Cartridge, 105-mm, HEP-T, M327, (DODIC 1315-C448)
Cartridge, 105-mm, Illuminating, M314A3, (DODIC 1315-C449)
Cartridge, 105-mm, Smoke, HC, BE, M84 or M84A1, (DODIC 1315-C452)
Cartridge, 105-mm, Smoke, WP, M60, (DODIC 1315-C454)
Cartridge, 105-mm, HE, M444, (DODIC 1315-C462)
Cartridge, 105-mm, Tactical, CS, M629, (DODIC 1315-C468)
Cartridge, 105-mm, HE, M760, (DODIC 1315-C473)
Cartridge, 105-mm, Smoke, WP, M60, (DODIC 1315-C477)
Cartridge, 105-mm, APERS-T, M546 with Fuze MT M563, (DODIC 1315-C513)
106-Millimeter Ammunition
Cartridge, 106-mm, HEAT, M344A1, (DODIC 1315-C650)
Cartridge, 106-mm, HEP-T, M346A1, (DODIC 1315-C651)
Cartridge, 106-mm, APERS-T, M581, (DODIC 1315-C660)
Figure 2-17. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop (continued)
2-20
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
LAYERS 1, 3, & 5
LOAD SPREADER
(¾-IN PLYWOOD)
LAYERS 2 & 4
HONEYCOMB
FILLERS
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-18.
4.2-Inch Ammunition
Cartridge, 4.2-in, HE, w/o Fuze, (DODIC 1315-C697)
Figure 2-18. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-21
Chapter 2
AMMUNITION
BOXES
LAYERS 1 & 3
HONEYCOMB
SKID
LAYERS
LAYERS 2 & 4
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-19.
90-Millimeter Ammunition
Cartridge, 90-mm, HEAT, M371, (DODIC 1315-C282)
4.2-Inch Ammunition
Cartridge, 4.2-in, HE, M329A1, (DODIC 1315-C704)
Cartridge, 4.2-in, HE, M329A1, (DODIC 1315-C705)
Cartridge, 4.2-in, Illuminating, M335A2, (DODIC 1315-C706)
Cartridge, 4.2-in, Smoke, WP, M328A1, (DODIC 1315-C708)
Antipersonnel and Antitank Mines
Mine, Antitank, HE, M121, Heavy with Fuze Combination M607,
(DODIC 1345-K181)
Demolition Items
Charge, Demolition, Block, 40-lb Cratering Ammonium Nitrate,
(DODIC 1375-M039)
Cord, Detonating, Reinforced Pliofilm/Wrapped Waterproof, Type I,
(DODIC 1375-M456)
Figure 2-19. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-22
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
STEEL
STRAPPING
HONEYCOMB
LAYERS
AMMUNITION
STEEL
STRAPPING
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-20.
90-Millimeter Ammunition
(Rigging Fiber Containers)
Cartridge, 90-mm, HEAT, M371, (DODIC 1315-C282)
Figure 2-20. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-23
Chapter 2
HONEYCOMB
LAYERS
AMMUNITION
BOXES
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-21.
90-Millimeter Ammunition
Cartridge, 90-mm, Canister, APERS, M590, (DODIC 1315-C410)
Figure 2-21. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-24
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
HONEYCOMB
LAYERS
AMMUNITION
BOXES
STEEL
SKID
STRAPPING
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-22.
90-Millimeter Ammunition
(Rigging Fiber Containers)
Cartridge, 90-mm, Canister, APERS, M590, (DODIC 1315-C410)
Figure 2-22. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-25
Chapter 2
HONEYCOMB
AMMUNITION
LAYERS
BOXES
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-23.
105-Millimeter Ammunition
Cartridge, 105-mm, HE, M548E1, (DODIC 1315-C463)
Cartridge, 105-mm, APDS-T, M728, (DODIC 1315-C494)
Cartridge, 105-mm, APDS-T, M392A2, (DODIC 1315-C505)
Cartridge, 105-mm, HEAT-T, M456A1E2, (DODIC 1315-C508)
Cartridge, 105-mm, TP-T, M490, (DODIC 1315-C511)
Cartridge, 105-mm, Smoke, WP-T, M416 with Fuze BD M534A1,
(DODIC 1315-C512)
Cartridge, 105-mm, HEP-T, M393A2, (DODIC 1315-C518)
Cartridge, 105-mm, APER-T, M494 with Fuze M571, (DODIC 1315-C519)
Figure 2-23. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-26
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
HONEYCOMB
LAYERS
STEEL
SKID
STRAPPING
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-24.
105-Millimeter Ammunition
(Rigging Fiber Containers)
Cartridge, 105-mm, HEAT-T, M456A1E2, (DODIC 1315-C508)
Cartridge, 105-mm, TP-T, M490, (DODIC 1315-C511)
Figure 2-24. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-27
Chapter 2
¾-IN PLYWOOD
STEEL
STRAPPING
STEEL
STRAPPING
AMMUNITION
HONEYCOMB
LAYERS
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-25.
105-Millimeter Ammunition
Cartridge, 105-mm, APFSDS-T, M833, (DODIC 1315-C524)
Figure 2-25. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-28
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
¾-IN PLYWOOD
STEEL
STRAPPING
AMMUNITION
HONEYCOMB
LAYERS
STEEL
STRAPPING
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-26.
105-Millimeter Ammunition
Cartridge, 105-mm, APFSDS-T, M900E1, (DODIC 1315-C543)
Figure 2-26. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-29
Chapter 2
AMMUNITION
HONEYCOMB
LAYERS
LOAD SPREADER
(¾-IN PLYWOOD)
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-27.
120-Millimeter Ammunition
Cartridge, 120-mm, APFSDS-T, M829A1, (DODIC 1315-C380)
Figure 2-27. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-30
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-28.
120-Millimeter Ammunition
Cartridge, 120-mm, HE, M934 with or without Fuze M734A1, (DODIC 1315-
C379)
Cartridge, 120-mm, HE, M933,with or without Fuze M734A1, (DODIC 1315-
C623)
Cartridge, 120-mm, M929, Smoke, WP, w/Fuze, PD, M745 or Fuze M734A1
(DODIC 1315-C624)
Figure 2-28. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-31
Chapter 2
CAUTION
The bottom layer of cartridges must be removed from their containers
and one cartridge from the second layer to meet weight limitations for
an A-22 container.
PALLETIZED
PROJECTILES
HONEYCOMB
LAYERS
LUMBER
(2” X 6” X 36”)
¾-IN PLYWOOD
(10” X 36”)
HONEYCOMB
LAYERS
(10” X 36”)
REMOVE CARTRIDGES
SKID
FROM THESE CONTAINERS
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-29.
120-Millimeter Ammunition
Cartridge, 120-mm, APFSDS-T, M829, (DODIC 1315-C786)
Cartridge, 120-mm, HEAT-MP-T, M830, (DODIC 1315-C787)
Figure 2-29. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-32
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
LAYERS 1, 3, & 5
LAYERS 2 & 4
HONEYCOMB
LAYERS
AMMUNITION
BOXES
HONEYCOMB STRIPS
SKID
( 6-IN WIDE)
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-30.
120-Millimeter Ammunition
Cartridge, 120-mm, HE, M57, (DODIC 1315-C788)
Cartridge, 120-mm, Illuminating, M91, (DODIC 1315-C790)
Figure 2-30. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-33
Chapter 2
HONEYCOMB
LAYERS
AMMUNITION
LOAD SPREADER
(¾-IN PLYWOOD)
SKID
The following ammunition items are rigged in an A-22 cargo bag for low-velocity airdrop as shown in
Figure 2-31.
120-Millimeter Ammunition
Cartridge, 120-mm, HEAT-MP-T, M830A1, (DODIC 1315-C791)
Cartridge, 120-mm, APFSDS-T, M829A2, (DODIC 1315-C792)
Cartridge, 120-mm, APFSDS, M829A3, (DODIC 1315-CA26)
Cartridge, 120-mm, M1028, (DODIC 1315-CA38)
Figure 2-31. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
2-34
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
23 October 2006
Preparing Low-Velocity A-22 Cargo Bag Loads
AMMUNITION
BOXES
HONEYCOMB
LAYERS
SKID
The following ammunition item is rigged in an A-22 cargo bag for low-velocity airdrop as shown in Figure
2-32.
152-Millimeter Ammunition
Cartridge, 152-mm, TD-T, M411E3, (DODIC 1320-D380)
Figure 2-32. Ammunition Layout in an A-22 Cargo Bag for Low-Velocity Airdrop
23 October 2006
FM 4-20.153/MCRP 4-11.3B/TO 13C7-18-41
2-35
|
|
