FM 100-60
Mineclearing Equipment Substitution Matrix _______________________________
Potential Substitutes
Baseline Systems
Comparable
Alternative
DIM Vehicle-Mounted
ML-1621 (GM)
MDV (SF)(*)
Mine Detection System (RS)
ML-1750 (GM)
VMMD (SF)(*)
Road Runner Detection
System (SF)(*)
MTK/MTK-2
MICLIC (US)
SAKR Mineclearing
Explosive Mineclearing
System (EG)(-)
Vehicle (RS)
AVLM (US)
LWD Line Charge Attachment
Type 762/GSL-111 (CH)
for Vehicles (PL)(*)
Giant Viper (UK)(-)
Plofadder Line Charge Attachment
for Vehicles (SF)(*)
Type 84 (CH)(*)
SVO (CZ)(*)
M1987 MRL (CH)(*)
Type 81 MRL (CH)(*)
KEY: (+) More capable. (-) Less capable. (*) Different capabilities for special uses.
NOTES:
1. The LWD, Plofadder, and Type 84 are not actually mineclearing vehicles, but rather attach-
ments to mount on any designated vehicles, such as tanks.
2. Unlike the MTK and MTK-2, the SVO, M1987, and Type 81 do not use line charges, but
rather dispense multiple explosive rockets into the minefield.
(continued)
B-7
FM 100-60
Mineclearing Equipment Substitution Matrix (continued) _____________________
Potential Substitutes
Baseline Systems
Comparable
Alternative
KMT-4/KMT-6
TWMP Track-Width
None
Tank-Mounted
Mine Plow (IS)
(All have similar capabilities.)
Mine Plow (RS)
EMP (UK)
M1982 (CH)
SADF Mine Plow (SF)
KMT-5/KMT-7
PT-54/PT-55 (RS)
None
Track-Width
(All have similar capabilities.)
Mine Roller (RS)
TWMP & Roller (US)
SADF Mine Roller (SF)
RKM Mine Rollers (IS)
D-5M (RO)
Minvalt-1 (SW)
KEY: (+) More capable. (-) Less capable. (*) Different capabilities for special uses.
B-8
FM 100-60
Armored Engineer and Route-Clearing
Vehicle Substitution Matrix________________________________ ______________
Potential Substitutes
Baseline Systems
Comparable
Alternative
IMR Armored
IMR-2 (RS)
Grizzley (Developmental US)(+)
Engineer Vehicle (RS)
Steyr Pionierpanzer (AU)
AMX-30 Combat Engineer
Tractor (FR)(*)
IWT (PL)
Pionierpanzer-2 Dachs (GM)(*)
Leopard-1 Armored Engineer Vehicle
(GM)(*)
CEV (US)(-)
Type-67 (JA)(-)
CET (UK)(-)
BAT/BAT-M
None
BAT-2 (RS)(+)
Route-Clearing Vehicle (RS)
M-9 ACE (US)(-)
Type-75 (JA)(-)
PKT (RS)(-)
BKT (RS)(-)
D-7/D-9 Dozer (US)(-)
KEY: (+) More capable. (-) Less capable. (*) Different capabilities for special uses.
NOTES:
1. The BAT-2 can also carry a combat engineer squad.
2. The armored engineer vehicles for special uses (*) include specialty equipment such as augers
and mine dispensers.
3. Among the route-clearing vehicles, the M-9 ACE, Type-75, D-7, and D-9 have no crane and
are slow-moving. The PKT and BKT are wheeled vehicles with little armor.
B-9
FM 100-60
Engineer Reconnaissance Vehicle Substitution Matrix _______________________
Potential Substitutes
Baseline Systems
Comparable
Alternative
IRM (RS)
IPR (RS)
TRI/MT-LB (PL)(-)
SEV/M-113 (CA)(-)
KEY: (+) More capable. (-) Less capable. (*) Different capabilities for special uses.
Tank-Mounted Dozer Blade Substitution Matrix _____________________________
Potential Substitutes
Baseline Systems
Comparable
Alternative
BTU Dozer Blade (RS)
Type 653 (CH)
None
(All have similar capabilities.)
RKM Dozer Blade (IS)
ABK-3 (IS)
UDK-1/UDK-2 (UK)
M-8/M-9 (US)
KEY: (+) More capable. (-) Less capable. (*) Different capabilities for special uses.
B-10
FM 100-60
Appendix C
Cargo Truck, Trailer, and
Radio Substitution
This manual uses generic descriptors to indicate truck and trailer capacity and radio capa-
bilities. The following list, based on equipment produced in the former Soviet Union, provides a
definition of terms and examples of equipment types in each generic category. However, users
may substitute any comparable piece of equipment that falls within the range of capabilities for
each system.
Trucks ________________________________ _______________________
Type
Drive
Load Capacity
Examples
Truck, Utility
4 x 4
500 to 600 kg
GAZ-69 (RS)
UAZ-469 (RS)
Land Rover Defender 130 (UK)
IMR A-0.75 (SR)
Truck, Light
4 x 4
1 to 2.5 mt
GAZ-66 (RS)
GAZ-3301 (RS)
TAM 110 T7 BV (SR)
Renault TRM 2000 (FR)
Truck, Medium
6 x 6
2.5 to 7 mt
Ural-375D (RS)
ZIL-131 (RS)
ZIL-157K (RS)
Truck, Heavy
6 x 6
7.5 mt or greater
KrAZ-255B (RS)
KrAZ-260 (RS)
IVECO Magirus 160-23 ANWM (GM)
AWD Bedford TM (UK)
C-1
FM 100-60
Trailers ________________________________ _______________________
Type
Load Capacity
Examples
Towed By
Trailer, Cargo, 1-Axle
0.5 mt
GAZ-704 (RS)
UAZ-3151 (RS)
UAZ-8109 (RS)
UAZ-469 (RS)
GKN Defence 750-kg (UK)
1.5 mt
TAPZ-755 (RS)
GAZ-66 (RS)
M104 Series (US)
Trailer, Cargo, 2-Axle
2.5 to 4.0 mt
GAZ-710 (RS)
ZIL-131 (RS)
IAPZ-754V (RS)
Ural-375D (RS)
782V (RS)
Ural-4320 (RS)
up to 6.8 mt
MAZ-5243 (RS)
MAZ-500 (RS)
KrAZ-255B (RS)
Trailer, Heavy Equipment
50 to 52 mt
ChMZAP-5247G (RS)
MAZ-537 (RS)
Transporter
ChMZAP-9990 (RS)
MAZ-537 (RS)
C-2
FM 100-60
Radios ________________________________ _______________________
Type
Example
Power
Frequency
Range
Output
VHF, Manpack, Low-Power
R-107 (RS)
1 W
20 to 52 MHz
6 to 25 km**
R-159M (RS)
4.5 W
30 to 75.999 MHz
10-50 km**
VHF, Portable, Low-Power
R-148 (RS)
1.1 to 2.1 W
37 to 51.95 MHz
5 km
VHF, Portable, Very-Low-Power
R-126 (RS)
0.5 W
48.5 to 51.5 MHz
1 to 4 km
VHF, Vehicle Mount, Medium-Power
R-123M (RS)
20 W
20 to 51.5 MHz
20 to 70 km***
R-173 (RS)
30 W
30 to 75.999 MHz
20 to 70 km***
HF, Manpack, Low-Power
R-104M (RS)
1 to 3.5 W
1.5 to 4.25 MHz
20 to 50 km****
HF, Vehicle Mount, Medium-Power
R-130M (RS)
10 to 40 W
1.5 to 10.99 MHz
50 to 75 km*****
HF, Vehicle Mount, High-Power
R-118 (RS)*
100 to 250 W
1.5 to 12 MHz
up to 100 km
(voice)
(voice)
400 W
up to 600 km
(teletype)
(teletype)
HF/VHF, Vehicle Mount, High-Power
R-161 (RS)*
1 kW
1.5 to 29.999 MHz,
75 to 300 km
30 to 59.999 MHz
(on move),
80 to 2,000 km
(stationary)
Not
Not
Warning Receiver, HF
R-311 (RS)
1 to 15 MHz
Applicable
Applicable
* The R-118 and R-161 radio sets listed are normally part of a radio station that shares the same alpha-
numeric designator, usually with a suffix. The station typically includes other radio sets with different
capabilities.
** For the R-107, range is 6 km with 1.5-meter whip antenna; 15 km with combined rod or long wire an-
tenna; 25 km with raised long wire antenna. For the R-159M, range with the same antenna types is 10
km, 25 km, and 50 km, respectively.
*** Range is 20 km while on the move; 40 to 70 km while stationary with telescoping antenna.
**** Range is 20 to 30 km with whip antenna; 30 to 50 km with long wire antenna.
***** Range is 50 km with 4-meter whip antenna; 75 km with 10-meter whip antenna or sloping wire an-
tenna; up to 350 km with symmetrical dipole antenna.
(continued)
C-3
FM 100-60
Radios (continued) ________________________________ ______________
Type
Example*
Power
Frequency
Range
Output
R-401 (RS)
Radio Relay, VHF
2.5 to 25 W
60 to 69.975 MHz
40 to 50 km
R-403 (RS)
(per hop LOS)
Radio Relay, VHF/UHF
R-405 (RS)
2.5 to 15 W
60 to 69.975 MHz,
40 to 50 km
390 to 420 MHz
(per hop LOS)
Radio Relay, VHF/UHF
R-415 (RS)
6 to 10 W
80 to 120 MHz,
30 to 40 km
390-430 MHz
(per hop LOS)
Radio Relay, UHF
R-419
6 to 10 W
160 to 240 MHz,
40 km
240 to 320 MHz,
(per hop LOS)
320 to 480 MHz,
480 to 645 MHz
Radio Relay, UHF
R-404 (RS)
10 W
1,550 to 2,000 MHz
40 to 50 km
R-414 (RS)***
(1.550 to 2.000 GHz)
(per hop LOS)
Troposcatter Radio Relay, SHF
R-412AM (RS)
1 kW
4.435 to 4.555 GHz,
150 to 200 km
4.630 to 4.750 GHz
(per hop)
Troposcatter Radio Relay, SHF
R-423-1 (RS)
1.5 kW
4.435 to 4.555 GHz,
90 to 230 km
4.630 to 4.750 GHz
(per hop)****
Troposcatter Radio Relay, SHF
R-423-2A (RS)
220 W
4.435 to 4.555 GHz,
90 to 230 km
4.630 to 4.750 GHz
(per hop)*****
* Each of the radio relay sets listed is normally part of a radio relay station that shares the same alpha-
numeric designator, usually with a suffix. The station typically includes other radio sets with different
capabilities for other than radio relay purposes.
** The R-415-3A radio relay station includes two R-415NV VHF/UHF radio relay sets (each covering 80
to 120 MHz and 390 to 430 MHz) and one R-415V UHF radio relay set (390 to 430 MHz). However,
the R-415-3A2 radio relay station includes only the two R-415NV sets.
*** The R-414-3 radio relay station includes the R-415N VHF radio relay set (80 to 120 MHz).
**** Maximim 2,000 km with retransmissions.
***** Maximum 450 km with retransmissions.
C-4
FM 100-60
