(a) The KGV-8B requires the KYK-13 and LCU for key loading.
(b) The KGV-8B has storage capacity for eight keys and is loaded using DTD.
It can be loaded with either red (normal unencrypted) or black (encrypted) keys and
does not require a keyer control panel (KCP) or USN LCU for loading keys.
(2) Employment. SDU employment is shown in Figure B-1.
2. Key Distribution
TADIL J crypto key distribution and handling are essentially the same as traditional
procedures for crypto, except for long-term electronic storage, multiple segments of
keys in the DTD, and the requirement to load two days crypto into the SDU at one time.
Use of the LCU or KCP is required for the KGV-8 (E2) and KGV-8A. All models of the
KGV-8 can use the same key material short titles. In addition, the KGV-8B can also use
the encrypted versions of those short titles.
3. Secure Data Unit Functions
a. Message Transmission. The terminal provides the plain text message to the SDU
that encrypts the message and provides the encrypted message to the terminal DPG.
The DDP draws a pseudorandom sequence pattern from the key located in the SDU.
This pattern provides the pseudorandom frequency-hopping pattern, the time jitter, and
the frequency spreading to the JTIDS terminal for antijam, low probability of
exploitation and low probability of intercept operations. The SDU provides a
pseudorandom code bit stream to the terminal to encrypt the message for TSEC.
b. Message Reception. The terminal accomplishes uncovering of the message
(TSEC) with the position reference code stream obtained from the SDU. It then passes
the message to the SDU for MSEC decryption and obtains the plain text message from
the SDU for exchange with the host system.
c. Common Variable Mode (CVM). In the CVM, the terminal to generate the
pseudorandom sequence for TSEC operations, and to provide MSEC, uses one
cryptographic variable (key). The operator selects a network design and a single crypto
variable logic label (CVLL) is assigned for both MSEC and TSEC operations. This is the
common means of operation.
USN
KGV-8 (E2)
KGV-8B
USAF
KGV-8A
USMC
KGV-8A and
KGV-8C
USA
KGV-8B
Figure B-1. SDU Employment
B-2
d. Partitioned Variable Mode (PVM). In the PVM, the terminal to generate the
pseudorandom sequence for encryption of the message (MSEC) uses one cryptographic
variable (key). A separate cryptographic variable is used to generate the pseudorandom
sequence for transmission of the message.
e. PVM Relay (Blind Relay). Messages received for PVM relay are TSEC-uncovered,
error corrected and coded, and then TSEC-covered for retransmission. These messages
are not MSEC decrypted.
4. Secure Data Unit Setup
The JTIDS terminal can use up to four pairs of crypto keys (today/next day), which
reside in eight SDU memory locations. The SDU (KGV-8) provides—
a. Pseudorandom frequency-hopping pattern.
b. Pseudorandom noise-spreading encryption.
c. Pseudorandom jitter time (STD and P2SP packing modes).
d. Message encryption
5. Cryptographic Variable Logical Label
Each TADIL J network design has a network description that specifies the number
and use of cryptographic variables used within the network design. Cryptographic
variables are used to establish crypto nets and are assigned reference labels called
CVLL. Circuits or groups of circuits called NPGs are established to operate by using
predetermined MSEC and TSEC cryptographic variables. Each NPG is assigned two
CVLLs during network design. The planned SDU location of the crypto keys
corresponding to the CVLLs is also established for each network platform participant.
The CVLL is a seven-bit number ranging from 1 to 127.
6. Cryptographic Net Isolation
Configuring the JTIDS terminal’s cryptographic variables creates crypto net
isolation between networks or network users. Differences in terminal loads isolate that
terminal from all other terminals with differing crypto loads. Use of cryptographic
variables to establish isolation of single or multiple units can provide NPG isolation,
blind relays, multinetting of functions (frequency division multiple access), and multiple
networks.
a. Blind Relays. Units designated as blind relays can receive and retransmit
information on assigned NPGs, but are unable to decode the information. Decoding is
accomplished by providing the TSEC key list to the relaying unit, but denying the relay
unit the MSEC key list.
b. Multinetting. Several transmission waveform parameters, including the
frequency-hopping pattern of a network, are pseudorandomly selected based upon the
B-3
encryption key. This allows two NPGs to use the same time slots because each NPG
uses a different frequency-hopping pattern. Different frequency-hopping patterns
ensure that, at any moment in time, the groups would not interfere with one another.
This frequency multiple access expands system capacity beyond any single-terminal
capacity.
c. Multiple Networks. When two or more user groups are geographically
collocated, i.e., within line-of-sight, isolation between the groups can be achieved by
using different crypto keys. This ensures that TADIL J units use different frequency-
hopping patterns, even if each network uses the same TADIL J network design.
7. Daily Cryptographic Rekey Standard
The US and NATO adopted a convention that stipulates that Class 2 JTIDS
terminals are to be rekeyed once a day. Class 2 JTIDS terminals can be loaded with
crypto keys sufficient for two days of operation, with an automatic capability to roll
over, i.e., switch from today’s key to tomorrow’s key at a preset time. Unless otherwise
stipulated in the OPTASKLINK message, encryption devices are rekeyed at 2400 Zulu.
a. Cryptographic Period Designator (CPD). JTIDS Class 2 terminals have eight
memory locations to store crypto keys in the SDU (KGV-8). These memory locations are
numbered “0” through “7”.
(1) For a normal (24-hour) crypto period, memory locations are assigned in pairs
designated as “0 and 1”, “2 and 3,” “4 and 5,” and “6 and 7.” Accordingly, locations 0, 2, 4,
and 6 represent one set of concurrently operating locations called the even locations
and are given the CPD of “0.” Locations 1, 3, 5, and 7 are referred to as the odd locations
and are assigned the CPD of “1.”
(2) To load two days’ keys into the SDU, the operator must determine whether
the key goes into the even location or the odd location. A convention has been accepted
by the US and NATO which defines 1 January 1985 as an odd or O day. Each subsequent
day is defined as odd or even based on this convention.
b. Cryptographic Rollover. At the end of a crypto period, all of the keys that have
been in use, i.e., odd or even, are automatically erased in the SDU and the current CPD
is changed. During the next crypto period, the terminal selects the complimentary set of
keys in the other memory locations for the same time slot assignment. The CVLL used
in the current and next crypto period is the same to permit operation across the crypto
period boundary without a requirement to reinitialize time slot assignments.
8. Key Loading Devices
a. KYK-13 Electronic Transfer Device. A hand-carried, battery-operated electronic
transfer device capable of storing up to six keys.
b. KOI-18 General Purpose Tape Reader. The KOI-18 is a battery-powered device
that reads an eight-level punched tape and converts the information to a serial output
that can be loaded into a KYK-13 or DTD.
B-4
c. LCU. A USN-unique device for loading specific SDU memory locations of the
KGV-8 (E-2) and KGV-8A. It is used in conjunction with the KYK-13 transfer device.
d. Key Control Panel. A USA device similar to the LCU.
e. AN/CYZ-10 DTD. A hand-held portable computer used to store and transfer keys.
The DTD can store up to 1,000 keys and is authorized for long-term storage. It can be
used to transfer keys into other DTDs or directly into the KGV-8 (E-2) or KGV-8B. The
DTD can accept black keys from a computer using JTIDS PC application software. A key
load status log data base and an audit trail data base, internal to the DTD,
automatically keep track of the different crypto keys loaded into and from the DTD.
Either database can be reviewed by the DTD user or uploaded into a PC for storage and
viewing.
