Seat Alhambra. Instruction - part 1

button.

●

Locking the vehicle without activating the

anti-theft system: Press the 

›››

button

for a second time within 2 seconds.

●

Unlocking: press the 

›››

button.

●

Unlocking the rear lid: Hold down the 

›››

in Introduction on page 112

button for at least 1 second.

Locking and unlocking with the central lock-
ing switch

●

Locking: press the 

›››

Fig. 2

button. None

of the doors can be opened from the outside.
The doors can be opened from the inside by
pulling the inside door handle.

●

Unlocking: press the 

›››

Fig. 2

button.



›››



›››



›››

page 8

›››

page 9

Locking or unlocking of driver door

Fig. 3

Driver door handle: hidden lock cylin-

der.

As a general rule, when the driver door is
locked all other doors are locked. Unlocking
instructionly only opens the driver door. Please
note the instructions for the anti-theft alarm

›››



●

Unfold the key shaft

›››



●

Insert the key shaft into the lower opening

in the cover on the driver door handle from

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

below

›››

Fig. 3

(arrow) then remove the cover

upwards.

●

Insert the key blade into the lock cylinder

to unlock or lock the vehicle.

Special Characteristics

●

The anti-theft alarm will remain active when

vehicles are unlocked. However, it is not trig-
gered

›››



●

If the driver door is opened, the alarm will

be triggered.

●

Switch the ignition on. The electronic im-

mobilizer recognises a valid vehicle key and
deactivates the anti-theft alarm system.



›››

Note

The anti-theft alarm is not activated when the
vehicle is locked instructionly using the key
shaft

›››



Locking the passenger side door and
sliding doors instructionly

Fig. 4

At the front of the passenger sliding

door: Emergency lock, hidden by a rubber
cap.

Fig. 5

Emergency locking of the vehicle using

the vehicle key

The passenger side door and the sliding
doors can be locked instructionly. The anti-theft
alarm is

not activated in this case.

●

Open the door.

●

Remove the rubber cap to the front of the

door. The rubber cap is marked with a lock
symbol 

›››

Fig. 4

●

Unfold the vehicle key blade

›››



●

Insert the key shaft horizontally into the

opening and moved the coloured lever for-
ward

›››

Fig. 5

●

Replace the rubber cap and close the door.

●

Check if the door is locked.

●

Carry out the same operation on the other

doors if necessary.

●

Have the vehicle checked by a specialised

workshop.



›››

Note

The doors can be opened and unlocked indi-
vidually from the inside by pulling the inside
door handle. To open, pull the inner door re-
lease lever twice

›››



in Introduction on page 122

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Opening the rear door

Fig. 6

Detailed view of the centre console:

button for unlocking the rear lid

Fig. 7

Opening the boot hatch from the out-

side

Before opening the rear lid, always remove
any load on its luggage rack

›››

in Introduc-

tion on page 122

Opening with the ignition key

●

Press the



button on the vehicle key un-

til the rear lid opens automatically.

To open using the centre console control

●

Press the



button on the centre console

›››

Fig. 6

. The rear lid will be automatically

opened.

●

The button is still operative when the igni-

tion is switched off.

Opening the rear lid with the button

●

Unlock the vehicle or open a door.

●

Raise the rear lid using the button

›››

Fig. 7

(arrow).



›››

Emergency unlocking the boot hatch

Fig. 8

From the luggage compartment: re-

move the boot hatch cover.

Fig. 9

From the luggage compartment: Emer-

gency unlocking of the booth hatch.

●

Remove equipment to access the inside of

the rear lid.

●

Remove the square cover in the inner trim

of the rear lid

›››

Fig. 8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

●

Push the release lever

›››

Fig. 9

in the di-

rection of the arrow to unlock the boot.

●

Instructionly open the rear lid.



›››

in Opening and closing the bonnet

Bonnet

Fig. 10

Release lever in the driver's footwell

area.

Fig. 11

Cam under the bonnet

●

Opening the bonnet: Pull the lever under

the dashboard

›››

Fig. 10

●

Lift up the bonnet. Press the release catch

under the bonnet upwards

›››

Fig. 11

. The ar-

rester hook under the bonnet is released.

●

The bonnet can be opened. Release the

bonnet stay and secure it in the fixture de-
signed for this in the bonnet.



›››

on page 270



›››

page 268

Electric windows*

Fig. 12

Detail of the driver door: controls for

the windows, and the electric child safety lock
buttons.

Buttons on the driver door

For the front electric windows.
For the sliding door electric windows.
To lock the sliding doors and their win-
dows.

Opening and closing the windows

Opening:

Push the  button.

Closing:

Pull the  button.

To stop the
one touch
function:

Press or pull on the corresponding win-
dow button.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials



Press the



button for the electronic

child safety lock to deactivate the con-
trols for the electric windows on the
sliding doors and to lock these doors

›››

page 119

. The indicator on the but-

ton will light up.



›››

in Electric windows: functions on

page 125



›››

page 125

Panoramic sunroof*

Fig. 13

On the interior roof lining: use the ro-

tary button for opening and closing

Fig. 14

On the interior roof lining: press the

button and pull on it to raise and lower the
sunroof.

To open the panoramic sliding sunroof, the
switch must be in the position

●

Opening: Turn the switch to position

›››

Fig. 13

●

Convenience position: Turn the switch to

position

›››

Fig. 13

●

Closing: Turn the switch to position

›››

Fig. 13

●

To tilt open: Push the switch to position

›››

Fig. 14

. For an intermediate position,

hold down the switch until you reach the de-
sired position.

●

Lowering: Pull the switch to position

›››

Fig. 14

. For an intermediate position,

hold down the switch until you reach the de-
sired position.



›››

in Panoramic sliding sunroof: oper-

ating on page 126



›››

page 126



›››

page 13

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Manually closing the panoramic sun-
roof

Fig. 15

On the interior roof lining: remove

cover.

Fig. 16

Allen bolt to close the panoramic slid-

ing sunroof

●

Push open the cover in the direction indica-

ted (arrow)

›››

Fig. 15

●

Insert a standard 4 mm Allen key

into the

Allen bolt

›››

Fig. 16

●

Rotate the Allen bolt to close the panoram-

ic sliding sunroof.

●

Re-install the lining.

●

Bring the vehicle to a specialised workshop

to check the panoramic sliding sunroof given
that the emergency closing operation could
damage general operation or the anti-trap
function of the panoramic sliding sunroof.



›››

in Manual adjustment of seats on

Before driving

Manually adjusting the front seat

Fig. 17

Front left seat controls

The controls are mirrored for the front right-
hand seat.

Mechanically and electrically adjusted con-
trols can be combined on the seat.

Fig. 17

Function

Necessary operations

Moving the
head restraint
backwards or
forwards.

Pull the lever and move
the seat forwards. The
front seat must be engag-
ed when the lever is re-
leased!

Adjusting the
lumbar sup-
port*.

Turn the lever.

Not included with the vehicle tool kit.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Fig. 17

Function

Necessary operations

Adjusting the
seat backrest
angle.

Turn the wheel.

Adjusting the
seat height.

Pull the lever up or push
down (several times if
necessary) from its home
position.



›››

page 140

Electrical controls on the front seat*

Fig. 18

Adjusting the front left seat forwards

or backwards, the height, the seat angle and
the front seat backrest

Fig. 19

Adjusting the lumbar support

The controls are mirrored for the front right-
hand seat.

Mechanically and electrically adjusted con-
trols can be combined on the seat.

Fig. 18

Press the control in the direction of the

arrow:

Move the seat backwards or for-
wards.

and

Raise or lower the seat.

Adjust the seat angle.

Forwards

or back-

wards.

Adjust the seat backrest angle.

Fig. 19

Press the corresponding area of the

switch:

Adjust the curve of the lumbar support.

Adjust the height of the lumbar support.



›››

in Electric driver's seat adjustment*

on page 141

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Adjustment of the head restraint

Fig. 20

Front seat: adjustment of the head re-

straint.

Grab the sides of the head restraints with
both hands and push upwards to the desired
position. To lower it, repeat the same action,
pressing the

button on the side.



›››

in Removing and installing the head

restraints on page 144



›››

page 57

›››

page 142

Adjustment of the seat belt

Fig. 21

Positioning and removing the seat

belt buckle.

Fig. 22

Correct seat belt and head restraint

positions, viewed from front and the side.

To adjust the seat belt around your should-
ers, adjust the height of the seats or the
height of the belt.

The shoulder part of the seat belt should be
well centred over it, never over the neck. The
seat belt lies flat and fits comfortably on the
upper part of the body.

The lap part of the seat belt lies across the
pelvis, never across the stomach. The seat
belt lies flat and fits comfortably on the pel-
vis.



›››

page 61



›››

page 64

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Seat belt tensioners

In the event of a head-on, lateral or rear colli-
sion, the seat belts on the front seats and the
outer seats of the second row will tighten au-
tomatically.

The tensioner can be triggered only once.



›››

in Service and disposal of belt ten-

sion devices on page 68



›››

page 67

Adjusting the exterior mirrors

Fig. 23

In the driver door: exterior mirror con-

trols

Adjusting the exterior mirrors: Turn the knob
to the corresponding position:

Turning the knob to the desired posi-
tion, adjust the mirrors on the driver
side (L, left) and the passenger side (R,
right) to the direction desired.
Depending on the equipment fitted on
the vehicle, the mirrors may be heated
according to the outside temperature.
Folding in mirrors.



›››

in Exterior mirrors on page 139



›››

page 139

Adjusting the steering wheel

Fig. 24

Mechanical steering wheel adjust-

ment

Adjust the steering wheel before your trip
and only when the vehicle is stationary.

L/R





●

Push the lever

›››

Fig. 24

downwards.

●

Adjust the steering wheel so that you can

hold onto the steering wheel with both hands
on the outside of the ring at the 9 o'clock and
3 o'clock positions and your arms slightly
bent.

●

Push the lever firmly upwards until it is

flush to the steering column

›››

in Adjust-

ing the steering wheel position on
page 58



›››

in Adjusting the steering wheel po-

sition on page 58

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Airbags

Front Airbags

Fig. 25

Location and deployment area of the

front airbag for the driver

Fig. 26

Location and deployment area of the

front airbag for the front passenger

In conjunction with the seat belts, the front
airbag system gives the driver and the front
passenger additional protection for the head
and chest in the event of a severe frontal col-
lision. Always remains as far away as possi-
ble from the front airbag. This way, in the
event of an accident, the front airbags can

deploy fully when triggered, providing maxi-
mum protection.

The front airbag for the driver is located in
the steering wheel

›››

Fig. 25

and the airbag

for the front passenger is located in the dash
panel

›››

Fig. 26

. Airbags are identified by the

word “AIRBAG”.

When the front airbags are triggered they fill
the zones marked in red (deployment area)

›››

Fig. 25

. Therefore, objects should never be

placed or mounted in these areas

›››

Front airbags on page 71

, Factory-fitted ac-

cessories are outside the range of the front
airbag for the driver and the front passenger,
e.g. the baseplate for the mobile phone sup-
port.

The airbag covers open out of the steering
wheel or dash panel and remain attached to
them when the driver and front passenger
front airbags are triggered

›››

Fig. 26



›››

in Front airbags on page 71

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The essentials

Disconnecting the passenger front air-
bag

Fig. 27

In the glove compartment on the front

passenger side: Key switch for enabling and
disabling the front passenger front airbag.

Disabling the front passenger front airbag

●

Switch the ignition off.

●

Open the glove compartment on the front

passenger side.

●

Unfold the vehicle key blade

›››


