MINI Convertible (2018 year). Instruction - part 13





-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Wheels and tires
do not change this position while using the ve-
5. Make sure that the vehicle jack foot stands
hicle jack.
vertically and at a right angle beneath the
jacking point.
1. Hold the vehicle jack with one hand, ar-
row 1, and grasp the vehicle jack crank or
lever with your other hand, arrow 2.
6. Make sure that the vehicle jack foot stands
vertically and perpendicularly beneath the
jacking point after extending the vehicle
2. Insert the vehicle jack into the rectangular
jack.
recess of the jacking point closest to the
wheel to be changed.
7. Crank up the vehicle jack until the entire
surface of the jack is in contact with the
3. Extend the vehicle jack by turning the vehi-
ground and the wheel in question is raised
cle jack crank or lever clockwise.
a maximum of 1.2 inches/3 cm off the
ground.
Mounting a wheel
Mount one emergency wheel only, as required.
1. Unscrew the lug bolts.
2. Remove the wheel.
3. Put the new wheel or emergency wheel on
and screw in at least two lug bolts in a
4. Take your hand away from the vehicle jack
crosswise pattern until hand-tight.
as soon as the vehicle jack is under load
If non-original light-alloy wheels of the ve-
and continue turning the vehicle jack crank
hicle manufacturer are mounted, the ac-
or lever with one hand.
companying lug bolts may have to be used
as well.
218

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Wheels and tires
MOBILITY
4. Hand-tighten the remaining lug bolts and
Safety information
tighten all lug bolts well in a crosswise pat-
WARNING
tern.
The emergency wheel has particular di-
5. Turn the vehicle jack crank counterclock-
mensions. When driving with an emergency
wise to retract the vehicle jack and lower
wheel, changed driving properties may occur,
the vehicle.
for instance reduced lane stability when brak-
6. Remove the vehicle jack and stow it se-
ing, longer braking distance, and changed self-
curely.
steering properties in the limit area. There is a
risk of an accident. Drive moderately and do
After the wheel change
not exceed a speed of 50 mph/80 km/h.
1. Tighten the lug bolts crosswise. The tight-
ening torque is 101 lb ft/140 Nm.
Overview
2. Stow the nonworking wheel in the cargo
The emergency wheel is housed in a well on
area, if necessary.
the underbody of the vehicle. The screw con-
The nonworking wheel cannot be stored
nection of the emergency wheel is under the
under the cargo floor panel because of its
cargo floor panel, on the floor of the storage
size.
compartment for the onboard vehicle tool kit.
3. Check tire inflation pressure at the next op-
The wheel change tools are under the cargo
portunity and correct as needed.
floor panel.
4. Reinitialize the run-flat tires.
Removing the emergency wheel
Reset the Tire Pressure Monitor TPM.
1. Loosen the nut using the wheel wrench
5. Check to make sure the lug bolts are tight
from the onboard vehicle tool kit.
with a calibrated torque wrench.
6. Have the damaged tire replaced at the
nearest dealer’s service center or another
qualified service center or repair shop.
Emergency wheel
Concept
In the event of a flat tire, the emergency wheel
2. Remove the retaining plate.
can be used in place of the wheel with the de-
fective tire. The emergency wheel is only in-
tended for temporary use until the defective
tire/wheel has been replaced.
General information
Mount one emergency wheel only.
Also check the tire inflation pressure of the
emergency wheel in the cargo area regularly,
and correct it as needed.
219

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Wheels and tires
3. Screw wheel lug wrench onto the thread
and hold in place with one hand.
4. Unlock the locking hexagon of the emer-
gency wheel well using the hexagon at-
tached to retaining plate.
5. Lower the emergency wheel with the wheel
wrench.
6. Unscrewing the wheel wrench
7. Pull out the well with emergency wheel un-
der the vehicle toward the rear.
8. Remove the spacer and emergency wheel
from the well.
9. Stow the well and spacer in the vehicle.
Replacing the tires
1. Have the damaged tire replaced.
2. Replace the emergency wheel with the new
wheel.
Installing the emergency wheel
Have the emergency wheel installed back into
the vehicle by a dealer’s service center or an-
other qualified service center or repair shop.
220

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine compartment
MOBILITY
Engine compartment
necessarily available in your vehicle, e. g., due
Vehicle features and op-
to the selected options or country versions. This
tions
also applies to safety-related functions and sys-
tems. When using these functions and systems,
This chapter describes all standard, country-
the applicable laws and regulations must be
specific and optional features offered with the
observed.
series. It also describes features that are not
Important features in the engine compartment
1
Filler neck for washer fluid
4
Jump-starting, positive terminal
2
Vehicle identification number
5
Jump-starting, negative terminal
3
Oil filler neck
6
Coolant reservoir
personal and property damage. The manufac-
Hood
turer of your vehicle recommends that, in the
effort to avoid such risks, work in the engine
Safety information
compartment be performed by a dealer’s serv-
WARNING
ice center or another qualified service center or
Improperly executed work in the engine
repair shop.
compartment can damage vehicle components
and impair vehicle functions. There is a risk of
221

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine compartment
WARNING
Hood is unlocked.
The engine compartment accommodates
moving components. Certain components in
the engine compartment can also move with
the vehicle switched off, for instance the radia-
tor fan. There is a risk of injury. Do not reach
into the area of moving parts. Keep articles of
clothing and hair away from moving parts.
WARNING
There are protruding parts, for instance
2. After the lever is released, pull the lever
locking hook, on the inside of the hood. There
again, arrow 2.
is a risk of injury. If the hood is open, pay atten-
tion to protruding parts and keep clear of these
Hood can be opened.
areas.
Indicator/warning lights
WARNING
When the hood is opened, a Check Control
An incorrectly locked hood can open
message is displayed.
while driving and restrict visibility. There is a
risk of an accident. Stop immediately and cor-
Closing the hood
rectly close the hood.
WARNING
Body parts can be jammed when opening
and closing the hood. There is a risk of injury.
Make sure that the area of movement of the
hood is clear during opening and closing.
NOTE
Folded-away wipers can be jammed
when the hood is opened. There is a risk of
Let the hood fall from approx. 16 inches/40 cm,
damage to property. Make sure that the wipers
arrow.
with the wiper blades mounted are folded
The hood must engage on both sides.
down onto the windshield before opening the
hood.
NOTE
When the hood is closed, it must engage
on both sides. Pressing again can damage the
hood. There is a risk of damage to property.
Open the hood again and then close it energet-
ically. Avoid pressing again.
Opening the hood
1. Pull lever, arrow 1.
222

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine oil
MOBILITY
Engine oil
NOTE
Vehicle features and op-
Too much engine oil can damage the en-
tions
gine or the catalytic converter. There is a risk of
This chapter describes all standard, country-
damage to property. Do not add too much en-
specific and optional features offered with the
gine oil. When too much engine oil is added,
series. It also describes features that are not
have the engine oil level corrected by a dealer’s
necessarily available in your vehicle, e. g., due
service center or another qualified service cen-
to the selected options or country versions. This
ter or repair shop.
also applies to safety-related functions and sys-
tems. When using these functions and systems,
the applicable laws and regulations must be
Electronic oil measure-
observed.
ment
General information
General information
The electronic oil measurement has two meas-
The engine oil consumption is dependent on
uring principles:
your driving style and driving conditions.
Monitoring.
Therefore, regularly check the engine oil level
Detailed measurement.
after refueling by taking a detailed measure-
ment.
When making frequent short-distance trips or
using a dynamic driving style, for instance
The engine oil consumption can increase in the
when taking curves aggressively, regularly per-
following situations, for example:
form a detailed measurement.
Sporty driving style.
Break-in of the engine.
Monitoring
Idling of the engine.
Concept
With use of engine oil types that are classi-
The engine oil level is monitored electronically
fied as not suitable.
while driving and can be shown on the Control
Different Check Control messages appear, de-
Display.
pending on the engine oil level.
If the engine oil level is outside its permissible
operating range, a Check Control message is
displayed.
Safety information
NOTE
Functional requirements
An engine oil level that is too low causes
A current measured value is available after ap-
engine damage. There is a risk of damage to
prox. 30 minutes of normal driving.
property. Immediately add engine oil.
223

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine oil
Displaying the engine oil level
Performing a detailed measurement
Via the Central Information Display (CID):
Via the Central Information Display (CID):
1.
"Vehicle info"
1.
"Vehicle info"
2. "Vehicle status"
2. "Vehicle status"
3.
"Engine oil level"
3.
"Measure engine oil level"
The engine oil level is displayed.
4. "Start measurement"
The engine oil level is checked and displayed
System limits
via a scale.
When making frequent short-distance trips or
using a dynamic driving style, it may not be
possible to calculate a measured value. In this
Adding engine oil
case, the measured value for the last, suffi-
ciently long trip is displayed.
General information
Only add engine oil when the message is dis-
Detailed measurement
played in the instrument cluster. The quantity
to be added is indicated in the message dis-
Concept
played in the instrument cluster.
The engine oil level is checked when the vehi-
Only add suitable types of engine oil, refer to
cle is stationary and displayed via a scale.
page 225.
If the engine oil level is outside its permissible
Safely park the vehicle and switch off the igni-
operating range, a Check Control message is
tion before adding engine oil.
displayed.
Take care not to add too much engine oil.
General information
Safety information
During the measurement, the idle speed is in-
creased somewhat.
WARNING
Operating materials, for instance oils,
Functional requirements
greases, coolants, fuels, can contain harmful in-
Vehicle is parked in a horizontal position.
gredients. There is a risk of injuries or danger to
Instruction transmission: shift lever in neutral
life. Follow the instructions on the containers.
position, clutch and accelerator pedals not
Avoid the contact of articles of clothing, skin or
depressed.
eyes with operating materials. Do not refill op-
erating materials into different bottles. Store
Steptronic transmission: selector lever in se-
operating materials out of reach of children.
lector lever position N or P and accelerator
pedal not depressed.
NOTE
Engine is running and is at operating tem-
An engine oil level that is too low causes
perature.
engine damage. There is a risk of damage to
property. Immediately add engine oil.
224

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Engine oil
MOBILITY
NOTE
NOTE
Too much engine oil can damage the en-
Incorrect engine oil can cause malfunc-
gine or the catalytic converter. There is a risk of
tions in the engine or damage it. There is a risk
damage to property. Do not add too much en-
of damage to property. When selecting an en-
gine oil. When too much engine oil is added,
gine oil, make sure that the engine oil has the
have the engine oil level corrected by a dealer’s
correct oil rating.
service center or another qualified service cen-
ter or repair shop.
Suitable engine oil types
Add engine oils that meet the following oil rat-
Overview
ing standards:
The oil filler neck is located in the engine com-
Gasoline engine
partment, refer to page 221.
BMW Longlife-01 FE.
Adding engine oil
BMW Longlife-14 FE+.
1. Open the hood, refer to page 221.
2. Turn the lid counterclockwise.
More information about suitable engine oil rat-
ings and viscosities of engine oils can be re-
quested from a dealer’s service center or an-
other qualified service center or repair shop.
Alternative engine oil types
If an engine oil suitable for continuous use is
not available, up to 1 US quart/liter of an en-
gine oil with the following oil rating can be
added:
3. Add engine oil.
Gasoline engine
4. Close the cap.
BMW Longlife-01.
API SL, API SM, or API SN.
Engine oil types to add
Viscosity grades
General information
Gasoline engine:
The engine oil quality is critical for the life of the
When selecting an engine oil, make sure that
engine.
the engine oil has the viscosity grade SAE
0W-30 or SAE 0W-20. The suitable viscosity
Safety information
grade is indicated on a label in the engine com-
partment.
NOTE
Viscosity class SAE 0W-20 is only suitable for
Oil additives can damage the engine.
particular engines.
There is a risk of damage to property. Do not
use oil additives.
More information about suitable engine oil rat-
ings and viscosities of engine oils can be re-
225

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Engine oil
quested from a dealer’s service center or an-
other qualified service center or repair shop.
Engine oil change
NOTE
Engine oil that is not changed in timely
fashion can cause increased engine wear and
thus engine damage. There is a risk of damage
to property. Do not exceed the service data in-
dicated in the vehicle.
The vehicle manufacturer recommends that
you have a dealer’s service center or another
qualified service center or repair shop change
the engine oil.
226

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Coolant
MOBILITY
Coolant
Vehicle features and op-
Coolant level
tions
Overview
This chapter describes all standard, country-
The coolant reservoir is in the engine compart-
specific and optional features offered with the
ment, refer to page 221.
series. It also describes features that are not
Open the hood, refer to page 221.
necessarily available in your vehicle, e. g., due
to the selected options or country versions. This
Checking
also applies to safety-related functions and sys-
tems. When using these functions and systems,
There are yellow Min and Max marks in the
the applicable laws and regulations must be
coolant reservoir.
observed.
1. Let the engine cool.
2. Turn the lid of the coolant reservoir slightly
counterclockwise to allow any excess pres-
General information
sure to dissipate, then open it.
Coolant consists of water and additives.
Not all commercially available additives are
suitable for the vehicle. Information about suit-
able additives is available from a dealer’s serv-
ice center or another qualified service center or
repair shop.
Safety information
3. Open the coolant reservoir lid.
WARNING
4. The coolant level is correct if it lies between
With the engine hot and the cooling sys-
the minimum and maximum marks in the
tem open, coolant can escape and lead to
filler neck.
scalding. There is a risk of injury. Only open the
cooling system with the engine cooled down.
WARNING
Additives are harmful and incorrect addi-
tives can damage the engine. There is a risk of
injury and risk of damage to property. Do not
allow additives to come into contact with skin,
eyes or articles of clothing. Use suitable addi-
tives only.
227

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Coolant
Adding
1. Let the engine cool.
2. Turn the lid of the coolant reservoir slightly
counterclockwise to allow any excess pres-
sure to dissipate, then open it.
3. If the coolant is low, slowly add coolant up
to the specified level; do not overfill.
4. Close the cap.
5. Have the cause of the coolant loss elimi-
nated as soon as possible.
Disposal
Comply with the relevant environmen-
tal protection regulations when dispos-
ing of coolant and coolant additives.
228

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Maintenance
MOBILITY
Maintenance
General information
Vehicle features and op-
Information on service requirements, refer to
tions
page 99, can be displayed on the Control Dis-
This chapter describes all standard, country-
play.
specific and optional features offered with the
series. It also describes features that are not
Service data in the remote control
necessarily available in your vehicle, e. g., due
Information on the required maintenance is
to the selected options or country versions. This
continuously stored in the remote control. The
also applies to safety-related functions and sys-
dealer’s service center can read this data out
tems. When using these functions and systems,
and suggest an optimized maintenance scope
the applicable laws and regulations must be
for the vehicle.
observed.
Therefore, hand the service advisor the remote
control with which the vehicle was driven most
recently.
MINI maintenance system
Storage periods
The maintenance system indicates required
maintenance measures, and thereby provides
Storage periods during which the vehicle bat-
support in maintaining road safety and the op-
tery was disconnected are not taken into ac-
erational reliability of the vehicle.
count.
In some cases, scopes and intervals may vary
If this occurs, have a dealer's service center or
according to the country-specific version. Re-
another qualified service center or repair shop
placement work, spare parts, fuels and lubri-
update the time-dependent maintenance pro-
cants, and wear materials are calculated sepa-
cedures, such as checking brake fluid and, if
rately. Further information is available from a
necessary, changing the engine oil and the mi-
dealer’s service center or another qualified
crofilter/activated-charcoal filter.
service center or repair shop.
Service and Warranty In-
Condition Based Service
formation Booklet for
CBS
US models and Warranty
and Service Guide Book-
Concept
let for Canadian models
Sensors and special algorithms take into ac-
count the driving conditions of the vehicle. CBS
Please consult your Service and Warranty Infor-
uses these to calculate the need for mainte-
mation Booklet for US models and Warranty
nance.
and Service Guide Booklet for Canadian models
The system makes it possible to adapt the
for additional information on service require-
amount of maintenance corresponding to your
ments.
user profile.
The manufacturer of your vehicle recommends
that maintenance and repair be performed by a
229

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Maintenance
dealer’s service center or another qualified
Emissions
service center or repair shop. Records of regu-
The warning light lights up:
lar maintenance and repair work should be re-
Emissions are deteriorating. Have
tained.
the vehicle checked as soon as pos-
sible.
The warning light flashes under certain cir-
Socket for OBD Onboard
cumstances:
Diagnosis
This indicates that there is excessive misfir-
ing in the engine.
Safety information
Reduce the vehicle speed and have the sys-
NOTE
tem checked immediately; otherwise, seri-
The socket for Onboard Diagnosis is an
ous engine misfiring within a brief period
intricate component intended to be used in
can seriously damage emission control
conjunction with specialized equipment to
components, in particular the catalytic con-
check the vehicle’s primary emissions system.
verter.
Improper use of the socket for Onboard Diag-
nosis, or contact with the socket for Onboard
Diagnosis for other than its intended purpose,
can cause vehicle malfunctions and creates
risks of personal and property damage. Given
the foregoing, the manufacture of your vehicle
strongly recommends that access to the socket
for Onboard Diagnosis be limited to a dealer's
service center or another qualified service cen-
ter or repair shop or other persons that have
the specialized training and equipment for pur-
poses of properly utilizing the socket for On-
board Diagnosis.
Position
There is an OBD socket on the driver's side for
checking the primary components in the vehi-
cle's emissions.
230

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
Replacing components
Hold the wiper firmly when changing the wiper
Vehicle features and op-
blade. Do not fold or switch on the wiper with-
tions
out a wiper blade installed.
This chapter describes all standard, country-
NOTE
specific and optional features offered with the
Folded-away wipers can be jammed
series. It also describes features that are not
when the hood is opened. There is a risk of
necessarily available in your vehicle, e. g., due
damage to property. Make sure that the wipers
to the selected options or country versions. This
with the wiper blades mounted are folded
also applies to safety-related functions and sys-
down onto the windshield before opening the
tems. When using these functions and systems,
hood.
the applicable laws and regulations must be
observed.
Replacing the wiper blades
1. To change the wiper blades, fold up the
Onboard vehicle tool kit
wiper arms.
2. Fold up and hold the wiper arm firmly.
3. Open the wiper blade lock, arrow.
Depending on the vehicle equipment, the on-
board vehicle tool kit is located on the right
side under the cargo floor panel or in a bag on
4. Pull the wiper blade down out of the holder
the right side of the cargo area.
on the wiper arm, arrow 1.
After use, secure the bag with the onboard ve-
hicle tool kit on a lashing eye again.
Wiper blade replacement
Safety information
NOTE
The window may sustain damage if the
5. Pull the wiper blade free from the holder of
wiper falls onto it without the wiper blade in-
the wiper arm, arrow 2.
stalled. There is a risk of damage to property.
231

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
6. Insert and latch a new wiper blade in re-
WARNING
verse order.
Work on switched-on lighting systems
7. Fold down the wiper arm.
can cause short circuits. There is a risk of injury
or risk of damage to property. When working
on the lighting system, switch off the lights in
question. If necessary, heed the bulb manufac-
Light/bulb replacement
turer's instructions.
General information
NOTE
Dirty bulbs have a reduced service life.
Lights and bulbs
There is a risk of damage to property. Do not
Lights and bulbs make an essential contribution
hold new bulbs with your bare hands. Use a
to vehicle safety.
clean cloth or something similar, or hold the
The manufacturer of the vehicle recommends
bulb by its base.
that you have appropriate work performed by a
dealer’s service center or another qualified
Light-emitting diodes (LEDs)
service center or repair shop if you are unfami-
liar with it or if it has not been described here.
WARNING
A spare light box is available from a dealer’s
Too intensive brightness can irritate or
service center or another qualified service cen-
damage the retina of the eye. There is a risk of
ter or repair shop.
injury. Do not look directly into the headlights
or other light sources. Do not remove the LED
Follow the safety information, refer to
covers.
page 232.
Light-emitting diodes (LEDs)
Headlight glass
Some items of equipment use light-emitting di-
Condensation can form on the inside of the ex-
odes installed behind a cover as a light source.
ternal lights in cool or humid weather. When
These light-emitting diodes are related to con-
driving with the lights switched on, the conden-
ventional lasers and are officially designated as
sation evaporates after a short time. The head-
Class 1 light-emitting diodes.
light glass does not need to be changed.
Follow the safety information, refer to
If despite driving with the headlights switched
page 232.
on, increasing humidity forms, for instance wa-
ter droplets in the light, have the headlights
Safety information
checked.
Lights and bulbs
Headlight setting
The headlight adjustments can be affected by
WARNING
changing lights and bulbs. After the headlight
Bulbs can get hot during operation. Con-
adjustment was changed, have it checked and,
tact with the bulbs can cause burns. There is a
if necessary, corrected by a dealer’s service
risk of injury. Only change bulbs after they have
center or another qualified service center or re-
cooled off.
pair shop.
232

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Replacing components
MOBILITY
Front halogen lights, bulb replacement
Bulbs: H4
1. Open the hood, refer to page 222.
Overview
2. Turn the lid counterclockwise, arrow, and
Halogen headlights
remove.
1
Low beams/high beams
3. Pull off the connector.
2
Turn signal
4. Unclip spring clip, arrow, and fold down.
Bug light
5. Remove the bulb from the headlight hous-
ing.
6. Insert the new bulb and install the cover in
1
Parking lights
the reverse order.
2
Daytime running lights
3
Fog lights
Turn signal
Follow the general instructions on lights and
Low beams/high beams
bulbs, refer to page 232.
Follow the general instructions on lights and
Bulbs: PW24W
bulbs, refer to page 232.
233

-------------------------------------------------------------------------------------------------------------------------------------------------------------

MOBILITY
Replacing components
With white turn signal lights: PWY24W
Parking lights/fog lights/daytime
running lights
1. Turn the steering wheel.
Follow the general instructions on lights and
2. Turn the lid counterclockwise, arrow 1, and
bulbs, refer to page 232.
remove.
Bulbs:
Parking lights for halogen headlights: W5W
Parking lights for LED headlights:
W5W NBV.
Daytime running light: PSX24W.
Fog light: H8.
Replacing the bulbs
1. Turn the steering wheel.
3. Unscrew the inner cover counterclockwise,
2. Turn the lid counterclockwise, arrow 2, and
and remove it.
remove.
4. Pull bulb holder out of the bulb housing; if
3. Pull off the connector.
needed, loosen it with small tilting move-
4. Remove the bulb holder.
ments if possible.
Parking lights: turn the bulb holder, ar-
row 1, counterclockwise and remove.
Daytime running lights: squeeze the
upper and lower locks of the bulb
holder, arrow 2, and remove the bulb
holder.
For better accessibility, remove the bulb
of the fog light as needed.
5. Pull the bulb out of the fixture.
6. Insert the new bulb and install the cover in
the reverse order.
234















Content      ..     11      12      13      14     ..
