Section 03 ENGINES Subsection 05 (TOP END) CAUTION: Always install new mono-hook cir- CAUTION: Circlips must not move freely after Before inserting piston in cylinder, lubricate the Cylinder Head Cover, Cylinder Head Apply a thin layer of Loctite 518 (P/N 293 800 CAUTION: Always install a gasket of the proper Before inserting piston in cylinder, lubricate the Install cylinders. Do not tighten. Install new rubber ring and round O-rings on each NOTE: Carefully clean screws before reinstalla- Install exhaust manifold with gaskets. Do not Torque cylinder screws in a crisscross sequence M8 29 N•m (21 lbf•ft) M10 40 N•m (29 lbf•ft) At assembly, torque cylinder head screws to 6 A32C9EA 4 2 8 12 10 11 9 1 3 5 7 TYPICAL Tighten exhaust manifold bolts in a criss-cross se- Apply Loctite 243 (P/N 293 800 060) on screw 1 A32C19A 1. Longer screw Reed Valve Blades have a curved shape. Install with their Check reed valve for proper tightness. There In case of a play, turn blade upside down and mmr2005-072 107 |
