Snowmobile Ski Doo REV SERIES (2006 year). Instruction - part 1

       2006

Shop Manual

2005

Shop Manual

REV SERIES

BOMBARDIER RECREATIONAL PRODUCTS INC.

2006

INTRODUCTION

MODEL

ENGINE

MODEL NUMBER

EXPEDITION

550F

FJ5A, FJ5B

380F

DG5B

550F

DF5A

500 SS

DC5A, DC5B

600 HO

DB5A, DB5B

600 HO SDI

DD5A, DD5B, DE5A, DE5B

GSX

800 HO DPM Power Tek

DA5A, DA5B

380F

EM5A, EM5B

550F

EL5A, EL5B

500 SS

ED5A, ED5B, ED5C

600 HO

EC5A, EC5B

600 HO SDI

EH5A, EH5B, EJ5A, EJ5B, EJ5C

GTX

800 HO DPM Power Tek

EA5A, EA5B, EA5C

380F

BR5A, BR5B, BR5C

550F

BP5A, BP5B, BP5C

500 SS

BF5A, BF5B, BF5C, BF5G, BF5H, BF5J, BF5L, BH5B,

BH5C, BH5D, BH5A, BH5E

600 HO

BC5A, BC5C, BC5F, BC5G, BC5H, BC5J, BC5K, BC5L,

BC5M, BE5A, BE5B, BE5C, BE5G, BE5H, BE5J, BE5K, BE5L,

BE5M, BE5N, BG5A, BG5B, BV5A, BV5B, BV5C, BV5D

MX Z

600 HO SDI

BK5A, BK5B, BK5C, BK5D, BK5F, BK5G, BK5H, BK5J, BK5K,
BK5L, BK5M, BK5N, BL5A, BL5B, BL5C, BL5G, BL5H, BL5J,

BL5K, BL5L, BL5M, BW5C, BW5F, BW5G, BW5H, BW5J,

BW5K, BW5L, BW5M, BX5C, BX5D, BX5E, BX5F, BX5G

MX Z (Adrenaline)

800 HO

BD5A, BD5B, BD5C, BD5G, BD5H, BD5J,

BD5K, BD5L, BD5M

MX Z

800 HO DPM Power Tek

BB5A, BB5B, BB5C, BB5D, BB5F, BB5G, BB5H,
BB5J, BB5K, BB5L, BB5M, BB5N, BS5C, BS5D,

BS5E, BS5F, BS5G, BS5H, BS5J, BS5K, BS5L, BS5M,

BS5N, BU5A, BU5B, BU5C, BU5D

550F

CM5A, CM5B

SUMMIT

800 HO DPM

CG5A, CG5B, CG5C, CG5D, CH5A, CH5B, CH5C,

CH5D, CJ5A, CJ5B, CJ5C, CK5A, CK5B, CL5A, CL5B,

CL5C, CP5A, CP5B, CP5C, CP5D

mmr2005-059

XIII

INTRODUCTION

VEHICLE IDENTIFICATION
NUMBER

Vehicle Identification Number Location

1

A33H01A

TYPICAL
1. Vehicle identification number

Identification Number Meaning

A00A8HA

2 B P S B X 5 A 9 Y 1 0 0 0 0 0 1

Model number

Serial number

Model year: y = 2000

1 = 2001

2 = 2002

etc.

ENGINE SERIAL NUMBER

Engine Serial Number Location

A03A0BA

1

TYPICAL — 2–STROKE FAN-COOLED ENGINES
1. Engine serial number

1

A32C01B

TYPICAL — 2–STROKE LIQUID-COOLED ENGINES
1. Engine serial number

LIST OF ABBREVIATIONS USED
IN THIS MANUAL

ABBREVIATION

MEANING

A

ampere

amp

ampere

A•h

ampere-hour

AC

alternate current

ACM

acceleration and control

modulator

AMG

absorbed glass mat

BDC

bottom dead center

BTDC

before top dead center

°C

degree Celsius

cc

cubic centimeter

CDI

capacitor discharge ignition

CTR

center

cm

centimeter

cm²

square centimeter

cm³

cubic centimeter

DC

direct current

DESS

digitally encoded security

system

DPM

digital performance

management

XIV

mmr2005-059

INTRODUCTION

ABBREVIATION

MEANING

°F

degree Fahrenheit

FC

fan cooled

fl. oz

fluid ounce

ft

foot

GRD

ground

H.A.C.

high altitude compensator

hal.

halogen

HI

high

IFP

internal floating piston

imp. oz

imperial ounce

in

inch

in²

square inch

in³

cubic inch

k

kilo (thousand)

kg

kilogram

km/h

kilometer per hour

kPa

Kilopascal

L

liter

lb

pound

lbf

pound (force)

lbf/in²

pound per square inch

LH

left hand

LO

low

LT

long track

m

meter

MAG

magneto

Max.

maximum

Min.

minimum

mL

milliliter

mm

millimeter

M.E.

millennium edition

MPEM

multi-purpose electronic

module

MPH

mile per hour

N

newton

ABBREVIATION

MEANING

N.A.

not applicable

no.

number

0

continuity

0.L

open line (open circuit)

O.D.

outside diameter

OPT

optional

oz

ounce

P/N

part number

PSI

pound per square inch

PTO

power take off

R

rectangular

RH

right hand

R.A.S.

response angle suspension

RAVE

Rotax adjustable variable

exhaust

RER

Rotax electronic reverse

RPM

revolution per minute

RMS

root mean square

RRIM

reinforced reaction injection

molding

SDI

semi-direct injection

Sp. Gr.

specific gravity

ST

semi-trapez

TDC

top dead center

TRA

total range adjustable

U.S. oz

ounce (United States)

V

volt

Vac

volt (alternative current)

VSA

variable sheave angle

mmr2005-059

XV
