DRIVE TRACK USAGE CHART

Below is a listing of drive tracks for Arctic Cat snowmobiles. This chart lists each track with its specifications such
as length, pitch, width, rail centers, and bar grip design.

From the information provided in this chart, note what other tracks can be substituted as a replacement track if a
recommended track isn’t available. Pay close attention to all critical specifications when choosing an alternative
track. Do not select a track with a lower rating than the track being replaced.

P/N

Length

Width

Rail Center

# Lugs in

Center Belt

Bar Design

Rating

Lug Height

0602-153

115”

16”

8.84”

Two

Full Block

2

.850”

0602-249

131”

15”

N/A

N/A

N/A

2

0602-754/755

136”

15”

8.84”

Four

Full Block

2

.725”

0602-725

156”

16”

8.84”

Four

Full Block

2

.725”

0602-680

136”

15”

8.84”

Four

Conical Stud

4

1.25”

0602-758

136”

15”

8.84”

Four

Wave

3

.920”

0602-677

121”

15”

8.84”

Four

Full Block

4

.725”

0602-752/753

121”

15”

8.84”

Four

Full Block

2

.725”

0602-756

136”

15”

8.84”

Four

Full Block

4

.725”

0602-759

136”

15”

8.84”

Four

Wave

4

.920”

0602-762

156”

16”

8.84”

Four

Full Block

2

.725”

0602-798

121”

15”

8.84”

Four

Full Block

4

.725”

0602-805

136”

15”

8.84”

Four

Deep Lug

2

1.40”

0602-925

121”

15”

8.84”

Four

Deep Lug

4

1.60”

0602-942

121”

15”

8.84”

Four

Wave

4

1.25”

0602-861

156”

20”

13.50”

Four

Full Block

4

.850”

0602-868

121”

15”

8.84”

Four

Full Block

2

.725”

0602-869

136”

15”

8.64”

Four

Deep Lug

4

1.40”

0602-904

136”

15”

8.84”

Four

Deep Lug

4

1.60”

0602-905

136”

15”

8.84”

Four

Deep Lug

4

2.00”

0602-921/922

121”

15”

8.84”

Four

Full Block

4

.725”

0602-824

121”

15”

8.84”

Four

N/A

4

1.40”

0602-923

121”

15”

8.84”

Four

Full Block

4

.850”

0602-928

121”

15”

8.84”

Four

Full Block

4

.725”

0602-962

156”

20”

13.50”

Four

Full Block

4

1.00”

0602-935

156”

16”

8.84”

Four

Full Block

4

1.00”

1602-004/005

121”

15”

8.84”

Four

Full Block

4

.850”

1602-129

121”

15”

8.84”

Four

Conical Stud

2

1.00”

1602-033

121”

15”

8.84”

Four

Full Block

4

.850”

1602-008

121”

15”

8.84”

Four

Aggressive Wave

4

1.25”

1602-238

128”

13.5”

8.84”

Four

Aggressive Wave

4

1.375”

1602-154

121”

15”

8.84”

Four

Aggressive Wave

4

1.375”

1602-015

68”

11”

8.84”

Four

Wave

2

.690”

1602-093

136”

15”

8.84”

Four

Full Block

2

.850”

1602-120

121”

15”

8.84”

Four

Conical Stud

4

1.00”

1602-089

121”

15”

8.84”

Four

Full Block

3

.850”

1602-124

121”

15”

8.84”

Four

Full Block

4

.850”

1602-141

121”

15”

8.84”

Four

Full Block

3

.850”

1602-137

144”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-080

144”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-130

144”

15”

8.84”

Four

Full Block

4

1.25”

1602-135

156”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-136

151”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-139

151”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-149

121”

15”

8.84”

Four

Wave

4

.850”

1602-160

136”

15”

8.84”

Four

Deep Lug

4

1.375”

1602-161

121”

15”

8.84”

Four

Conical Stud

4

1.25”

1602-176

121”

15”

8.84”

Four

Full Block

4

.850”

9-145

9

DRIVE TRACK USAGE CHART (Cont)

* This track can only be used on AWS V chassis with a Torque Sensing Link Rear Suspension.

P/N

Length

Width

Rail Center

# Lugs in

Center Belt

Bar Design

Rating

Lug Height

1602-188

136”

15”

8.84”

Four

Wave

2

.725”

1609-191

144”

15”

8.84”

Four

Aggressive Wave

4

1.25”

1602-225

151”

15”

8.84”

Four

Aggressive Wave

4

1.25”

1602-226

121”

15”

8.84”

Four

Aggressive Wave

4

1.00”

1602-321

121”

15”

8.84”

Four

Full Block

2

.850”

1602-235

136”

15”

8.84”

Four

Conical Stud

4

1.00”

1602-236

144”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-237

151”

15”

8.84”

Four

Deep Lug

4

2.00”

1602-258

128”

13.5”

8.84”

Four

Full Block

4

1.00”

1602-262

136”

15”

8.84”

Four

Conical Stud

4

2.25”

1602-263

144”

15”

8.84”

Four

Conical Stud

4

2.25”

1602-264

151”

15”

8.84”

Four

Aggressive Wave

4

2.25”

1602-330

128”

13.5”

8.84”

Four

Full Block

4

.725”

6799-800

136”

15”

8.84”

Four

Wave

4

1.50”

6799-841*

121”

15”

8.84”

Four

Deep Lug

4

2.00”

6799-842

136”

15”

8.84”

Four

Deep Lug

4

2.00”

6909-819

136”

15”

8.84”

Four

Wave

4

1.25”

7009-851

121”

15”

8.84”

Four

Aggressive Wave

4

1.25”
