Fig. 2-375 AN190 19. Align the cylinder exhaust ports using a straight edge; then secure each cylinder base with four Fig. 2-376 0729-585 20. Place the cylinder head O-rings into position on each cylinder. NOTE: If reusing O-rings and they are slightly stretched, shrink the O-rings by cooling them (in a 21. Being very careful not to move the two O-ring seals, hold the cylinder head above the cylinder Fig. 2-377 AN188 Be very careful not to move the cylinder heads 22. Apply a thin coat of High-Temp Sealant (p/n 0636-069) to the three water manifold gaskets. Fig. 2-378 AN187 23. Tighten the cylinder head cap screws in three steps using the pattern shown to 2-2.5 kg-m (14.5-18 Fig. 2-379 0729-587 ! CAUTION 2-88 |
