20. Install the oil-injection pump retainer taking care to align the pinion and water pump shafts with their Fig. 2-340 AJ106 21. Place the end plate into position on the crankcase; then apply blue Loctite #242 to the four screws and Fig. 2-341 AJ103 Make sure the slot of the oil-injection pump shaft 22. Apply a thin coat of silicone sealant to both sides of the oil pump gasket. Install the gasket and The shorter screw must be installed in the top Fig. 2-342 AJ107 23. Install the piston rings on each piston so the letter on the top or inclined surface of each ring faces the Fig. 2-343 726-306A Incorrect installation of the piston rings will 24. Apply oil to the connecting-rod small end bearings; then install the small-end bearings and thrust Fig. 2-344 AQ059 25. Place each piston over the connecting rod so the arrow on each piston will point toward the exhaust ! CAUTION ! CAUTION ! CAUTION 2-80 |
