Fig. 2-77 B160 23. Remove the cap screws securing the crankcase halves. Note the position of the different-sized cap Fig. 2-78 A831 24. Separate the crankcase halves by installing two crankcase cap screws in diagonal corners leaving DO NOT drive any tool between the crankcase 25. Remove the rubber bands holding the connecting rods; then separate the crankcase halves. Account Disassembling Engine (440 LC/550 cc Models) 1. Using the spanner wrench to secure the flywheel, remove the flywheel nut, lock washer, and flat Fig. 2-79 AN015 2. Install the Crankshaft Protector Cap (p/n 0644-234) onto the end of the crankshaft. NOTE: A suitable substitute protective cap can be made by welding a 3 mm (1/8 in.) plate on one side 3. Using the Flywheel Puller/Spanner Wrench (p/n 0144-310) or suitable substitute, remove the To prevent damage to the crankshaft, the puller ! CAUTION ! CAUTION 2 2-19 |
