2-36 INSP ADJ 3. Adjust: • Track deflection Adjustment steps: the track off of the ground. b. Loosen the rear axle nut 1. twice. Stop the engine. d. Check the track alignment with the slide runner 2. If the alignment is incorrect, turn the left and 5 Slide runner e. Adjust the track deflection until the specified amount is obtained. CAUTION: The adjusters should be turned an equal f. Recheck the alignment and deflection. If neces- sary, repeat steps (c) to (e) until the specified g. Tighten the rear axle nut. Track alignment È É Shifted to left 3 Left adjuster Turn out Turn in 4 Right adjuster Turn in Turn out Track deflection More than specified Less than specified 3 Left adjuster Turn in Turn out 4 Right adjuster Turn in Turn out T
R . . Rear axle nut: 75 Nm (7.5 m · kg, 54 ft · lb) È É |
