Snowmobile Polaris 600 RUSH (2010 year). Instruction - part 5





1.18

General Information

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

2012 800 RUSH

Model Numbers:

800 RUSH

S12BF8GSA / S12BF8GSL


800 RUSH PRO-R

S12BP8GSA / S12BP8GSB / S12BP8GSC / S12BP8GSL

S12BP8GEL / S12BP8GSM / S12BP8GSP

NOTE:   OPTIONAL - USE 2 GRAM LIGHTER CLUTCH
WEIGHTS WHEN OPERATING IN PROLONGED
WARM TEMPERATURES (LATE FALL/SPRING
SEASON) TO MAINTAIN PEAK OPERATING RPM.

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S4360-8044-OL8G

Displacement / # Cylinders

794cc / 2

Bore (inches/mm)

3.34 / 85

Stroke (inches/mm)

2.75 / 70

Piston to Cylinder
Clearance (inches/mm)

.004-.0055 / 0.103-0.141

Installed Ring Gap

(inches / mm)

.017-.025 / 0.450-0.650

Operating RPM +0-300

8250

Idle RPM ±200

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Orange

Thermostat Opening
Temperature (° F/ ° C)

120 / 49

Fuel Delivery

Type - Number of Fuel
Injectors

DC-CFI - 2

Throttle Body Marking

1204094

Throttle Body Bore

48mm

TPS Voltage @ Idle

(5 VDC +/- .01 Input)

0.94 +/- 0.01 VDC

Fuel Pressure - PSI (bar)

58-60 (4.0-4.1)

Fuel Octane (R+M/2)

10% Ethanol 24

 Resistor


Premium/Non-Ethanol
160

 Resistor

<91 Octane

(Non-Oxygenated)

OR

87/89/91+

(Up to10% Oxygenated)

91+

(Non-Oxygenated)

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-66

BLACK

120-310

7043681

BLU/BLK

123-203

7043064

64/42 - .36

5135401

22:36-70

600-1200

(2000-4000)

10-64

1200-1800

(4000-6000)

10-62

1800-2400

(6000-8000)

10-60

BLK/PUR

160-240

7043363

2400-3000

(8000-10,000)

BLACK

140-330

7043342

20:38-70

3000-3600

(10,000-12,000)

10-58

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

General

Width (in/cm)

48 / 121.9

Length (in/cm)

108 / 274

Height (in/cm)

46 / 117

Estimated Dry Weight (lb/kg)

465 / 211

Fuel (Gallons / Liters)

11 / 41.6

Oil (Quarts / Liters)

3.4 / 3.3

Cooling System
Capacity(Qts/ L)

6 / 5.7

Brake Fluid

DOT 4

Drive Belt

Part Number

Width (inches / cm)

Side Angle

Circumference (inches / cm)

Center Distance (inches / cm)

3211115

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase

Center Distance (inches)

Top Gear (Stock)

Bottom Gear (Stock)

Chain (Stock)

Gear Lube

Capacity (oz / ml)

Reverse System

7.53

22
36
70

Polaris Synthetic (80W)

9 / 266

PERC

1.19

General Information

1

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

NOTE:  * = Rider weight in everyday clothing.

** = From full soft (CCW) position.

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

121 (307)

Pitch

Plies

2.52

2

Lug Height - Inches (cm)

Base

PRO-R

1.0 (2.54) (Hacksaw)

1.25 (3.175) (Ripsaw)

Track tension sag in/mm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft

1/4



- 3/8

(6.3 - 9.6mm)

Electrical

Alternator Output

Operating Voltage

Watts @ 13.5 VDC (Total)

13.5 - 14.5 VDC

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F (49_C)

Spark Plug Gap in.(mm)

.027 (.70)

Spark Plug

NGK GR9A-EG

Front Suspension

Suspension Type

PRO-RIDE (Fixed Camber)

Shocks

Base

PRO-R

Fox HPG w/IFP

Walker Evans Needle Piggyback

16 Click Compression Adjustable

Factory Setting** = 6

IFS Spring Rate

lbs/in (N/mm)

100 (17.5)

Preload - Inches (cm)

Base

PRO-R

3.25 (8.25)
2.875 (7.3)

Travel-Inches (cm)

9 (22.9)

Ski Center Distance

Inches (cm)

Setup Width

42.5 (108)

41.52 (105)

Camber Inches (cm)

NOT ADJUSTABLE

Toe Out Inches (mm)

0 -1/8

 (0 - 3)

Rear Suspension

Suspension Type

PRO-RIDE Progressive

Front Track Shock

(FTS)

Base

PRO-R

Fox HPG w/IFP

Walker Evans w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 2

FTS Spring Rate

lbs/in (N/mm)

120 - 310 (21 - 54.25)

FTS Spring Installed
Length-Inches (cm)

Base Preload

PRO-R Preload

7.5 (19.05)

1.0 (2.54)
1.0 (2.54)

Rear Track Shock

(RTS)

Base

PRO-R

Fox HPG w/IFP

Walker Evans Needle

w/Remote Reservoir

16 Click Compression Adjustable

Factory Setting** = 4

Standard RTS Spring

Rider Weight*

120 - 260lbs.

Rate lbs/in (N/mm)

PN: 7043195-133

170 (29.75)

LW RTS Spring

Rider Weight*

90 - 150lbs.

Rate lbs/in (N/mm)

PN: 7041575-385

120 (21)

HD RTS Spring

Rider Weight*

240 - 335+lbs.

Rate lbs/in. (N/mm)

PN: 7043585-385

260 (45.5)

RTS Spring

Rider / Weight Setting

Spring length set to rider weight

using adjustment gauge.

STD Gauge PN: 9923267

STD gauge supplied with vehicle. LW
and HD springs - Use tape measure
and RTS Spring Guide Table located
in the Steering/Suspension Chapter.

Rear Travel

Inches (cm)

14 (35.6)

1.20

General Information

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

2012 800 RUSH PRO-R LE

Model Numbers:

S12BV8GSM / S12BV8GEM

NOTE:   OPTIONAL - USE 2 GRAM LIGHTER CLUTCH
WEIGHTS WHEN OPERATING IN PROLONGED
WARM TEMPERATURES (LATE FALL/SPRING
SEASON) TO MAINTAIN PEAK OPERATING RPM.

Engine

Engine Type

Liberty Liquid-Cooled /

Case Reed Induction

Model Number

S4360-8044-OL8G

Displacement / # Cylinders

794cc / 2

Bore (inches/mm)

3.34 / 85

Stroke (inches/mm)

2.75 / 70

Piston to Cylinder
Clearance (inches/mm)

.004-.0055 / 0.103-0.141

Installed Ring Gap

(inches / mm)

.017-.025 / 0.450-0.650

Operating RPM +0-300

8250

Idle RPM ±200

1700

Engagement RPM ±200

3800

Exhaust Valve Spring

Orange

Thermostat Opening
Temperature (° F/ ° C)

120 / 49

Fuel Delivery

Type - Number of Fuel
Injectors

DC-CFI - 2

Throttle Body Marking

1204094

Throttle Body Bore

48mm

TPS Voltage @ Idle

(5 VDC +/- .01 Input)

0.94 +/- 0.01 VDC

Fuel Pressure - PSI (bar)

58-60 (4.0-4.1)

Fuel Octane (R+M/2)

10% Ethanol 24

 Resistor


Premium/Non-Ethanol
160

 Resistor

<91 Octane

(Non-Oxygenated)

OR

87/89/91+

(Up to10% Oxygenated)

91+

(Non-Oxygenated)

Clutch Settings

ALTITUDE

meters

(feet)

DRIVE CLUTCH

DRIVEN CLUTCH

Shift

Weight

Clutch
Spring

Clutch
Spring

Driven

Helix

Gearing

0-600

(0-2000)

10-66

BLACK

120-310

7043681

BLU/BLK

123-203

7043064

64/42 - .36

5135401

22:36-70

600-1200

(2000-4000)

10-64

1200-1800

(4000-6000)

10-62

1800-2400

(6000-8000)

10-60

BLK/PUR

160-240

7043363

2400-3000

(8000-10,000)

BLACK

140-330

7043342

20:38-70

3000-3600

(10,000-12,000)

10-58

Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)

Re-torque after running engine.

General

Width (in/cm)

48 / 121.9

Length (in/cm)

108 / 274

Height (in/cm)

46 / 117

Estimated Dry Weight (lb/kg)

465 / 211

Fuel (Gallons / Liters)

11 / 41.6

Oil (Quarts / Liters)

3.4 / 3.3

Cooling System
Capacity(Qts/ L)

6 / 5.7

Brake Fluid

DOT 4

Drive Belt

Part Number

Width (inches / cm)

Side Angle

Circumference (inches / cm)

Center Distance (inches / cm)

3211115

1.460 / 3.7

26_

46.77 / 118.8

11.5 / 29.2

Chaincase

Center Distance (inches)

Top Gear (Stock)

Bottom Gear (Stock)

Chain (Stock)

Gear Lube

Capacity (oz / ml)

Reverse System

7.53

22
36
70

Polaris Synthetic (80W)

9 / 266

PERC

1.21

General Information

1

9923311 - 2010-2012 PRO-RIDE RUSH/Switchback/RMK Service Manual

© 2011 Polaris Sales Inc.

NOTE:  * = Rider weight in everyday clothing.

** = From full soft (CCW) position.

Track

Width - Inches (cm)

15 (38)

Length - Inches (cm)

121 (307)

Pitch

Plies

2.52

2

Lug Height - Inches (cm)

1.352 (3.43) (Cobra)

Track tension sag in/mm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft

1/4

- 3/8(6.3 - 9.6mm)

Electrical

Alternator Output

Operating Voltage

Watts @ 13.5 VDC
(Total)

13.5 - 14.5 VDC

400

Ignition Timing

18_ @1700 RPM

Coolant Temp = 120_F

(49_C)

Spark Plug Gap
in.(mm)

.027 (.70)

Spark Plug

NGK GR9A-EG

Front Suspension

Suspension Type

PRO-RIDE (Fixed Camber)

Shocks

Walker Evans Piggyback

16 Click Compression

Adjustable / 16 Click Rebound

Adjuster

Factory Compression Setting**

= 6

Factory Rebound Setting = 8

IFS Spring Rate

lbs/in (N/mm)

80 (14)

Preload - Inches
(cm)

3.25 (8.25)

Travel-Inches (cm)

9 (22.9)

Ski Center Distance

Inches (cm)

Setup Width

42.5 (108)

41.52 (105)

Camber - Inches
(cm)

NOT ADJUSTABLE

Toe Out - Inches
(mm)

0 -1/8

 (0 - 3)

Rear Suspension

Suspension Type

PRO-RIDE Progressive

Front Track Shock

(FTS)

Walker Evans w/Remote

Reservoir

16 Click Compression

Adjustable

Factory Setting** = 2

FTS Spring Rate

lbs/in (N/mm)

120 - 310 (21 - 54.25)

FTS Spring Installed
Length-Inches (cm)

Preload

7.5 (19.05)

1.0 (2.54)

Rear Track Shock

(RTS)

Walker Evans Needle

w/Remote Reservoir

16 Click Compression

Adjustable

Factory Setting** = 4

Standard RTS
Spring

Rider Weight*

120 - 260lbs.

Rate lbs/in (N/mm)

PN: 7043195-133

170 (29.75)

LW RTS Spring

Rider Weight*

90 - 150lbs.

Rate lbs/in (N/mm)

PN: 7041575-385

120 (21)

HD RTS Spring

Rider Weight*

240 - 335+lbs.

Rate lbs/in. (N/mm)

PN: 7043585-385

260 (45.5)

RTS Spring

Rider / Weight
Setting

Spring length set to rider weight

using adjustment gauge.

STD Gauge PN: 9923267

STD gauge supplied with

vehicle. LW and HD springs - Use

tape measure and RTS Spring

Guide Table located in the

Steering/Suspension Chapter.

Rear Travel

Inches (cm)

14 (35.6)
