Polaris TRACTOR Sportsman 570 6X6 (2018 year). Instruction - part 31





127

MAINTENANCE

PVT System

PVT Drying

There may be some instances when water is accidently ingested into the

PVT system. Dry it out before operating.
1. Position the vehicle on a level surface.
2. Place the transmission in PARK.

3. Remove the drain plug. Allow the water to drain completely.

Reinstall the drain plug.

4. Start the engine.
5. Apply varying throttle

for 10-15 seconds to

expel the moisture and

air-dry the belt and

clutches. Do not hold

the throttle wide open for more than 10 seconds.

6. Allow the engine RPM to settle to idle speed, then shift the

transmission to the lowest available range.

7. Test for belt slippage. If the belt slips, repeat the process.
8. Perform service as soon as possible. Your POLARIS dealer can

assist.

128

MAINTENANCE

Battery

Battery electrolyte is poisonous. It contains sulfuric acid. Serious burns can

result from contact with skin, eyes or clothing.
Antidote:
External: Flush with water.
Internal: Drink large quantities of water or milk. Follow with milk of magnesia,

beaten egg, or vegetable oil. Call physician immediately.
Eyes: Flush with water for 15 minutes and get prompt medical attention.
Batteries produce explosive gases. Keep sparks, flame, cigarettes, etc. away.

Ventilate when charging or using in an enclosed space. Always shield eyes

when working near batteries. KEEP OUT OF REACH OF CHILDREN.

Your vehicle may have either a sealed battery, which requires little

maintenance, or a conventional battery. A sealed battery can be

identified by its flat covers on the top of the battery. A conventional

battery has six filler caps on the top of the battery.
Always keep battery terminals and connections free of corrosion. If

cleaning is necessary, remove corrosion with a stiff wire brush. Wash

with a solution of one tablespoon baking soda and one cup water. Rinse

well with tap water and dry off with clean shop towels. Coat the

terminals with dielectric grease or petroleum jelly. Be careful not to

allow cleaning solution or tap water into a conventional battery.
An optional extreme use battery may be available for your model. If the

performance of the factory-installed battery is inadequate due to

operation in extreme cold or due to extended use of multiple electrical

accessories, please see your POLARIS dealer. Ask your dealer to

provide any installation procedures that may differ for an extreme use

battery.

129

MAINTENANCE

Battery

Improperly connecting or disconnecting battery cables can result in an explosion

and cause serious injury or death. When removing the battery, always

disconnect the negative (black) cable first. When reinstalling the battery, always

connect the negative (black) cable last.

Battery Removal

1. Place the transmission in PARK. Disconnect the battery hold-down

strap. Remove the battery cover (if equipped).

2. On conventional batteries, remove the battery vent tube.
3. Disconnect the black (negative) battery cable first. Disconnect the

red (positive) battery cable last.

4. Lift the battery out of the vehicle. Be careful not to tip a

conventional battery sideways, which could spill electrolyte. If

electrolyte spills, immediately wash it off with a solution of one

tablespoon baking soda and one cup water to prevent damage to the

vehicle.

Battery Installation

1. Ensure that the battery is fully charged. Place the battery in the

battery holder.

2. With conventional batteries, install the battery vent tube. The vent

tube must be free of obstructions and securely installed. Route the

tube away from the frame and vehicle body to prevent contact with

electrolyte.

Battery gases could accumulate in an improperly installed vent tube and cause

an explosion, resulting in serious injury or death. Always ensure that the vent

tube is free of obstructions and is securely installed as recommended.

130

MAINTENANCE

Battery

Battery Installation

3. On conventional batteries, coat the terminals with dielectric grease

or petroleum jelly.

4. Connect and tighten the red (positive) cable first. Connect and

tighten the black (negative) cable last.

5. Install the battery cover (if equipped). Secure the battery hold-down

strap.

6. Verify that cables are properly routed. Cables should be safely

tucked away at the front and rear of the battery.

Battery Storage

Whenever the vehicle is not used for a period of three months or more,

remove the battery from the vehicle, ensure that it's fully charged, and

store it out of the sun in a cool, dry place. Check battery voltage each

month during storage and recharge as needed to maintain a full charge.
POLARIS recommends maintaining battery charge by using a

POLARIS Battery Tender charger or by charging about once a month to

make up for normal self-discharge. Battery Tender can be left connected

during the storage period, and will automatically charge the battery if

the voltage drops below a pre-determined point. See page 139



for the

part numbers of POLARIS products.
