Polaris TRACTOR Sportsman 570 6X6 (2018 year). Instruction - part 16





67

OPERATION

Hauling Cargo

1. Always read and understand the load distribution warning labels on

the vehicle. Never exceed the weight capacities specified for the

vehicle.

2. Always load the cargo box with the load as far forward as possible.
3. Always operate the vehicle with extreme caution whenever hauling

or towing loads. Balance, handling and control may be affected.

4. NEVER exceed 16 km/h when rear cargo loads are above 91 kg.
5. Make sure the cargo box dump latch is securely latched before

loading and operating. Unintentional dumping will result if weight

is placed in the rear of the box and the latch is not secured.

6. Always attach a towed load to the hitch point.

Load cargo as far forward

as possible

68

OPERATION

Hauling Cargo

Towing Loads

Towing is approved OFF-ROAD ONLY. Operating a Tractor/trailer

combination on public roads is prohibited. See your POLARIS dealer

about configuring the vehicle to be certified to tow a trailer on-road. Do

not tow any trailer on a grade steeper than 15°.
• Use the front hitch for vehicle recovery or towing only. Always

remove the front hitch before operating in forward gear.

• The combination of rear rack cargo weight and tongue weight must

not exceed the rear rack capacity.

• The total load (operator, passenger, accessories, cargo and weight on

hitch) must not exceed the maximum weight capacity of the vehicle.

Using an improper hitch or exceeding the maximum

tongue weight capacity can result in serious damage

to the vehicle and will void your warranty. Never

install a hitch longer than 10 cm. Never install

automotive accessories on your POLARIS Tractor.

Always install POLARIS-approved (or equivalent)

accessories designed for Tractor use.

Capacities

Rear Hitch

Front Hitch

Maximum Towed Load (Level Ground)

750 kg

386 kg

Maximum Vertical Hitch Weight

75 kg

39 kg

Maximum

10 cm

69

OPERATION

Hauling Cargo

Dumping Cargo

If cargo weight is placed toward the rear of the cargo box, the load may dump

unexpectedly and cause serious injury. When loading cargo, always position the

weight as far forward and as low as possible.

1. Select a level site to dump the cargo box. Do not attempt to dump or

unload the vehicle while parked on an incline.

2. Place the transmission in

PARK.

3. Lock the parking brake.
4. Dismount the vehicle.
5. Check cargo distribution. If

cargo has shifted to the rear

of the box, exercise

caution.

6. Lower the tailgate.
7. Pull one of the cargo box

release levers forward.

8. Firmly grasp a cargo box

handle and slowly lift the

front of the cargo box to

dump the cargo.

To prevent a crushing injury to hands and fingers, keep hands and fingers away

from the lower front edge of the cargo box while lowering the box.

9. Lower the cargo box and make sure the release latch is secured.
10. Secure the tailgate.

Driving with the cargo box in the raised position can cause serious injury and

damage to the vehicle. The cargo box could close unexpectedly and injure the

driver. The rear tires will also catch the rear of the bed, damaging the vehicle

and creating hazardous driving conditions. Never drive this vehicle with the

cargo box in the raised position. Never leave this vehicle parked or unattended

with the cargo box in the raised position.

Box Release

Levers

70

OPERATION

Towing the Tractor

If towing the Tractor is necessary, shift the transmission into neutral for

better mobility and to prevent damage to the belt. Always attach the tow

cable to the front tow loop of the disabled Tractor. A rider must be on

board to steer the disabled Tractor while towing.
