Polaris TRACTOR Sportsman 570 6X6 (2018 year). Instruction - part 14





59

OPERATION

Driving Downhill

When driving downhill, follow these precautions:
1. Always move the AWD switch to ADC AWD before ascending or

descending a hill. See page 33.

2. Avoid steep hills. Maximum incline is 15°.
3. Avoid hills with slippery or loose surfaces.
4. Never drive downhill at high speed. Slow down.
5. Drive straight downhill. Avoid driving downhill at an angle, which

can cause the vehicle to pitch sharply to one side.

6. Shift body weight uphill. A passenger should also shift body weight

uphill.

7. Apply the brakes slightly to aid in slowing.

Always follow the procedures outlined in this manual for driving downhill and for

braking on hills.

15° Maximum

60

OPERATION

Turning Around on a Hill (K-Turn)

If the vehicle stalls while climbing a hill, never back it down the hill!

Use the K-turn to turn around.

1. Always move the AWD switch to ADC AWD before ascending or

descending a hill. See page 33.

2. Stop the vehicle. Keep body weight uphill.
3. Lock the hydraulic parking brake.
4. Leave the transmission in forward gear. Turn the engine off.
5. If a passenger is on board, ask the passenger to dismount first, then

the operator may dismount. Dismount on the uphill side of the

vehicle, or on the left if the vehicle is pointing straight uphill.

passenger should not remount until the vehicle returns to firm, level

ground.

6. Staying uphill of the vehicle, and turn the handlebars full left.
7. Squeeze the brake lever to release the parking brake.
8. Slowly release the brake lever and allow the vehicle to roll around

to your right until it's pointing across the hill or slightly downward.

2.4 m

61

OPERATION

Turning Around on a Hill (K-Turn)

9. Lock the hydraulic parking brake.
10. Remount from the uphill side. Keep your weight uphill. A passenger

should not remount until the vehicle returns to firm, level ground.

11. Apply the foot brake.
12. With the transmission still in forward, start the engine.
13. Squeeze and release the brake lever to release the parking brake.
14. Release the foot brake and drive slowly downhill. Control speed

with either the hand or foot brake until the vehicle is on level

ground.

Always follow the procedures outlined in this manual for braking if you stall or

roll backwards while climbing a hill. Never back down a hill.

62

OPERATION

Driving Through Water

Follow these procedures

when driving through

water:
1. Check water depth and

current before crossing.

2. Choose a crossing

where both banks have

gradual inclines.

3. Drive slowly. Avoid

rocks and obstacles.

4. Avoid operating in

water deeper than the

bottom of the footrests.

If it's unavoidable,

travel slowly, balance your weight carefully and avoid sudden

movements. Maintain a slow and steady forward motion. Do not

make sudden turns, stops or throttle changes.

5. Wet brakes may have reduced stopping ability. Dry the brake pads

by driving slowly and applying the brakes lightly several times until

braking action is normal.

6. If your vehicle becomes fully immersed, service is required before

starting the engine. Your POLARIS dealer can provide this service.

If it’s impossible to bring the vehicle in before starting the engine,

follow the steps described on page 122, and take the vehicle in for

service at the first opportunity.

Always follow the procedures outlined in this manual for driving through water.

Never drive through deep or fast-flowing water.

If the vehicle stops while fully submerged, major engine damage can result if the

machine is not thoroughly inspected. Have the vehicle serviced before starting

the engine.

Maximum

Depth
