Polaris TRACTOR Sportsman 570 6X6 (2018 year). Instruction - part 5





23

FEATURES AND CONTROLS

Mirrors

Use the mirrors to assist in traffic maneuvers. Always check and adjust

the mirrors before driving the Tractor.

Throttle Lever

Failure to check or maintain proper operation of the throttle system can result in

an accident if the throttle lever sticks during operation. Check the lever for

proper operation before starting the engine. Check occasionally during

operation.
Do not start or operate a Tractor with sticking or improperly operating throttle

controls. Contact your dealer for repair if throttle problems arise.

Press the throttle lever to increase

engine speed and vehicle movement.
Release the lever to reduce engine

speed and vehicle movement.

24

FEATURES AND CONTROLS

Brakes

Aggressively applying the brakes when backing down a hill may cause rear

tipover. Aggressively applying the brakes while moving forward may cause the

rear wheels to skid and result in loss of control. Read this owner's manual and

understand the operation of all brake systems on this vehicle. Always use

caution whenever applying the brakes.

Foot Brake

The all-wheel foot brake is located on the

right footrest. The foot brake operates both

front and rear brakes. Press the brake pedal

down with your foot to apply the all-wheel

brakes. If the rear wheels begin to skid or

slide while using the foot brake, reduce

brake pressure.

Hand Brake Lever

The hand brake operates both front and rear

brakes. Squeeze the brake lever toward the

handlebar to apply the all-wheel brakes. If

the rear wheels begin to skid or slide while

using the brake, reduce lever pressure.

Parking Brake

1. Place the transmission in PARK.
2. Squeeze the brake lever toward the

handlebar. Push the parking brake lock

forward to engage the lock. Release the

brake lever.

3. To release the parking brake lock,

squeeze and release the brake lever.

Operating the vehicle while the parking brake is engaged could result in an

accident and serious injury or death. Always release the parking brake lock

before operating.

Foot Brake

25

FEATURES AND CONTROLS

Electronic Power Steering (EPS)

Electronic power steering (EPS), if equipped, engages when the ignition

key is turned to the ON position. EPS remains engaged whether the

vehicle is moving or idle. See page 35 for EPS Warning Indicator

information.

Fuel Tank Cap

This vehicle is equipped with a

digital fuel gauge that will

indicate a low fuel condition.

Refuel when the gauge indicates a

low fuel condition.
Always refuel with the engine

stopped, and outdoors or in a well

ventilated area. Refuel on a level

surface.
Remove the fuel tank cap to add

fuel to the fuel tank. Use either

leaded or unleaded gasoline with a

minimum pump octane number of

87 = (R + M/2) octane. Do not use

fuel with ethanol content greater

than 10 percent, such as E-85 fuel.

Fuel Tank Cap

26

FEATURES AND CONTROLS

Seat

Seat Removal

1. Grasp one side of the seat

near the rear edge.

2. Pull upward abruptly to

disengage the under-seat

fasteners.

3. Remove the seat.

Backrest Adjustment

Loosen the backrest knobs (if

equipped) on each side of the

backrest mount and slide the

backrest forward or rearward to

the desired position. Tighten the

knobs securely.

Seat Height Adjustment

To raise or lower the seat, install

or remove the seat height

adjustment bracket. Make sure

the seat is securely installed

before operating.

Backrest Knob

Height

Adjustment

Bracket
