19

SAFETY

Safety Labels and Locations

General Alert (Multi-Lingual) (7181540)
Before you operate this vehicle, read the owner’s manual. Never allow anyone

under 16 years of age to operate this vehicle. Wear approved helmet, goggles,

and protective clothing. Never use alcohol or drugs before or while operating.

Never carry more than one passenger on this vehicle. This vehicle is approved

for on-road use.
Override Alert (7181544)
Read Owner’s Manual. Improper use of override button can lead to loss of

control resulting in severe injury or death. Do not activate override while throttle

is engaged. Always apply throttle gradually while in reverse.
AWD Alert (7181543)
Read Owner’s Manual. Do not push switch to engage AWD if the rear wheels

are spinning. This may cause severe drive shaft and clutch damage.
Hill Operation Alert (7181436)
Read Owner’s Manual. Never operate this vehicle on HILLS steeper than 15

degrees

15

°

Front Hitch Alert (7181428)
Read Owner’s Manual. Use the front hitch for vehicle recovery or towing only.

Always remove the front hitch before operating in forward gear.

SPEEDO
REVERSE
OVERRIDE

7181544

7181428

7181543

15°

7181536

General Alert

Hill Operation

Alert

Override

Alert

AWD Alert

Front Hitch Alert

<

16

<

16

7181540

20

FEATURES AND CONTROLS

Switches

Momentary High Beam Switch
Press this switch with your left

forefinger to activate the headlight high

beam. The lights will return to low

beam when the switch is released.

Winch Switch (if equipped)
See page 72 for winch information.

Mode/Reverse Override Switch
Press the switch to toggle through the speedometer display modes

(except in reverse). See page 34. To gain additional power while

operating in reverse, press the override switch before opening the

throttle. This will cancel the reverse speed limit function.
The reverse override switch also acts as a MODE switch when held

down for approximately one half second. See the instrument cluster

information beginning on page 34.

Tip: The override switch will not function as a MODE switch if the transmission

is in reverse.

Activating the override switch while the throttle is open can cause loss of control.

Do not activate the override switch while the throttle is open.

Mode/Reverse

Override Switch

Main Key

Switch

AWD Switch

Winch

Switch

(if equipped)

Light Switch

(High/Low Beam)

Work Light Switch

Winch Switch

Momentary High

Beam Switch

21

FEATURES AND CONTROLS

Switches

Main Key Switch
STOP: End all electrical power to the

vehicle.
LIGHTS ON: Turn the headlights on.

The engine stop switch must be in

the RUN position.
PARKING LIGHTS ON: After

starting the engine, release the key

switch to this position. The parking

lights and taillights are on in this position.
START: Start the engine. The headlights are not on in this position. See

page 50 for starting procedures.

Do not attach a large key fob or key ring to the main switch. It may contact the

gas tank cap when turning, causing an interruption to the electrical system and

an unexpected engine shut-down during operation. This could result in serious

injury or death.

Engine Stop Switch
The engine will not start or run when the

switch is in the OFF position.

OFF (STOP)

RUN

Light Switch (High/Low Beam)
Use the light switch to change the

headlights from high beam to low beam.

High Beam

Low Beam

STOP

PARKING

LIGHTS ON

LIGHTS ON

START

Override

Switch

Engine

Stop

Switch

Light

Switch

Horn

Switch

Hazard

Switch

Turn

Signal

Switch

22

FEATURES AND CONTROLS

Switches

Work Light Switch
The work light switch controls a light located in the pod. Use the light

when additional light is needed at the front of the vehicle, but turn the

work light off when driving the vehicle (on-road).

Turn Signal Switch

Push the toggle switch either left or right to activate the

corresponding turn signal light. The indicator in the gauge will also

flash. Return the toggle to the center position and push it inward to end

the signal.

Hazard Warning Switch

Push the hazard warning switch

to cause all turn signal lights to

flash simultaneously. Use this

feature to alert others of an

emergency or other situation

requiring caution.

Horn Switch

Press the horn switch to sound

the horn.

AWD Switch
Use the AWD switch to

engage ADC AWD, AWD or

4X6. See page 31. The vehicle

automatically engages AWD

when operating in reverse if

the AWD switch is set to

either AWD position.

Horn

Switch

Hazard

Switch

Turn

Signal

Switch

AWD

Switch
