Polaris Sportsman 570 (2018 year). Instruction - part 36





CAMBER AND CASTER

The camber and caster are non-adjustable.

FRONT SPRING

The front shock absorber spring is non-adjustable.

REAR SPRING

The rear shock absorber spring is adjusted by rotating the cam either clockwise
or counter-clockwise to increase or decrease spring tension.

q

Cam

w

High Tension

e

Low Tension

146

MAINTENANCE

HANDLEBARS

The handlebars can be adjusted for rider preference.

WARNING

Improper adjustment of the handlebars or incorrect torquing of the adjuster

block tightening bolts can cause limited steering or loosening of the

handlebars, resulting in loss of control and serious injury or death. Follow the

adjustment procedures exactly, or see your authorized dealer for service.

1. Remove the upper headlight pod (if equipped).

2. Loosen the four handlebar bolts.

3. Adjust the handlebar to the desired height. Be sure the handlebars do not

contact the gas tank or any other part of the machine when turned fully to the
left or right.

4. Torque the front two bolts to 14-17 Nm, then torque the rear two bolts. A gap

of up to 3 mm will remain at the rear of the clamp blocks.

147

MAINTENANCE

CLEANING AND STORAGE

WASHING THE VEHICLE

Keeping your POLARIS vehicle clean will not only improve its appearance but it
can also extend the life of various components.

NOTICE

High water pressure may damage components. POLARIS recommends

washing the vehicle by hand or with a garden hose, using mild soap.

Certain products, including insect repellents and chemicals, will damage

plastic surfaces. Do not allow these types of products to contact the vehicle.

The best and safest way to clean your POLARIS vehicle is with a garden hose
and a pail of mild soap and water.

1. Use a professional-type washing cloth, cleaning the upper body first and the

lower parts last.

2. Rinse with clean water frequently.

3. Dry surfaces with a chamois to prevent water spots.

WASHING TIPS

• Avoid the use of harsh cleaners, which can scratch the finish.
• Do not use a power washer to clean the vehicle.
• Do not use medium to heavy duty compounds on the finish.
• Always use clean cloths and pads for cleaning and polishing. Old or reused

cloths and pads may contain dirt particles that will scratch the finish.

If a high pressure water system is used for cleaning (not recommended),
exercise extreme caution. The water may damage components and could
remove paint and decals. Avoid directing the water stream at the following items:

• Wheel bearings
• Radiator
• Transmission seals
• Cab and body panels
• Electrical components
• Switches and controls
• Fuel system components
• Labels and decals

If an informational or graphic label becomes illegible or comes off, contact your
POLARIS dealer to purchase a replacement. Replacement safety labels are
provided by POLARIS at no charge.

Grease all zerk fittings immediately after washing. Allow the engine to run for a
while to evaporate any water that may have entered the engine or exhaust
system.

148

MAINTENANCE

POLISHING THE VEHICLE

POLARIS recommends the use of common household aerosol furniture polish
for polishing the finish on your POLARIS vehicle. Follow the instructions on the
container.

POLISHING TIPS

• Avoid the use of automotive products, some of which can scratch the finish of

your vehicle.

• Always use clean cloths and pads for cleaning and polishing. Old or reused

cloths and pads may contain dirt particles that will scratch the finish.

CHROME WHEEL CARE (IF EQUIPPED)

Proper maintenance will protect chrome wheels from corrosion, preserve wheel
life and ensure a "like new" appearance for many years. Chrome wheels
exposed to road salt (or salt in the air in coastal areas) are more susceptible to
corrosion if not properly cleaned. Clean chrome wheels more often if they're
exposed to salt or other corrosive elements.

1. Wash chrome wheels frequently. Use a mild detergent. Never use abrasive

cleaners on plated or painted surfaces.

2. Rinse well with clear water. Soap, detergents, salt, dirt, mud, and other

elements can cause corrosion.

3. Polish the clean chrome wheels periodically. Use an automotive grade

chrome polish.

4. Routinely and liberally apply a weather resistant wax to each polished

chrome wheel. Choose a product suitable for chrome finishes. Read and
follow the product labels and instructions.

REMOVING CORROSION

If light rust is found on the chrome finish, use steel wool (#0000-OTT grade) to
remove it. Gently rub the affected areas with the steel wool until the corrosion
has been removed. Clean and polish the wheel as outlined above.

STORAGE TIPS

NOTICE

Starting the engine during the storage period will disturb the protective film

created by fogging and damage could occur. Never start the engine during the

storage period.

149

MAINTENANCE
