Snowmobile Polaris Rush (2010 year). Instruction - part 16





65

OPERATION

n

Oil

Low Oil Level

Always maintain the oil level between

the “add” mark and the bottle neck.

Do not fill the bottle neck. See page

61 for oil recommendations.
1. Immediately stop the engine if the

low oil indicator light comes on.

2. Open



the left side panel.

3. View the oil level in the oil bottle.
4. Add oil as needed before operating.

NOTICE: Operating the snowmobile without adequate engine lubrication can

result in serious engine damage. Always check the oil level when refu-

eling. Add oil as needed.

The oil bottle cap is vented to allow proper oil flow. See your Polaris

dealer for recommended replacement parts.

“Add”

Mark

66

OPERATION

n

Engine Stop Switch

Push down on the engine

stop switch (+) to

ground out the ignition

and stop the engine

quickly. Pull the switch

up to the ON position to

allow restarting.

n

Throttle Safety Switch

The throttle safety switch is designed to stop the engine whenever all

pressure is removed from the throttle lever and the throttle cable or

valves do not return to the normal closed position.

WARNING! Operating the snowmobile with a faulty throttle safety switch can

result in serious injury or death in the event of an accident. If the throttle safety

switch does not shut off the engine during a carburetor/throttle system

malfunction, immediately push down the engine stop switch. Do not start the

engine again until the malfunction has been corrected by your dealer.

Test the throttle safety switch

system daily before operation.
1. Sit on the seat.
2. Start the engine and allow it

to idle.

3. Hold the throttle lever pin

stationary by exerting pres-

sure on the pivot pin in the direction shown in the illustration.

4. Apply a slight amount of throttle. A properly functioning switch

must shut down the engine.

+

67

OPERATION

Throttle Lever

WARNING! An improperly functioning throttle lever may cause erratic

snowmobile behavior and loss of control, which could result in serious injury or

death. If the throttle lever does not work properly, DO NOT start the engine.

If the engine stops abruptly when the throttle lever is released:
1. Turn the ignition switch to OFF.
2. Visually inspect the throttle cable and carburetor/throttle body to

determine what caused the safety switch to activate.

3. Test the throttle lever by compressing and releasing it several times.

The lever and cable must return to the idle position quickly and

completely.

4. If the throttle lever operates properly, turn the ignition switch on and

go through normal starting procedures.

5. If the engine doesn't start, take the snowmobile to an authorized

Polaris dealer for service.

Excessive freeplay in the throttle cable may cause the safety switch to

activate, preventing the engine from starting. If this occurs, return the

snowmobile to an authorized Polaris dealer for service.
If an emergency exists and it's necessary to start the engine, the throttle

safety switch and engine stop switch may be disconnected from the wire

harness. When these switches are disconnected, the ignition key switch

must be used to shut off the engine. DO NOT continue to operate the

snowmobile with the throttle safety switch disconnected. Return the

snowmobile to an authorized Polaris dealer for service as soon as possi-

ble.

68

OPERATION

Emergency Stopping

The following chart lists methods for stopping the snowmobile in the

event of an emergency. See page 66 for more information about the

engine stop switch and throttle safety switch.

SYSTEM

WHAT IT DOES

Ignition Switch

Interrupts ignition circuit

Brake

Slows jackshaft

Engine Stop Switch

Interrupts ignition circuit

Throttle Safety Switch

Interrupts ignition circuit

Tether Switch (Option)

Interrupts ignition circuit
