Snowmobile Polaris Rush (2010 year). Instruction - part 15





61

OPERATION

Engine Break-In

Oil Injection System

Always check and fill the oil bottle when refueling. See page 65.

NOTICE: Serious engine damage can occur without the proper lubrication.

Check the oil bottle level often during the first tank of fuel. If the oil

level doesn't go down, contact your dealer immediately.

Oil Recommendations

This snowmobile is equipped with a variable exhaust system (VES).

Engine lubrication comes from oil added to the fuel and oil injection

systems.
Polaris recommends using Polaris Semi-Synthetic Oil for premixing the

first tank of fuel at 40:1 (one pint of oil per 5 gallons of fuel) and for the

first fill of the oil tank. After this initial treatment, Polaris recommends

the use of VES Gold Plus Synthetic 2-cycle oil. See page 110 for the

part numbers of Polaris products.
Never mix brands of oil. Serious chemical reactions can cause injection

system blockage, resulting in serious engine damage. Oils may also be

incompatible and the result could be sludge formation, filter blockage,

and reduced cold weather flow rates. All Polaris oils are compatible

with each other.

62

OPERATION

Track Warm-Up

WARNING! A loose track or flying debris could cause serious injury or death.

Stand clear of the front of the snowmobile and the moving track. Never hold the

snowmobile up or stand behind it while warming up the track. Do not use

excessive throttle during warm-up or when the track is free-hanging. Use a

stable rear support.
WARNING! Use of traction products such as studs, ice growsers, etc. will

increase the possibility of track damage and/or failure. This could cause loss of

control, resulting in serious injury or death. Always inspect for track damage

before operating the snowmobile.

Follow these steps to ensure proper warm-up of the engine, drive train

and track.
1. Use an appropriate stand to securely support the rear of the snow-

mobile at the rear bumper. The track should be about 4I (10 cm) off

the ground.

2. Start the engine and allow it to warm up two to three minutes.
3. Depress the throttle abruptly and allow the track to rotate several

revolutions.

TIP: It will take longer to warm up the track sufficiently during colder outdoor

temperatures.

4. Release the throttle, apply the brakes, shut off the engine and lower

the snowmobile to the ground.

5. Grasp the skis by their front loops and move them from side to side

to loosen snow and ice.

Slide Rail and Track Cooling

NOTICE: Inadequate cooling and lubrication will lead to overheating of the slide

rail and track, resulting in premature wear and failure. Reduce speeds

and frequently drive into fresh snow to allow adequate cooling and

polishing of the slide rail and track surfaces. Avoid operating on ice,

hard-packed surfaces or roads.

63

OPERATION

Fuel

Gasoline is highly flammable and explosive under certain conditions.
• Always exercise extreme caution whenever handling gasoline.
• Always refuel outdoors or in a well-ventilated area.
• Always turn off the engine before refueling.
• Do not overfill the tank. Do not fill the tank neck.
• Do not smoke or allow open flames or sparks in or near the area where refu-

eling is performed or where gasoline is stored.

• If gasoline spills on your skin or clothing, immediately wash it off with soap

and water and change clothing.

• Never start the engine or let it run in an enclosed area. Engine exhaust fumes

are poisonous and can cause loss of consciousness or death in a short time.

The engine exhaust from this product contains chemicals known to cause can-

cer, birth defects or other reproductive harm. Operate this vehicle only outdoors

or in well-ventilated areas.

Fuel Recommendation

For peak performance, Polaris recommends the use of 91 octane fuel or

higher. Although 87 octane fuel is usable, some engine performance will

be lost and fuel economy will decrease. Do not use lower than 87 octane

fuel. Do not use fuel containing more than 10% ethanol. Never use E85

fuel in your snowmobile.

NOTICE: Operating with obstructed fuel systems will result in serious engine

damage. Perform maintenance as recommended.
Prolonged exposure to petroleum based products may damage paint.

Always protect painted surfaces when handling fuel.

WARNING

WARNING

64

OPERATION

Fuel Resistor

This snowmobile is equipped with a

feature that allows the engine control-

ler to select the proper operating soft-

ware based on the type of fuel being

used. The proper fuel resistor must be

installed to match the type of fuel you

are using.
The snowmobile comes from the fac-

tory with the resistor installed that

should be used when operating with

fuel containing up to 10% ethanol.

The resistor is labeled “10% ETHA-

NOL 24 OHM” (see illustration).
The resistor is installed into the wir-

ing harness on the left side of the

snowmobile just above the top of the

oil bottle (see photo).
If the snowmobile is operated with

non-ethanol fuel be sure to install the

resistor labeled “NON-ETHANOL

160 OHM”. This resistor is provided

in the tool kit.

NOTICE: Engine damage may occur if ethanol fuel is used while the non-etha-

nol fuel resistor is installed. The check engine light may also display in

this condition as this could cause detonation.

If you’re unsure of the type of fuel in the fuel tank, make sure the

“10% ETHANOL 24 OHM” resistor is installed. This is the preferred

default and will provide the most engine protection.

Fuel System Deicers

If you use non-ethanol fuel (sometimes labeled “non-oxygenated”),

Polaris recommends the regular use of isopropyl-based fuel system

deicer. Add one to two ounces per gallon (8-16 ml per liter) of gasoline

to prevent damage resulting from fuel system icing. Never use deicers

or additives containing methanol. Polaris recommends the use of Car-

bon Clean Plus. See page 110 for the part numbers of Polaris products.
If you use fuel with up to 10% ethanol (sometimes labeled “oxygen-

ated”) do not add deicers or additives that contain any form of alcohol.

10

%

   ETHANOL

24  OHM

NON-ETHANOL

160  OHM

Resistor
