GENERAL INFORMATION
1.22
Tool List
Tool Part Number
Description
2870338
Drive Clutch Spider Nut Socket
2870426
P--85 CLutch Offset Alignment Tool 5/8”
8700220
Clutch Compression Tool
PS--45909
TEAM Clutch Compression Tool Extensions (To be used with Clutch Com-
pression tool)
2870576
Drive Clutch Bore Tapered Reamer
2870910
Roller Pin Tool
2870974
Jackshaft Installer
2871173
Primary Clutch Compressor
2871296
Jackshaft Installer
2872085
Clutch Puller (3/4--16 x 14mm)
2872401
20mm C--Clip Tool
2872987
Spider Remover/Installer
PS--45259
Gas Fill Tool & Gauge
PS--45259--1
Gas Fill Needles (20 Pack)
PS--45260
Lower Retainer Wrench
PS--45261
IFP Positioning/Extraction Tool
PS--45262
Cylinder Head Wrench
PS--45263
Wear Band Tool
PS--45152
THIN Rear Suspension Wrench
PS--45909
High Performance Driven Clutch Compression Tool
PS--45908
T--Handle Walker Evans IFP Tool
PS--45629
Body Clamps for Walker Evans 1 3/4”
2871358
Clutch Holding Fixture
9314177--A
Clutch Holding Wrench
PS--45484
Rivet Punch (To remove self--piercing rivets)
PS--45678
Shock Shaft Seal Protector (.51 diameter shock shaft)
2201639
Shock Shaft Seal Protector (.498 diameter shock shaft)
2201640
Shock Shaft Seal Protector (.620 diameter shock shaft)
PU--45485
Exhaust Spring Removal Tool
2874522
Walker Evans Racing Shock Oil (5w)
