Snowmobile Polaris 600 RMK, 600 SwitchBack (2006 year). Instruction - part 18





73

MAINTENANCE

Periodic Maintenance Interval Table

See

Frequency

Item

Page

150 mi.

(240 km)

500 mi.

(800 km)

1000 mi.

(1600 km)

2000 mi.

(3200 km)

Pre-

Season

CHASSIS

Ski Toe Alignment

-

I

I

I

Suspension

Mounting Bolts

-

I

I

I

I

I

Steering Fasteners

-

I

I

I

I

C

Rear Suspension

Fasteners

-

I

I

I

I

I

Suspension Shock Oil

-

I

I

I

I

Cooling Fins and Shroud

-

I

I

I

I

Drive Shaft Bearings

107

L

L

L

I

Jackshaft Bearings

106

L

L

L

I

Skags (Wear Bars)

-

I

I

I

I

I

Ski Saddle/Spindle Bolts

-

I

I

I

I

I

Drive Chain Tension

87

I

I

I

I

I

Hood Straps

52

I

I

I

I

I

Rear Wheel Idler Bolts

99

I

I

I

I

I

Idler Bolt Jam Nut

99

I

I

I

I

I

Rear Suspension Pivot

Shafts

74

L

L

L

Camber Alignment

-

I

I

I

Handlebar Centering

-

I

Tether Switch and Strap

56

I

I

I

I

I

Track Alignment

100

I

I

I

I

I

Track Tension

98

I

I

I

I

I

Front Limiter Strap

-

I

I

I

I

I

Rail Slide Condition

104

I

Chaincase Oil

76

I

I

I

R

I

- Inspect (clean, adjust, tighten, lubricate, replace if necessary)

- Clean

- Replace

- Lubricate

74

MAINTENANCE

Lubrication

Front Suspension

The front suspension and steering components do not require

lubrication.

Rear Suspension

Lubricate the suspension pivot shafts with Polaris Premium All Season

Grease at 500 miles (800 km) initially, every 1000 miles (1600 km)

after that, and before off-season storage each year. Lack of lubrication

will adversely affect your ride and the life of the suspension. For more

information about suspension lubrication and adjustments, see your

Polaris dealer.

L

L

L

L

L

+

+

75

MAINTENANCE

Lubrication

Driveshaft Bearing

Inject grease into the fitting on the

speedometer sensor housing until grease

purges from the seal on the inside of the

tunnel. This should take approximately two

pumps. Do not use more than four pumps.

Throttle Cable

Lubricate the throttle cable lightly with

grease or oil. With the engine off, turn

the handlebars to the left and lubricate

liberally as shown.

Choke and Cable

Lubricate the choke slide and cables

lightly with oil or grease. Before

turning the engine off, operate the choke

intermittently to draw moisture out of

the choke plunger area and reduce the

possibility of the choke becoming

frozen.

+

1

2

3

76

MAINTENANCE

Lubrication
n

Chaincase Oil

Check the chaincase oil level at the

intervals outlined in the

maintenance charts beginning on

page 71. The sight glass (1) is

located on the lower rear of the

chaincase. Maintain the oil level at

or slightly below the center of the

sight glass (2). Change the

chaincase oil after the first 500

miles (800 km), then every 1000

miles (1600 km) or seasonally.
Polaris recommends the use of

Polaris Synthetic Chaincase Lube.

See page 108 for the part numbers of

Polaris products.

Oil Check
1. Position the machine on a level surface.
2. View the oil level at the sight glass.
3. Remove the fill plug (3) and add the recommended oil as needed.

Do not overfill.

4. Reinstall the fill plug, making sure it is seated properly.
