Snowmobile Polaris 600 IQ Widetrak (2017 year). Instruction - part 21





87

MAINTENANCE

Cooling System

Coolant High Temperature Indicator Light

The high temperature indicator light will illuminate when engine
coolant temperature becomes too hot for safe continued operation of the
engine. If you must drive your machine after the high temperature
indicator light has come on, drive slowly and stop frequently to allow
the engine to cool down. Driving in deep snow will also help cool the
engine. See your dealer for service.

Add coolant if the level is low. Engine performance will be reduced if
you continue operating when the high temperature light is on.

Flushing the Cooling System

To ensure that the coolant maintains its ability to protect the engine, we
recommend that the system be completely drained every five (5) years
and fresh Antifreeze 50/50 Premix added. Have your POLARIS dealer
perform this service.

88

MAINTENANCE

Cooling System

Bleeding the Cooling System

CAUTION! Steam and hot liquids will cause burns to your skin. Never bleed the
cooling system or remove the pressure cap when the engine is warm or hot.

Use of a non-standard pressure cap will not allow the recovery system to
function properly. If the pressure cap needs replacement, contact your
dealer for the correct part.

NOTICE: If coolant flow becomes restricted or plugged, coolant loss, air lock or

engine damage may result. Most cooling systems are equipped with a
filter that should be periodically inspected or replaced.

Perform the bleeding procedure when the engine is cold.

1. Position the vehicle so that the top of the tunnel is level. Elevate the

front of the vehicle slightly if necessary.

2. Place the transmission in neutral.

3. Remove the pressure cap and fill the coolant bottle with properly

mixed coolant to the maximum mark.

4. Remove the bleed screw from the water outlet manifold and/or the

thermostat housing. Allow the coolant to bleed through the system
until it runs out the bleed holes. Reinstall the bleed screw into the
manifold.

5. Add coolant to the coolant bottle to the maximum mark.

6. Start the engine and run at a fast idle for two to three minutes.

Loosen the bleed screw occasionally to purge any trapped air.

7. Stop the engine and check the coolant bottle level. Fill as required.

8. Feel the heat exchangers under the tunnel. If the system is bled

properly, they'll be warm to the touch. If they're not, repeat step 6.
Lift the front of the machine slightly to assist in the bleeding.

9. Replace the pressure cap and carefully lower the front end of the

machine.

89

MAINTENANCE

Brakes

Hydraulic Brake Inspection

Inspect the brake lever reserve before each use of the snowmobile. See
page 57.

Brake pads must be replaced when the brake pad material becomes
thinner than the backing plate, approximately 1/16” (1.5 mm). A kit is
available for replacing brake pads. See your dealer.

WARNING! Brake failure during operation can result in serious injury or death.
Be sure the brake pads do not drag on the disc and that brake lever travel is not
excessive. Always replace brake pads when the brake pad material becomes
thinner than the backing plate, approximately 1/16” (1.5mm).

Brake Components

• Brake Caliper

• Gearcase

• Brake  Disc

• Backing Plate

• Brake Pad Material -

Replace when thickness
is less than 1/16" (1.5
mm).

Brake Disc

Backing

Plate

Brake Pad

Material

Gearcase

Brake

Caliper

90

MAINTENANCE

Brakes

Brake Fluid

After opening a bottle of brake fluid, always discard any unused portion. Never
store or use a partial bottle. Brake fluid is hygroscopic, meaning it rapidly
absorbs moisture from the air. The moisture causes the boiling temperature of
the brake fluid to drop, which can lead to early brake fade and the possibility of
accident or serious injury.

Keep the master cylinder cover free of dirt and debris. The vent slits allow for
diaphragm movement, and if they become plugged, movement of brake fluid
below the diaphragm may be restricted, altering brake function.

NOTICE: Brake fluid will damage decals, paint and some plastics. Always wipe

up spills immediately.

Check the brake fluid in the mas-
ter cylinder before each ride.

View the brake fluid level through
the sight glass on the top of the
master cylinder. The eye will
appear dark when the fluid level is
full. If the sight glass is any color
other than black, add brake fluid.

1. Position the handlebars so the

master cylinder is level.

2. Remove the master cylinder

cover.

3. Add DOT 4 brake fluid only. Do not overfill. See page 116 for the

part numbers of POLARIS products.

WARNING

Sight

Glass

Master

Cylinder
