Snowmobile Polaris 600 IQ Widetrak (2017 year). Instruction - part 20





83

MAINTENANCE

Spark Plugs

Normal Spark Plug

The normal insulator tip is gray, tan or light brown. There will be few
combustion deposits. The electrodes are not burned or eroded. This
indicates the proper type and heat range for the engine and the service.

Tip: The tip should not be white. A white insulator tip indicates overheating,

caused by use of an improper spark plug or incorrect throttle body adjust-
ments.

Wet Fouled Spark Plug

The wet fouled insulator tip is black. A damp oil film covers the firing
end. There may be a carbon layer over the entire nose. Generally, the
electrodes are not worn. General causes of fouling are excessive oil or
rich fuel mixture.

84

MAINTENANCE

Intake Filters

The intake foam filters limit snow
ingestion into the intake system. When
operating in loose powder snow, check
the foam filters periodically to remove
any accumulation of snow.

NOTICE: Operating the snowmobile with

the intake filters removed may
cause intake icing. The result will
be poor fuel economy or intake
malfunction. Always reinstall the
intake filters before operating the
snowmobile.

Fuel Pump

All fuel pump service must be performed by an authorized POLARIS
dealer. Do not attempt to service the fuel pump.

Fuel Filter/Fuel Lines

See your POLARIS dealer for replacement of the fuel filter at the
intervals outlined in the Periodic Maintenance Table beginning on page
76.

Contaminated or poor quality fuel will shorten the life of the fuel filter
and result in poor engine performance. Always store fuel in clean fuel
containers. If low fuel pressure or reduced engine performance occurs
between the recommended fuel filter service intervals, the filter may
need replacement. See your dealer.

Inspect the fuel lines regularly for signs of deterioration or damage.
Always check fuel line condition after periods of storage. Normal dete-
rioration from weather and fuel compounds may occur. Replace worn or
damaged fuel lines promptly.

NOTICE: Kinking the fuel lines or using a pliers or similar tools to remove fuel

lines may cause damage to the lines. If a fuel line has been damaged
or kinked, replace it promptly.

Intake Filter

85

MAINTENANCE

Oil Lines

Inspect oil line condition every 1000 miles (1600 km).

Oil Filter

The oil filter is located at the side of the
oil tank. Have your dealer change the oil
filter and bleed the system annually or
every 1000 miles (1600 km). Have your
dealer inspect the return check valve as
well.

Tip: The direction of the arrows indicates the

direction of flow through the filter.

Exhaust System

Check the exhaust system for wear or damage at the intervals outlined in
the Periodic Maintenance Table beginning on page 76.

CAUTION! Hot exhaust system parts can cause burns. Allow adequate time for
the exhaust system to cool. Never perform this procedure with the engine
running.

1. Allow the engine and exhaust system to cool completely.

2. Open the hood.

3. Inspect the muffler and pipes for cracks or damage. Check for weak

or missing retaining springs or damper/support grommets.

4. Replace any damaged or missing components.

5. Clean the plastic surfaces next to the muffler with aerosol

Carburetor and Throttle Body Cleaner. See page 116 for the part
numbers of POLARIS products.

6. Close the hood.

86

MAINTENANCE

Cooling System

Coolant

POLARIS recommends the use of POLARIS Antifreeze 50/50 Premix.
This antifreeze is already premixed and ready to use. Do not dilute with
water. See page 116 for the part numbers of POLARIS products.

Any time the cooling system has been drained for maintenance or repair,
replace the coolant with fresh Antifreeze 50/50 Premix.

Tip: Never add tap water to the cooling system. Minerals cause deposits and

may react adversely with the metals in the engine and cooling system.

Use of a non-standard pressure cap will not allow the recovery system to
function properly. If the pressure cap needs replacement, contact your
dealer for the correct part.

CAUTION! Steam and hot liquids will cause burns to your skin. Never remove
the pressure cap when the engine is warm or hot.

Coolant Level

The engine coolant level is controlled by the recovery system. The
recovery system components are:

• Coolant recovery bottle
• Coolant reservoir
• Pressure cap
• Connecting hoses

Always maintain the coolant level at the “COLD FILL” mark on the
coolant recovery bottle (when the engine is cold).

NOTICE: Operating the snowmobile with insufficient coolant will result in

overheating and serious engine damage. Always maintain the coolant
level as recommended.
