Snowmobile Polaris 600 IQ Widetrak (2017 year). Instruction - part 6





27

SAFETY

Safety Decals and Locations

Operation Warning

An operation warning decal is present on the console of all POLARIS
snowmobiles:

WARNING

• To avoid serious injury or death, read and understand all warnings and the

Owner’s Manual before operation. If manual is missing, contact a POLARIS
dealer for a replacement.

• This vehicle is capable of high speeds. Buried objects or uneven terrain can

cause loss of control. Reduce speed and use extreme caution when
operating in unfamiliar terrain.

• Excessive speed, especially at night or with limited visibility, can result in

insufficient time for you to react to terrain changes, to avoid unexpected
obstacles, or to stop safely.

• Never consume alcohol or drugs before or while operating this vehicle.

• In an emergency, push down the Auxiliary Shut-Off Switch, located on the top

of the throttle control assembly, to stop the engine. Then pull the brake lever
to stop.

• Always wear an approved helmet, eye protection, and adequate clothing

while operating this vehicle.

• This vehicle is designed for adult use only. Check local laws for age

requirements.

• When operating with a passenger (on approved models only), reduce speed

and allow extra space for steering and stopping. A passenger reduces your
ability to control the vehicle.

• When operating on hard-packed snow, ice, or when crossing roads, steering

and braking ability are greatly reduced. Reduce speed and allow extra space
to turn or stop.

• To maintain vehicle control on ice or hard-packed surfaces, you should have

a proper balance of ski carbides to track studs. See Owner’s Manual for
proper use of traction products.

• Repeated stops from high speed may cause fading or sudden loss of braking

ability.

• Parking brake may relax when used for long periods. Do not leave brake

engaged for more than five minutes.

• Before starting the engine, check throttle, brake, and steering for proper

operation. Make sure hood is latched. Be seated and in position to control the
vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when refueling.

28

FEATURES

3

4

5

6

12

2

1

9

10

11

13

14

15

16

17

18

7

8

1.

Nosepan

2.

Skis

3.

Front Bumper

4.

Hood

5.

Headlight

6.

Windshield

7.

Mountain Bar

8.

Handlebar

9.

Seat

10. Backrest

11. Taillights
12. Cargo Carrier
13. Rear Bumper
14. Snow Flap
15. Track
16. Suspension
17. Passenger Grab Handle
18. Seat Latch
19. Fuel Filler Cap

19

29

FEATURES

2

5

6

14

7

8

12

13

3

10

9

1

4

1.

Glove Box

2.

MFD Display

3.

Ignition Switch

4.

Shifter

5.

Recoil Starter Handle

6.

Brake Lever

7.

Handlebar Grip Warmer
Switch

8.

Thumbwarmer Switch

9.

Throttle Control

10. Engine Stop Switch
11. Electronic Reverse Button
12. MFD Control Switch
13. Headlight Dimmer Switch
14. Parking Brake Lock

11

30

FEATURES

Backrest

The backrest can be adjusted for rider comfort. Whenever making
adjustments, always make sure all lock levers are securely locked before
operating.

Tip: If an adjustment is difficult, rotate the lock levers counter-clockwise to

relieve tension, then make the adjustment. Always tighten the levers after
adjusting.

Height Adjustment

1. Lift the upper lock levers (A) on

both backrest supports to release the
locks.

2. Raise or lower the backrest to the

desired position.

3. Push the lock levers inward to

secure the locks. Rotate levers
clockwise to tighten.

Angle Adjustment

1. Lift the lock lever at the center of

the backrest (B).

2. Tilt the backrest forward or rearward to the desired position.

3. Push the lock lever inward to secure the lock.

Operator/Passenger Conversion

1. Lift the lower lock levers (C) on both backrest supports to release

the locks.

2. Move the backrest forward for operator use or rearward for

passenger use.

3. Push the lock levers inward to secure the locks. Rotate levers

clockwise to tighten.

Adjustable Headlights

Move the headlight adjuster to raise or
lower the headlight beam.

• Move the adjuster to the left to lower

the beam.

• Move the adjuster to the right to raise

the beam.

A

C

B
