Snowmobile Polaris 600 IQ Touring (2010 year). Instruction - part 28





113

MAINTENANCE

Steering System

Steering Inspection and Adjustment

Check all steering system fasteners weekly and before a long ride.

Tighten any loose fasteners.

+

+

+

+

+

114

MAINTENANCE

Steering System

Ski Alignment

WARNING! Improper ski alignment or adjustment may cause loss of steering

control, resulting in serious injury or death. Do not attempt to change the ski

alignment or camber adjustment. See your Polaris dealer.

With the handlebars in a straight ahead position, and with vehicle

weight compressing the suspension, measure from the straight edge of

the skis at the center of the ski mounting bolt. The measurement

between the skis at point X should be 1/8" to 1/4" (3-6 mm) greater than

the measurement at point Y.

Tip: If the skis are misaligned, we recommend that your dealer correct the align-

ment, since camber adjustment may also be affected.

X

Y

10 in.

(25.4 cm)

10 in.

(25.4 cm)

115

MAINTENANCE

Steering System

n

Ski Skags

WARNING! Worn skis and/or skags will adversely affect handling. Loss of

vehicle control may result, causing serious injury or death. See your dealer's

studding chart for recommended skags. If you install longer or more aggressive

carbide skags than the original equipment, it may also be necessary to add track

studs to maintain proper vehicle control while turning on hard-packed snow or

ice.

Check skags before each use of the snowmobile to ensure positive steer-

ing characteristics. Skags must be replaced when worn to half their orig-

inal diameter.

Tip: Carbide skags must be replaced if any abnormal wear or chipping is found.

Skag Replacement

Some models are equipped with single skags. Some models are

equipped with dual skags.
1. Raise and support the front of

the snowmobile so the skis are

approximately 6" (15 cm) from

the ground.

2. Remove the attaching nuts and

pry the skag downward.

3. Remove the front end of the

skag.

4. Remove the rear end of the

skag.

5. Reverse the steps to install a

skag.

Skag

116

MAINTENANCE

Extended Storage

Off-season or extended storage of your snowmobile requires preventive

measures to aid against deterioration and to prolong the useful life of

many components. See page 118 for the part numbers of Polaris prod-

ucts.

Cleaning and Preservation

Proper storage starts with cleaning, washing, and waxing the hood,

chassis, and plastic parts. Wipe down remaining surfaces with a damp

cloth. Clean and touch up with paint any rusted or previously painted

surfaces. Be sure that corrosive salt and acids are removed from surfaces

before beginning preservation with waxes and rust inhibitors (grease, oil

or paint).
The snowmobile should be stored in a dry garage or shed, out of direct

sunlight, and covered with a fabric snowmobile cover. Plastic tarp may

cause condensation to form and damage snowmobile components.

Controls and Linkage

Lubricate all bushings and cables at the intervals outlined in the Periodic

Maintenance Table beginning on page 85.

Bearings

Grease the jackshaft and drive shaft clutch side bearings with Polaris

Premium All-Season Grease or a similar high quality grease to prevent

corrosion.

Clutch and Drive System

Remove the drive belt and store in a cool dry location. Do not lubricate

clutch components, except the driven clutch shaft bushing as outlined in

the service manual. See your dealer.
