Snowmobile Polaris 600 IQ Racer (2015 year). Instruction - part 7

31

THE PERFECT FIT

Front Suspension Adjustments

Rebound Damping Force
Adjustment

Increase the rebound damping
force by turning the adjuster
clockwise to increase the stiffness.

Decrease the rebound damping
force by turning the adjuster
counter-clockwise to increase the
softness.

The maximum adjustment for this
adjuster is the fully turned in
position. The minimum
adjustment is 16 clicks out from
the maximum position.

CAUTION! Do not turn the adjuster past the minimum or maximum adjustment.
The adjuster may be damaged.

Front Springs

For models without externally adjustable or revalvable shocks, the front
springs can be changed if spring preload alone isn't sufficient and
further adjustment is desired to control suspension stiffness. See your
POLARIS dealer for more information.

Standard Position

Rebound adjuster

4 clicks out from fully turned in position

Adjuster

Stiffer

Softer

32

THE PERFECT FIT

Rear Suspension Adjustments

The following information is provided only as a guideline to be used for
initial suspension set-up. Your set-up may vary based on your desired
riding style. Rider weight, riding style, trail conditions, and vehicle
speed all affect suspension action.

Each rear suspension can be adjusted to suit rider preference and deliver
the best performance for a given set of conditions. However, all
suspension designs and adjustments involve a compromise, or trade-off.
For example, a suspension set up for snow-cross racing would provide a
very stiff ride on the trail. A suspension set up for trail riding would
bottom out harshly on a snow-cross course.

Make adjustments to one area at a time so you can evaluate the change.
For further assistance, see your dealer.

Suspension Performance Tips

• Rider weight usually determines the position at which the spring

preload should be set. However, this may vary with riding style. With
a little experimentation, each rider can find a preferred setup. These
adjustments are easy to make, involve very little time or effort, and
greatly affect the ride.

• When riding on ice or hard-packed snow, adding a set of bogie wheels

to the rail may enhance the machine's performance. Bogie wheel kits
are available from your dealer.

TIP: Keep the suspension pivot points lubricated. This will reduce moisture and

rust build-up and ensure proper function of the suspension components.
Grease rear suspension pivots before adjusting the rear suspension. Refer
to Suspension Maintenance beginning on page 92.

Track Tension

Track adjustment is critical for proper handling. Always maintain
correct tension and alignment. Refer to the track tension maintenance
section beginning on page 86.

33

THE PERFECT FIT

Rear Suspension Adjustments

Torsion Spring Tension

To adjust rear torsion spring tension, rotate the three-position cam using
the engine spark plug tool. Different rate torsion springs are available if
a firmer ride is desired. See your dealer for more information.

Cam Adjustments

Soft Tension: Move the long end of the cam to the front.

Medium Tension: Move the short end of the cam upward.

Firm Tension: Move the long end of the cam upward.

Soft Tension

Medium Tension

Firm Tension

34

THE PERFECT FIT

Rear Suspension Adjustments

Compression Damping

High Compression Damping
Force Adjustment

Increase the high compression
damping force by turning the
adjuster clockwise to increase the
stiffness.

Decrease the high compression
damping force by turning the
adjuster counter-clockwise to
increase the softness.

The maximum adjustment for this
adjuster is the fully turned in
position. The minimum
adjustment is 22 clicks out from
the maximum position.

CAUTION! Do not turn the adjuster
past the minimum or maximum
adjustment. The adjuster may be
damaged.

Standard Position

Front Track

suspension

high speed

adjuster

14 clicks out from

fully turned in

position

Rear Track

suspension

high speed

adjuster

14 clicks out from

fully turned in

position

Front Track Suspension

Rear Track Suspension

Stiffer

Softer

Stiffer

Softer

 Adjuster
