Snowmobile Polaris 550 IQ / 550 Shift (2012 year). Instruction - part 7

28

THE PERFECT FIT

Front Suspension Adjustments

Independent Front Suspension (IFS)

Break in the suspension for about 150 miles (240 km) before making
any fine-tuning adjustments.

Settings will vary from rider to rider, depending on rider weight, vehicle
speed, riding style, and trail conditions.  We recommend starting with
factory settings and then customizing each adjustment individually to
suit rider preference.  The machine should be methodically tested, one
change at a time, under the same conditions (trail and snow conditions,
vehicle speed, riding position, etc.) after each adjustment until the best
ride is achieved.

IFS Components

1. Skis

2. Front shocks and springs

3. Rod ends

4. A-arms

IFS Adjustment Options
• Front shock spring preload
• Optional springs

1

2

3

4

29

THE PERFECT FIT

Front Suspension Adjustments

Shock Spring Preload

Increasing spring preload will increase
ski-to-ground pressure. Decreasing spring
preload will decrease ski-to-ground pres-
sure. When adjusting, be sure the springs
on both the left and right sides of the
machine are at the same adjustment.

To change front shock spring preload,
grasp the spring and rotate it.

Increasing the spring preload too much
may adversely affect the handling of the
snowmobile and the performance of the
suspension. Never exceed one inch of pre-
load beyond the factory settings, and
ensure that both sides are adjusted the
same. When decreasing preload, make
sure at least two turns of preload are hold-
ing the spring between the retainer on the
top of the shock and the threaded spring
preload adjuster nut on the shock body.
Failure to do so could cause the retainer to fall off when the suspension
is fully extended.

Tip: Not all models have shocks with thread adjustable spring preload. See your

dealer for more information.

NOTICE: On some models equipped with a plastic adjuster nut, the nut will

break if it is unscrewed from the threaded body. Do not force the nut if
resistance suddenly increases while you’re turning it.

Low

Preload

High

Preload

30

THE PERFECT FIT

Rear Suspension Adjustments

Rider weight, riding style, trail conditions, and vehicle speed all affect
suspension action.

Each rear suspension can be adjusted to suit rider preference and deliver
excellent performance for a given set of conditions.  However, all sus-
pension designs and adjustments involve a compromise, or trade-off.
For example, a suspension set up for snowcross racing would provide a
very stiff ride on the trail.  A suspension set up for trail riding would
bottom out harshly on a snowcross course.

Refer to the suspension setup label on your snowmobile, or see your
POLARIS dealer for initial suspension setup information. Additional
adjustments can be made after initial setup. Make adjustments to one
area at a time so you can evaluate the change. For further assistance, see
your dealer.

31

THE PERFECT FIT

Rear Suspension Adjustments

Suspension Performance Tips

• Rider weight usually determines the position at which the spring pre-

load should be set. However, this may vary with riding style. With a
little experimentation, each rider can find a preferred setup. These
adjustments are easy to make, involve very little time or effort, and
greatly affect the ride.

• In deep snow, a new rail slide will offer improved performance over

worn rail slide. It can also improve top speed.

• When riding on ice or hard-packed snow, adding a set of bogie wheels

to the rail may enhance the machine's performance.  Bogie wheel kits
are available from your dealer.

• POLARIS offers track kits for improved flotation in deep snow.  See

your dealer for assistance.

Tip: Keep the suspension pivot points lubricated. This will reduce moisture and

rust build-up and ensure proper function of the suspension components.
Grease rear suspension pivots before adjusting the rear suspension. Refer
to the Pre-Ride Suspension Inspection on page 45.

Track Tension

Track adjustment is critical for proper handling. Always maintain cor-
rect tension and alignment. Refer to the track tension maintenance sec-
tion beginning on page 86.
