Snowmobile Polaris 550 IQ / 550 Shift (2012 year). Instruction - part 6





24

SAFETY

Safety Decals and Locations

Operation Warning

• To avoid serious injury or death, read and understand all warnings

and the Owner's Manual before operation. If manual is missing, con-
tact a POLARIS dealer for a replacement.

• This vehicle is capable of high speeds. Buried objects or uneven

terrain can cause loss of control. Reduce speed and use extreme
caution when operating in unfamiliar terrain.

• Excessive speed, especially at night or with limited visibility, can

result in insufficient time for you to react to terrain changes, to
avoid unexpected obstacles, or to stop safely.

• Never consume alcohol or drugs before or while operating this vehi-

cle.

• In an emergency, push down the Auxiliary Shut-Off Switch, located

on the top of the throttle control assembly, to stop the engine. Then
pull the brake lever to stop.

• Always wear an approved helmet, eye protection, and adequate

clothing while operating this vehicle.

• This vehicle is designed for adult use only. Check local laws for age

requirements.

• When operating with a passenger (on approved models only)

reduce speed and allow extra space for steering and stopping.  A
passenger reduces your ability to control the vehicle.

• When operating on hard-packed snow, ice, or when crossing roads,

steering and braking ability are greatly reduced. Reduce speed and
allow extra space to turn or stop.

• To maintain vehicle control on ice or hard-packed surfaces, you

should have a proper balance of ski carbides to track studs. See
Owner's Manual for proper use of traction products.

• Repeated stops from high speed may cause fading or sudden loss

of braking ability.

• Parking brake may relax when used for long periods. Do not leave

brake engaged for more than five minutes.

• Before starting engine, check throttle, brake, and steering for proper

operation. Make sure hood is latched. Be seated and in position to
control the vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when
refueling.

25

FEATURES

1.

Hood

2.

Headlight

3.

Windshield

4.

Handlebar

5.

Seat

6.

Taillights

7.

Rear Bumper

8.

Snow Flap

9.

Console Storage Compartment
(if equipped)

10. Suspension
11. Track
12. Skis
13. Nosepan
14. Front Bumper (do not use for pulling or dragging the snowmobile)
15. Passenger Grab Handle (LXT)
16. Passenger Seat (LXT)
17. Passenger Backrest (LXT Accessory)
18. Cargo Bag (LXT Accessory)
19. Cargo Rack (LXT Accessory)

5

11

2

3

4

10

8

12

13

14

1

9

7

6

15

16

17

18

19

26

FEATURES

1.

Fuel Filler Cap/Dipstick

2.

Recoil Starter Handle

3.

Reverse Indicator

4.

Headlight Adjuster

5.

Speedometer

6.

Engine Stop Switch

7.

Choke Lever

8.

Ignition Switch

9.

Brake Lever

10. Parking Brake
11. Handlebar Grip Warmer Switch
12. Thumbwarmer Switch
13. Electronic Reverse Button
14. Headlight Dimmer Switch
15. Throttle Control

1

8

6

2

7

4

5

3

13

14

10

11

12

9

15

27

FEATURES

Cargo Bag

The accessory cargo bag is secured
to the rear of the tunnel with straps.

The maximum weight capacity for
the cargo area is 30 lbs. (14 kg).
Always secure cargo before operat-
ing. Do not exceed the weight limit.
Do not allow a passenger to sit on the
cargo area.

Adjustable Headlights

Adjust the headlight beam by moving
the adjuster to the left or right.

Passenger Grab Handle

If equipped, the passenger grab handles
can be adjusted for rider preference.

1. Remove the hardware securing the

grab handles to the grab handle
tube.

2. Reposition the grab handles to one

of the three available positions and
reinstall the hardware securely.

Cargo Bag

Adjustment Positions
