Snowmobile Polaris 340 Edge / 550 LX (2008 year). Instruction - part 16





64

OPERATION

Reverse Operation

WARNING

Improper reverse operation, even at low speeds, may cause loss of control,

resulting in serious injury or death. Damage will occur to the chaincase or

transmission if shifting is attempted when the engine is operating above idle

speed.

Shift to or from reverse only when the snowmobile is stopped and when

engine speed is at idle.

Look behind the vehicle before and while backing.

Avoid sharp turns.

Apply throttle slowly.

CAUTION

Engaging the starter when the engine is running WILL result in serious

engine damage, especially if the transmission is in reverse. Never engage

the starter when the engine is running.

65

OPERATION

Reverse Operation

Electronic Reverse (PERCt)

Electronic reverse will activate only if the engine RPM is below 4000. If

your machine is running at an altitude of over 6000 feet, adjust the igni-

tion setting as described below. Always make sure the vehicle is stopped

and the engine is running at idle before shifting to reverse.

Engaging Reverse
1. Stop the snowmobile and leave the engine idling.
2. Make sure the area behind your vehicle is clear.
3. Push the yellow reverse button (+)

on the left-hand control for one

second, then release. The engine

will automatically reduce RPM and

start a reverse rotation. A flashing

reverse light on the instrument

panel will indicate that the trans-

mission is in reverse.

4. Apply the throttle slowly to make

sure the transmission is in reverse.

NOTE: The maximum engine RPM will be 6000 when in reverse.
NOTE: If the engine stops running, the snowmobile will be in forward

gear when it's restarted.

+

66

OPERATION

Reverse Operation

Electronic Reverse (PERCt)

Disengaging Reverse
1. Stop the snowmobile and leave the engine idling.

2. Push the yellow reverse button for one second and release. The

engine will slow and begin to rotate forward. The light on the

instrument panel will shut off.

3. Apply the throttle slowly to make sure the transmission is in for-

ward.

Altitude Setting
At higher altitudes (above 6000 feet), the engine will require a different

ignition setting to improve the success of the reverse system. To set for a

higher altitude, start the engine and hold the button down until the light

on the instrument panel flashes rapidly, then release the button.

To set the reverse for lower elevations, continue holding the button

down until the reverse indicator light blinks slowly. Once set, it's stored

in memory until changed, whether the engine is running or not.

CAUTION

Engaging the starter when the engine is running WILL result in serious

engine damage, especially if the transmission is in reverse. Never engage

the starter when the engine is running.

67

OPERATION

Daily Storage

At the end of each ride, park the snow-

mobile on a level surface and support it at

the rear with an appropriate track stand.

The track should be suspended approxi-

mately 4I (10 cm) off the ground.

Remove the key and cover the machine.

Towing

Do not use the front bumper to pull or drag the snowmobile. The front

bumper is not designed for this type of use and may detach from the

vehicle if force is applied.

For your safety, do not attempt to use a tow hitch until you've read the

following warnings and understand the proper hitch functions.

If the snowmobile becomes inoperable and must be towed, and if it isn't

possible to use a rigid tow bar, attach the tow rope to the ski spindles

(not to the ski loops) to prevent damage to the steering components.

Remove the drive belt before towing, and have someone ride on the

towed snowmobile to operate the brake and steering when necessary.

WARNING

Objects towed with a rope have no braking power and can easily collide with

the rear of the snowmobile or other objects, resulting in serious injury or

death. DO NOT tow toboggans, sleds, saucers, or any type of vehicle with a

rope. Only a stiff metal pole connecting the towed object and the tow hitch on

the snowmobile should be used. If passengers are to be towed on a tobog-

gan or sled, make sure the pole is at least four feet (1.2 meters) long to pre-

vent any possibility of contact between the snowmobile's track and a person

riding in the towed object.
Braking distances increase when towing loads. Slow down to maintain con-

trol of the snowmobile.

CAUTION

Towing a disabled snowmobile with the drive belt in place can result in seri-

ous damage to the engine and drive system. Always remove the drive belt

from a disabled snowmobile before towing.
