Snowmobile Polaris 340 Edge / 550 LX (2008 year). Instruction - part 6





24

SAFETY

Safety Decals and Locations

Operation Warning

The operation warning decal is located on the console of all Polaris

snowmobiles:

• To avoid serious injury or death, read and understand all warnings

and the Owner's Manual before operation. If manual is missing, con-

tact a Polaris dealer for a replacement.

• This vehicle is capable of high speeds. Buried objects or uneven

terrain can cause loss of control. Reduce speed and use extreme

caution when operating in unfamiliar terrain.

• Excessive speed, especially at night or with limited visibility, can

result in insufficient time for you to react to terrain changes, to

avoid unexpected obstacles, or to stop safely.

• Never consume alcohol or drugs before or while operating this vehi-

cle.

• In an emergency, push down the Auxiliary Shut-Off Switch, located

on the top of the throttle control assembly, to stop the engine. Then

pull the brake lever to stop.

• Always wear an approved helmet, eye protection, and adequate

clothing while operating this vehicle.

• This vehicle is designed for adult use only. Check local laws for age

requirements.

• When operating with a passenger (on approved models only)

reduce speed and allow extra space for steering and stopping. A

passenger reduces your ability to control the vehicle.

• When operating on hard-packed snow, ice, or when crossing roads,

steering and braking ability are greatly reduced. Reduce speed and

allow extra space to turn or stop.

• To maintain vehicle control on ice or hard-packed surfaces, you

should have a proper balance of ski carbides to track studs. See

Owner's Manual for proper use of traction products.

• Repeated stops from high speed may cause fading or sudden loss

of braking ability.

• Parking brake may relax when used for long periods. Do not leave

brake engaged for more than five minutes.

• Before starting engine, check throttle, brake, and steering for

proper operation. Make sure hood is latched. Be seated and in posi-

tion to control the vehicle.

Oil injection system: Use unmixed fuel only. Check oil level when

refueling.

25

FEATURES

1. Hood

2. Headlight

3. Windshield

4. Handlebar

5. Seat
6. Storage Compartment

7. Taillights

8. Rear Bumper

9. Snow Flap

10. Track

11. Suspension

12. Ski

13. Nosepan

14. Front Bumper (do not use for pulling or dragging the snowmobile)

5

10

2

3

4

11

9

12

13

14

1

8

7

6

General

Representation

26

FEATURES

Some Polaris snowmobiles are equipped with special features such as a

reverse indicator light, electronic fuel gauge, temperature light and elec-

tric shock control gauge. Not all models come with these features. Refer

to your Owner's Manual Supplement for the features on your model.

1. Brake Lever

2. Speedometer

3. Tachometer (Accessory)

4. Engine Stop Switch

5. Throttle Control
6. Hood Hold Down Straps

7. Choke

8. Recoil Starter Handle

9. Fuel Filler Cap

10. Ignition Switch

9

10

3

4

5

6

8

2

7

1

Supersport Shown

27

FEATURES

11. High Beam Indicator (340)

12. Reverse Indicator (340)

13. Low Oil Level Indicator (340)

14. Parking Brake

15. Handlebar Grip Warmer Switch

16. Thumbwarmer Switch

17. Electronic Reverse Button

18. Headlight Dimmer Switch

14

17

16

15

18

340 Edge

11

12

13
