5.9 Motor pumps - DPU 60-series - Duo
75
Motor pumps - Duo
Petrol
specifications
DPU 61 PXC 15
DPU 61 PXC 20
equipped with
CORE
CORE
article number
150.152.215
150.152.276
150.152.218
150.152.278
EN 13204 classification 1)
MTO
MTO
number of tool connections
2
2
number of tools working simultaneously
2
2
working pressure
bar / Mpa
720 / 72
720 / 72
4-stroke petrol engine
5.5 HP - 4.1 kW
5.5 HP - 4.1 kW
pump type
2 x 2-stage radial
2 x 2-stage radial
capacity fuel tank
cc
1400
1400
continuous operation
hours
4
4
capacity oil tank
cc
4000
4000
output 1st stage 0-190 bar
cc/min
2 x 2565
2 x 2565
output 2nd stage 190-720 bar
cc/min
2 x 660
2 x 660
weight ready for use 2)
kg
78.9
83.7
dimensions (L x W x H)
mm
500x822x497
500x822x497
length of hoses
m
15
20
colour of hoses
orange/orange
orange/blue
orange/orange
orange/blue
sound emission
dB(A)
84
84
temperature range
-20°C - +55°C
-20°C - +55°C
electric start
√
√
√
√
also available in dual hose version
√
√
√
√
1) EN 13204: MTO = Multiple Tool Operation | 2) inclusive hydraulic and engine oil, fuel, hoses and couplers
DPU 61 PC
5.10 Motor pumps - MPU 60-series - Trio
76
Motor pumps - Trio
Petrol
Electric
specifications
MPU 60 PC
MPU 60 PXC 3)
MPU 60 DC
equipped with
CORE
CORE
article number
150.152.437
150.152.438
150.152.439
EN 13204 classification 1)
MTO
MTO
number of tool connections
3
3
number of tools working simultaneously
3
3
working pressure
bar / Mpa
720 / 72
720 / 72
4-stroke petrol engine
5.5 HP - 4.1 kW
--
electric engine
--
230 VAC - 1.8 kW - 50 Hz - 1 Ph
pump type
3 x 2-stage radial
3 x 2-stage radial
capacity fuel tank
cc
1400
--
continuous operation
hours
4
no limitation
capacity oil tank
cc
4000
4000
output 1st stage 0-190 bar
cc/min
3 x 2110
3 x 1900
output 2nd stage 190-720 bar
cc/min
3 x 660
3 x 590
weight ready for use 2)
kg
50.6
54.0
55.5
dimensions (L x W x H)
mm
500x372x497
500x372x497
sound emission
dB(A)
84
74
temperature range
-20°C - +55°C
-20°C - +55°C
also available in dual hose version
√
√
√
1) EN 13204: MTO = Multiple Tool Operation | 2) inclusive hydraulic and engine oil, fuel, hoses and couplers | 3) electric start
MPU 60 DC
MPU 61 PC 20
Motor pumps - Trio with hose reels
hoses
art.nr
model
length
colour
weight
dimensions
metres
left
right
kg
mm (LxWxH)
150.152.386
MPU 61 PC 15
15
80.0
822x500x497
•
•
150.152.391
MPU 61 PC 15
15
80.0
822x500x497
•
•
150.152.393
MPU 61 PC 20
20
84.8
822x500x497
•
•
150.152.394
MPU 61 PC 20
20
84.8
822x500x497
•
•
150.152.396
MPU 61 PXC 15 3)
15
83.4
822x500x497
•
•
150.152.397
MPU 61 PXC 15 3)
15
83.4
822x500x497
•
•
150.152.399
MPU 61 PXC 20 3)
20
88.2
822x500x497
•
•
150152.400
MPU 61 PXC 20 3)
20
88.2
822x500x497
•
•
150.152.389
MPU 61 DC 15
15
84.9
822x500x497
•
•
150.152.383
MPU 61 DC 15
15
84.9
822x500x497
•
•
150.152.388
MPU 61 DC 20
20
89.7
822x500x497
•
•
150.152.384
MPU 61 DC 20
20
89.7
822x500x497
•
•
5.11 Hand pumps - three stage
77
HTT 1800 UC
Hand pumps - three stage
specifications
HTT 1800 UC
equipped with
CORE
article number
150.142.024
number of tool connections
1
working pressure
bar / MPa
720 / 72
source of energy
hand
capacity oil tank
cc
1800
output 1st stage - 0 - 60 bar
cc
28 cc
output 2nd stage - 60 - 260 bar
cc
7.6 cc
output 3rd stage - 260 - 720 bar
cc
3.1 cc
weight, ready for use
kg
17.2
dimensions (L x W x H) 1)
mm
856 x 400 x 214
temperature range
-20°C - +55°C
also available in dual hose version
√
1) dimensions bottom plate | tested according to EN 13204
Features / Benefits
Unique three-stage hand pump
Ergonomic design pump handle
standard 2-stage pumps
extra output compared
to 2-stage pumps
output per stroke
28 cc
automatic change
7.6 cc
over pressure
2.3 cc
45 bar
260 bar
720 bar
- less operating force needed at higher
- faster tool speed at most frequently used
- adjustable in 2 positions for optimal ease of
pressures
pressures
operation
5.11 Hand / foot pumps - two stage
78
Hand / foot pumps - two stage
specifications
HTW 300 ABU1)
HTW 700 ABU
HTW 1800 C2)
HTW 1800 BU2)
FTW 1800 C2)
FTW 1800 BU2)
equipped with
single hose
dual hoses
CORE
dual hoses
CORE
dual hoses
article number
150.449.001
150.442.013
150.142.021
150.142.003
150.142.022
150.142.000
number of tool connections
1
1
1
1
1
1
working pressure
bar / MPa
720 / 72
720 / 72
720 / 72
720 / 72
720 / 72
720 / 72
source of energy
hand
hand
hand
hand
foot
foot
capacity oil tank
cc
300
700
1800
1800
1800
1800
up to 50 bar -
up to 50 bar -
up to 45 bar -
up to 45 bar -
up to 45 bar -
up to 45 bar -
output per stroke 1st stage
cc
5
11
28
28
28
28
up to 720 bar -
up to 720 bar -
up to 720 bar -
up to 720 bar -
up to 720 bar -
up to 720 bar -
output per stroke 2nd stage
cc
1
2
2.3
2.3
2.3
2.3
weight, ready for use
kg
4.0
9.1
10.8
11.5
11.3
12.0
dimensions (L x W x H) 3)
mm
560 x 90 x 115
740 x 200 x 170
765 x 240 x 236
775 x 240 x 236
765 x 240 x 223
775 x 240 x 223
temperature range
-20°C - +55°C
1) for use with single acting tools only | 2) tested according to EN 13204 | 3) dimensions bottom plate (except HTW 300 ABU)
HTW 300 ABU
HTW 700 ABU
FTW 1800 BU
HTW 1800 BU
5.11 Hand / foot pumps - two stage
79
FTW 1800 C
HTW 1800 C
Features / Benefits
No pressure remains on the first stage after
Scraper ring protects the piston against dirt
automatic change-over
operation force needed
0
45 bar
720 bar
- less power needed for pumping
- hydraulic system will not be polluted and damaged by dirt entering
the plunger
6.1 CORE Technology (see also pages 22-25)
80
Turning point in safety, speed and ease of operation
One hose system (hose in hose)
Saves valuable time in set up and use
high pressure hose
low pressure
return hose
return oil
Easy to handle before, during and after use
6.2 Hoses / hose reels - CORE
81
Hoses - CORE
model
art. nr.
length m
weight kg*
colour
safety ratio all hoses
C 05 OU
150.570.042
5
2.5
4 : 1 = 2880 bar
C 10 OU
150.570.043
10
4.7
C 15 OU
150.570.044
15
6.9
C 20 OU
150.570.095
20
9.1
C 05 BU
150.570.045
5
2.5
C 10 BU
150.570.046
10
4.7
C 15 BU
150.570.047
15
6.9
C 20 BU
150.570.096
20
9.1
C 05 GU
150.570.057
5
2.5
C 10 GU
150.570.058
10
4.7
C 15 GU
150.570.059
15
6.9
C 20 GU
150.570.146
20
9.1
C 05 ZU
150.570.060
5
2.5
C 10 ZU
150.570.061
10
4.7
C 15 ZU
150.570.062
15
6.9
--elivered with bend restrictors on both sides and hose
C 20 ZU
150.570.225
20
9.1
binders
* weight filled with oil and with couplers
Single hose reels - CORE
length
weight 1)
dimensions
model
art. nr
colour
model
art. nr
colour
m
kg
mm (L x W x H)
left
right
15
17.1
435 x 290 x 515
HR 4415 CLO
150.072.078
HR 4415 CRO
150.072.084
20
19.5
435 x 290 x 515
HR 4420 CLO
150.072.079
HR 4420 CRO
150.072.085
25
22.2
435 x 335 x 515
HR 4425 CLO
150.072.083
HR 4425 CRO
150.072.086
15
17.1
435 x 290 x 515
HR 4415 CLB
150.072.080
HR 4415 CRB
150.072.087
20
19.5
435 x 290 x 515
HR 4420 CLB
150.072.081
HR 4420 CRB
150.072.088
25
22.2
435 x 335 x 515
HR 4425 CLB
150.072.082
HR 4425 CRB
150.072.089
1) weight inclusive hose filled with oil and with couplers | all hose reels are according to EN 13204 and NFPA 1936
All single and double hose reels with brake system to prevent unrolling of hose during transport.
All single and double hose reels with 1.2 m connection hose with bend restrictor.
HR 4420 CLO
HR 4520 COB
Double hose reels - CORE
length
weight 1)
dimensions
model
art. nr.
colour
model
art. nr.
colour
m
kg
mm (L x W x H)
2 x 15
33.4
435 x 565 x 515
HR 4515 COB
150.072.075
HR 4515 COO
150.072.098
2 x 20
38.3
435 x 565 x 515
HR 4520 COB
150.072.076
HR 4520 COO
150.072.099
2 x 25
43.6
435 x 655 x 515
HR 4525 COB
150.072.077
HR 4525 COO
150.072.100
1) weight inclusive hoses filled with oil and with couplers | all hose reels are according to EN 13204 and NFPA 1936
6.2 Electric hose reels - CORE
82
Electric hose reels - CORE
specifications
HR 4425 ACLO
HR 4425 ACRB
HR 4430 ACLO
HR 4430 ACRB
article number
150.072.067
150.072.072
150.072.059
150.072.064
working pressure
bar / MPa
720 / 72
720 / 72
electric engine
VDC
24
24
rewinding of hose
electric
electric
dimensions (L x W x H)
mm
483 x 546 x 457
483 x 546 x 457
weight, ready for use 1)
kg
38.0
40.5
length of hose
m
25
30
version
left
right
left
right
colour of hose
1) weight inclusive hose filled with oil and with coupler
Connection hoses - CORE
specifications
C 1.5 OU
C 1.5 BU
C 02 OU
C 02 BU
C 03 OU
C 03 BU
article number
150.570.049
150.570.050
150.570.123
150.570.124
150.570.125
150.570.126
length
m
1.5
2
3
weight 1)
kg
1.0
1.2
1.6
colour
1) weight filled with oil and with couplers
HR 4425 ACLO
Features / Benefits
Available in left-and right version
Electric driven rewinding system
- allows for an efficient lay out in rescue trucks
- quick, easy and perfect rewinding of hose
- easy to clean during rewinding
6.3 Hoses / hose reels - Dual
83
safety ratio all hoses
Hoses - bundled
4 : 1 = 2880 bar
model
art. nr.
length m
weight kg1)
colour
BVL 5 SOU
150.572.055
5
4.5
Hoses - single
BVL 5 SGU
150.572.056
5
4.5
model
art. nr.
length m
weight kg1)
colour
BVL 5 SRU
150.572.123
5
4.5
B 1 SOU
150.570.063
1
1.0
BVL 5 SBU
150.572.126
5
4.5
B 2 SOU
150.572.035
2
1.3
BVL 10 SOU
150.572.111
10
7.8
B 3 SOU
150.572.033
3
1.6
BVL 10 SGU
150.572.112
10
7.8
B 3 SGU
150.572.034
3
1.6
BVL 10 SRU
150.572.124
10
7.8
B 5 SOU
150.572.058
5
2.3
BVL 10 SBU
150.572.127
10
7.8
B 5 SGU
150.572.059
5
2.3
BVL 15 SOU
150.572.121
15
11.0
1) weight filled with oil and with couplers
BVL 15 SGU
150.572.122
15
11.0
BVL 15 SRU
150.572.125
15
11.0
BVL 15 SBU
150.572.128
15
11.0
BVL 20 SOU
150.572.062
20
14.3
BVL 20 SGU
150.572.061
20
14.3
1) weight filled with oil and with couplers
All hoses inclucing quick couplers with lock-ring security and anti-kink springs on both
BVL 5 SOU
B 3 SOU
ends.
Single hose reels - dual
length
weight
dimensions
model
art. nr
colour
model
art. nr
colour
m
kg1)
mm (L x W x H)
left
right
15
19.5
397 x 242 x 484
HR 3415 LO
150.072.012
HR 3415 RG
150.072.016
20
22.0
397 x 242 x 484
HR 3420 LO
150.072.013
HR 3420 RG
150.072.017
1) weight inclusive hoses filled with oil and with couplers
All single and double hose reels with brake system to prevent unrolling of hose during transport.
All single and double hose reels with 1.2 m connection hose with bend restrictor.
HR 3420 RG
HR 3520 OG
Double hose reels - dual
length
weight
dimensions
model
art. nr
colour
m
kg 1)
mm (L x W x H)
left
right
15
39.5
397 x 464 x 484
HR 3515 OG
150.072.022
20
44.5
397 x 464 x 484
HR 3520 OG
150.072.023
1) weight inclusive hoses filled with oil and with couplers
7.1 Advisory rescue sets
84
The broad range of Holmatro rescue tools, assist tools and accessories allows you to to select a combination that will
match your rescue needs in the best possible way. Alternatively, you can choose between a number of advisory sets. All
sets are also available in dual hose version. For the technical specifications of the individual items see the respective pages
of this catalogue.
Basic Rapid Intervention set
6
7
1
4
Alternative:
2
8
5
A
3
A random selection of
tools lying on a tool
station.
Basic Rapid Intervention set, consisting of:
item
description
model
art.nr.
page
1
combi tool
CT 4150 C
150.012.099
44
2
pulling set in case
150.582.018
44
3
ram jack
RA 4331 C
150.032.046
50
extension pipe
165 mm
150.181.321
4
extension pipe
330 mm
150.181.322
54
extension pipe
600 mm
150.181.323
B
F
5
ram support
HRS 22
150.181.011
114
6
petrol pump
SR 10 PC 1
150.152.690
67
7
hose 10 m. orange
C 10 OU
150.570.043
81
G
Alternative set, replace items 3 and 4 for:
8
telescopic RAM jack
TR 4350 C
150.032.040
56
C
Optional set assist tools, consisting of:
item
description
art.nr.
page
A
tool station 200 x 150 cm
150.182.043
120
H
B
chocks set A
150.562.010
112
D
C
blocks set B
150.562.004
112
D
Secunet airbag safety cover
350.182.005
118
E
Safetypen
350.182.088
119
F
set protection covers SEP 5
150.581.676
120
G
protection shield
150.182.045
119
E
H
Glas-Master
150.182.060
118
7.2 Advisory rescue sets
85
Basic Medium Rescue set
1
8
5
8
7
2
Alternatives:
9
3
6
11
10
4
A
Basic Medium Rescue set, consisting of:
item
description
model
art.nr.
page
A random selection of tools
1
cutter
CU 4035 C NCT II
150.012.095
32
lying on a tool station.
2
spreader
SP 4240 C
150.012.105
40
3
set pulling attachments
150.582.006
40
4
set pulling chains
150.582.152
40
ram jack
RA 4331 C
150.032.046
50
extension pipe
165 mm
150.181.321
5
extension pipe
330 mm
150.181.322
54
F
extension pipe
600 mm
150.181.323
ram jack
RA 4322 C
150.032.041
52
6
ram support
HRS 22 NCT
150.003.105
113
7
Duo petrol pump
SR 20 PC 2
150.152.696
68
B
8
hose 10 m. orange (order 2 x )
C 10 OU
150.570.043
81
Alternative set, replace items 5, 7 and 8 for:
G
9
telescopic ram jack
TR 4350 C
150.032.040
56
10
Duo petrol pump
DPU 31 PC
150.152.180
64
hose reel with 2 x 15 m
11
HR 4515 COB
150.072.075
81
orange and blue hoses
C
Optional set assist tools, consisting of:
item
description
art.nr.
page
A
tool station 250 x 200 cm
150.182.044
120
H
B
chocks set A
150.562.010
112
C
blocks set B
150.562.004
112
D
Secunet airbag safety cover
350.182.005
118
D
E
Safetypen
350.182.088
119
F
set protection covers SEP 10
150.581.677
120
G
protection shield
150.182.045
119
H
Glas-Master
150.182.060
118
E
7.3 Advisory rescue sets
86
Advanced Medium Rescue set
6
6
1
7
8
2
3
9
4
11
10
5
Advanced Medium Rescue set, consisting of:
item
description
model
art.nr.
page
1
cutter
CU 4050 C NCT II
150.012.094
32
2
spreader
SP 4240 C
150.012.105
40
12
3
set pulling attachments
150.582.006
40
4
set pulling chains
150.582.152
40
5
cutting tip (order 2 x)
150.013.703
40
ram jack
RA 4331 C
150.032.046
50
extension pipe
165 mm
150.181.321
6
extension pipe
330 mm
150.181.322
54
extension pipe
600 mm
150.181.323
7
set pulling attachments*
150.582.281
54
ram jack
RA 4322 C
150.032.041
13
8
52
ram jack
RA 4332 C
150.032.047
9
ram support
HRS 22 NCT
150.003.105
113
10
mini cutter
CU 4007 C
150.012.232
34
11
Duo petrol pump
SR 20 PC 2
150.152.696
68
12
hose 10 m. orange (order 2 x)
C 10 OU
150.570.043
81
14
13
hand pump
HTW 1800 C
150.142.021
78
14
hose 5 m. orange
C 05 OU
150.570.042
81
* use pulling chains item 4
7.3 Advisory rescue sets
87
Alternative set, replace items 6, 7, 8, 11 and 12 for:
15
telescopic ram jack
TR 4340 C
150.032.039
extension pipe
250 mm
150.181.330
56
16
extension pipe
450 mm
150.181.331
17
telescopic ram jack
TR 4350 C
150.032.040
56
18
Duo petrol pump
DPU 31 PC
150.152.180
64
15
hose reel with 2 x 20 m
19
HR 4520 COB
150.072.076
81
orange and blue hoses
16
17
18
19
A
Optional set assist tools, consisting of:
item
description
art.nr.
page
A
tool station 250 x 200 cm
150.182.044
120
B
chocks set A
150.562.010
112
C
blocks set B
150.562.004
112
D
Secunet airbag safety cover
350.182.005
118
E
Safetypen
350.182.088
119
F
set protection covers SEP 10
150.581.677
120
G
protection shield
150.182.045
119
H
Glas-Master
150.182.060
118
A random selection of tools lying on a tool station.
B
C
D
E
F
G
H
7.4 Advisory rescue sets
88
Heavy Duty Rescue set
6
1
2
7
8
9
4
3
10
11
5
12
Heavy Duty Rescue set, consisting of:
item
description
model
art.nr.
page
16
1
cutter
CU 4055 C NCT II
150.012.166
32
2
spreader
SP 4260 C
150.012.110
42
3
set pulling attachments
150.182.021
42
13
4
set pulling chains
150.582.261
42
5
cutting tip (order 2 x)
150.013.166
42
ram jack
RA 4331 C
150.032.046
50
accessories in box
150.582.008
54
6
set pulling chains in box
150.582.021
54
14
ram jack
RA 4322 C
150.032.041
52
ram jack
RA 4332 C
150.032.047
52
7
ram support
HRS 22 NCT
150.003.105
113
8
mini cutter
CU 4007 C
150.012.232
34
15
9
wedge jack
PW 4624 C
150.062.046
106
10
special materials cutter
SMC 4006 C
150.012.189
104
11
petrol pump
SPU 16 PC
150.152.671
62
12
hose 5 m. orange
C 05 OU
150.570.042
81
13
Duo petrol pump
SR 20 PC 2
150.152.696
68
17
14
hose 10 m. orange (order 2 x)
C 10 OU
150.570.043
81
15
hand pump
HTW 1800 C
150.142.021
78
16
hose 5 m. orange
C 05 OU
150.570.042
81
17
hand operated combi tool
HCT 4120
150.012.146
91
7.4 Advisory rescue sets
89
Alternative set, replace items 6, 13 and 14 for:
18
telescopic ram jack
TR 4340 C
150.032.039
extension pipe
250 mm
150.181.330
56
19
extension pipe
450 mm
150.181.331
20
telescopic ram jack
TR 4350 C
150.032.040
56
18
21
Duo petrol pump
DPU 31 PC
150.152.180
64
hose reel with 2 x 20 m.
22
HR 4520 COB
150.072.076
81
orange and blue hoses
19
20
21
22
A
Optional set assist tools, consisting of:
item
description
art.nr.
page
A
tool station 250 x 200 cm
150.182.044
120
B
chocks set A
150.562.010
112
C
blocks set B
150.562.004
112
D
Secunet airbag safety cover
350.182.005
118
E
Safetypen
350.182.088
119
F
set protection covers SEP 10
150.581.677
120
G
protection shield
150.182.045
119
H
Glas-Master
150.182.060
118
A random selection of tools lying on a tool station.
B
C
D
E
F
G
H
8.1 Self-contained tools - Hand-operated cutter
90
HCU 4010 GP
Hand-operated cutter
specifications
HCU 4010 GP
article number
150.012.147
EN 13204 classification
AC116-D-10.3
max. working pressure
bar / MPa
720 / 72
blade opening
mm
142
cutting force
kN / t
254 / 25.9
round bar (acc. to EN 13204)
mm
24
weight, ready for use
kg
10.3
dimensions (L x W x H
mm
645 x 205 x 181
Cutter - accessories
360O rotatable and fold flat pump handle
√
description
art. nr.
temperature range
-20°C - +55°C
carrying strap
150.582.506
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
carrying harness
150.553.115
endurance test tool
1000 cycles of biting in material that cannot be cut
carrying / storage case
150.003.377
Features / Benefits
No separate pump and hose needed
Handle can rotate 180° and be folded up
180°
- ideal in confined spaces
8.2 Self-contained tools - Hand-operated combi tool
91
HCT 4120
Hand-operated combi tool
specifications
HCT 4120
article number
150.012.146
EN 13204 classification
BK26/268-E-10.8
max. working pressure
bar / MPa
720 / 72
spreading
mm
268
max. spreading force
kN / t
220 / 22.4
min. spreading force 1)
kN / t
26 / 2.7
cutting opening
mm
191
cutting force
kN / t
247 / 25.2
round bar ( acc to EN 13204 )
mm
24
squeezing force
kN / t
46 / 4.7
Combi tool - accessories
pulling distance
mm
181
desription
art.nr.
pulling force
kN / t
61 / 6.2
set pulling attachments 1)
150.582.551
weight, ready for use
kg
10.8
2 set pulling chains 3m + 1.5 m 1)
150.582.152
dimensions (L x W x H)
mm
698 x 205 x 181
case with set pulling attachments
360O rotatable and fold flat pump handle
√
150.582.028
and pulling chains 1)
temperature range
-20°C - +55°C
carrying / storage case
150.003.377
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
carrying harness 2)
150.553.115
endurance test tool
1000 cycles of spreading while the tool is loaded and
carrying strap 2)
150.582.506
1000 cycles of biting in material that cannot be cut
1) see also page 44
1) according to EN 13204: 25 mm from tips over full spreading range | tested according to EN 13204 and NFPA 1936
2) see also page 92
Features / Benefits
Non-slip carrying handle and perfect balance
Multi functional
- easy to manoeuvre
- easy to carry over difficult terrain
- spreading, cutting, squeezing and pulling
8.2 Self-contained tools - Hand-operated combi tools
92
Hand-operated combi tools
specifications
HCT 5111
HCT 5111 RH
HCT 5117
HCT 5117 RH
article number
150.012.262
150.012.258
150.012.263
150.012.259
max. working pressure
bar / Mpa
720 / 72
720 / 72
spreading
mm
281
431
max. spreading force
kN / t
457 / 46.6
54 / 5.5
min. spreading force 1)
kN / t
48 / 4.9
28 / 2.9
cutting opening
mm
196
352
cutting force
kN / t
206 / 21
204 / 20.8
round bar (acc. to EN 13204)
mm
24
24
squeezing force
kN / t
44 / 4.5
27 / 2,8
pulling distance
mm
--
426
pulling force
kN / t
--
30 / 3.1
weight ready for use
kg
8.7
9.4
dimensions (LxWxH)
mm
540x287x193
540x223x145
626x287x193
626x223x145
i-Bolt technology
√
√
√
√
carrying handle with integrated lighting
√
--
√
--
360° rotatable & fold flat carrying handle
--
√
--
√
360° rotatable & fold flat pump handle
√
√
√
√
temperature range
-20°C - +55°C
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
endurance test tool
1000 cycles of spreading while the tool is loaded and 1000 cycles of biting in material that cannot be cut
1) according to EN 13204: 25 mm from tips over full spreading range
HCT 5111 RH
HCT 5117 RH
HCT 5117
Hand-operated combi tools - accessories
for models
HCT 5111
HCT 5111 RH
HCT 5117
HCT 5117 RH
1
carrying harness
150.553.115
150.553.115
150.553.115
150.553.115
2
carrying strap
150.582.506
150.582.506
150.582.506
150.582.506
3
set pulling attachments
--
--
150.182.241
150.182.241
4
set pulling chains, 1.5 m + 3.0 m
--
--
150.582.548
150.582.548
5
5
carrying/storage bag
150.182.228
150.182.227
150.182.228
150.182.227
3
4
1
2
8.2 Self-contained tools - Hand-operated combi tools
93
HCT 5111
Features / Benefits
Extremely compact & ultra-lightweight
Multifunctional
- weights only 8.7 to 9.4 kg
- 5117 models also suitable for pulling
- easy to carry, handle, transport and store
- suitable for a variety of operations, from rapid intervention to
- ideal for use in confined spaces or at remote locations
USAR
- you can cut/spread open a modern vehicle with just one tool
Non-slip selection ring
- suitable for dive operations / under water use
- easy, intuitive selection of cutting or
spreading function
- offers good grip
Optional: 360° rotatable, flat foldable carrying handle
- continuous swivel with 11 locking positions for use of the tool at
almost any angle
- collapsible for extra compact transporation and storage
Self-contained and ergonomic
- rapid deployment: simply fold out the pump handle and start
pumping
- pump handle 360° rotatable and lockable in 22 positions for use of
the tool in any position
- pump handle also flat foldable for compact transportation and
storage
8.3 Self-contained tools - hand operated wedge
94
HPW 4624
Hand-operated Power Wedge
Power Wedge - accessories
specifications
HPW 4624
description
art. nr.
article number
150.062.132
carrying strap
150.582.506
max. working pressure
bar / MPa
720 / 72
carrying harness
150.553.115
carrying / storage case
150.003.375
cylinder
double acting
min. insertion height
mm
6
max. lifting height
mm
51
spreading force
kN / t
253 / 25.8
wedge angle
15°
weight ready for use
kg
11.8
dimensions (L x W x H)
mm
713 x 270 x 197
carrying handle with integrated lighting
√
temperature range
-20°C - +55°C
Features / Benefits
Handle foldable and rotatable
Self-contained
Small insertion height with high
spreading force
A Power Wedge is the first tool to use in
a lifting
- also easy to use in confined spaces
operation. It creates an initial gap for positioning
other equipment such as spreaders or lifting bags.
- easy carrying and storage
- can be used in any position
Enough space created to insert other lifting equipment
8.4 Self-contained tools - Greenline battery driven cutters
95
GCU 4050 NCT II
Battery driven cutters - exclusive battery
Batteries - required articles
specifications
GCU 4035 NCT II
GCU 4050 NCT II
description
art. nr.
article number
150.052.031
150.052.027
battery BPA 28-4 (4.1 Ah)
150.005.214
battery BPA 28-3 (3.0 Ah)
150.005.823
max. working pressure
bar / MPa
720 / 72
720 / 72
blade opening
mm
159
181
cutting force
kN / t
355 / 36.2
927 / 94.5
Battery driven cutters - accessories
round bar (acc. to EN 13204)
mm
32
41
description
art. nr.
weight ready for use 1)
kg
19.2
22.7
battery charger BCH 1 (220 - 240 VAC)
150.182.208
dimensions (LxWxH)
mm
829x297x217
890x297x217
battery charger BCH 2 (100 - 120 VAC)
150.182.209
i-Bolt technology
√
√
mains power connector BMC 1 (220 - 240 VAC)
150.182.206
carrying handle with integrated lighting
√
√
mains power connector BMC 2 (100 - 120 VAC)
150.182.207
temperature range
-20°C - +55°C
battery pouch
150.182.214
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
carrying harness
150.553.115
endurance test tool
1000 cycles of biting in material that cannot be cut
carrying/storage bag
150.182.228
endurance test dead man's handle
6000 cycles
carrying strap
180.182.249
1) inclusive battery
Features / Benefits - Greenline battery driven tools
Powered by lithium-ion battery technology
Ergonomic and user-friendly
- high battery capacity for long operation time
- well-balanced
- low self-discharge rate for long battery life
- control handle on back of tools so you can rotate them freely while
- no memory effect
your hand stays in the same position
- no energy consumption when idle
- battery on top of tools: Easy to change, even in narrow spaces
- LED indicator shows battery capacity during use; when tool is not
used or when battery is not on tool, press button on battery to
check state of charge level
- battery 100% rechargeable in 60 minutes
- easy click-on / click-off system on top to change battery with one
hand, within seconds
- suitable for air transportation
- suitable for use at high altitudes
8.5 Self-contained tools - Greenline battery driven spreader
96
GSP 4240
Battery driven spreader - exclusive battery
Batteries - required articles
specifications
GSP 4240
description
art. nr.
battery BPA 28-4 (4.1 Ah)
150.005.214
article number
150.052.026
battery BPA 28-3 (3.0 Ah)
150.005.823
max. working pressure
bar / Mpa
720 / 72
spreading
mm
686
Battery driven spreader - accessories
max. spreading force
kN / t
206 / 21.0
description
art. nr.
max. spreading force 1)
kN / t
73 / 7.4
battery charger BCH 1 (220 - 240 VAC)
150.182.208
min. spreading force 2)
kN / t
43 / 4.4
battery charger BCH 2 (100 - 120 VAC)
150.182.209
squeezing force
kN / t
65 / 6.6
mains power connector BMC 1 (220 - 240 VAC)
150.182.206
pulling distance
mm
466
mains power connector BMC 2 (100 - 120 VAC)
150.182.207
pulling force
kN / t
90 / 9.2
spreading tip, with extra long tooth
150.183.189
weight ready for use 3)
kg
23.3
cutting tip
150.013.703
dimensions (LxWxH)
mm
884x316x232
set pulling attachments
150.582.006
built-in Speed Valve
√
set pulling chains, 1.5 m + 3.0 m
150.582.152
carrying handle with integrated lighting
√
set pulling chains, in case
150.582.021
temperature range
-20°C - +55°C
battery pouch
150.182.214
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
carrying harness
150.553.115
endurance test tool
1000 cycles of spreading and pulling while the tool is loaded
carrying strap
180.182.249
endurance test dead man's handle
6000 cycles
1)
25 mm from the tips | 2) according to EN 13204: 25 mm from tips over full spreading range
| 3) inclusive battery
Features / Benefits - Greenline battery driven tools
Emission-free
- no fumes from a pump: healthier for rescuers and victims
- ideal for use in confined and/or underground spaces like tunnels,
busses, trains and collapsed buildings
- environmentally friendly
All weather proof
- suitable for use at below zero temperatures, up to -20°C
- suitable for use in wet weather conditions
8.6 Self-contained tools - Greenline battery driven rams
97
GRA 4321
Battery driven rams - exclusive battery
Batteries - required articles
specifications
GRA 4321
GRA 4331
description
art. nr.
article number
150.052.029
150.052.028
battery BPA 28-4 (4.1 Ah)
150.005.214
battery BPA 28-3 (3.0 Ah)
150.005.823
operator type
battery
battery
number of plungers
1
1
max. working pressure
bar/Mpa
720 / 72
720 / 72
Battery driven rams - accessories
spreading force over full stroke
kN / t
161 / 16.4
161 / 16.4
description
art. nr.
spreading / pulling stroke
mm
250
350
Battery charger BCH 1, 220-240V
150.182.208
retracted length
mm
566
691
Battery charger BCH 2, 100-120V
150.182.209
extended length
mm
816
1041
Mains power connector BMC 1
150.182.206
pulling force over full stroke
kN / t
50 / 5.1
50 / 5.1
Mains power connector BMC 2
150.182.207
weight excl. battery
kg
17.5
18.3
Battery pouch
150.182.214
weight, ready for use 1)
kg
18.4
19.2
Ram support HRS 22 NCT
150.003.105
dimensions (LxWxH)
mm
566 x 452 x 234
691 x 452 x 234
Ram support HRS 22
150.181.011
temperature range
-20 °C + 55 °C
-20 °C + 55 °C
Extension pipe 165 mm
150.181.321
sound emission at 4 m / 1m (loaded)
dB(A)
65 / 74
65 / 74
Extension pipe 330 mm
150.181.322
Extension pipe 600 mm
150.181.323
1) inclusive battery
Wedge piece
150.181.324
Conical tip
150.181.325
Base plate round
150.181.326
Connection piece
150.181.327
Pulling chains set 1.5m + 3.0m
150.582.152
Pulling chains set, in case
150.582.021
Accessories set, in case
150.582.008
Pulling attachments set
150.582.281
Rim adapter set, in case
150.182.580
Features / Benefits - Greenline battery driven tools
Carrying handle with integrated
Wide variety of other accessories
LED lighting
- including different heads, a base plate, ram supports and pulling
- provides illumination when rescue scene
accessories
lighting is (still) absent
- to increase your options in various rescue situations
- never work in your own shadow by day
8.7 Self-contained tools - Battery dri
ven combi tools
98
Battery driven combi tools
specifications
GCT 4120
GCT 4150
GCT 5111
GCT 5117
article number
150.052.038
150.052.032
150.052.036
150.052.037
max. working pressure
bar / Mpa
720 / 72
720 / 72
720 / 72
720 / 72
spreading
mm
268
360
281
431
max. spreading force
kN / t
220 / 22.4
211 / 21.5
457 / 46.6
54 / 5.5
min. spreading force 1)
kN / t
26 / 2.7
35 / 3.6
48 / 4.9
28 / 2.9
cutting opening
mm
191
229
196
352
cutting force
kN / t
247 / 25.2
380 / 38.7
206 / 21
204 / 20.8
round bar (acc. to EN 13204)
mm
24
32
24
24
squeezing force
kN / t
46 / 4.7
76 / 7.7
44 / 4.5
27 / 2.8
pulling distance
mm
181
416
--
426
pulling force
kN / t
61 / 6.2
51 / 5.2
--
30 / 3.1
weight ready for use 2)
kg
14.5
19.9
13.7
14.4
dimensions (LxWxH)
mm
789x297x207
901x297x212
677x295x204
775x295x204
i-Bolt technology
--
√
√
√
carrying handle with integrated lighting
√
√
√
√
temperature range
-20°C - +55°C
hydraulic safety factor
2 x max. working pressure of 720 bar = 1440 bar
endurance test tool
1000 cycles of spreading while the tool is loaded and 1000 cycles of biting in material that cannot be cut
endurance test dead man's handle
6000 cycles
1)
according to EN 13204: 25 mm from tips over full spreading range | 2) inclusive battery
Batteries - required articles
description
art. nr.
battery BPA 28-4 (4.1 Ah)
150.005.214
battery BPA 28-3 (3.0 Ah)
150.005.823
GCT 4120
Battery driven combi tools - accessories
for models
GCT 4120
GCT 4150
GCT 5111
GCT 5117
1
battery charger BCH 1 (220 - 240 VAC)
150.182.208
150.182.208
150.182.208
150.182.208
2
battery charger BCH 2 (100 - 120 VAC)
150.182.209
150.182.209
150.182.209
150.182.209
3
mains power connector BMC 1 (220 - 240 VAC)
150.182.206
150.182.206
150.182.206
150.182.206
4
mains power connector BMC 2 (100 - 120 VAC)
150.182.207
150.182.207
150.182.207
150.182.207
5
set pulling attachments
150.582.551
150.582.026
--
150.182.241
6
set pulling chains, 1.5 m + 3.0 m
150.582.152
150.582.152
--
150.582.548
7
pulling set, in case
150.582.028
150.582.018
--
--
8
battery pouch
150.182.214
150.182.214
150.182.214
150.182.214
9
carrying harness
150.553.115
150.553.115
150.553.115
150.553.115
10
carrying strap
180.182.249
180.182.249
180.182.249
180.182.249
11
carrying/storage bag
150.182.228
150.182.228
150.182.228
150.182.228
1-2
3-4
5
6
7
8
9
10
11
8.7 Self-contained tools - Greenline battery driven combi tools
99
GCT 5111
Features / Benefits - Greenline battery driven combi tools 5000-series
Optimal performance to weight ratio
Equipped with iBolt
- extremely high spreading force compared to size and weight
- flat central bolt construction for better access to narrow spaces
(model GCT 5111)
- squeezes the blades together directly, which resluts in less blade
- extremely high spreading distance compared to size and weight
separation and a better cutting performance
(model GCT 5117)
- high cutting force compared to size and weight (both models)
Multifunctional
- one tool for cutting, spreading and squeezing
- model GCT 5117 also suitable for pulling
- suitable for a variety of operations, from rapid intervention to USAR
- you can gain access to a modern vehicle with just one tool*
- your choice: GCT 5111 for highest spreading force, GCT 5117 for
highest spreading distance
* tested on a 2014 model Opel Insignia, avoiding the pillars
Lowest sound level
- less stressful for victims
- easier communication between rescuers and victims
- equipment produces no sound when idle
Self-contained
- for optimal freedom of movement
- rapid deployment: simply press the start button and start working
9.1 Door openers
100
Door opener HDR 50
Door opener HDR 50 - pump
specifications
HDR 50
hand pump with operating set,
model HTW 700 ADCV
article number
150.061.002
article number
150.062.009
spreading jack
pushing jack
max. working pressure
bar / MPa
720 / 72
max. working pressure
bar / MPa
720 / 72
720 / 72
pump
two-stage
capacity
kN / t
47 / 4.8
51 / 5.2
usable oil contents
cc
700
return of plunger
spring return
gravity return
weight, ready for use
kg
8.0
hydraulic system
single acting
single acting
temperature range
-20°C - +55°C
pushing length
mm
--
300
see also HTW 700 ABU, page 78
min. length including grip heads
mm
710
--
Pump supplied with 2 m. orange hose connecting the operating valve
mechanically extendible in 4 steps of 50 mm
mm
50 - 100 - 150 -200
--
DCV 720 U to the pump.
hydraulically extendible
mm
125
--
max. width between doorposts (excl. extension)
mm
1035
--
max. width between doorposts (incl. extension)
mm
1310
--
weight, ready for use
kg
11.0
required oil content (effective)
cc
295
temperatue range
-20°C - +55°C
hydraulic safety factor
2 x 720 bar = 1440 bar
HTW 700 ADCV
safety factor hoses
4:1= 2880 bar
Door opener HDR 50 consisting of
synthetic carrying/storage box, dimensions in mm (L x W x H)
600 x 400 x 184
hydraulic spreading jack with 2 steel grip heads, mounted with
blue hose 2 m. with
standard coupler
hydraulic pushing jack, mounted with: - aluminium pushing plate
rectangular 150 x 50
and with
mm, black
- connection hose,
red, with standard
length 1.76 m.
coupler
adjustable carrying strap
black
- easy to store and easy to transport
Door opener HDR 50 - accessories - with unique quick lock system
item
art.nr.
extension piece 275 mm, black. To be mounted on the end of the spreading jack to increase the maximum reach.
1
150.063.031
steel grip head with extra long tooth. Provides extra grip on narrow doorposts. The extra long tooth penetrates the crack between door and doorpost.
2
150.063.011
steel round grip head. With recess for round pushing plate.
3
150.000.262
steel grip head with extra long tooth. With recess for round pushing plate. Provides extra grip on narrow doorposts. The extra long tooth penetrates
4
150.000.259
the crack between door and doorpost.
steel wedge head. To be used on narrow or slippery (steel) doorposts.
5
150.063.010
steel corrugated grip head. With recess for round pushing plate.
6
150.000.261
steel rectangular pushing plate, with rubber layer, 150 x 50 mm. For weak, flexible doors, open structure doors, gates etc.
7
150.063.032
steel round pushing plate, with rubber layer. For use in combination with recessed grip heads.
8
150.000.266
operating set DCV 720 U with orange hose 2 m. In case another single acting pump is used.
9
150.061.005
2
3
9
5
6
8
4
1
7
- accessories can be mounted within seconds
9.1 Door openers
101
spreading
pushing
HDR 50
Features / Benefits
Versatile and lightweight
Many possibilities to adapt to every size door
- spreading jack manually extendible in 4 positions over 200 mm and
hydraulically extendible with extra 125 mm
Quick-lock connection system
- opens every inward opening door, regardless of locks, door-chains or
catches, in less than 30 seconds
- extra long stroke of 300 mm will also brake longer chains
- easy to carry and very quick to install
- accessories can be changed
in a second
9.1 Door openers
102
Door opener HDO 100
specifications
HDO 100
article number *
150.062.007
max. working pressure
bar / MPa
720 / 72
hydraulic system
single acting
spreading force
kN / t
100 / 10.2
150.062.007
retracted length
mm
300
stroke
mm
130
max. length
mm
430
weight, ready for use
kg
6.7
dimensions (L x W x H)
mm
300 x 120 x 154
required oil content
cc
207
temperature range
-20°C - +55°C
* 150.062.007 = with rotating hose connection and handle, delivered in synthetic
carrying / storage box
150.062.008
150.062.008 = with 30 cm. pigtail hose, without handle
150.062.123 = with flexible 360° rotating connection hose , length 30 cm, and rotating
handle + hand pump HTW 300 ABU + 3 m single hose B 3 SOU in
synthetic carrying box.
Recommended pumps
specifications
HTW 300 ABU
AHS 1400 FDU
article number
150.449.001
150.602.001
max. working pressure
bar / MPa
720 / 72
720 / 72
weight ready for use
kg
4.0
6.5
see also page
78
76
For single hoses see page 83.
150.062.123
Features / Benefits
Versatile
Rotatable handle
360°
- 360° rotatable handle for optimal ease of installation
High pushing force
- opens every inward opening door, regardless of locks, door-chains or
catches in less than 30 seconds
- opens doors and breaks door-chains very quickly
9.2 Concrete Crusher
103
CC 20 C
Concrete crusher
specifications
CC 20 C
equipped with
CORE
article number
150.012.234
max. working pressure
bar / MPa
720 / 72
max. opening
mm
230
crushing force
kN / t
68 / 6.9
shape of tip
pointed
required oil content
cc
132
weight ready for use
kg
22.9
dimensions (L x W x H)
mm
880 x 440 x 210
temperature range
-20°C - +55°C
also available in dual hose version
√
Features / Benefits
Heavy duty
Ideal combination
Limited dust
- a perfect combination: crushing concrete
with the CC 20 C and cutting re-bar with
mini cutter CU 4007 C (or SMC 4006 C).
- designed to quickly break away
large, thick pieces of concrete
- supports a clear view at the rescue scene
9.3 Special Materials Cutter
104
Special Materials Cutter
specifications
SMC 4006 C
equipped with
CORE
article number
150.012.189
max. working pressure
bar / Mpa
720 / 72
blade opening
mm
25
max. cutting force
kN / t
193 / 19.7
weight, ready for use
kg
6.8
dimensions (L x W x H)
mm
389 x 114 x 234
required oil content
cc
10
temperature range
-20°C - +55°C
SMC 4006 C
also available in dual hose version
√
Application
Cutting performance
Materials
Materials exceeding
Cutting
according to EN
EN13204 in terms of
performance
Re-bar
13204; S235
hardness
68
60
60 HRc
Ø 8.5 mm
50
49 HRc
Ø 12 mm
40
130
30
28 HRc
Ø 16 mm
Padlock
100
22
75
75 HRb
Ø 20 mm
50
Special Materials Cutter - accessories
25
description
art. nr.
0
100 HRb = 22 HRc
Chain
carrying / storage case
150.003.379
Features / Benefits
Lightweight
Special blade and jaw design
Compact
- re-bar, chain and padlock can easily be cut
- for use in confined spaces
Adjustable rotating carrying handle
360°
- simplifies cutting at various angles
- easy to carry, also over rough terrain
- easy to use in any position
- for easy positioning in confined spaces
9.4 Minicutter
105
1
Minicutter
specifications
HMC 8 U
article number
150.012.025
2
max. working pressure
bar / MPa
720 / 72
cylinder (spring return)
single acting
max. cutting force
kN / t
79 / 8.1
max. depth of jaw
mm
40
width of jaw
mm
40
weight, ready for use
kg
3.0
dimensions (L x W x H)
mm
333 x 62 x 86
3
required oil content
cc
43
temperature range
-20°C - +55°C
For required hand pump HTW 300 ABU or bigger see page 78.
For single hoses see page 83.
Minicutter HMC 8 U in various versions
1
with fixed coupler
150.012.025
2
with 30 cm. pigtail hose in synthetic case
150.012.026
with 360° rotation elbow and 30 cm pigtail hose in
3
150.012.027
synthetic case
4
with 360° rotation elbow and hand pump HTW 300
4
150.012.028
ABU, mounted with 2 m. hose, in synthetic case
Features / Benefits
Compact and lightweight
8 tons capacity
- easy to use in confined and difficult te reach spaces
- cuts car pedals, steering wheels etc.
9.5 Power Wedge
106
PW 4624 C
Power Wedge
specifications
PW 4624 C
equipped with
CORE
article number
150.062.046
max. working pressure
bar / MPa
720 / 72
cylinder
double acting
min. insertion height
mm
6
max. lifting height
mm
51
spreading force
kN / t
253 / 25.8
wedge angle
15°
weight, ready for use
kg
9.5
dimensions (L x W x H)
mm
672 x 225 x 186
required oil content
cc
122
Power Wedge - accessories
temperature range
-20° C - +55° C
description
art. nr.
also available in dual hose version
√
carrying / storage case
150.003.375
For required hand pump HTW 300 ABU or bigger see page 78.
For hoses see pages 81.
Features / Benefits
Just 6 mm insertion height
Lifting height 51 mm
- enough to free trapped victims or to install a Holmatro spreader or high pressure lifting bag
- can be inserted in places where no other lifting
device can be used
9.6 Pipe squeezer
107
Pipe squeezer
specifications
HPS 60 AU
article number
150.182.024
max. working pressure
bar / MPa
720 / 72
HPS 60 AU
cylinder (spring return)
single acting
max. squeezing force
kN / t
147 / 15.0
max. outside diameter pipe
mm
60
max. wall thickness pipe
mm
4
remaining opening
mm
2
weight, ready for use
kg
8.6
dimensions (L x W x H)
mm
420 x 216 x 155
required oil content
cc
130
temperature range
-20°C - +55°C
For required hand pump HTW 300 ABU or bigger see page 78.
For single hoses see page 83.
Features / Benefits
Large squeeze surface
Easy to install
60 mm
- squeezes pipes with a maximum diameter of 60 mm
- can be opened and closed by hand very quickly without any tools
Prevents/limits potentially dangerously situations
Environmentally friendly
- saves costs in case of fire or other emergency
- limits leaking of dangerous liquids
9.7 Cable cutters
108
HWC 16 R
HCC 85 R
HWC 25 R
HCC 100 R
HWC 32 R
Cable cutters
Steel cable cutters
Electric cable cutters
specifications
HWC 16 R
HWC 25 R
HWC 32 R
HCC 85 R
HCC 100 R
article number
150.012.266
150.012.267
150.012.268
150.012.269
150.012.270
working pressure
bar / MPa
720 / 72
720 / 72
720 / 72
720 / 72
720 / 72
capacity
kN / t
52 / 5.3
146 / 14.9
249 / 25.4
49 / 5
87 / 8.9
max. jaw opening
mm
20
50
32
85
100
capacity steel cable 6 x 19
Ø mm
20
30
32
-
-
capacity solid steel
Ø mm
13
19
25
-
-
capacity ground cable
Ø mm
18
50
32
50
75
capacity telephone cable
Ø mm
-
-
-
85
100
weight, ready for use
kg
2.0
8.4
8.9
6.8
12.7
dimensions (L x W x H)
mm
260 x 54 x 75
441 x 91 x 210
358 x 90 x 156
501 x 77 x 245
545 x 86 x 263
required oil content
cc
49
106
135
65
140
temperature range
-20°C - +55°C
For required hand pump HTW 300 ABU or bigger see page 78. For single hoses see page 83.
Features / Benefits
All models can be folded open in a second
Delivered in carrying bag
All models with
hardened cutting blade
- easy to install around cables
- longer life span
9.8 Toe jack
109
Toe jack
specifications
TJ 3610
article number
150.012.049
working pressure
bar / MPa
720 / 72
max. lifting capacity on saddle
kN / t
118 / 12.0
max. lifting capacity on toe
kN / t
98 / 10.0
closed height
mm
448
lifting height / plunger stroke
mm
250
max. lifting height on saddle
mm
698
min. insertion height toe
mm
56
max. lifting height on toe
mm
306
weight, ready for use
kg
20.5
dimensions (L x W x H)
mm
300 x 160 x 448
required oil content
cc
415
temperature range
-20°C - +55°C
TJ 3610
Features / Benefits
High lifting power
12 t
10 t
Compact and lightweight rescue lifting jack can be used with:
HTW 700 ABU
HTW 1800 ABU
HTT 1800 U
- hand pump HTW 700 ABU and single
- hand pump HTW 1800 ABU and single
- hand pump HTT 1800 U and single hose
hose (for technical details see pages 78
hose (for technical details see pages 78
(for technical details see pages 77 and
and 83)
and 83)
83)
9.9 Aluminium jacks
110
Aluminium jacks
specifications
HLJ 50 A 6
HLJ 50 A 10
article number
150.112.060
150.112.059
working pressure
bar / MPa
720 / 72
720 / 72
return of plunger *
air
air
lifting capacity
kN / t
510 / 52
510 / 52
closed height
mm
150
196
stroke
mm
61
104
weight, ready for use
kg
7.0
8.7
dimensions ( L x W x H )
mm
279 x 214 x 150
279 x 214 x 196
required oil content
cc
432
709
HLJ 50 A 6
temperature range
-20°C - +55°C
-20°C - +55°C
*Return of the plunger by the 6 bar air pressure in the jack. Easy to fill with air pump HAP 10 U
(art.nr. 350.542.005) when the unloaded return becomes slower.
For required hand pump see page 78. For single hoses see page 83.
HLJ 50 A 10
Features / Benefits
Working as a team
Jacks with tilting saddle
- larger model fits in opening created by the smaller model
- adapt themselves to loads at an angle of 5° maximum
Compact jacks with 2 large handles
- easy to install in small spaces in even the most difficult circumstances
9.10 Hydraulic jack set
111
12
14
13
11
10
9
8
16
6
7
5
15
4
3
2
1
Hydraulic jack set HRK 10 U, art. nr. 150.062.011, consisting of:
Hydraulic jacks
HCJ 10 S 6
HCJ 10 S 15
Hydraulic wedge
HW 1000
specifications
nr. 13
nr. 14
specifications
nr. 15
article number
150.062.114
150.062.115
article number
150.562.012
working pressure
bar / MPa
720 / 72
720 / 72
working pressure
bar / MPa
720 / 72
max. lifting capacity
kN / t
99 / 10.1
99 / 10.1
minimum insertion height
mm
15
closed height
mm
202
292
maximum lifting height
mm
90
stroke plunger
mm
60
150
spreading force *
kN / t
10 / 1.0
weight, ready for use
kg
3.5
5.1
weight, ready for use
kg
2.1
required oil content
cc
83
207
required oil content
cc
10
temperature range
-20°C - +55°C
temperature range
-20°C - +55°C
Both jacks with standard saddle for normal lifting applications. Both jacks
*Spreading force is over the full spreading range, measured at
have thread on the plunger head, on the jack housing and in the jack
10 mm from the tip.
base to screw on the various accessories. Never use a jack without an
Wedge is single acting with spring return.
accessory mounted on the plunger head.
Jacks are single acting with spring return.
Hydraulic hand pump
HTS 550 A
Accessories
specifications
nr. 16
item
qty.
description
art. nr.*
article number
150.142.033
1
1
plunger toe to push out of centre. Attention: max. capacity 5 tons only!
150.581.662
working pressure
bar / MPa
720 / 72
2
1
jack toe to push out of centre. Always to be used with plunger toe nr.1.
100.581.515
oil content
cc
550
3
2
flat base to mount on the bottom side of the jacks. Provides a larger base.
100.181.512
weight, incl. oil
kg
6.0
4
1
spreading head
100.581.525
On the pump a hydraulic hose is mounted,
5
2
cross head for even better grip
100.181.516
length 2 meters, with anti-kink springs on both
6
2
connection socket, 2 x female thread. To connect 2 extension pipes.
100.181.510
ends and a quick coupler on the end.
7
2
connection nipple, 2 x male thread. To connect 2 items with female thread.
100.181.515
8
1
extension pipe 125 mm
100.181.501
to be mounted only on
9
1
extension pipe 250 mm
100.181.502
the bottom side of the
10
1
extension pipe 500 mm
100.181.503
jacks
11
1
extension pipe 750mm
100.181.504
12
1
steel storage / carrying case
150.581.001
*art. nr. per 1 piece
10.1 Assist tools
112
Chocks & Blocks
SET A - art. nr. 150.562.010
item
qty.
description
weight kg
art. nr.*
A
2
step chock
6.3
150.563.060
B
2
wedge small
0.5
150.563.049
C
2
wedge large
1.0
150.563.050
SET B - art. nr. 150.562.004
item
qty.
description
weight kg
art. nr.*
B
2
wedge small
0.5
150.563.049
C
2
wedge large
1.0
150.563.050
D
2
lock block low
1.0
150.563.061
lock block
E
2
2.0
150.563.071
medium
F
2
lock block high
3.0
150.563.073
*art. nr. per 1 piece
Set A:
2 x A
270
95
755
75
150
2x B
230
150
75
75
230
2 x C
Set B:
2 x F
75
2 x E
2 x D
50
25
230
75
2 x B
230
75
150
75
230
2 x C
Features / Benefits
Made of recycled polyethylene
- environment-friendly, 100% re-usable
One-piece moulding
- virtually indestructible, longer life span than hardwood
Interlocking profile
- do not slip away thanks to unique profile design
Non-absorbent material
- water- and oil-resistant
Lightweight
- floats on water
Higher allowable surface pressure than wood
- 100 kg/cm2 in all directions
20% higher friction coefficient than wood
- more grip
10.2 Assist tools
113
Ram support
specifications
HRS 22 NCT
article number
150.003.105
maximum load
kN / t
220 / 22.4
dimensions (L x W x H)
mm
450 x 150 x 280
weight ready for use
kg
14.9
Features / Benefits
Wider ram support
Teeth provide grip
Can be used in different orientations
- ensures that the ram support will not slip or tilt
- also perfect for use on smaller sills and B-
pillars of older model cars
- for wider door sills and B-pillars of new
Bars with profile
model cars
- vertical position in small door opening
- horizontal position in large door opening
- the ram always stays centrally positioned
- prevents tilting of ram support
10.2 Assist tools
114
Ram support
specifications
HRS 22
article number
150.181.011
maximum load
kN / t
216 / 22
dimensions (L x W x H)
mm
400 x 106 x 240
weight, ready for use
kg
7.7
Features / Benefits
Offers a stable ramming platform
Three different ramming platforms
- force of the ram is distributed over a larger area
- a larger opening can be created with 1 ram
- ram can be positioned both horizontally and vertically
Side plates widen out at the base
- fits every door post
10.3 Assist tools
115
Rim adapter
specifications
article number
150.182.580
weight complete set, incl.case
kg
12.4
length tensioning belt
m
4
force tensioning belt
kN / t
10 / 1
5
Rim adapter consisting of:
nr.
description
art. nr.
Tilting saddle that can be mounted on the
1
150.182.047
3
head of a ram
Adapter for rim and steering column to be
2
150.181.328
4
mounted on the other side of the ram
Support plate to provide a solid base for
3
150.011.519
the ram, even in loose soil
Two tensioning belts to secure the support
4
390.511.073
plate to the truck
2
1
5
Synthetic storage and carrying case
150.581.078
The rim adapter set fits on every 16.4 tons Holmatro ram.
See pages 50 and 52.
Features / Benefits
Can be installed without the rescuer having to
Lifting operation can be controlled precisely with
move under the truck
the deadmans handle of the ram
- safe
Versatile
- steering columns of trucks
can also be pushed away in a
controlled manner
- safe for operator and victim
The Holmatro rim adapter set is an innovative solution for quick and
safe creation of space under heavy goods vehicles. Victims often lie
near or under the rear axle. When dealing with heavy goods vehicles
lifting the chassis to create space below the axle requires lots of lift
and often leads to unsafe situations. With the help of the Holmatro
rim adapter set the rear wheel is lifted in a stable way into its suspen-
sion which creates space.
10.4 Assist tools
116
V-Strut
specifications
article number
150.062.158
max. axial load
kN / t
16 / 1.6
closed length
mm
1080
number of stroke steps
24
stroke step size
mm
30
total stroke
mm
720
extended length
mm
1800
weight
kg
7.9
dimensions (L x W x H)
mm
1080 x 149 x 210
length tensioning belt
m
5
V-Strut - accessories
item
description
art. nr.
1
sheet metal knife
150.062.183
2
base support plate
150.011.519
1
2
Features / Benefits
Unique auto-lock system
Serrated, multi-purpose head
- pulls out and locks automatically in one movement
- for optimal grip on all types of vehicles
- locking holes over the full strut length at very small intervals
- enables fine length adjustment for accurate positioning of the strut
Snap hook
- for fast and easy detachment and reattachment
Squeeze and push mechanism
Tensioning belt
- to release the strut quickly and easily after use
- tensioning belt with hook and ratchet mechanism
- for quick and easy attachment to the car
- enables the rapid creation of a stable triangle
Extremely lightweight
Heat resistant cover
- easy to carry
- slideable, heat-resistant protection cover around tensioning belt
- easy to work with
- protects the belt against hot exhausts
High shoring capacity
Base plate with non-slip profile
-
up to 16 kN shoring load
- for optimal grip on all surfaces
- enough to stabilize any type of car
10.5 Assist tools
117
Modern vehicles present the rescuer with many challenges. The presence of passive safety
systems such as airbags and seatbelt pre-tensioners, which must be identified and located,
coupled with stronger construction means that modern vehicles are now more difficult to
access. In order to perform a safe and timely extrication, you need the right equipment for
the job. Choosing the proper assist tools is just as important as using the correct hydraulic
rescue tools. However, these assist tools are often overlooked and constantly misplaced
at the scene of the rescue.
With the Rescue Support Bag, these helpful tools are there when you need them, in one
place and always ready for use.
Rescue Support Bag
art. nr.
Features / Benefits
RSB 1
150.182.155
- Bag made of high-quality, rugged,
Consisting of
light weight and flexible material
Item
description
function
that is fire-resistant and water-
Removal of tyre valves for
repellent.
1
tyre deflator
150.003.213
pneumatic stabilization.
- Flap with Velcro fastening.
- Flap can be fold down and stays
2
seatbelt cutter
Cutting seatbelts.
980.005.022
open because of an extra Velcro
strip on the inside of the flap.
To remove interior trim e.g.
- Waist and thigh straps are
3
trim removal hook
150.003.210
rubber seals and plastic trim.
adjustable.
- Extra section in front of bag.
To remove interior trim e.g.
4
trim removal fork
150.003.209
screw covers and plugs.
5
window punch
Glass management.
980.005.045
To measure distances from
6
flexible steel rule
590.000.109
hazards.
To mark cut points away from
hazard areas or for recording
7
marker pen
150.003.212
other critical information such
as patient observations.
Allows for extra visibility in
8
mini LED torch
980.000.352
dark areas.
Cutting away interior trim,
9
multi-cutter
150.003.211
rubber and fabric.
bag inclusive waist
For well-organized storage of
10
150.003.215
and thigh straps
the tools.
10.6 Assist tools
118
-Fast
Glas-Master
-Effective
specifications
Glas-Master
-Versatile
article number
150.182.060
dimensions (L x W x H)
mm
420 x 245 x 35
weight, ready for use
kg
1.0
The Glas-Master is delivered including a window punch and
mounting clips
-Safe
- catches large amounts of glass
Glass cutter
fragments and dust
specifications
HGC 7
-Quick - cuts glued or laminated windshields
article number
150.012.410
in a very short time
weight, ready for use
kg
1.6
-Silent - hand-operated ratchet mechanism
Secunet airbag safety cover
specifications
Secunet
article number
350.182.005
weight, ready for use
gr
250
Secunet is delivered in a synthetic storage box and with a wall-mounting bracket
for installation of storage box in rescue vehicle.
Features / Benefits
- special woven fibre cloth
• strong - soft - resistant to high temperatures
- also covers part of steering column
• no gas and parts of steering wheel or column can escape
- reduces sound level of airbag activation
- easy to install, within seconds
- lightweight and compact
- suitable for all passenger cars and modern vans
10.6 Assist tools
119
Safetypen
specifications
Safetypen
article number
350.182.088
dimensions (L x W x H)
mm
113 x 32 x 23
weight ready for use
kg
0.065
Features / Benefits
One tool, two functions
- Combination of window punch and seat belt cutter
Durable punch
- Easily breaks tempered glass*
- With special coating for improved corrosion resistance
* Tested on 10 mm thick car windows
Ultra-sharp cutting edge
- To cut seat belts in a smooth way
Smart design
- Protects cutting edge to avoid contact with fingers
Hose binder
specifications
hose binder
article number
150.182.039
150.182.040
number
5 x
20 x
Features / Benefits
- special loop for attachment over coupler
- with an eye to store hoses in hanging position
• binder remains attached to hose and does not get lost
• saves space and prevents damage
- made of strong durable nylon
- with Velcro fastening
- for hoses lengths 5, 10 and 15 meter
Protection shield
specifications
protection shield
article number
150.182.045
dimensions (L x W)
mm
900 x 500
weight, ready for use
kg
2.9
Features / Benefits
- ensures optimal safety for the victim
• offers protection against sharp edges, glass fragments,
slipping tools or ejected parts
- made of thick yet flexible PVC material
• durable - strong - flexible
- transparent
• enables continuous monitoring of the victim
- fitted with 4 handles
• to hold in any required position
10.7 Assist tools
120
Sharp Edge Protection covers
Features / Benefits
specifications
SEP 5
SEP 10
- lightweight
article number
150.581.676
150.581.677
- wear-resistant, fire-retardant polyester
description
dimensions cm
weight kg
content
content
• longer life span
- water-repellent
cover with Velcro
26 x 30
0.18
2 x
4 x
• other materials such as Kevlar® absorb
blanket with magnets
60 x 60
0.52
2 x
4 x
water, become heavy and unmanageable
blanket with magnets
150 x 60
1.20
1 x
2 x
when wet and require long drying time
- striking orange colour
• dangerous spots are clearly marked
- with padded lining
• offers extra protection
- blankets with powerful magnets
• for instant and optimal attachment
to the vehicle
- covers with Velcro
• remain in position under all circumstances
- removable magnets
• washable
Tool stations
Features / Benefits
specifications
tool station
- made of PVC-coated polyester fabric
article number
150.182.043
150.182.044
• durable
dimensions (L x W)
cm
200 x 150
250 x 200
• does not absorb dirt and therefore
easy to clean
weight
kg
2.3
3.7
• water-repellent
- foldable material
• easy to carry
• easy to store
- striking orange colour
• clearly marks the spot where all tools are
assembled
10.7 Assist tools
121
Sharp Edge Protection blanket
specifications
SEP 2.5 ST
article number
350.182.075
dimensions (L x W x H)
mm
2500x1000x5
weight ready for use
kg
3.5
Delivered in black polyester bag (weight 1 kg)
Features / Benefits
Extreme durable material
Ultimate protection
- 100% woven polyester with acryl felt inside
- allows to climb over walls, fences or other objects with sharp edges
on top such as glass fragments, razor wire of jagged profile
Water repellent and fire retardant
- for use in various conditions
Easy cleaning
- with damp cloth or washable (if air-dried properly afterwards)
Accompanying carrying bag
- with adjustable strap for easy carrying on your shoulder or back
- for easy storage
- can be opened by means of clips or by using its Velcro fastening
- upside-down design ensures easy release of the blanket when
opening the bag
11.1 High pressure lifting bags
122
Lifting bags - high pressure - 8 bar
max.
light
thickness
air
water
max. effective
dimensions
inflation
reflecting
weight
incl.
content
content
model
art. nr.
lifting force
(LxW)
height
labels
profile
(8 bar)
(8 bar)
kN / t
mm
mm
on nr. of corners
kg
mm
litre
litre
HLB 1
350.321.003
10 / 1
80
150 x 150
1
0.6
22
6.3
0.7
HLB 3
350.321.004
35 / 3.7
130
228 x 228
1
1.5
22
16.2
1.8
HLB 5
350.321.006
50 / 5.1
150
270 x 270
1
2.0
22
22.5
2.5
HLB 10
350.321.007
100 / 10.2
215
380 x 380
3
3.8
25
76.5
8.5
HLB 12
350.321.008
120 / 12.2
225
408 x 408
3
5.0
25
90
10
HLB 18
350.321.009
180 / 18.3
240
660 x 360
3
6.8
25
171
19
HLB 20
350.321.010
200 / 20.3
290
508 x 508
3
6.7
25
189
21
HLB 24
350.321.012
240 / 24.4
215
1000 x 310
3
9.5
25
216
24
HLB 29
350.321.017
300 / 30.6
348
611 x 611
3
9.8
25
373
41.5
HLB 32
350.321.013
320 / 32.6
380
658 x 658
3
13.0
25
450
50
HLB 40
350.321.014
400 / 40.7
405
714 x 714
3
15.1
25
558
62
HLB 67
350.321.015
670 / 68
520
908 x 908
3
23.5
25
1206
134
Tested according to EN 13731.
Accessories lifting bags - high pressure
1
item
description
model
art. nr.
air hoses in 3 colours and 2 lengths:
1A
5 metre
yellow
AH 5 YU
350.572.006
1B
5 metre
blue
AH 5 BU
350.572.007
3
1C
5 metre
red
AH 5 RU
350.572.008
2
1D
10 metre
yellow
AH 10 YU
350.572.009
1E
10 metre
blue
AH 10 BU
350.572.011
1F
10 metre
red
AH 10 RU
350.572.012
shut-off hose with safety; lifting bag remains under pressure and hose and air source
2
350.582.035
can be used elsewhere
pressure reducer with 5/8"DIN connection; suitable for both 200 and 300 bar;
3
PRV 823 AU
350.182.002
complete with 2 metre hose
4
5
4
double control unit (push buttons), with safety valve set at 8.5 bar
DCV 10 U
350.582.034
5
single control unit (push buttons), with safety valve set at 8.5 bar
SCV 10 U
350.582.042
9
6A
connection piece for connection of two 300 bar air bottles with 5/8" DIN connection
350.582.430
6B
connection piece for connection of two 200 bar air bottles with 5/8" DIN connection
350.582.420
6
7
synthetic control box for operation of 2 lifting bags, with safety valves set at 8.5 bar
HDC 10 AU
350.182.003
universal adapter set for connection of lifting bags on various air-sources, like the
8
UAS 10
350.582.050
7
air system of a truck, a compressor or a truck tyre; in synthetic case
9A
air bottle 6 litres, 300 bar
350.581.096
9B
air bottle 6 litres, 200 bar
350.581.086
Air control sets - in synthetic orange case
300 BAR
200 BAR
8
model
HCS 10 U
DCS 10 U
HCS 10 U
DCS 10 U
art. nr.
350.582.038
350.582.039
350.582.435
350.582.436
item.
quantity
quantity
quantity
quantity
1B
1 x
1 x
1 x
1 x
1C
1 x
1 x
1 x
1 x
2
2 x
2 x
2 x
2 x
3
1 x
1 x
1 x
1 x
4
--
1 x
--
1 x
6A
1 x
1 x
--
--
6B
--
--
1 x
1 x
7
1 x
--
1 x
--
11.1 High pressure lifting bags
123
Features / Benefits
Light reflecting labels on top side
Non-slip design
- better visibility in dark
- maximum grip on all surfaces
environment which improves
- interlocking when 2 bags are
safety and user friendliness
used on top of each other
Reinforced with 3 aramide inlays
Unique lower profile edges
- light weight
- easy insertion under
- highly flexible
all circumstances
- proven durability
CE-icons
With carrying straps
With centring cross on both
(models HLB 40 and HLB 67)
sides
- optimal safety for the user
- easy to carry and easy to install
- easy and safe to position
11.1 Advisory lifting bag sets
124
The broad range of Holmatro pneumatic high pressure lifting bags and accessories allows you to select a combination that
will match your rescue operations in the best possible way. Alternatively you can choose between a number of advisory sets.
Basic lifting bag set, consisting of:
item
description
model
art. nr.
qty.
1
lifting bag 5 tons
HLB 5
350.321.006
1
2
lifting bag 10 tons
HLB 10
350.321.007
1
3
double control unit
DCV 10 U
350.582.034
1
4
pressure reducer
PRV 823 AU
350.182.002
1
5
6
5
air hose 5 m. red
AH 5 RU
350.572.008
1
6
air hose 5 m. blue
AH 5 BU
350.572.007
1
7
air bottle
6 litres, 300 bar
350.581.096
1
For specification of individual items see page 122.
2
1
3
4
7
Medium lifting bag set, consisting of:
item
description
model
art. nr.
qty.
1
lifting bag 10 tons
HLB 10
350.321.007
1
5
5
2
lifting bag 20 tons
HLB 20
350.321.010
1
3
lifting bag 32 tons
HLB 32
350.321.013
1
4
lifting bag 40 tons
HLB 40
350.321.014
1
5
air control set
DCS 10 U
350.582.039
1
6
air bottle
6 litres, 300 bar
350.581.096
2
5
For specification of individual items see page 122.
5
4
5
3
5
2
6
1
11.1 Advisory lifting bag sets
125
Heavy duty lifting bag set, consisting of:
item
description
model
art. nr.
qty.
5
1
lifting bag 10 tons
HLB 10
350.321.007
2
2
lifting bag 20 tons
HLB 20
350.321.010
2
3
lifting bag 40 tons
HLB 40
350.321.014
2
4
lifting bag 67 tons
HLB 67
350.321.015
2
5
5
air control set
DCS 10 U
350.582.039
2
6
air bottle
6 litres, 300 bar
350.581.096
4
For specification of individual items see page 122.
5
5
5
5
4
6
3
2
1
11.2 Low pressure lifting bags
126
Lifting bags - low pressure - sets
lifting
dimensions
max.
weight*
height
height
air content
capacity
in storage bag
working
model
art. nr.
(LAB set)
deflated
inflated
(a pair)
(a pair)
(L x W)
pressure
t
mm
kg
mm
mm
bar
litres
LAB 4 UN
350.512.204
3.6
600 x 600
27.0
60
580
0.5
626
LAB 6 UN
350.512.206
5.8
750 x 750
34.0
60
580
0.5
978
LAB 9 UN
350.512.209
8.2
900 x 900
41.0
60
580
0.5
1410
LAB 16 UN
350.512.216
14.6
1200 x 1200
65.0
60
580
0.5
2506
* LAB set consists of: 2 x LAB, 1 x carrying bag, 2 x AL 5 U, 1 x PRV 823 AU, 1 x LDC 0.5 AU, 1 x LAB repair kit
Tested according to EN 13731.
Lifting bags - low pressure - set components
Lifting bags - low pressure - optional accessories
single lifting bags
model
art. nr.
air hose
art. nr.
LAB 2
350.511.204
length 10 m
350.572.110
LAB 3
350.511.206
LAB 4.5
350.511.209
connection pieces
art. nr.
LAB 8
350.511.216
for 2 bottles of 200 bar
350.582.420
carrying bags
for model
art. nr.
for 2 bottles of 300 bar
350.582.430
LAB 4 UN
350.581.131
air bottles
art. nr.
LAB 6 UN
350.581.132
6 litres - 200 bar
350.581.086
LAB 9 UN
350.581.133
6 litres - 300 bar
350.581.096
LAB 16 UN
350.581.134
air hose
model
art. nr.
length 5 m
AL 5 U
350.572.106
control box
model
art. nr.
double control box
LDC 0.5 AU
350.182.011
pressure reducer
model
art. nr.
5/8"DIN connection
PRV 823 AU
350.182.002
with 2 m hose
11.3 Tank sealing
127
Tank sealing system
Tank sealing system HLS 2 consists of:
specifications
HLS 2
item
description
qty.
article number
350.582.020
1
harness
1
max. working pressure
bar
1.5
2
sealing plate (465 x 465 mm)
1
capacity lifting bag at 1.5 bar
t
2
3
protective cover orange (for item 8)
1
Lifting bag HLB 10 to be ordered seperately - see page 122.
4
protective cover green (for item 9)
1
5
corner belt with buckle (length 635 mm)
4
Features / Benefits
6
carrying belt with buckle (length 455 mm)
2
7
shut-off hose, safety valve set at 1.5 bar
1
Unique construction
8
stretch belt with ratchet, orange, length 10 m
1
- flexible
9
stretch belt with ratchet, green, length 10 m
2
- high chemical resistance
- quick and safe to install
2
1
3
4
6
8
9
5
7
11.4 Leak sealing
128
6
1
2
3
sealing compartment
4
3
3
5
Leak sealing system
specifications
HVSP 250 U
Vacuum leak sealing system HVSP 250 U consists of:
article number
360.302.011
1. vacuum sealing plate
max. working pressure
bar
6
2. stainless steel pressure gauge with protection cap
3. vacuum pump with air hoses length 3 m
dimensions sealing pad (L x W)
mm
600 x 390
4. drain cock with drain hose, length 3 m
thickness pad
mm
35
5. tube gel for optimal sealing, art. nr. 360.581.130
dim. sealing compartment (L x W)
mm
250 x 50
6. steel storage cage (L x W x H) 620 x 430 x 200 mm
length draining hose
m
3
air consumption (at 6 bar)
l/ min
300
Delivered completely mounted and ready for use.
weighth ready for use
kg
5.3
Features / Benefits
Rapid leak sealing
- reduces risks of fire or explosions
- prevents or limits environmental damage
Emergency drainage system
- after sealing fluid can be stored in other container
Special rubber compound
- high chemical resistance
Stainless steel pressure gauge
- no rust
12 PowerShore
129
12.1 PowerShore - introduction
130
Strut operating systems
One system for every rescue situation
all struts with max. load capacity 100 kN/ 10.2 t, depending
Holmatro PowerShore is a versatile and easy to assemble emergency
on the shore length
shoring system providing quick and reliable stabilization for every
1. manual (mechanical) - strut is extended manually; no lifting
rescue situation. No matter what kind of operation your are faced with
capacity
- light vehicle rescue
- heavy vehicle rescue
- trench rescue
- collapsed structure rescue (USAR)
this system meets any shoring requirement.
2. pneumatic - strut is operated by means of an 8 bar pneumatic
One system for shoring and lifting
system, consisting of an air bottle, pressure reducer, control unit and
air hoses; lifting capacity 4 kN / 0.4 t
Consisting of various lightweight, fully compatible components with
snap-lock connection Holmatro PowerShore can be assembled
in seconds. With the help of many different extension lengths and
accessories virtually any object can be shored at various angles. The
load is safely secured by means of a manual or automatic locking
system. Holmatro PowerShore is also available with integrated
pneumatic or, for even more power, hydraulic lifting cylinders. This
3. hydraulic - strut is operated by means of a 720 bar hydraulic hand
allows for a combination of shoring and lifting operations is situations
pump with hose and pressure gauge; lifting capacity 100 kN / 10.2 t
where potentially life saving ‘working space’ needs to be created.
Strut locking systems:
1. locknut locking system - secured manually.
2. auto-lock locking system - secured automatically. Allows for
remote shoring: a shore is positioned in an unsafe area and then
extended from a remote, safe location by either hydraulic or pneumatic
pressure.
Available combinations
Combining the three operating and two locking systems results in five different strut types:
Manual (mechanical)
Pneumatic (air)
Hydraulic (oil)
Locknut
Manual Locknut strut
Pneumatic Locknut strut
Hydraulic Locknut strut
Auto-lock
--
Pneumatic Auto-lock strut
Hydraulic Auto-lock strut
12.2 PowerShore - products
131
PowerShore - struts with hydraulic cylinder
working
force at
oil content at
locking
retracted length
stroke
weight
model
art. nr.
pressure
working
max. stroke
system
mm
mm
kg
bar/MPa
pressure kN/t
cc
HS 1 Q 5 FL
150.011.547
Auto-lock
632
252
10.3
720 / 72
100 / 10.2
346
HS 1 Q 10 FL
150.011.536
Auto-lock
1092
252
13.0
720 / 72
100 / 10.2
346
HS 1 L 5 +
150.011.543
Locknut
575
252
9.2
720 / 72
100 / 10.2
346
HS 1 L10 +
150.011.537
Locknut
1035
252
11.9
720 / 72
100 / 10.2
346
PowerShore - struts with pneumatic cylinder
working
force at
max. air/wa-
locking
retracted length
stroke
weight
model
art. nr.
pressure
working
ter content
systhem
mm
mm
kg
bar/MPa
pressure kN/t
litres
AS 3 Q 5 FL
150.011.546
Auto-lock
632
252
8.4
8
4 / 0.4
20.4 / 2.3
AS 3 Q 10 FL
150.011.545
Auto-lock
1092
252
11.2
8
4 / 0.4
20.4 / 2.3
AS 3 L 5+
150.011.532
Locknut
575
252
7.3
8
4 / 0.4
20.4 / 2.3
AS 3 L 10+
150.011.531
Locknut
1035
252
10.1
8
4 / 0.4
20.4 / 2.3
Auto-lock with integrated spacer: plunger with automatic locking mechanism that locks in steps of 9 mm. Retracting the plunger is only
possible after releasing the locking mechanism. The integrated spacer, a spring operated flex mechanism with 13 mm stroke, is used to overcome
one 9 mm step of the Auto-lock system and creates a max. pretension in the strut of 4.0 kN / 0.4 t.
Locknut: plunger with thread and Locknut. When the plunger is extended the Locknut can be secured. The pressure can then be released. Axial
displacement per rotation is 16.5 mm.
All struts are equipped with a female snap-lock system on both sides. Cylinders are single acting with spring return. All struts can be used with all
extensions and heads.
AS 3 Q 5 FL
AS 3 L5+
HS 1 L 5+
HS 1 Q 5 FL
PowerShore - mechanical struts
locking
retracted
stroke
weight
model
art. nr.
system
length mm
mm
kg
MS 2 L 2+
150.011.538
thread
250
127
3.5
MS 2 L 5+
MS 2 L 5+
150.011.533
Locknut
575
250
6.7
MS 2 L 2+
Thread: plunger with thread. When the plunger is extended the thread is self-
retaining. Axial displacement per rotation is 16.5 mm.
Locknut: plunger with thread and Locknut. When the plunger is extended the
Locknut can be secured. Axial displacement per rotation is 16.5 mm.
SX 1
PowerShore - extension pipes / connector
extension
colour
weight
outside
working
SX 2
model
art. nr.
mm
code
kg
Ø mm
load kN/t*
SX 1
150.011.501
125
white
1.5
90
100 / 10.1
FX 1
SX 2
150.011.502
250
blue
1.9
90
100 / 10.1
SX 5
SX 5
150.011.503
500
yellow
2.8
90
100 / 10.1
SX 10
150.011.504
1000
green
4.6
90
100 / 10.1
SX 10
SX 15
150.011.506
1500
red
6.4
90
100 / 10.1
FX 1
150.011.505
--
--
1.4
89
100 / 10.1
* depending on total length - see user manual
Extension pipes: with male snap-lock system on one side and female snap-lock system on the other side.
Connector FX1: with female snap-lock system on both sides. To connect the male end of an extension with one of the heads. In this way it is
possible to make a fixed shore that cannot be extended.
12.2 PowerShore - products
132
Accessories - to be used in combination with struts with hydraulic cylinder
item
description
model
art. nr.
hand pump, oil content 700 cc, weight ready for use 9.9 kg, presssure gauge 0-720
1
HTW 700 APS
150.012.504
bar, rubber protection cover for pressure gauge, hose 3 metres with quick-coupler
1
Accessories - to be used in combination with struts with pneumatic cylinder
item
description
model
art. nr.
1
2
1
single control unit with safety valve
SCV 10 U
350.582.042
2
double control unit with safety valve
DCV 10 U
350.582.034
3
air bottle 6 litres, 300 bar
-
350.581.096
3
4
pressure reducer with hose of 2 metres, suitable for both 200 and 300 bar
PRV 823 AU
350.182.002
4
air hose 5 metres, colour yellow
AH 5 YU
350.572.006
air hose 5 metres, colour blue
AH 5 BU
350.572.007
5
air hose 10 metres, colour yellow
AH 10 YU
350.572.009
5
air hose 10 metres, colour blue
AH 10 BU
350.572.011
Accessories - all accessories to be used on struts and extension pipes are equiped with a male snap lock system
description
art. nr.
description
art. nr.
Flat head - aluminium. For support against a flat
Pointed head. For use in e.g. narrow gaps;
150.011.509
150.011.524
surface; 0.3 kg, ø 89 mm.
1.2 kg, ø 89 mm.
Flat head with nailing plate - aluminium. For
Base support plate. Can support 3 swivel heads
support against a flat surface; with nailing holes;
150.011.541
and is suitable for the use of up to 3 tensioning
150.011.519
0.8 kg, 150 x 150 mm.
belts to create a stable triangle; 4.0 kg.
Trench support plate - zinc plated steel.
Tilting head - aluminium. For support on
Can be nailed to wooden plates to
uneven or tilting surfaces. Max. angle 45o in all
150.182.038
150.011.549
support 2 swivel heads in e.g. a trench;
directions; 1.7 kg, 95 x 95 mm.
0.9 kg, 280 x 110 x 75 mm.
Tilting head with nailing plate - aluminium.
For support on uneven or tilting surfaces;
Tensioning belt. Length 4.0 m, width 35 mm,
150.182.048
390.511.073
with nailing holes. Max. angle 45o in all
weight 1.4 kg, load 10 kN / 1.1 t..
directions; 2.5 kg, 150 x 150 mm.
Beam support head. For use with beams
Adjustable hook wrench. To create a pre-load
150.011.513
150.581.689
up to 150 mm; with nailing holes; 1.7 kg.
with the MS 2 L 2+. Two pieces are advised.
Beam support head. For use with beams
Rope with carbine hook. To lower struts, e.g. into
150.011.514
150.011.548
up to 100 mm; with nailing holes; 1.2 kg.
a trench.
Rubber anti-roll block. Prevents struts and
L-support head. For use with wide
150.011.520
extensions from rolling on uneven surfaces and
150.113.057
beams; with nailing holes; 1.0 kg.
protects against dirt and damage.
Swivel head - aluminium. Can be placed in
almost any position and against each other for
150.182.046
Storage / carrying bag for accessories.
150.011.005
mutual support; 2.0 kg.
V-block head small - aluminium. For support of
150.011.516
Storage / carrying bag for struts and extensions.
150.011.006
pipes; 0.7 kg, ø 89 mm.
V-block head large - aluminium. For support of
pipes; 1.7 kg.
150.011.522
2-way block. To support 2 tilting heads.
150.062.074
Opening x width 141 x 100 mm.
3-way swivel head. Contains 3 integrated swivel
Cone head. For support on concrete or steel
150.011.517
heads for use with up to 3 shoring lines in various
150.062.075
surfaces; 0.5 kg, ø 89 mm.
directions.
Cross head. For use on many kinds of surfaces;
150.011.523
1.1 kg.
12.3 PowerShore - features / benefits
133
Features / Benefits
Snap-lock system
Numerous fields of application
- vehicle extrication
- industrial accidents
- urban search and rescue
- trench rescue
- all items can be connected within seconds
- naval damage control
10 tons hydraulic strut
Lightweight
-easy to carry
-easy to assemble and very quick to position
Reflective colour coding of extension pipes
- avoids miscommunication
- easy to spot, especially in the dark
Versatile
- the PowerShore system includes hydraulic, pneumatic and manual
- shoring at various angles possibles
struts, to deal with every rescue situation, enabling both shoring and
lifting
Hydraulic strut
Pneumatic strut
Manual strut
12.3 PowerShore - features / benefits
134
Features / Benefits
Powerful
Fast
- 100 kN / 10.1 t max. load capacity, depending on the shore length
-male-female snap-lock (dis)connection system for extremely
- 100 kN / 10.1 t max. lifting capacity with integrated hydraulic lifting
fast coupling and uncoupling
modules
-fully compatible components ensure quick assembly
- reflecting colour codes enable quick length as-
Safe
sessment, even in the dark
- load is secured by manual “Locknut” or automatic locking “Auto-
lock” system
- auto-lock pneumatic or hydraulic systems enable ‘remote shoring’,
i.e. when a shore is positioned in an unsafe area and then extended
from a remote safe location by either pneumatic or hydraulic
pressure
Smooth edges
- no protruding parts
- smooth edges will not catch your clothes
12.4 PowerShore - set examples
135
Mechanical shoring sets
PSM 1
basic mechanical shoring set
set art. nr.:
150.062.097
PSM 2
advanced mechanical shoring
set
set art. nr.:
150.062.098
14
2
5
Application examples
4
1
The following examples are some of
the applications that can be achieved
12
13
15
with these sets. For a more detailed
description of all possible applications,
3
11
please contact your local Holmatro
sales representative.
7
8
2
Vehicle extrication rescue
6
10
9
- stabilization of vehicle on its side (see
picture below table)
- stabilization of vehicle on its roof
- stabilization in ‘light vehicle under
heavy vehicle’ scenarios
item
art. nr.
description
PSM 1*
PSM 2*
1
150.011.538
MS 2 L 2+ (manual Locknut strut))
1
2
Collapsed structure rescue (USAR)
2
150.011.501
SX 1 (extension 125 mm)
1
2
- creation of safe areas using single spot
shores (see picture below)
3
150.011.502
SX 2 (extension 250 mm)
1
2
- creation of door or window shores
4
150.011.503
SX 5 (extension 500 mm)
1
2
- follow-up shoring of lifted loads
5
150.011.504
SX 10 (extension 1000 mm)
1
2
6
150.011.523
cross head
1
2
Trench collapse rescue
7
150.182.038
tilting head
1
2
- creation of safe working zones in
8
150.011.516
V-block head small
-
2
shallow trenches
9
150.011.520
L-support head
1
2
10
390.511.073
tensioning belt
2
4
11
150.581.689
hook wrench
2
2
12
150.011.519
base support plate
1
2
accessories (optional, not included in the sets)
13
150.011.006
storage bag struts & extensions
1
1
14
150.011.005
storage bag accessories
-
1
15
150.113.057
anti-roll block
7
14
* the numbers listed in these columns represent the number of components as included in the set
For specification of individual items see pages 131 and 132.
Stabilization of a vehicle on its side.
Spot shore used to protect an exit route.
12.4 PowerShore - set examples
136
Hydraulic shoring sets
PSH 1
basic hydraulic shoring set
set art. nr.:
150.062.099
PSH 2
27
advanced hydraulic shoring
1
8
2
set
7
3
set art. nr.:
150.062.100
26
28
PSH 3
9
heavy duty hydraulic shoring
6
set
4
25
5
set art. nr.: 150.062.101
24
12
14
21
23
Application examples
15
22
The following examples are some of
16
the applications that can be achieved
10
17
with these sets. For a more detailed
20
11
19
description of all possible applications
13
18
please contact your local Holmatro
sales representative.
item
art. nr.
description
PSH 1*
PSH 2*
PSH 3*
Vehicle extrication rescue
- stabilization of vehicle on its side
1
150.011.538
MS 2 L 2+ (manual Locknut strut)
-
2
2
- stabilization of vehicle on its roof
2
150.011.543
HS 1 L 5+ (hydraulic Locknut strut)
2
2
2
- stabilization in ‘light vehicle under heavy
3
150.011.547
HS 1 Q 5 FL (hydraulic Auto-lock strut)
-
-
2
vehicle’ scenarios
4
150.012.504
HTW 700 APS (hand pump)
2
2
4
- controlled lifting of vehicles
5
150.011.501
SX 1 (extension 125 mm)
2
2
4
- stabilization of heavy goods vehicles
6
150.011.502
SX 2 (extension 250 mm)
2
2
4
7
150.011.503
SX 5 (extension 500 mm)
2
2
4
Collapsed structure rescue
8
150.011.504
SX 10 (extension 1000 mm)
2
2
4
(USAR)
- creation of safe areas using single spot
9
150.011.505
FX 1 (double female connector)
-
-
2
shores
10
150.062.074
2-way block
-
1
1
- creation of door or window shores
11
150.011.519
base support plate
2
4
4
- follow-up shoring of lifted loads
12
150.062.075
3-way swivel head
-
-
1
- combined shoring / lifting operations
13
150.011.523
cross head
2
2
4
14
150.182.046
swivel head
2
2
4
Trench collapse rescue
15
150.182.038
tilting head
2
2
4
- creation of safe working zones in
trenches using remote shoring
16
150.011.522
V-block head large
-
-
2
17
150.011.516
V-block head small
2
2
2
18
150.011.524
pointed head
-
-
2
19
150.011.509
flat head
-
2
2
20
390.511.073
tensioning belt
4
6
6
21
150.011.548
rope
-
-
2
22
150.581.689
hook wrench
-
2
2
23
150.011.520
L-support head
2
2
2
24
150.011.514
beam support head 100 mm
-
2
2
25
150.011.513
beam support head 150 mm
-
-
1
accessories (optional, not included in the sets)
26
150.011.006
storage bag struts & extensions
1
1
2
27
150.011.005
storage bag accessories
1
1
2
28
150.113.057
anti-roll block
14
16
32
* the numbers listed in these columns represent the number of components as included in the set
For specification of individual items see pages 131 and 132.
12.4 PowerShore - set examples
137
Pneumatic shoring sets
PSP 1
basic pneumatic shoring set
set art. nr.:
150.062.102
PSP 2
2
1
3
29
30
advanced pneumatic shoring
33
set
7
set art. nr.:
150.062.103
6
28
27
31
32
8
Application examples
26
The following examples are some of
5
the applications that can be achieved
23
with these sets. For a more detailed
4
24
description of all possible applications
22
25
please contact your local Holmatro
13
14
21
sales representative.
20
10
15
Vehicle extrication rescue
16
9
- stabilization of vehicle on its side
19
11
12
17
18
- stabilization of vehicle on its roof
- stabilization in ‘light vehicle under heavy
vehicle’ scenarios
item
art. nr.
description
PSP 1*
PSP 2*
- stabilization of heavy goods vehicles
1
150.011.538
MS 2 L 2+ (manual Locknut strut)
2
2
Collapsed structure rescue
2
150.011.546
AS 3 Q 5 FL (pneumatic Auto-lock strut)
2
2
(USAR)
3
150.011.532
AS 3 L 5+ (pneumatic Locknut strut)
-
2
- creation of safe areas using single spot
4
150.011.501
SX 1 (extension 125 mm)
2
4
shores
5
150.011.502
SX 2 (extension 250 mm)
2
4
- creation of door or window shores
6
150.011.503
SX 5 (extension 500 mm)
2
4
- follow-up shoring of lifted loads
7
150.011.504
SX 10 (extension 1000 mm)
2
4
Trench collapse rescue
8
150.011.505
FX 1 (double female connector)
-
2
- creation of safe working zones in
9
150.062.074
2-way block
1
1
trenches using remote shoring
10
150.062.075
3-way swivel head
-
1
11
150.011.519
base support plate
2
4
12
150.011.523
cross head
2
4
13
150.182.046
swivel head
2
2
14
150.182.038
tilting head
2
4
15
150.011.522
V-block head large
-
2
16
150.011.516
V-block head small
2
2
17
150.011.524
pointed head
-
2
18
150.011.509
flat head
-
2
19
390.511.073
tensioning belt
4
6
20
150.581.689
hook wrench
2
2
21
150.011.520
L-support head
2
2
22
150.011.514
beam support head 100 mm
-
2
23
150.011.513
beam support head 150 mm
-
1
24
350.182.002
PRV 823 AU (pressure reducer)
1
2
25
350.582.034
DCV 10 U (double control unit)
1
2
26
350.572.011
AH 10 BU (air hose)
1
1
27
350.572.009
AH 10 YU (air hose)
-
1
28
350.572.007
AH 5 BU (air hose)
-
1
29
350.572.006
AH 5 YU (air hose)
1
1
accessories (optional, not included in the sets)
30
350.581.096
air bottle, 6 litres, 300 bar
1
2
31
150.113.057
anti-roll block
16
32
32
150.011.006
storage bag struts & extensions
1
2
33
150.011.005
storage bag accessories
1
2
* the numbers listed in these columns represent the number of components as included in the set
For specification of individual items see pages 131 and 132.
12.4 PowerShore - set examples
138
Combined shoring sets
PSX 1
39
basic combined shoring set
40
5
6
set art. nr.:
150.062.104
PSX 2
3
1
advanced combined shoring
37
2
set
10
36
set art. nr.:
150.062.105
PSX 3
9
35
38
34
heavy duty combined shoring
set
11
4
8
33
set art. nr.: 150.062.106
7
30
31
32
Application examples
17
29
The following examples are some of
18
19
26
28
the applications that can be achieved
13
with these sets. For a more detailed
27
20
25
description of all possible applications
12
please contact your local Holmatro
14
15
22
21
23
sales representative.
16
24
Vehicle extrication rescue
item
art. nr.
description
PSX 1*
PSX 2*
PSX 3*
- stabilization of vehicle on its side
1
150.011.538
MS 2 L 2+ (manual Locknut strut)
2
4
8
- stabilization of vehicle on its roof
2
150.011.543
HS 1 L 5+ (hydraulic Locknut strut)
2
2
4
- stabilization in ‘light vehicle under heavy
3
150.011.547
HS 1 Q 5 FL (hydraulic Auto-lock strut)
-
2
2
vehicle’ scenarios
4
150.012.504
HTW 700 APS (hand pump))
2
4
4
- controlled lifting of vehicles
5
150.011.546
AS 3 Q 5 FL (pneumatic Auto-lock strut)
2
2
4
- stabilization of heavy goods vehicles
6
150.011.532
AS 3 L 5+ (pneumatic Locknut strut)
-
2
2
7
150.011.501
SX 1 (extension 125 mm)
4
8
16
Collapsed structure rescue
8
150.011.502
SX 2 (extension 250 mm)
4
8
16
(USAR)
9
150.011.503
SX 5 (extension 500 mm)
4
8
16
- creation of safe areas using single spot
10
150.011.504
SX 10 (extension 1000 mm)
4
8
16
shores
11
150.011.505
FX 1 (double female connector)
2
4
4
- creation of door or window shores
12
150.062.074
2-way block
1
2
3
- follow-up shoring of lifted loads
- combined shoring / lifting operations
13
150.062.075
3-way swivel head
1
2
2
14
150.011.519
base support plate
4
6
8
Trench collapse rescue
15
150.011.523
cross head
4
4
6
- creation of safe working zones in trenches
16
150.011.516
V-block head small
2
2
4
using remote shoring
17
150.182.048
tilting head with nailing plate
2
2
4
18
150.182.046
swivel head
4
4
8
19
150.182.038
tilting head
4
8
12
20
150.011.522
V-block head large
2
2
4
21
150.011.524
pointed head
2
2
2
22
150.011.517
cone head
2
2
4
23
150.011.509
flat head
2
2
4
24
150.581.689
hook wrench
2
4
8
25
390.511.073
tensioning belt
6
8
12
26
150.011.548
rope
2
4
8
27
150.011.541
flat head with nailing plate
2
4
6
28
150.011.520
L-support head
2
6
8
29
150.011.514
beam support head 100 mm
2
2
4
30
150.011.513
beam support head 150 mm
2
2
4
31
350.182.002
PRV 823 AU (pressure reducer)
1
2
2
32
350.582.034
DCV 10 U (double control unit)
1
2
2
33
350.572.011
AH 10 BU (air hose)
1
1
1
34
350.572.009
AH 10 YU (air hose)
-
1
1
35
350.572.007
AH 5 BU (air hose)
-
1
1
36
350.572.006
AH 5 YU (air hose)
1
1
1
accessories (optional, not included in the sets)
37
350.581.096
air bottle, 6 litres, 300 bar
1
2
2
38
150.113.057
anti-roll block
32
64
120
39
150.011.006
storage bag struts & extensions
2
3
6
40
150.011.005
storage bag accessories
2
3
6
* the numbers listed in these columns represent the number of components as included in the set
For specification of individual items see pages 131 and 132.
12.4 PowerShore - set examples
139
Trench shoring sets
PST 1
basic trench shoring set
set art. nr.:
150.062.107
PST 2
2
1
advanced trench shoring
21
set
6
19
set art. nr.:
150.062.108
5
20
Application examples
22
18
The following examples can be
achieved with these sets. For a more
12
4
3
17
detailed description of all possible
applications please contact your
16
local Holmatro sales representative.
14
13
11
Trench collapse rescue
15
- creation of safe working zones in
trenches using remote shoring
9
10
7
8
- stabilization of unsecured
installations (pipes etc.) in collapsed
trenches
item
art. nr.
description
PST 1*
PST 2*
1
150.011.538
MS 2 L 2+ (manual Locknut strut)
2
4
2
150.011.546
AS 3 Q 5 FL (pneumatic Auto-lock strut)
2
4
3
150.011.501
SX 1 (extension 125 mm)
4
8
4
150.011.502
SX 2 (extension 250 mm)
4
8
5
150.011.503
SX 5 (extension 500 mm)
4
8
6
150.011.504
SX 10 (extension 1000 mm)
2
4
7
150.182.038
tilting head
8
16
8
150.062.074
2-way block
2
4
9
150.581.689
hook wrench
2
4
10
150.011.549
trench support plate
1
2
11
150.011.522
V-block head large
-
2
12
150.011.548
rope
4
8
13
350.572.006
AH 5 YU (air hose)
-
1
14
350.572.007
AH 5 BU (air hose)
-
1
15
350.572.009
AH 10 YU (air hose)
1
1
16
350.572.011
AH 10 BU (air hose)
1
1
17
350.182.002
PRV 823 AU (pressure reducer)
1
2
18
350.582.034
DCV 10 U (double control unit)
1
2
accessories (optional, not included in the sets)
19
350.581.096
air bottle, 6 litres, 300 bar
1
2
20
150.011.006
storage bag struts & extensions
1
2
21
150.011.005
storage bag accessories
1
2
22
150.113.057
anti-roll block
24
48
* the numbers listed in these columns represent the number of components as included in the set
For specification of individual items see pages 131 and 132.
Remote shoring of a trench.
Trench shoring with pneumatic
Auto-lock struts.
13.1 Service
140
To be assured of optimum tool functioning, regular maintenance is highly recommended.
All our dealers are factory trained at Holmatro in giving full technical service to your rescue tools. For your own Holmatro
rescue tools inspection and maintenance a variety of products is available.
5
Oil / grease
item
art.nr.
description
3
4
1
150.581.095
teflon lubricating oil, sprayer, for greasing blades daily
2
150.581.093
graphite spray, sprayer, for greasing parts in general
2
1
3
150.581.094
Molycote, grease
4
100.581.051
Holmatro hydraulic oil, 1 litre
6
5
100.581.055
Holmatro hydraulic oil, 5 litres
6
150.581.103
Holmatro motor oil, 0.6 litre
7
150.581.083
copper grease for maintenance of moving parts
8
150.581.413
white grease, for greasing parts of control handle
7
9
150.581.412
copper grease, to mount steel bolts in aluminium parts
8
9
Testing equipment
1
2
3
item
art.nr.
description
1
150.000.660
plug-in type pressure gauge set, CORE
2
150.582.410
plug-in type pressure gauge set, dual hoses
3
150.000.815
digital test set PFM 1 C, to check pressure and flow, CORE
digital test set PFM 1, to check pressure and flow, dual
4
150.152.312 hoses
test frame HTF 80, for spreaders and combi tools,
5
150.182.514
0 - 100 kN / 0 - 22000 LBS
6
150.182.069
rpm counter, with cable, for counting rpm’s of engine
4
5
6
--
150.582.547
set of spray cans for hair crack investigation
Upgrading existing tools with LED lights
Handles with 4 integrated LED lights for your existing 3000-series cutters, sprea-
ders and combi tools.
art. nr.
for cutter
for combi tool
for spreader
150.014.232
CU 3031 - 3035
CT 3150
--
150.014.233
CU 3040 - 3050
--
--
150.014.230
--
--
SP 3230 - 3240
150.014.231
--
--
SP 3260 - 3280
150.014.229
BCU 3010
BCT 3120
--
13.1 Service
141
Converting a traditional dual hose system to a CORE system
Any Holmatro traditional dual hose system can easily be converted to a Holmatro CORE Technology system. This conversion
takes no more than a couple of minutes.
Traditional dual hose
Conversion in a couple of minutes
CORETM Technology
Your local dealer can help you with tool conversions.
Sets of 2 blades for cutters and combi tools
3000-series
4000 series
art.nr.
for cutter model
art.nr.
for cutter model
150.113.165
3005
150.113.165
4005
150.014.019
4006
150.113.156
3010*
150.113.156
4010*
150.013.386
3020
150.013.550
4020
150.113.177
3030
150.013.551
4030
150.113.212
3031
150.000.849
4031
150.113.172
3035 GP
150.000.882
4035 GP
150.113.186
3035 NCT
150.000.883
4035 NCT
150.113.182
3040 GP
150.113.182
4040 GP
150.113.221
3040 NCT
150.013.440
3050 NCT
150.013.440
4050 NCT
150.013.553
4055 NCT
art.nr.
for combi tool model
art.nr.
for combi tool model
150.113.167
3110
150.113.153
3120*
150.113.153
4120*
150.113.169
3150
150.013.642
4150
* also for battery driven and hand-operated cutters and combi tools
14.1 Holmatro Online
142
Holmatro.com
Visit our website for up-to-date product information, the latest
news, an overview of our innovations, videos, training materials
and much more.
Holmatro Rescue World
Follow us on Facebook and discover a world full of pictures,
videos, rescue tools and techniques, discussions and exciting
contests, all related to your challenging job of saving lives. Join
our worldwide family of firefighters and rescuers and engage
with them on our page.
Holmatro Rescue Blog
Read all about the latest rescue techniques, new car technology,
extrication planning & training, medical considerations and
other important focus points during various rescue operations
on the weblog of our Holmatro Rescue Consultant.
blog.holmatro.com
4
1
3
Important safety notice
This catalogue contains information on rescue tools and rescue techniques that can be employed in different rescue operations. The situations shown in this catalogue are examples only and merely
meant to assist the user of this catalogue in understanding certain basic rescue techniques and rescue tools available.
Holmatro disclaims any liability for any damage or injury, whether direct, indirect or otherwise, and whether asserted in contract, tort, warranty or otherwise, incurred as a result of the use of rescue
techniques and/or rescue tools described in this catalogue or the use of any other rescue techniques and/or rescue tools that are employed in any training or emergency situation, except to the
extent, and limited to, the terms of any warranty provided by Holmatro for its own equipment. Holmatro makes no warranty, expressed or implied, with respect to its own equipment from the contents
of this catalogue, including without limitation, any warranty of merchantability or warranty of fitness for a particular purpose.
Disclaimer
While the greatest care has been devoted to the content, it is possible that the information in this printed matter is incorrect or incomplete. N.V. Holmatro and its affiliated companies (hereafter:
Holmatro) cannot be held liable in any way for the consequences of activities undertaken on the basis of this printed matter. If you have any doubts about the correctness or completeness of the
information, you shall contact Holmatro (phone number: +31 (0)162-589200).
Nothing from this printed matter can be copied and/or made public in any way without the explicit authorisation of Holmatro.
