MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. Airworthiness Limitations Schedule (Cont.)
Finite Life
Mandatory
Component
Part Number
Model
Hours
Inspection
(1)
(2)
(1)
Hours
Drive Shafts, Couplings and Clutches
Drive shaft, main rotor transmission
369D/E/F
369A5510
3790
Coupling, main transmission drive shaft
369D/E/F/FF
369H5660
4300
500N
369H5660
3200
Overrunning clutch assembly
369D/E/F/FF
369F5450−501
On Cond.
100
(24)
500/600N
Sprag assembly, overrunning clutch
369D/E/F/FF
369A5364
(3)
300
(10)
369D25351
500N
369D25351
(3)
300
(10)
369D/E/F/FF
369F5456
(3)
300
(17)
500/600N
Drive shaft, fan
500N
500N5200
2620
600N
500N5200
1200
(36)
Drive shaft, tail rotor
369D/E
369D25518
13900
369F/FF
369DSK152−11
13900
369D25518−503
14610
Coupling − tail rotor drive shaft (Bendix)
369D/E/F
369A5501
4980
(NOTE: Not certified on 369FF Model)
(9)
369H92564
(7)
4980
Anti−Torque System
Gearshaft assembly, tail rotor input
369D/E
369D25434
12000
369D25434−3
12000
Gearshaft assembly, tail rotor input
369F/FF
369D25434
3365
369D25434−3
3365
Gearshaft, tail rotor output pinion
369D/E/F/FF
369D25430
7290
369D25430−5
7290
Blade assembly, tail rotor
369D/E
369D21613
5200
369D21613−11
5140
369D21613−31
5140
369D21613−41
5140
369D21613−51
5140
369D21613−61
5140
369D21613−71
5140
369D21640−501
(38)
400
369D21640−503
(38)
5140
369D21640−505
(38)
5140
369D21640−507
(38)
5140
369F/FF
369D21606
5140
369D21642−501
(38)
400
369D21642−503
(38)
5140
369D21642−505
(38)
5140
369D21642−507
(38)
5140
Page 9
FAA APPROVED
04-00-00
TR12-003
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. Airworthiness Limitations Schedule (Cont.)
Finite Life
Mandatory
Component
Part Number
Model
Hours
Inspection
(1)
(2)
(1)
Hours
Blade assembly, tail rotor
369D/E
369D21615
10000
(optional 4−blade)
369D21641−501
(38)
400
369D21641−503
(38)
10000
369D21641−505
(38)
10000
369D21641−507
(38)
10000
Hub, tail rotor
369D/E/F/FF
369A1725
3450
Retention strap assembly, tail rotor
369D/E/F
369A1706
5100
369FF
369A1706−507
5100
369A1706−509
5100
Blade assembly, NOTAR fan
500N
500N5310−15
7500
500N5310−19
7500
500N5310−23
7500
Blade assembly, NOTAR fan
600N
500N5310−19
12500
500N5310−23
12500
Hub, fan
500N
500N5352−7
7500
500N5352−9
7500
600N
500N5352−9
7500
Tension−Torsion Strap, NOTAR®
500N
500N5311−5
(43)(44)
600N
Shaft, NOTAR fan support
600N
500N5357−13
4000
Pitch plate assembly
500/600N
500N5363−7
7500
Tube assembly, fan pitch
500N
500N7113−3
600
(18)
Rotating cone assembly
500N
500N3740−1
10000
500N3740−41
10000
500N3740−81
10000
600N
500N3740−61
10000
500N3740−71
10000
Tailboom
Bolts, tailboom attach
369D/E/F/FF
MS21250−06014
21950
Page 10
TR12-003
04-00-00
FAA APPROVED
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. Airworthiness Limitations Schedule (Cont.)
Finite Life
Mandatory
Component
Part Number
Model
Hours
Inspection
(1)
(2)
(1)
Hours
Tailboom assembly
369D/E
369D23500
10300
369F/FF
369D23500−507
10300
Tailboom assembly
500N
500N3500−19
10204
100
(14)
500N3500−29
10204
500N3500−501
10204
500N3600−501
10204
100
(14)
600N
600N3500−503
2500
(25)
600N3500−505
5900
600N3500−507
1000
600N3500−509
6000
(19)
600N3500−511
6000
(19)
600N3500−513
2500
(25)
600N3500−515
5900
600N3500−517
1000
Empennage fittings
600N
500N3530−7/8
On Cond.
100
(26)
500N3530−9/10
On Cond.
100
(26)
Vertical stabilizer assembly
369D/E
369D23600
12700
369F/FF
369D23600−505
3388
Torque tube, horizontal stabilizer
500N
500N3950−5
5000
600N
500N3950−7
3000
(45)
500N3950−9
3000
(45)
600N3950−1
400
600N3950−3
1000
Horizontal stabilizer assembly
369D
(12)
369D23601
7700
369E
(12)
421−087−505
7700
421−087−905
(13)
7700
369F/FF (12)
421−087−503
7700
421−087−903
(13)
7700
600N
500N3910−25
10000
(19)
500N3910−27
10000
(19)
Controls
Longitudinal idler bellcrank assembly
369D
369A7301
6500
369A7301−501
6500
369E/F/FF
369A7301−501
6500
500N
369A7301−501
2870
Idler assembly, longitudinal pitch mixer
369D/E/F/FF
369A7603
13600
500N
369A7603
6050
Longitudinal control rod
500N
369A7011−13
7740
369A7011−15
7740
Socket, cyclic stick
600N
369A7141
1000
8
(27)
Cyclic tube assembly
600N
369D27132−503
1200
8
(27)
Page 11
FAA APPROVED
04-00-00
TR13-001
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. Airworthiness Limitations Schedule (Cont.)
Finite Life
Mandatory
Component
Part Number
Model
Hours
Inspection
(1)
(2)
(1)
Hours
Housing, collective stick
600N
369A7347
450
Tube, collective pitch control
600N
369A7348
400
Tube assembly, collective pitch (pilot)
600N
369H7354−3
600
Socket, cyclic stick
600N
369A7802
1000
8
(27)
Tube, collective pitch (co−pilot)
600N
369A7809
1800
Housing, collective stick
600N
369A7820
450
Housing, collective stick
600N
369H7837
450
Tube assembly, collective pitch (co−pilot)
600N
369H7838−3
1000
Fuselage Sta. 75 controls support bracket
600N
369N2608−11
6000
(41)
600N2608−9
Unlimited
Airframe
Landing gear brace
600N
600N6010−17/19
5900
(28)
Landing gear strut
600N
600N6022−7
696
(29)
600N6022−8
696
(29)
600N6022−9
696
(29)
600N6022−10
696
(29)
600N6022−11
696
(29)
600N6022−12
696
(29)
600N6022−13
696
(29)
600N6022−14
696
(29)
Landing gear foot
600N
600N6043−3
3900
(30)
Floats
Squib cartridge, used on Emergency float
369D/E/F/FF
12552−1
5 years
kit 369D292473−5, −6, −9, −10, −11, −12
500N
(Holex, Inc.)
NOTE: Life is based from original date of
281993
5 years
manufacture.
(Walter Kidde)
12754−1
5 years
(Holex, Inc.)
5003527
5 years
(Tavco)
Stabilizer support, utility float
369D/E
369D292036
3190
369DSK66
3190
NOTES:
(1) Life−limited components interchanged between models or configurations must be restricted to the lowest
service life indicated for the models or configurations affected. Life−limited components removed at
retirement are to be mutilated/destroyed or conspicuously marked to prevent inadvertent return to service.
Parts are applicable only on models under which a service life is listed.
Life−limited components cannot be altered or permanently marked in any manner without compromising
the part integrity. Part tagging or other record keeping system is required.
Related component records must be updated each time component is removed from service.
(2) Service life shown for the basic (no dash number) part numbers apply to all dash numbered versions
unless otherwise indicated.
Page 12
TR12-003
04-00-00
FAA APPROVED
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
(3)
With no cargo hook attached: − No retirement life assigned (Ref. Sec. 05−10−00, Component Overhaul or
Recommended Replacement Schedule).
With cargo hook attached and no separate log: − 1800 hours.
With cargo hook attached and with separate log: − 1800 hours of external load operating time when logged
separately.
(For 369D/E/F/FF helicopters with 369A5364 or 369D25351 sprag assembly, Refer to AD 90−19−02.)
(4)
Inspect in accordance with Main Rotor Strap Pack Lamination Inspection at 100−hour intervals, or 25−hour
intervals if 2 laminates (369D/E/F/FF − 500N) or 1 laminate (600N) have failed in any one leg or tongue
area of any strap assembly. A single cracked laminate between the shoes at the outboard end of a strap
pack is cause for rejection of the hub assembly
369D/E/F/FF − 500N: (Ref. Sec. 62−20−00, Main Rotor Strap Pack Lamination Inspection).
600N: (Ref. Sec. 62−20−60, Main Rotor Strap Pack Lamination Inspection).
(For 369D/E/F/FF helicopters, refer to AD 89−02−01.)
(5)
The 369D21100−513, −515, 516, 517 and −523 main rotor blades are not interchangeable with any earlier
configuration blades (Basic, −505 or −509); however, the −505 and −509 blades are interchangeable and
the −513 and −515 blades are interchangeable. The −505 and −509 configuration blades may be modified
to the −513M configuration, which is fully compatible with the −513 blade. (For information concerning
modification, contact MDHI Customer Service Department.)
(6)
For the 369D/E helicopters, the 369D21120−501, −503 main rotor blade has all the same inspections and
interchangeability as the 369D21100−517 main rotor blade.
For the 369F/FF − 500N helicopters, the 369D21121−501, −503 main rotor blade has all the same
inspections and interchangeability as the 369D21102−517 main rotor blade.
For the 600N helicopters, the 369D21121−501, −503 main rotor blade has all the same inspections and
interchangeability as the 369D21102−523 main rotor blade.
(7)
Used with 369H90123 Rotor Brake Kit.
(8)
Inspect main rotor drive shaft every 300 hours (Ref. Sec. 63−10−00, Main Rotor Drive Shaft Inspection
(300 Hour)) (Reference AD 81−26−01).
(9)
Failsafe device, P/N 369D25530 bolt and 369D25531 socket, must be used at both ends of tail rotor
driveshaft in accordance with Tail Rotor Drive Shaft Installation with Bendix Couplings (Reference AD
86−20−07).
(10)
For helicopters equipped with a cargo hook, inspect overrunning clutch sprag assembly P/N 369D25351,
clutch inner race P/N 369A5353 and outer race 369A5352 every 300 hours (Ref. C.O.M., Sec. 63−10−10,
Overrunning Clutch Sprag Inspection (300 Hour)). To establish time in service, either clutch total time with
hook attached or a separate and permanent log of external load operating time per CFR 91.417, may be
used.
(For 369D/E/F/FF helicopters with 369A5364 or 369D25351 sprag assembly, Refer to AD 90−19−02.)
(11)
Inspect main rotor blade root fittings and main rotor lead−lag link assemblies every 25 hours in accordance
with Main Rotor Blade Upper and Lower Root Fitting Attach Lug and Lead−Lag Link Attach Lug Inspection
(25 Hour) and every 100 hours in accordance with Main Rotor Blade Upper and Lower Root, Fitting Attach
Lug and Lead−Lag Link Attach Lug Inspection (100 Hour) (Ref. Sec. 62−10−00) (Reference AD
95−03−13).
(12)
Tip plates, tip weights (where applicable) and attaching hardware have no retirement life and may be
reused on replacement horizontal stabilizers.
(13)
421−087−903 and −905 require the addition of tip plates, tip weights and attaching hardware before
installation.
(14)
Inspect the three upper slot bridges for cracks (Ref. Sec. 05−20−00).
(15)
Inspect main rotor drive shaft every 300 hours (Ref. Sec. 63−10−00, Main Rotor Drive Shaft Inspection
(300 Hour)).
(16)
Inspect for deterioration every 600 hours up to a total time of 4200 hours and every 300 hours thereafter
until deterioration is sufficient to retire assembly
369D/E/FF − 500N: (Ref. Sec. 62−20−00, Main Rotor Damper and Attachments Inspection)
600N: (Ref. Sec. 62−20−60, Main Rotor Damper and Attachments Inspection).
Page 13
FAA APPROVED
04-00-00
TR12-003
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
(17)
For helicopters equipped with a cargo hook, inspect overrunning clutch sprag assembly P/N 369F5456,
clutch inner race P/N 369F5455 and outer race 369F5453 every 300 hours. To establish time in service,
either clutch total time with hook attached or a separate and permanent log of external load operating time
may be used.
(18)
500N7113−11 tube assembly, fan pitch is an On−Condition part and replaces the 500N7113−3 tube
assembly.
(19)
Interim hours: life extension testing in progress.
(20)
Inspect upper and lower blade root fittings every 100 hours in accordance with Main Rotor Blade Upper
and Lower Root, Fitting Attach Lug and Lead−Lag Link Attach Lug Inspection (100 Hour) (Ref. Sec.
62−10−00)
(For 369D/E/F/FF − 500N helicopters, Reference AD 96−10−09).
(21)
Main rotor blades, P/N 369D21102−517 with S/N 1976 thru 2100, 2106 thru 2115 are not to be installed on
600N helicopter (Reference Service Bulletin SB600N−007R2) (Reference AD 98−15−26).
(22)
Inspect main rotor blades with 600 or more hours of operation every 25 hours of helicopter operation with a
10X magnifying glass for cracking of the lower surface of the blade emanating from the root fitting and
doubler at the inboard end of the blade and to detect debonding between the blade root end fitting and
doubler if missing or cracked adhesive or paint is observed. (Reference Service Bulletins SB369D−195R3,
SB369E−088R3, SB369F−075R3, SB500N−015R3) (Reference AD 98−15−26).
(23)
Perform Main Rotor Blade Upper and Lower Root, Fitting Attach Lug and Lead−Lag Link Attach Lug
Inspection (25 Hour) up to a total time of 500 hours and every 15 hours thereafter and every 100 hours in
accordance with Main Rotor Blade Upper and Lower Root Fitting, Attach Lug and Lead−Lag Link Attach
Lug Inspection (100 Hour) (Ref. Sec. 62−10−00) until retirement of 369H1203−BSC and −21 Lead−Lag
Link Assembly. (Reference AD 95−03−13).
(24)
Inspect clutch retainer and bearing carrier for evidence of spinning and/or wear (Ref. Sec. 05−20−20).
(25)
The 600N3500−503 tailboom may be reworked to a 600N3500−505 tailboom, and the 600N3500−513
tailboom may be reworked to a 600N3500−515 tailboom by modifying the attachment fittings to all−steel
fittings.
(26)
(Ref. Sec. 05−20−00) Using a flashlight and 10X magnifying glass, inspect horizontal stabilizer mounting
brackets for cracks (pay particular attention to the forward inboard legs) (Ref. Tailboom Inspection).
(27)
Sockets must be inspected for cracks every eight hours after the initial 100 hour inspection.
(28)
Log all landings: Brace life is limited to 35400 logged landings or 5900 hours flight time if landing are not
logged (assumed six landings per one hour of flight time).
(29)
Log all landings: Strut life is limited to 4170 logged landings or 696 hours flight time if landing are not
logged (assumed six landings per one hour of flight time).
(30)
Log all landings: Foot life is limited to 23780 logged landings or 3900 hours flight time if landing are not
logged (assumed six landings per one hour of flight time).
(31)
The following main rotor blades have a finite life of 2,500 hours or 15,000 torque events*, whichever occurs
first;
P/N 369D21100−517 with S/N H664, H665, H667, H669, H671, H672, H674, H676, H679, H680, H683
thru H724, H726 thru H999 and J000 thru J039, J041 thru J055 and
P/N 369D21102−517 with S/N 1976 thru 2100, 2106 thru 2115.
* TORQUE EVENT (TE) − A TE is recorded for every transition from forward flight to a hover (Reference
Service Bulletins SB369D−195R3, SB369E−088R3, SB369F−075R3, SB500N−015R3).
(32)
RIN = (200 x Hrs.) + (52 x TE).
(33)
RIN = (160 x Hrs.) + (24 x TE).
(34)
RIN = (153 x Hrs.) + (3 x TE).
(35)
RIN = (50 x Hrs.) + (3 x TE).
(36)
RIN = (768 x Hrs.) + (11 x TE).
(37)
After accumulation of 750 flight hours and 13,720 TE, perform Main Rotor Blade Torque Event Inspection
(Ref. Sec. 62−10−00) every 35 flight hours or 200 TE’s (whichever occurs first).
Page 14
TR12-003
04-00-00
FAA APPROVED
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
(38)
The 369D21640−501, −503, −505, −507 tail rotor blades are two−way interchangeable with the 369D21613
tail rotor blades in sets of two only.
The 369D21641−501, −503, −505, −507 tail rotor blades are two−way interchangeable with the 369D21615
tail rotor blades in sets of two only (installed on the same inboard or outboard hub).
The 369D21642−501, −503, −505, −507 tail rotor blades are two−way interchangeable with the 369D21606
tail rotor blades in sets of two only.
(39)
The 369H1203−BSC, −11, −21, −31, −51 and −61 lead lag link assemblies can only be installed using the
369H1235−BSC bearing.
(40)
The 369H1203−53 lead lag link assembly can only be installed using the 369H1235−1 bearing.
(41)
The 369N2608−11 Control Support Bracket must be removed from 600N helicopters equipped with YSAS
(Ref. SB600N−040).
(42)
RIN = (29 x Hrs.) + (1 x TE).
(43)
The tension−torsion straps have a 5−year calendar life that starts the day the package is opened (Ref.
Sect 64−25−30). If the date the package was opened is unknown, the 5−year calendar life is based on the
manufacturing cure date.
For straps installed before 06 March 2008 on Model 500N helicopters serial numbers LN−001 thru LN−105
and Model 600N helicopters serial numbers RN003 thru RN074, the initial calendar replacement is based
on the cure date on the strap. Refer to Table 2 to find the expiration date.
(44)
500N5311−5 straps previously installed on MD900 helicopters are life limited to 2,500 hours when installed
on 500N and 600N series helicopters.
(45)
Use only on 600N helicopters without a yaw stability augmentation system (YSAS) (Pre−TB600N−006R1).
Table 2. Tension−Torsion Strap Expiration Date
Manufacturers Cure Date
Expiration Date
Before 03/1999
09/2008
03/1999 thru 02/2001
03/2009
03/2001 thru 02/2005
03/2010
03/2005 thru 02/2008
Cure Date Plus 5 Years
Page 15
FAA APPROVED
04-00-00
TR12-003
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This page intentionally left blank!
Page 16
Revision 42
04-00-00
FAA APPROVED
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
04−00−01
Airworthiness
Limitations
Supplements
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
UK CAA ALS SUPPLEMENT
1. UK CAA Airworthiness Limitations
Section Supplement
NOTE:
D The following components are further
limited when helicopters are operating
under UK CAA TC.
D Refer to 04-00-00 for all other Compo
nent Mandatory Replacement Times and
Component Mandatory Inspections.
Airworthiness Limitations
Component Mandatory Replacement Schedule
Component
Part Number
Finite Life
Mandatory
(1)
(2)
Hours (RIN)
Inspection
(1)
Hours
Main Rotor System
Drive shaft, main rotor
600N5510
14000
(1,000,000)
(3)
Tailboom
Tailboom assembly
600N3500−503
800
(4)
NOTES:
(1) Life−limited components interchanged between models or configurations must be restricted to the lowest
service life indicated for the models or configurations affected. Life−limited components removed at
retirement are to be destroyed or conspicuously marked to prevent inadvertent return to service. Parts are
applicable only on models under which a service life is listed.
(2) Service life shown for the basic (no dash number) part numbers apply to all dash numbered versions
unless otherwise indicated.
(3) RIN = (50xHrs.) + (3xTE)
(4) The 600N3500−503 tailboom may be reworked to a 600N3500−505 tailboom by modifying the attachment
fittings to all steel fittings.
REVISION:
DATE
FAA SIGNATURE AND DATE *
Initial Issue:
24 May 2000
* FAA approval in behalf of UK CAA per letter, Winnert to Wang, Ref. 9/33/0649/A26479, Dated 2 May 2000.
Page 1
04-00-01
Revision 26
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
Page 2
Revision 43
04-00-01
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Chapter
05
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
TABLE OF CONTENTS
Para/Figure/Table
Title
Page
05-00-00 Continued Airworthiness
A
Checks/Inspections
1
1. General Description of Inspections
1
A. Airworthiness Limitations
1
B. Continued Airworthiness
1
2. Documentation
2
A. Records of Aircraft Inspection
2
B. Additional Documentation
2
3. Visual Inspection Criteria
2
A. General Visual Inspection
2
05-10-00 Continued Airworthiness
A
Component Overhaul/Recommended Replacement
1
1. Component Overhaul or Recommended Replacement Schedule
1
Table 1. Component Overhaul Schedule
1
Table 2. Component Recommended Replacement Schedule
3
Table 3. Kamatics Component Overhaul Schedule
4
05-20-00 Continued Airworthiness
A
100-Hour or Annual Inspection Checklist
1
1.
100-Hour or Annual Inspection
1
Table 1. 100-Hour or Annual Inspection
1
2. Retirement Index Numbers Attachment
11
Table 2. Permanent Record of Retirement Index Numbers/Torque Events
11
05-20-10 Continued Airworthiness
A
300-Hour Inspection Checklist
1
1.
300-Hour Inspection
1
Table 1. 300-Hour Inspection
1
05-20-15 Continued Airworthiness
A
Yearly Inspection Checklist
1
1. Yearly Inspection
1
Table 1. Yearly Inspection
1
05-20-20 Continued Airworthiness
A
Special Inspections
1
1. Special Inspection Hourly and Calendar
1
Table 1. Special Inspections Hourly
1
Table 2. Special Inspections Calendar
5
Page i
05 Contents
Revision 44
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
TABLE OF CONTENTS (Cont.)
Para/Figure/Table
Title
Page
05-50-00 Continued Airworthiness
A
Conditional Inspections
1
1. General
1
2. Hard Landing
1
3. Overspeed
1
4. Overtorque
2
5. Sudden Stoppage
2
6. Lightning Strike
2
7. Conditional Inspection Table
2
Table 1. Conditional Inspections
3
Page ii
Revision 44
05 Contents
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−00−00
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
CHECKS/INSPECTIONS
1. General Description of Inspections
(1). COMPONENT OVERHAUL/RE
COMMENDED REPLACEMENT
The following Continued Airworthiness
(Ref. Sec. 05-10-00) is a schedule for
Sections specify inspections and other main
the overhaul and recommended replace
tenance required under the Federal Aviation
ment of components and/or assemblies
Regulations unless an alternative program has
and scheduled maintenance checks.
been FAA approved.
(2).
100-HOUR OR ANNUAL INSPEC
NOTE: Because this manual pertains to MDHI
TION CHECKLIST (Ref. Sec.
model 369D, 369E, 369FF, 500N and 600N
05-20-00) is a schedule of inspections
helicopters (including the basic 500MD con
that must be accomplished every 100
figuration), it may contain inspection re
hours of helicopter operation or on a
quirements applicable to specific equipment
12-month (annual) basis.
not installed on individual helicopters.
An Annual Inspection is required on
When this situation is encountered, require
this helicopter for continued airworthi
ments that are not applicable should be dis
ness and may be accomplished in
regarded.
combination with a 100-hour inspec
tion.
The inspection intervals designated herein are
the maximum allowable and should not be
NOTE:
exceeded. When unusual local conditions, such
D To comply with the requirements of ser
as environmental conditions, utilization, etc.
vice bulletins which have been incorpor
dictate, it is the prerogative and responsibility
ated into the appropriate maintenance
of the operator to increase the scope and
and inspection manuals, the latest
frequency of the inspections as necessary to
100-Hour or Annual Inspection must be
ensure safe operation. Each item shall conform
used.
with the FAA Requirements, A.D.'s and
Manufacturer Bulletins and Letters. Over
D Refer to applicable Rolls-Royce Engine
flying the inspection interval, or any change
Operation and Maintenance Manual (Ref.
desired to the requirements of this chapter,
Table 201, 01-00-00) for detailed require
may be requested through the local aviation
ments on inspection of the engine.
regulatory authority.
(3).
300-HOUR INSPECTION CHECK
A. Airworthiness Limitations
LIST (Ref. Sec. 05-20-10) is a schedule
of inspections that must be accom
Refer to section 04-00-00 for mandatory
plished every 300 hours of helicopter
inspections and component mandatory
operation.
retirement schedule.
(4). YEARLY INSPECTION CHECK
B. Continued Airworthiness
LIST (Ref. Sec. 05-20-15) is a schedule
of inspections that must be accom
This section contains the requirements for
plished on a yearly basis.
Component Overhaul/Recommended Replace
ment, 100-Hour or Annual Inspection Check
(5). SPECIAL INSPECTIONS (Ref. Sec.
list, 300-Hour Inspection Checklist, Special
05-20-20) consist of inspections that
Inspection Schedule and Conditional Inspec
are contingent upon elapsed flight time
tions.
or calendar time.
Page 1
05-00-00
Revision 38
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
(a). Special Inspections Hourly should
shall include a visual examination of the area,
be referred to for additional inspec
component, detail, assembly, or installation
tion requirements that must be
and its surrounding environment, as well as
performed at specified periodic
any associated equipment within the immedi
hourly intervals.
ate vicinity, using any inspection aids con
sidered necessary.
(b). Special Inspections Calendar
should be referred to for additional
A. General Visual Inspection
inspection requirements that must be
A visual inspection that will detect obvious
performed at specified periodic
unsatisfactory conditions/discrepancies. This
calendar intervals.
type of inspection may require cleaning,
(6). CONDITIONAL INSPECTIONS (Ref.
removal of fillets, fairings, access panels/doors,
Sec. 05-50-00) includes inspection
etc.
requirements for unusual or other
(1). Metal parts (all metal parts, bodies, or
specific conditions or circumstances
casings of units in systems and in
that might occur.
electrical, instrument, and radio
installations, ducting, tubing, rods, and
2. Documentation
bellcranks). Inspect for the following:
A. Records of Aircraft Inspection
(a). Cleanliness, external signs of dam
age, leaks, overheating, discharge, or
(1). Aviation regulatory agencies require
fluid contamination.
pilot's, mechanics, owners and operat
ors to be familiar with, and to maintain
(b). Obstruction of drainage or vent holes.
records of aircraft maintenance,
inspections and repairs. This includes,
(c). Correct seating and sealing of
but is not limited to, Airworthiness
fairings and serviceability of fasten
Directives, Manufacturers Notices,
ers.
Scheduled Inspections and Time/Cycle
(d). Security of attachment, fasteners,
limited-life components.
and connections.
B. Additional Documentation
(e). Distortion, dents, scores, chafing,
pulled or missing fasteners, rivets,
(1). Additional documentation is required to
bolts, or screws.
be available, or inside the aircraft,
during operation. This documentation
(f). Signs of cracks or wear.
includes: Airworthiness and Registra
tion Certificates, Rotorcraft Flight
(g). Separation of bond.
Manual, Weight and Balance informa
(h). Failure of welds or spot welds.
tion and Radio Permits. It is important
that all required documentation be
(i). Deterioration of protective treatment
reviewed and revised as necessary
and corrosion.
during regular inspections, mainten
(2). Composite, rubber, fabric, fiberglass,
ance and operation of the helicopter.
and plastic parts (coverings, ducting,
3. Visual Inspection Criteria
flexible hoses, flexible mountings, seals,
insulation of electrical cables, windows,
Any time an area of the helicopter is visible
etc.). Inspect for the following:
during an inspection or maintenance action,
(a). Cleanliness, cracks, cuts, chafing,
the following ”Visual Inspection Criteria” shall
kinking, twisting, crushing, or
be accomplished without requiring disas
contraction -(sufficient free length).
sembly or removal of adjacent equipment
unless otherwise specified. It will normally
(b). Damage, delamination, or deteriora
apply to those areas, surfaces, or items which
tion.
become visible by the removal or opening of
access doors, panels, fairings, or cowlings. It
(c). Crazing.
Page 2
Revision 38
05-00-00
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
(d). Loss of flexibility (other than fabric
(b). If protective covers are required to be
covered component).
removed, check for cleanliness,
scoring, pitting or burning of con
(e). Overheating.
tacts, brushes for condition, and
security of exposed contacts.
(f). Fluid saturation.
(c). Overheating.
(3). Control System Components. Inspect
(d). Fluid contamination.
for the following:
NOTE:
For detailed Wiring Inspection criteria,
refer to CSP-HMI-3, Section 96-00-00.
(a). Correct alignment, no binding.
(5). Wire harness. Inspect for the following:
(b). Distortion, signs of bowing, scoring,
chafing, fraying, kinking, signs of
(a). Routing, contact with structure,
wear, flattening, cracks, or loose
proper support and protection.
fasteners.
(b). Strain at termination points, free
movement of shock-mounted or
(c). Deterioration of protective treatment
hinged equipment and proper slack
or corrosion.
for equipment installation and
maintenance.
(d). Electrical bonding correctly posi
tioned, undamaged, and secure.
(6). Inside fuel cell areas. Inspect for the
following:
(e). Attachments, end connections, and
(a). Leaks, cleanliness, foreign objects,
locking devices secure.
cracks.
(4). Electrical components (circuit protec
(b). Components for security and general
tion devices, wiring, connectors, plugs,
condition.
motors, generators, actuators, relays,
(c). Plumbing, and wiring for security,
solenoids, and contacts). Inspect for the
and general condition.
following:
(7). Markings, labels, and placards. Inspect
(a). Cleanliness, obvious damage, corro
for the following:
sion, security of attachments and
connections.
(a). Legibility and security of attachment.
Page 3
05-00-00
Revision 38
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
Page 4
Revision 38
05-00-00
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−10−00
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
COMPONENT OVERHAUL/RECOMMENDED REPLACEMENT
1. Component Overhaul or Recommended
overhaul/exchange. Any shaft or coupling
Replacement Schedule
removed for After Main Rotor Drive System
Sudden Stoppage - Level 2, conditional
Table 1 is the Overhaul Schedule. The listed
inspection requirements (Ref. CSP-HMI-2,
components or assemblies should be removed
05-50-00, Table 1) is not eligible for overhaul
from the helicopter and overhauled at inter
or exchange.
vals specified.
Neither the assignment of an airworthiness
Table 2 is the Recommended Replacement
life to a component nor failure to assign an
Schedule. The listed components should be
airworthiness life constitutes a warranty of
removed from the helicopter and scrapped at
any kind. The only warranty applicable to the
intervals specified.
helicopter and any components is that
Table 3 is the Kamatics Component Overhaul
warranty included in the Purchase Agreement
Schedule. The listed shafts and couplings
for the helicopter or the component.
should be removed from the rotorcraft and
overhauled at the interval specified. To be
NOTE: Hours for the 369F Model helicopters
eligible for the program, the shaft or coupling
will be the same as the 369FF unless other
must be serviceable before return to MDHI for
wise noted.
Table 1. Component Overhaul Schedule
Component (1)
Model
Part Number (2)
Hours
Main rotor transmission assembly
369D/E/FF − 500N
369D25100
3000
369D25100
4000
(12)
369D/E/FF − 500N
369F5100
5000
600N
369F5100
3000
Main rotor swashplate assembly
369D/E/FF − 500N
369D27609
2770
(3)(9)
600N
600N7630−3
2700
(4)(9)
Main rotor hub assembly
369D/E/FF − 500N
369D21200
2770
(7)(9)
600N
600N1200
2700
(7)(9)
Landing gear damper
369D/E/FF − 500N
369D26300
On Cond.
(6)
369D26301
On Cond.
(6)
600N
600N6300
On Cond.
(6)
Overrunning clutch assembly
369D/E/FF − 500N
369A5350−603
1800
(5)
369A5350−605
1800
(5)
369D/E/FF − 500/600N
369F5450
1800
(10)(11)
Tail rotor transmission
369D/E
369D25400
4800
369FF
3365
369D/E
369D25300
4800
Starter/Generator
(8)
369D/E − 500N
369A4550
1200
369FF − 600N
369D28550
1200
NOTES:
(1) Components interchanged between models or configurations must be restricted to the lowest service life
indicated for the models or configurations affected. Components removed at retirement are to be destroyed
or conspicuously marked to prevent inadvertent return to service. Parts are applicable only on models
under which a service life is listed.
Page 1
05-10-00
Revision 44
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
(2)
Service life shown for basic part number applied to all dash−numbered versions unless otherwise
indicated.
(3)
Bearing assembly must be relubricated every 2 years or 2770 hours, whichever occurs first (Ref.
CSP−COM−5, Sec. 62−30−10).
(4)
Bearing assembly must be relubricated every 2 years or 2700 hours, whichever occurs first (Ref.
CSP−COM−5, Sec. 62−30−60).
(5)
Under some operating conditions, overrunning clutch splines may need to be regreased more often than at
the 100−hour intervals and bearings may need to be regreased more often than at the 300−hour intervals.
With no cargo hook attached, inspect and regrease splines every 100 hours and bearing every 300 hours
(Ref. Sec. 63−10−00, Installation of Overrunning Clutch Subassembly and CSP−COM−5, Ball Bearing
Inspection and Grease Repack).
With cargo hook attached, inspect sprag assembly, inner race and outer race every 300 hours or 300 hours
of actual hook time when logged separately as per FAR 91.417, regrease clutch splines every 100 hours
and bearing every 300 hours (Ref. Sec. 63−10−00, Installation of Overrunning Clutch Subassembly and
CSP−COM−5, Ball Bearing Inspection and Grease Repack).
(6)
When inspected per Landing Gear Damper Inspection (Ref. Sec. 32−10−00 for 369D/E/FF − 500N, or Sec.
32−10−60 for 600N).
(7)
Use only main rotor hubs overhauled by MDHI or approved MDHI Licensees.
(8)
Refer to data plate to determine start/generator manufacturer.
(9)
The shelf life of bearings preserved with grease is limited to 4 years.
(10)
Regrease overrunning clutch bearings every 300 hours (Ref. CSP−COM−5, Sec. 63−10−15).
(11)
Interim hours: life extension testing in progress.
(12)
The 369D25100 main rotor transmission overhaul time may be extended from a mandatory 3000 hour
overhaul time to a mandatory 4000 hour overhaul time, provided, the transmission is operated with Mobil
SHC626 since last overhaul.
The transmission shall not exceed 3000 hours if cargo hook time has reached a quantity of 750 hours.
Page 2
Revision 44
05-10-00
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 2. Component Recommended Replacement Schedule
Component (1)
Model
Part Number (2)
Hours
Tail rotor swashplate (duplex) bearings
369D/E/FF
369D21832
On Cond.
(3)(9)
Fan support bearing
500/600N
500N5364
2400
(8)(9)
Pitch plate bearing
500/600N
500N7120
2400
(8)(9)
Thrust bearing cup, upper
369D/E/FF − 500N
369D21255
On Cond.
(3)(9)
Thrust bearing cone, upper
369D/E/FF − 500N
369D21254
On Cond.
(3)(9)
Thrust bearing cup, upper
600N
369D21255
600
(5)(9)
Thrust bearing cone, upper
600N
369D21254
600
(5)(9)
Thrust bearing cup, lower
369D/E/FF − 500N
369D21257
On Cond.
(3)(9)
Thrust bearing cone, lower
369D/E/FF − 500N
369D21256
On Cond.
(3)(9)
Thrust bearing cup, lower
600N
369D21257
5400
(4)(9)
Thrust bearing cone, lower
600N
369D21256
5400
(4)(9)
Bearings, oil cooler blower
369D/E/FF − 500/600N
369H5655−3
1200
369D/E/FF − 500/600N
369H5655−5
1200
Belt, oil cooler blower
369D/E/FF − 500N
369D25623
1200
600N
93920219
1200
Cyclic stick trim switch
(7)
369D/E/FF − 500N
A218−100646−02
1000
NOTES:
(1) Limited−life or scheduled replacement components interchanged between models or configurations must
be restricted to the lowest service life indicated for the models or configurations affected. Limited−life or
scheduled replacement components removed at retirement are to be destroyed or conspicuously marked
to prevent inadvertent return to service. Parts are applicable only on models under which a service life is
listed.
(2) Service life shown for basic part number applied to all dash−numbered versions unless otherwise
indicated.
(3) Bearing assembly must be relubricated every 2 years or 2770 hours, whichever occurs first (Ref. Sec.
64−30−00, Tail Rotor Swashplate Bearing Regreasing).
(4) Bearing assembly must be relubricated every 2 years or 2700 hours, whichever occurs first (Ref. Sec.
62−20−60, Main Rotor Hub Tapered Bearing Grease Repack, Inspection and Replacement).
(5) Bearing assembly must be relubricated every 2 years or 300 hours, whichever occurs first (Ref. Sec.
62−20−60, Main Rotor Hub Upper Bearing Grease Repack, Inspection and Replacement).
(6) Deleted
(7) Installed in 369D27133 grip assembly made by Guardian Electric Co., PN A218966714−00 (Ref. Sec.
67−10−20, Cyclic Stick Grip Switch Replacement (Standard Grip)).
(8) Bearing assembly must be relubricated every 2 years or 1200 hours, whichever occurs first (Ref. Sec.
64−25−30, Anti−Torque Fan Bearing Regreasing).
(9) The shelf life of bearings preserved with grease is limited to 4 years.
Page 3
05-10-00
Revision 37
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 3. Kamatics Component Overhaul Schedule
Component
Part Number
Serial Number (3)
Initial TBO Date
Next Overhaul
Interconnecting Shaft
369D25515
0001 thru 0535
2010 − 2011
2021
(1)
Interconnecting Shaft
369D25515
0536 thru 1070
2012
2022
(1)
Interconnect Shaft
500N5215
0001 thru 0516
2013
2023
(1)
Interconnect Shaft
500N5215
0517 thru 1017
2014
2024
(1)
Interconnect Shaft
500N5215
1018 thru 1550
2015
2025
(1)
Interconnect Shaft
500N5215
1551 thru 1667
2016
2026
(1)
Interconnect Shaft
500N5215
1668 thru 1777
2017
2027
(1)
Interconnect Shaft
500N5215
1776 thru 1824 (2)
2018
2028
(1)
Tail Rotor Driveshaft Coupling
369D25501−BSC
N/A
2010 − 2011
2021
(1)
Tail Rotor Driveshaft Coupling
369D25501−3
0001 thru 0493
2010 − 2011
2021
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
0001 thru 0505
2010 − 2011
2021
(1)
Tail Rotor Driveshaft Coupling
369D25501−3
0494 thru 1087
2012
2022
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
0506 thru 1011
2012
2022
(1)
Tail Rotor Driveshaft Coupling
369D25501−3
1088 thru 1581
2013
2023
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
1012 thru 1517
2013
2023
(1)
Tail Rotor Driveshaft Coupling
369D25501−3
1582 thru 2071
2014
2024
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
1518 thru 2023
2014
2024
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
2024 thru 2523
2015
2025
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
2524 thru 3024
2016
2026
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
3025 thru 3525
2017
2027
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
3526 thru 4025
2018
2028
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
4026 thru 4525
2019
2029
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
4526 thru 5025
2020
2030
(1)
Tail Rotor Driveshaft Coupling
369D25501−9
5026 thru 5527 (2)
2021
2031
(1)
NOTES:
(1) Interconnect shafts and tail rotor driveshaft couplings will be overhauled at ten (10) year intervals after
this date.
(2) Subsequent serial number components, not installed as part of the initial OEM installation on new
rotorcraft, shall have the initial TBO date ten (10) years from the documented date of initial installation.
Documented date of initial installation to be recorded by installer in the Rotorcraft Log Book and on
component card.
(3) Serial number components listed in Table 3 with 0 hours (new condition) shall have the initial TBO date
ten (10) years from the documented date of initial installation. Documented date of initial installation to be
recorded by installer in the Rotorcraft Log Book and on component card.
Page 4
TR12-001
05-10-00
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−20−00
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
100−HOUR OR ANNUAL INSPECTION CHECKLIST
1.
100−Hour or Annual Inspection
NOTE:
D The Chap/Sect column of the following
table is for reference unless a specific in
This check sheet is designed to be used when
spection requirement is called out. If
performing 100-Hour or Annual inspections as
there is only two numbers in the column,
defined under FAR, Part 43, Appendix D. This
it refers to the Chapter. If there is three
checklist, when completed, should be kept as a
numbers, it refers to the Section the in
permanent part of the helicopter's records.
spection is found.
Adherence to Maintenance Manual informa
D Refer to applicable Rolls-Royce engine in
tion is required, and the manual should be
spection check list for required engine
consulted when using the checklist.
maintenance.
Table 1. 100−Hour or Annual Inspection
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
GENERAL
ALL
Thoroughly clean helicopter and engine prior to start of inspection.
20
ALL
Remove trim panels, covers and access panels as necessary.
52−50−00
ALL
Ensure all placards and markings are installed.
11−00−00
ALL
Ensure compliance with component mandatory retirement schedule.
04−00−00
ALL
Calculate and record TE’s or RIN’s, of all affected components, in Table 2.
04−00−00
ALL
Ensure compliance with component overhaul schedule.
05−10−00
ALL
Ensure compliance with all applicable airworthiness directives, service
N/A
bulletins and special inspections.
ALL
Review aircraft maintenance records for recorded discrepancies and correct
N/A
discrepancies as applicable.
ALL
Refer to related manufacturer’s publications for detailed requirements on
01−00−00
inspection of engine, starter/generator, battery and all installed STC
equipment.
EXTERIOR
ALL
Air intake for cleanliness and foreign matter.
71
Visible portion of engine compressor inlet for foreign object damage.
CAUTION:
Ensure that compressor cover is installed to prevent FOD.
ALL
Engine air plenum chamber for:
71
53
Damage and cleanliness.
Wear and security of internal components.
*
Particle separator mounting structure for cracks or damage.
Page 1
Form HOE005 (Rev 5/04)
05-20-00
Revision 35
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
ALL
Fuselage upper surfaces for:
52
53
Damage and condition.
Mast base drain holes clean and free of debris (blow air thru holes to
ensure no clogging).
Engine air inlet fairing free from damage. No delamination noted. Bypass
door operationally checked. Seals free from damage.
Engine air bypass door operationally checked. Seals free from damage.
71
Cable system checked for smooth operation.
Engine access doors for proper operation of latches and closure,
52
distortion, damage, cracks and security.
ALL
Fuselage for:
52
53
Damage and condition.
Compartment fresh air vents in doors and front of canopy for easy of
operation and security.
Fuel cell vent fairings free of obstructions and obvious damage.
Pilot’s and passenger/cargo compartment doors for condition of door
glass, vents and proper operation of latching and locking mechanisms.
Door hinges and pins for play or wear. Ensure door pin locking tab is
engaged with slot in frame.
No evidence of oil leakage around fuselage drain holes.
369D/E/FF
Sta. 142.0 tail rotor control bellcrank support for cracking or damage, use
67−20−10
bright light and mirror (Ref. Upper Fuselage and Tailboom Control Linkage
Inspection).
500/600N
Anti−torque fan inlet for:
53
Screen for cleanliness and damage.
Attaching hardware for security.
Interior of fan inlet for cleanliness and damage.
Driveshaft cover for damage.
ALL
Check for no gap between tailboom and fuselage at attach points.
53
Check tailboom skin around stabilizer fittings for cracks.
Tailboom attachment−to−fuselage for security, evidence of corrosion or
cracks, loose rivets or buckling.
Page 2
Revision 39
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
500/600N
Thruster cones and tip cap (500N only) for damage and security. Inspect
53−40−30
for wear between thruster cones and tailboom at points of contact.
53−50−30
Using a flashlight and 10X magnifying glass, inspect horizontal stabilizer
mounting brackets for cracks (pay particular attention to the forward inboard
legs) (Ref. Tailboom Inspection).
Using a bright flashlight, inspect fore and aft radii of the lower portion of
the three upper slot bridges for cracks, illuminate area under the flap. The
flap may be raised slightly, using finger pressure only, to aid in checking this
area (Ref. Tailboom Inspection).
Using a bright light and 10X magnifying glass, inspect the four tailboom
attachment lugs for cracks and fiber damage. Pay particular attention to area
on top of the lug from the radius block to 2 inches aft (Ref. Tailboom
Inspection).
Tailboom closeout fairings for security of attachment hardware. Inspect
for damage and chafing between closeout fairing and tailboom.
369D/E/FF
Horizontal stabilizer for:
53−50−10
Skin damage and loose rivets.
Tip plates for damage. Check for secure attachments (Ref. Horizontal
Stabilizer and Tip Plates Inspection).
500/600N
Horizontal stabilizer for:
53
Skin damage and loose rivets.
Mounting fittings for cracks and security.
Stabilizer attach bolts for security.
369D/E/FF
Vertical stabilizer for:
53−50−10
Damage to leading and trailing edges and damaged stressed side panels
(no repair of side panels permitted).
Mounting fittings for cracks and security.
Tail skid for obvious damage and security (Ref. Vertical Stabilizer
Inspection).
500/600N
Vertical stabilizers for:
53
Damage to leading or trailing edges and damaged side panels.
Cracks in skin, no cracks permitted (pay particular attention to areas
around mounting bolts).
Stabilizer attach bolts for security.
Stabilizer mount bushings for wear, security and correct installation.
Excess play in control linkage, bearings and security of attaching
hardware.
Page 3
Form HOE005 (Rev 5/04)
05-20-00
Revision 40
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
LANDING GEAR
ALL
Landing gear skid tubes and fairings for:
32
Wear and damage in excess of permissible limits.
Upper fairing fillets for freedom of movement and general condition.
Strut attachment points for security and pivot (swivel) bearings for
excessive play.
Landing gear dampers for correct extension, security of attachment and
for signs of fluid leakage. Pivot bearings for excessive play.
Passenger steps for security and damage.
369D/E/FF
Remove landing gear fairing fillets and visually inspect landing gear strut
500N
assemblies for cracks and damage.
369D/E/FF
For aircraft 369D; 001 & subs, 369E; 0001 thru 0528, 369FF; 0001 thru 0114
500N
and 500N; 001 thru 077: Remove plug button from inboard of fairing
assembly. Using a bright light and 10X magnifying glass, inspect rivet hole in
underside of strut for cracks. If crack is found, strut must be scrapped.
CABIN
ALL
Compartment heat and anti−icing valve controls for:
21
Easy and correct operation and rigging.
Heating system heat diffusers for security.
ALL
Seat belts for condition and security.
25
Inertia reels for condition and proper extension/retraction.
ALL
Pilot/copilot controls for:
67
76
Wear, looseness and general condition of control rods and rod end
bearings.
Quick−release pins for condition.
Cyclic, collective and anti−torque controls for free movement.
Cyclic trim actuators for security.
Collective torque tube, support bracket and bungee support bracket for
evidence of cracks, gouges or other visible damage in attach lug and bungee
support bracket attach areas; gaps between bracket and cradle cap of
collective torque tube (use bright light and mirror).
N1 power controls for obvious damage.
Check for minimum cyclic friction adjustment (resistance to turning
spring with fingers).
Flight control system one−way lock (Uniloc) for oil leakage, condition and
security. Fluid reservoir 1/2 − 3/4 full; replenish if low.
Page 4
Revision 35
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
NOTE: With main rotor blades stationary, some friction drag is felt in the cyclic. The collective also has some drag,
plus resistance of the collective bungee spring. Heavy drag is an indication of droop stop deformation caused
by droop stop pounding.
ALL
Engine N1 and N2 (N/A 600N) power controls for:
76
Free movement, full travel, security, obvious damage and proper rigging.
Pilot’s and copilot’s throttle rigging checks at FULL, GROUND IDLE and
CUTOFF positions.
MAIN ROTOR
ALL
Main rotor mixer control push−pull rods, links, scissors and bellcranks for
62
excessive bearing play, bent rods or links, worn bushings and cracked
67
bellcranks or brackets; all rodends centered.
ALL
Main rotor pitch control rod assemblies, upper and lower rod end bearing for
62−30−00
evidence of axial play and for any extrusion, displacement or damage to the
62−30−60
bearing teflon liner. Check that all rodends are centered and security of
lockwire (Ref. Pitch Control Rod Inspection).
ALL
Swashplate for evidence of galling or corrosion of spherical bearing, and
62
seals for deterioration and evidence of grease leakage. Upper and lower dust
boots free from damage and security. Swashplate interrupters and magnetic
pick−up secure.
ALL
Main rotor hub retention strap assemblies for breaks or cracks in strap pack
62−20−00
laminations. Check visible portions of both lead and lag legs of pack in each
62−20−60
pitch housing (Ref. Main Rotor Strap Pack Lamination Inspection). Refer to
04−00−00 for strap pack lamination airworthiness requirements.
ALL
Outboard ends of main rotor hub retention strap assemblies for gaps
62−20−00
between pack laminates (Ref. Main Rotor Strap Pack Lamination
62−20−60
Inspection).
ALL
Main rotor hub feathering bearings for excessive wear (Ref. Main Rotor
62−20−00
Hub Inspection).
62−20−60
Main rotor droop stop ring for corrosion, dents and scratches.
Main rotor droop stop striker plate rollers for play and excessive wear.
Main rotor droop stop follower attachment pins for proper installation.
Main rotor droop stop plunger for corrosion, dents and scratches.
ALL
Main rotor blade damper assemblies for obvious damage, security and
62−20−00
excessive play in blade and pitch housing bearings, bonding of elastomeric
62−20−60
material and corrosion (Ref. Main Rotor Damper and Attachments
Inspection).
ALL
Using bright light and 5X magnifying glass, inspect all main rotor hub
62−20−00
assembly lead−lag links for corrosion, discoloration, pitting, intergranular
62−20−60
cracks or stress corrosion cracks. Any discoloration or pitting is evidence of
more than superficial corrosion, and the main rotor hub must be removed for
replacement of lead−lag links (Ref. Main Rotor Hub Inspection).
Page 5
Form HOE005 (Rev 5/04)
05-20-00
Revision 35
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
ALL
Main rotor hub bearings for roughness by rotating main rotor assembly
62−20−00
several times by hand and listening for unusual noise (Ref. Main Rotor Hub
62−20−60
Inspection).
NOTE: Do not confuse with normal no−load transmission and overrunning clutch noise.
ALL
Main rotor blade and damper attach pins tight and levers properly locked.
62
ALL
Entire trailing edge and tabs for nicks, scratches and cracks generating from
62−10−00
trailing edge (Ref. Main Rotor Blade Inspection).
WARNING: Using a bright light and 5X to 10X magnifying glass, inspect root fitting,
attach lugs and doublers for cracks and security.
ALL
Inspect main rotor blade root fittings, attach lug and lead−lag link attach lug
62−10−00
every 100 hours in accordance with Main Rotor Blade Upper and Lower Root
Fitting, Attach Lug and Lead−Lag Link Attach Lug Inspection (100 Hour). Pay
particular attention to the lower side of the root fitting.
ALL
Using a bright light and 10X magnifying glass, inspect main rotor blade
62−10−00
abrasion strips for security of bonding on lower and upper surfaces, and by
tapping at bond lines. Any blisters, bubbling or lifting of abrasion strip
indicates a void (Ref. Main Rotor Blade Inspection).
ALL
Tip area of main rotor blades for evidence of corrosion; pay particular
62−10−00
attention to mating area of blade skin−to−tip weight interface; verify integrity
of sealant coating (Ref. Main Rotor Blade Forward Tip Cap Inspection and
Corrosion Protection).
ALL
Drain holes in main rotor blade aft tip cap and vent holes in lower skin for
62
clogging. Main rotor tip caps for security and evidence of corrosion.
369D/E/FF
Main rotor hub fairing for cracks, damage and security.
62
500N
DRIVE TRAIN
ALL
Main transmission lubrication and cooling system for:
63
Main transmission case and cooling installation for evidence of leakage
and security of attachment.
Oil cooler blower, mount, ducting and hardware for security and damage.
Oil lines for chafing damage.
Clamps attached to oil lines for evidence of cushion wear or deterioration
(if noted, remove clamp and inspect tube under clamp for chafing damage).
Pressure switch for security and deterioration; wiring for chafing.
369D/E/FF
Tach generator for security and deterioration; wiring for chafing.
63
500N
ALL
Rotor brake for:
63
Pucks and disc for wear and general condition.
Hydraulic lines for security and leaks.
Master cylinder for leaks.
Air in system (spongy feel at brake actuating handle when force is
applied).
Page 6
Revision 35
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
ALL
Overrunning clutch for:
63
Evidence of oil leakage.
Proper operation: turn rotor in forward direction by hand − engine must
decouple; turn rotor in reverse direction − engine must rotate (listen for
turbine noise during reverse rotation). Rotor brake disc should not drag.
NOTE: Normal seal drag may be sufficient to rotate engine at low rpm.
369D/E/FF
For aircraft equipped with 369A5350 overrunning clutch, regrease clutch
63
500N
splines.
ALL
Engine−to−main transmission drive shaft couplings and shaft for condition
63−10−00
and security of attachment.
Bendix couplings only: inspect shaft coupling diaphragms for scratches,
nicks or cracks (Ref. Main Transmission Drive Shaft Inspection (Bendix)).
500/600N
Main transmission−to−fan transmission drive shaft for dents, bulkhead
63
chafing and obvious damage.
Inter−Connect drive shaft for dents and obvious damage.
Free movement of control rod thru interconnect drive shaft.
369D/E
Bendix couplings only: Check tail rotor blade tip movement in excess of 0.75
63
inch, without main rotor blade movement, when tail rotor blades are rocked
back and forth in plane of rotation.
369D/E/FF
Tail rotor drive shaft for:
63−15−10
Evidence of buckling, dents, bulkhead chafing and obvious damage.
Align aft coupling index stripe with corresponding tail rotor transmission
stripe and verify that bulkhead−to−drive shaft index stripes align (Ref. Tail
Rotor Drive Shaft Twist Inspection).
ANTI−TORQUE
Tail Rotor System
369D/E/FF
Tail rotor transmission for:
63−25−10
Corrosion, excessive oil leakage, cracks and other damage.
Check torque of mounting nuts (also tailboom extension hardware on
369FF helicopters) (Ref. Tail Rotor Transmission Installation).
369D/E/FF
Tail rotor and pitch control assembly for:
64
Binding and unusual sounds (teeter blades to check for binding).
Control rod, pitch control links, hub and drive fork for play or damage.
Boots for installation and deterioration.
Retaining nut and lockwasher secure (no broken tangs noted and nut
has not rotated, visual inspection of torque stripe).
*
Pitch control for evidence of seal rotation or loss of grease.
Page 7
Form HOE005 (Rev 5/04)
05-20-00
Revision 39
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
369D/E/FF
Drive fork for;
64
Elastomeric bearing elements for bond failure.
Apply teetering force by hand (stop−to−stop) to rotor blades and inspect
elastomers for radial−molded ridges on each bearing face. Discontinuity in
molded ridges indicates bearing failure. There should by no apparent motion
between the cage and fork, observed motion indicates bond failure.
NOTE: Light swelling, pock marks and crumbs are surface conditions and do not indicate bearing failure.
369D/E
If equipped with conical−type teetering bearings, torque check teeter bolt.
64
Conical bearings for axial or radial play (no play allowed).
369D/E/FF
Tail rotor blades for:
64−10−00
Evidence of damage, including leading edges, trailing edges, skin.
Open vent and drain holes.
Loose or damaged tip caps.
Rivets securing tip cap for installation and condition.
Abrasion strips free of damage, no excessive erosion noted and no
separation in bond around edges or at tip end of blade (Ref. Tail Rotor Blade
Inspection).
While holding hub stationary, check tail rotor blade pitch bearings for
lead−lag play in excess of 0.250 inch (6.35 mm) at blade tip. If excess play is
found, remove blades, replace pitch bearings and inspect hub−to−pitch
bearing contact surface of hub (Ref. COM).
369D/E/FF
Perform Tail Rotor Balance.
18
NOTARR Anti−Torque System
500/600N
Rotate rotor system and check for unusual noises.
64
Fan assembly for cleanliness and damage.
Fan blades for excessive play.
Fan seal for cleanliness, cracks, damage and corrosion.
Check gap between fan blades and tip seal.
Check gap between fan blades and hub.
NOTE: If any of these gaps for any blade exceeds the average gap of the other blades by more than 0.10 inch
(2.54 mm), remove and inspect the tension−torsion strap for that blade.
500/600N
Perform Fan Blade Inspection (100−Hour).
64−25−30
500/600N
Fan Transmission for corrosion, excessive oil leakage, cracks, damage and
63
security on mounting frame. Drain line for cracks and security.
Page 8
Revision 39
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
500/600N
Remove rotating cone and tip cap (500N) and inspect:
67
Cables, cable ends and pulleys for condition and security. Perform
Forward and Center Cable Assembly Inspection and Sector Assembly
and Control Cable Inspection.
Aft cable ends and turnbuckles for condition and security. Evidence of
corrosion pitting requires replacement.
Rotating cone control tubes and cables for freedom of movement and
unusual sounds.
Reinstall rotating cone and tip cap (500N).
ELECTRICAL
NOTE: When possible, use auxiliary power source, not battery, during POWER ON inspection.
ALL
XMSN OIL TEMP, FUEL FILTER and CHIPS warning lights; electrical
95−00−00
circuits for continuity to lamps by connecting jumper wire from each sender
or chip detector terminal stud to an unpainted grounding surface; check each
light for illumination (ref. Caution/Warning System Operational Check).
ALL
Push PRESS TO TEST switch: all caution and warning lights ON; depress
95
instrument light rheostat knob; verify CAUTION lights dim.
369D/E/FF
Conduct operational check of automatic reignition system; igniter noise heard
PFM
500N
and reignition indicator light functions. Reset as required.
369D/E/FF
Do a check of the TOT indicating system for correct calibration (ref. TOT
95−30−00
500N
Indicating System Calibration or Digital TOT Indicating System Inspection).
600N
Do a check of the TOT indicating system for correct calibration (ref. Digital
95−30−00
TOT Indicating System Inspection).
CAUTION: Do not leave landing light ON for more that one minute during next check; lamp will overheat and
lamp life will be shortened.
ALL
Exterior lighting (landing, position and anti−collision lights) for proper
96
operation; all switches OFF after check.
WARNING: Do not leave pitot heater ON for more than one minute during next check; severe burns to
personnel may result.
ALL
PITOT HTR switch ON for a few seconds. Heated pitot tube will feel warm to
95
the touch; turn switch to OFF after check.
600N
Apply power to aircraft and disconnect CIT sensor (Ref. CIT (Compressor
76−00−00
Inlet Temperature) Sensor Replacement); Verify ECU FAIL light illuminates.
Re−connect CIT sensor.
ALL
Clean battery and inspect for:
96
Connector pins for evidence of corrosion.
Leakage (if battery is leaking (wet), remove and replace battery).
Battery case for cracks in support flanges.
Dc wiring for chafing caused by wiring rubbing against battery case.
*
Deep cycle charge (recondition) battery every 100 hours or on
conditional basis at operator’s discretion.
Page 9
Form HOE005 (Rev 5/04)
05-20-00
TR12-003
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
ALL
Functionally check and inspect all installed avionics, auxiliary or optional
97
systems and equipment. Do not actuate hoist guillotine or emergency floats.
ENGINE COMPARTMENT
ALL
Exhaust stack(s) and exhaust supports for cracks, defects and improper
78
attachment.
ALL
Engine compartment plumbing and electrical relay installation on left or right
96
side oleo (landing gear damper) support fitting for good condition and
security of mounting. Diodes for broken terminals and wires. Diode bracket
for security and corrosion.
ALL
Entire engine for:
71
75
Loose bolts; loose or broken connections.
76
Accessories for security and broken or missing lockwire.
Fuel and oil lines for chafing and kinking.
Fuel drain line valve for leakage.
Oil cooler and cooler deflector for security and obvious damage.
Accessible areas for obvious damage; evidence of fuel and oil leaks.
Engine mounts for cracks and play in mounting hardware at engine and
airframe (retorque any loose mounting bolts).
Fuel control and compressor exterior for condition and security.
369D/E/FF
RPM governor lever control rod (replace if aluminum).
76−10−00
500N
369D/E/FF
Clean and lubricate drive splines of starter−generator drive shaft, and female
96
500N
splines in engine accessory gear case on dry spline installations.
369D/E/FF
Anti−ice air tubes and compressor scroll for cracks or breaks at the anti−ice
75−10−00
500N
air valve and bleed port. If cracks exist, check engine for possible vibration
causes (Ref. Engine Anti−icing System and applicable Allison Engine
Operation and Maintenance Manual).
AFTER INSPECTION
ALL
Touch−up all damaged paint and exterior markings, as necessary.
20
ALL
Ensure all fluid levels are correct; service as required.
12
ALL
Perform operational check of particle separator filter (Ref. Scavenge Air
71−10−10
Operational Check).
Page 10
TR12-003
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 100−Hour or Annual Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Torque Events
Model
Requirement
Chap/Sect
Initial
ALL
Install or close all stressed panels, covers and trim panels removed or
52−50−00
opened for inspection. Check closure, fit and security. All loose equipment
for proper stowage.
CAUTION: Helicopter must not be flown unless controls access panel and fuel cell access panels in cargo
compartment are securely installed. These are stressed panels.
POST INSPECTION RUN UP
See applicable Pilot’s Flight Manual for cockpit check and engine starting procedures. For troubleshooting
procedures, refer to applicable section of this manual.
100−HOUR OR ANNUAL INSPECTION CERTIFICATION
It is certified that this helicopter has been thoroughly inspected as required by FAR, found to be airworthy, and
appropriate entries made in the helicopter log book. It is further certified that the helicopter conforms to FAA
specifications, that all FAA Airworthiness Directives and Manufacturer’s Service Notices and Maintenance
Manual data have been complied with, and the helicopter records are in proper order
Signature
Rating Type or Certificate No.
Date
2. Retirement Index Numbers Attachment
Refer to Section 04-00-00 for components
requiring calculation of RIN's/TE's and
Table 2 is to be used for calculating and
information pertaining to calculation of
recording the Retirement Index Number (RIN)
RIN's/TE's.
or Torque Events (TE) of components that are
affected by Torque Events (TE).
Component must be scrapped when it reaches
This record of RINs/TE's should be kept as a
1,000,000 RIN's or maximum TE's (Ref. Sec.
permanent record.
04-00-00).
Table 2. Permanent Record of Retirement Index Numbers/Torque Events
Component
Part No.
Serial No.
Hours
TE’s
RIN’s
Signature
Page 11
Form HOE005 (Rev 5/04)
05-20-00
Revision 39
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 2. Permanent Record of Retirement Index Numbers/Torque Events
Component
Part No.
Serial No.
Hours
TE’s
RIN’s
Signature
Page 12
Revision 39
05-20-00
Form HOE005 (Rev 5/04)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−20−10
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
300−HOUR INSPECTION CHECKLIST
1.
300−Hour Inspection
NOTE:
D The Chap/Sect column of the following
table is for reference unless a specific in
This check sheet is designed to be used when
spection requirement is called out. If
performing scheduled inspections as defined
there is only two numbers in the column,
under FAR Part 91. This checklist, when
it refers to the Chapter. If there is three
completed, should be kept as a permanent part
numbers, it refers to the Section the in
of the helicopter's records. Adherence to
spection is found.
Maintenance Manual information is required,
D Refer to applicable Rolls-Royce engine in
and the manual should be consulted when
spection check list for required engine
using the checklist.
maintenance.
Table 1. 300−Hour Inspection
Registration No.
Serial No.
Helicopter Hours
Chap/Sec
Model
Requirement
t
Initial
EXTERIOR
ALL
Retorque tailboom attachment bolts.
53
500/600N
Remove rotating cone and tip cap (500N) and inspect:
53
Cone rollers for condition and security.
Four fasteners that attach 500N3760−1 upper input shaft to the
stationary thruster for play (replace pins and collars if any play is found).
Three fasteners that attach 500N3759 support shaft assembly for play (if
play is found in top bolt, retorque to 10 − 15 inch−pounds (1.13 − 1.69 Nm).
Replace pins and collars if any play is found in bottom fasteners).
Reinstall rotating cone and tip cap (500N).
369D/E/FF
Remove engine inlet bypass door and inspect:
71−10−10
.Latches, hinges and hardware for condition, wear and security.
.Cables, cable ends and pulleys for condition, corrosion and wear.
Remove and replace the latch retention cotter pin (located inside the
attach ”U” clamp) (Ref. Engine Air Inlet Bypass Door 300−Hour Inspection).
369D/E/FF
Check horizontal and vertical stabilizer attach bolts for proper torque (Ref.
53−50−10
Horizontal Stabilizer Tip Plate Installation and Vertical Stabilizer Installation).
369D/E/FF
Check lower surface of horizontal stabilizer for drain holes. Also check for
53−50−10
gaps between upper and lower doublers and stabilizer skin (Ref. Horizontal
Stabilizer and Tip Plates Inspection).
500/600N
Control tubes and bellcranks in horizontal stabilizer for condition and
53
security.
Page 1
Form HOE006 (04/06)
05-20-10
Revision 39
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 300−Hour Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Chap/Sec
Model
Requirement
t
Initial
500/600N
Inspect S.A.S. system for:
67
Actuator for security and damage (no damage allowed).
Wiring for condition and security (no wire chaffing, fraying or insulation
cracking allowed).
Actuator mounting bracket for cracks, pay particular attention to area
around four rivet attach holes (no cracks allowed).
Rate gyro and control box for security in mount and electrical connector
secure. Inspect mount for security and condition (no corrosion or cracks
allowed).
LANDING GEAR
ALL
Perform Landing Gear Inspection.
32−10−00
ALL
Perform Cabin Entry Step Inspection.
32−10−00
CABIN
ALL
Remove instrument console base covers and inspect anti−torque pedal
67
crossover torque tube and bellcrank for cracks, damage and security.
ALL
Push−pull rods for excessive bearing play, wear and security.
67
ALL
Perform Tunnel−Routed Control Rod Inspection.
67−10−00
ALL
Check oil tank for security and evidence of leakage and damage.
79
MAIN ROTOR
ALL
Perform Swashplate Inspection.
62
ALL
Perform Lead−Lag Bolt Inspection.
62
ALL
Perform Main Rotor Hub Droop Angle Check.
62
ALL
Perform Main Rotor Blade Inspection.
62
ALL
Inspect main rotor mast, mast base and mast base support structure for
63−30−00
evidence of cracks. Check with bright light and 5X magnifying glass. Visually
check mast support bolts for security and condition. Inspect internal bore for
chipping, orange peeling or flaking paint (Ref. Main Rotor Static Mast
Inspection and Repair).
ALL
Inspect hoisting eye−bolts for cracks or corrosion.
63
369D/E/FF
369D25510 drive shaft only, perform Main Rotor Drive Shaft Inspection
63−10−00
500N
(300−Hour).
DRIVE TRAIN
ALL
Remove, inspect and clean main transmission chip detectors.
63
369D/E/FF
369A5350 Overrunning Clutch: Perform Ball Bearing Inspection and Grease
COM
500N
Repack (300 Hour).
ALL
369F5450 Overrunning Clutch: Perform Ball Bearing Grease Repack (300
COM
Hour).
369D/E/FF
Remove tail rotor drive shaft and check boom fairing and tailboom for
53
buckles, dents, bulkhead chafing and obvious damage.
Page 2
Revision 39
05-20-10
Form HOE006 (04/06)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. 300−Hour Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Chap/Sec
Model
Requirement
t
Initial
369D/E/FF
Remove tailboom control rod and inspect for wear though hard anodized
67−20−10
surface (Ref. Tailboom Control Rod Replacement); inspect grommets for
wear and deterioration.
369D/E/FF
Check shaft damper for proper friction drag. Inspect damper for damage and
63−15−10
security (Ref. Tail Rotor Drive Shaft Damper Inspection).
369D/E
Check forward and aft coupling bolt and socket for indication of contact,
63−15−10
Bendix couplings only (Ref. Tail Rotor Drive Shaft Inspection).
ANTI−TORQUE
Tail Rotor System
369D/E/FF
Remove, inspect and clean chip detectors.
63
369D/E/FF
Check for contact between tail rotor bellcrank and tail rotor transmission
67
housing at extreme right pedal travel.
369D/E/FF
Tail rotor assembly: Elastomeric teeter bearings for wear; bond between
64−20−00
concentric metal cones and elastomer rings of bearing assembly (Ref.
Elastomeric Bearing Inspection).
369D/E/FF
Remove blade stop for thorough inspection; in particular, check for cracks or
64−30−00
splits in stem area (Ref. Tail Rotor Blade Stop Inspection).
NOTARR Anti−Torque System
500/600N
Check balance weights for security. If any balance weight stud is found to be
64
loose, perform Fan Balance Stud Replacement.
500/600N
Remove, inspect and clean fan transmission chip detector.
63
500/600N
Remove tailboom:
53
Perform visual inspection of fan assembly for:
64
Cracks, nicks or corrosion.
Blades for cracks, nicks or impact damage.
Check pitch horn counterweights for security. If counterweight(s) are
found loose, perform Pitch Horn Counterweight Set Screw Replacement
(Ref. Sec. 64−25−30). NOTE: Access the forward counterweights through
the fan inlet (fan hub fairing must be removed).
Gap between fan blade and tip seal and gap between fan blade and hub
(inboard end of the blade). If any of these gaps for any blade exceeds the
average gap of the other blades by more than 0.10 inch (2.54 mm)., remove
and inspect the tension−torsion strap for that blade.
Fan liner for cracks, debonding or corrosion of liner material.
P−seal for tears, deterioration and debonding.
Reinstall tailboom (on 600N only, install new tailboom mounting bolts).
ELECTRICAL
NOTE: When possible, use auxiliary power source during POWER ON inspection, not battery.
ALL
Perform Battery Temperature Sensing Switches Testing.
96
369D/E/FF
Deleted. Moved to Section 05−20−00, 100−Hour or Annual Inspection
500N
Checklist, Table 1. 100−Hour or Annual Inspection, ELECTRICAL.
Page 3
Form HOE006 (04/06)
05-20-10
TR12-003
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. 300−Hour Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Chap/Sec
Model
Requirement
t
Initial
ENGINE COMPARTMENT
ALL
Inspect starter/generator for:
96
Condition of brushes, electrical connections and commutator.
Screens for clogging.
Condition of O−ring on drive spline.
Damper backplate and clutch for condition.
ALL
Perform Fuel Filter (Bypass) Caution Light Pressure Switch Test.
28−00−00
28−00−60
NOTE: Also, perform this operational check whenever low pressure fuel pump filter element is replaced for any
reason, or if contaminated.
Page 4
Revision 38
05-20-10
Form HOE006 (04/06)
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−20−15
Continued
Airworthiness
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
YEARLY INSPECTION CHECKLIST
1. Yearly Inspection
NOTE:
D The Chap/Sect column of the following
table is for reference unless a specific in
This check sheet is designed to be used when
spection requirement is called out. If
performing special inspections as defined
there is only two numbers in the column,
under FAR Part 91. This checklist, when
it refers to the Chapter. If there is three
completed, should be kept as a permanent part
numbers, it refers to the Section the in
of the helicopter's records. Adherence to
spection is found.
Maintenance Manual information is required,
D Refer to applicable Allison engine inspec
and the manual should be consulted when
tion check list for required engine main
using the checklist.
tenance.
Table 1. Yearly Inspection
Registration No.
Serial No.
Helicopter Hours
Model
Requirement
Chap/Sect
Initial
1 YEAR
EXTERIOR
ALL
Perform Pitot Static System Inspection.
95−10−00
ALL
Check outside air temperature probe for security and obvious damage.
95
ALL
Particle separator for condition and servicing.
71
NOTE: If equipped with a Donaldson Particle Separator, ensure O−rings for rubber boot are
71−10−10
not deteriorated (Ref. Donaldson Particle Separator Inspection).
ALL
Perform engine air inlet Air Pressure Sensing Switch Calibration Check.
71−10−10
71−10−60
LANDING GEAR
369D/E/FF
Perform Landing Gear Strut Inspection.
32−10−00
500N
CABIN
ALL
First aid kit contents and security of attachment.
25
Fire extinguisher for charge pressure and security of attachment.
26
ALL
Inspect seats, interior trim, panels and covers for damage and security.
25
Inspect seat base structure for evidence of deformation.
ALL
Perform Tank Vent System Inspection.
28−00−00
28−00−60
369D/E/FF
Inspect fuel vent system rollover valve for condition and operation (Ref. Tank
28−00−00
500N
Vent System Inspection).
NOTE: The 369H8108−505, 369H8108M, 369H8108−501M,−503M and 369D28108−1 rollover valves do not re-
quire a yearly inspection.
Page 1
05-20-15
Revision 29
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. Yearly Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Model
Requirement
Chap/Sect
Initial
ALL
Actuate and visually inspect fuel shutoff valve for proper operation.
28−00−00
28−00−60
Inspect fuel cell sending unit for electrical terminals and wiring for
security and condition.
Inspect wiring harness between sending unit and instrument cluster.
Check FUEL LEVEL LOW caution light for proper operation (Ref. Fuel
Level Low Caution Light System Test).
600N
Aircraft WITHOUT airframe fuel filter option:
28−00−60
Perform Fuel Transfer System Functional Check.
ALL
Inspect instrument plumbing and electrical wiring for chafing, damage and
95
security.
96
NOTE: In the following inspection, do not pull on torque or oil pressure lines.
369D/E/FF
Inspect torque and oil pressure lines from the firewall forward to the
95
500N
instruments for seepage, chafing, cracking, damage and security.
ANTI−TORQUE
500/600N
Drain fan transmission. Flush with sufficient new oil to remove sludge
12
accumulation. Refill with new oil.
369D/E/FF
Drain tail rotor transmission. Flush with sufficient new oil to remove sludge
12
accumulation. Refill with new oil.
369D/E/FF
Inspect Tail Rotor Blade Assembly pitch horn area for corrosion.
64−30−00
FLIGHT CONTROLS
500/600N
Inspect forward thruster cable at Sta. 123.30 for crack in relieved area
67
between threads and swage.
Inspect the conduit cap of the telescopic swivel end for crack, corrosion and
obvious damage to the cable swage area or evidence of ball separation.
500N
Inspect center thruster cable at Sta. 264.00 for crack in relieved area
67
between threads and swage.
Inspect the conduit cap of the telescopic swivel end for crack, corrosion and
obvious damage to the cable swage area or evidence of ball separation.
600N
Inspect center thruster cable at Sta. 292.00 for crack in relieved area
67
between threads and swage.
Inspect the conduit cap of the telescopic swivel end for crack, corrosion and
obvious damage to the cable swage area or evidence of ball separation.
ELECTRICAL
NOTE: When possible, use auxiliary power source, not battery, during POWER ON inspection.
ALL
Check wiring from battery connector to warning lights for continuity, use an
96
ohmmeter.
ENGINE COMPARTMENT
ALL
Inspect firewall insulator panels for security and obvious damage.
53
ALL
Inspect overrunning clutch firewall seal and engine compressor firewall
63
(plenum chamber) seal for proper sealing and good condition.
71
Page 2
TR12-001
05-20-15
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. Yearly Inspection (Cont.)
Registration No.
Serial No.
Helicopter Hours
Model
Requirement
Chap/Sect
Initial
4 YEARS
NOTE: Shelf life of bearings preserved with grease is limited to 4 years. For this reason, it is of extreme import-
ance that bearings carry the date of last lubrication or preservation and inspection. After 2 years of shelf life,
it is advisable to relubricate bearings upon installation.
ALL
Clean, inspect and relubricate (repack) main rotor swashplate bearings that
COM
have been in storage.
500/600N
Clean, inspect and relubricate (repack) fan support and pitch plate bearings
64
that have been in storage.
369D/E/FF
Clean, inspect and relubricate (repack) tail rotor swashplate (duplex)
64
bearings that have been in storage.
Page 3
05-20-15
Revision 31
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
Page 4
Revision 43
05-20-15
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−20−20
Continued
Airworthiness
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
SPECIAL INSPECTIONS
1. Special Inspection Hourly and Calendar
NOTE:
D The Chap/Sect column of the following
This table is a schedule of time-phase inspec
table is for reference unless a specific in
tions that are contingent upon elapsed flight
spection requirement is called out. If
time or calendar time. These inspections
there is only two numbers in the column,
require a Log Book entry. Adherence to
it refers to the Chapter. If there is three
Maintenance Manual information is required,
numbers, it refers to the Section the in
and the manual should be consulted when
spection is found.
using this checklist.
D Refer to applicable Rolls-Royce engine in
spection check list for required engine
maintenance.
Table 1. Special Inspections Hourly
Model
What to Inspect
Chap/Sect
AFTER INSTALLATION OF NEW 369F5100 MAIN ROTOR TRANSMISSION
ALL
Perform transmission run−in (Ref. Main Transmission Run−In Procedure)
63−20−25
2 − 10 HOURS AFTER INSTALLATION OF TAIL ROTOR TRANSMISSION
369D/E/FF
Using drag torque previously recorded, apply a torque load of 75 − 95 inch−pounds
63−25−10
(8.47 − 10.73 Nm) plus the noted drag torque (noted for each individual nut) to each
mounting nut of the transmission (Ref. Tail Rotor Transmission Installation).
EVERY 10 HOURS or BEFORE FIRST FLIGHT OF EVERY DAY
600N
Effectivity: RN003−RN059 (Ref. SB600N−039), Perform Tailboom Attach Fitting
53−30−30
Inspection (Ref. EAD 2001−24−51) (Not required if TB600N−007R1 has been
accomplished).
EVERY 15 HOURS
369D/E/FF
Effectivity: 369H1203−BSC or 369H1203−21 lead−lag link assemblies with at least
62−10−00
500 hours, perform Main Rotor Blade Upper and Lower Root Fitting Attach Lug and
Lead−Lag Link Attach Lug Inspection (25 Hour) and every 100 hours in accordance
with Main Rotor Blade Upper and Lower Root Fitting Attach Lug and Lead−Lag Link
Attach Lug Inspection (100 Hour) until retirement of 369H1203−BSC or−21 Lead−Lag
Link Assembly. (Reference AD 95−03−13).
25 HOURS AFTER REPLACING TAIL ROTOR DRIVE FORK HINGE BOLT
369D/E/FF
Check rotational torque of bolt by applying 125 inch−pounds (14.12 Nm) with torque
64−20−10
wrench. If 125 inch−pounds (14.12 Nm) torque does not rotate bolt, preload is correct
64−20−20
(Ref. COM, Hub and Fork Assembly).
25 HOURS AFTER INSTALLATION OF OIL COOLER BLOWER
ALL
With two pounds of force applied, check belt tension for 0.17 to 0.20 inch (4.32 − 5.08
63
mm) deflection. Check pulley (Ref. Cooling Blower Belt Tension Check and
Adjustment). Check oil cooler blower driven pulley retaining nut for minimum torque of
160 inch−pounds (18.08 Nm). If loss of torque is noted, remove pulley nut and
inspect pulley shaft and splines for condition. Reinstall nut and torque to 160 − 190
inch−pounds (18.08 − 21.47 Nm) plus drag torque.
Page 1
05-20-20
Revision 43
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. Special Inspections Hourly (Cont.)
Model
What to Inspect
Chap/Sect
EVERY 25 HOURS WITH 2 FAILED LAMINATES IN MAIN ROTOR STRAP ASSEMBLY
369D/E/FF
Inspect in accordance with Main Rotor Strap Pack Lamination Inspection at 25−hour
62−20−00
500N
intervals if 2 laminates have failed in any one leg or tongue area of any strap
assembly. A single cracked laminate between the shoes at the outboard end of a strap
pack is cause for rejection of the hub assembly (Ref. Main Rotor Strap Pack
Lamination Inspection).
EVERY 25 HOURS WITH 1 FAILED LAMINATES IN MAIN ROTOR STRAP ASSEMBLY
600N
Inspect in accordance with Main Rotor Strap Pack Lamination Inspection at 25−hour
62−20−60
intervals if 1 laminate has failed in any one leg or tongue area of any strap assembly.
A single cracked laminate between the shoes at the outboard end of a strap pack is
cause for rejection of the hub assembly (Ref. Main Rotor Strap Pack Lamination
Inspection).
EVERY 25 HOURS
NOTE: This inspection does not apply to 369D21100−516, −517, −523 and 369D21102−503, −517, −523 main
rotor blades or the 369H1203−51 and −61 lead−lag links.
369D/E/FF
Visually inspect exposed portion of all installed main rotor blade upper and lower root
62−10−00
fitting attach lugs and main rotor hub lead−lag link attach lugs for broken or cracked
lugs, corrosion or other damage to the lug areas (Ref. Main Rotor Blade Upper and
Lower Root Fitting Attach Lug and Lead−Lag Link Attach Lug Inspection (25−Hour)).
EVERY 50 HOURS
369D/E/FF
Effectivity: On models equipped with Rotorcraft Litter Kit: visually inspect litter doors
CSP−026
500N
for condition and security of quick−release fasteners. Rubber gasket between window
glass and door for proper sealing.
EVERY 50 HOURS IF CRACKS ARE FOUND IN FAN LINER
NOTE: If cracks protrude into Felt Metal Seal, replace seal.
500/600N
Inspect fan liner to ensure cracks do not protrude into Felt Metal Seal (Ref.
64−25−30
Anti−Torque Fan Liner (Felt Metal Seal) Inspection).
EVERY 100 HOURS
ALL
If installed, floats and associated components for condition and security.
32
ALL
Effectivity: With 369F5450−501 overrunning clutch installed, remove clutch assembly
63
and inspect clutch retainer, bearing carrier and housing at pin and shoulder for
evidence of spinning and/or wear. If spinning and/or wear is observed, replace clutch
assembly.
EVERY 300 HOURS
600N
Replace tailboom attach bolts with new bolts, scrap removed bolts
53−40−30
(Ref. Tailboom Installation).
Inspect radius blocks and tailboom attach points for corrosion and cracks
(Ref Tailboom Inspection).
EVERY 300 HOURS OR ONE YEAR (Whichever occurs first)
ALL
Effectivity: For 369D25100 main transmission serviced with MIL−L−23699 oil, drain
12
main transmission oil system; Flush with sufficient new oil to remove sludge
accumulation. Replace filter and refill with new oil.
Page 2
Revision 43
05-20-20
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 1. Special Inspections Hourly (Cont.)
Model
What to Inspect
Chap/Sect
500/600N
Effectivity: Forward and center cable couplings; Using a bright light and 10X
67−20−30
magnifying glass, inspect inner coupling male and female connectors for corrosion
pitting or cracks; none allowed.
EVERY 300 HOURS OR TWO YEARS (Whichever occurs first)
600N
Main rotor upper thrust bearing assembly must be relubricated every 2 years or 300
62−20−60
hours, whichever occurs first (Ref. Main Rotor Hub Upper Bearing Grease Repack,
Inspection and Replacement).
EVERY 300 HOURS
ALL
Effectivity: 369D21400−503 (369D/E/FF − 500/600N) or M50452 (369D/E/FF − 500N)
62−20−00
lead−lag dampers with at least 4200 hours, inspect for deterioration until deterioration
62−20−60
is sufficient to retire assembly (Ref. Main Rotor Damper and Attachments Inspection
and Main Rotor Damper Weight Loading and Extension Check).
NOTE: The following inspection does not apply to 369D25100−505 and −507 transmissions.
369D/E/FF
Visually inspect upper surface of main transmission output shaft assembly (ring gear
63−20−00
carrier) for bulging or raised surfaces. Using 10X magnifying glass, inspect upper
surface of shaft for cracks. (Ref. COM, Output Drive Shaft Visual Inspection)
369D/E
Replace anti−ice/airframe fuel filter element (if installed) (Ref. Anti−Ice Fuel Filter
28−25−00
500/600N
Replacement).
ALL
Mist eliminator and access door for proper installation (attaching hardware for
71
security).
ALL
Hoist installation (if installed) for condition and security.
25
EVERY 600 HOURS OR ONE YEAR (Whichever occurs first)
ALL
Effectivity: 369D25100 main transmission serviced with Mobil AGL oil and 369F5100
12
main transmission, drain main transmission oil system; Flush with sufficient new oil to
remove sludge accumulation. Replace filter and refill with new oil.
369D/E/FF
Effectivity: 369F5510 Main Rotor Drive Shaft, perform 369F5510 Main Rotor Drive
63−10−00
500N
Shaft Inspection (Ref. 600N5510 and 369F5510 Main Rotor Drive Shaft Inspection).
600N
Effectivity: 600N5510 Main Rotor Drive Shaft, perform 600N5510 Main Rotor Drive
63−10−00
Shaft Inspection (Ref. 600N5510 and 369F5510 Main Rotor Drive Shaft Inspection).
EVERY 600 HOURS
ALL
Cyclic control system for excessive slack or free play. Cyclic control stick, at grip, for
67−10−00
play in excess of 3/8 inch (9.53 mm) (Ref. Main Rotor Flight Control System 600−Hour
Inspection).
ALL
Effectivity: 369D21400−503 (369D/E/FF − 500/600N) or M50452 (369D/E/FF − 500N)
62−20−00
lead−lag dampers with less than 4200 hours, inspect for deterioration until
62−20−60
deterioration is sufficient to retire assembly (Ref. Main Rotor Damper and Attachments
Inspection and Main Rotor Damper Weight Loading and Extension Check).
500/600N
Using a dial indicator, measure the rotation of the fan pitch control clevis mounted on
63−25−30
the fan pitch control tube. If clevis rotation is more than 0.025 in. (0.635 mm), inspect
67−20−30
splines on fan pitch control tube (Ref. Fan Pitch Control Tube Inspection) and splines
in tube support (Ref. Tube Support Inspection).
Page 3
05-20-20
TR12-001
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
Table 1. Special Inspections Hourly (Cont.)
Model
What to Inspect
Chap/Sect
EVERY 1200 HOURS
ALL
Test battery over temperature sensor unit for proper operation and accuracy (Ref.
96−05−00
Battery Temperature Sensing Equipment Operational Check).
500/600N
Perform visual inspection, using a 10x magnifying glass, on horizontal stabilizer
53
mounting brackets (pay particular attention to the forward inboard legs).
500N
Regrease YSAS actuator (Ref. YSAS Actuator Regrease Procedure).
67−20−30
600N
Perform Forward Upper Longeron Inspection (L153, R153).
53−30−30
EVERY 1200 HOURS OR 2 YEARS (WHICHEVER OCCURS FIRST)
500/600N
Clean, inspect and relubricate (repack) fan support and pitch plate bearings (Ref.
64−25−30
Anti−Torque Fan Bearing Regreasing).
500/600N
Perform Anti−Torque Fan Inspection.
64−25−30
500/600N
Check pitch bearing retainer for cracks or damage.
64
EVERY 2700 HOURS OR 2 YEARS (WHICHEVER OCCURS FIRST)
600N
Main rotor lower thrust bearing assembly must be relubricated every 2 years or 2700
62−20−60
hours, whichever occurs first.
600N
Clean, inspect and relubricate (repack) main rotor swashplate bearings.
62−30−60
EVERY 2770 HOURS OR 2 YEARS (WHICHEVER OCCURS FIRST)
369D/E/FF
Clean, inspect and relubricate (repack) main rotor swashplate bearings and main rotor
62−20−00
500N
hub tapered bearings (Ref. Main Rotor Hub Tapered Bearing Replacement).
369D/E/FF
Clean, inspect and relubricate (repack) tail rotor swashplate bearings (Ref. Tail Rotor
64−30−00
Swashplate Bearing Regreasing).
EVERY 6,000 HOURS
DELETED
AT 6000 HOURS AND EVERY 100 HOURS THEREAFTER
600N
Remove tunnel control boot. Inspect interface between 369H2564 tunnel beams and
53−30−30
369D22508−7 web for cracks (Ref. Control Tunnel (FS 78.50) Beam Inspection).
600N
Effectivity: (RN003−RN077 with TB600N−007 completed, and RN078 and subs)
53−30−30
Perform Forward Upper Longeron Inspection (L137, R137).
AT 15,000 HOURS AND EVERY 1500 HOURS THEREAFTER
600N
Effectivity: (RN003−RN077 with TB600N−007 completed, and RN078 and subs)
53−30−30
Perform Lower Longeron Inspection (L158, R158).
Page 4
Revision 43
05-20-20
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Table 2. Special Inspections Calendar
Model
What to Inspect
Section
(DAILY) BEFORE FINAL SHUTDOWN IN CORROSIVE ENVIRONMENT
ALL
It is recommended that before shutdown from the last flight of the day, for helicopters
20−40−00
operating in a corrosive environment, a Tri−Flow wash be preformed on the main
rotor hub and strap pack assembly (Ref. Main Rotor Hub Corrosion Prevention
(Tri−Flow Wash Procedure)).
(DAILY) AFTER FINAL SHUTDOWN IN CORROSIVE ENVIRONMENT
500N
It is recommended that after shutdown from the last flight of the day, for helicopters
20
operating in a corrosive environment, the splitter bungee spring be sprayed with
Tri−Flow.
EVERY 6 MONTHS OR 5 INFLATIONS
ALL
Inflate emergency floats to 4.5 psi (0.3164 kg/cm2) for one hour. Check for leaks and
32−82−00
condition. Continue inflation to 5.5 psi (0.3867 kg/cm2) and check that chamber
pressure relief valves operate. Pressure−test float compartments (Ref. Float
Compartments Pressure Test).
AFTER COMPRESSOR WATER WASH/RINSE WITH PARTICLE SEPARATOR INSTALLED
ALL
During engine run after compressor water wash with particle separator installed, it is
RFM
recommended that scavenge air switch be switched on to remove any moisture that
has accumulated in the solenoid air valve.
BEFORE OPERATION OF BREEZE HOIST SYSTEM
ALL
Prior to daily hoisting operations: unreel and inspect entire length of hoist cable for
01
broken strands (cluster of 7 wires), excessive broken wires, corrosion, and security of
attachment to cable drums and swivel hook. Replace cable if broken strand or
excessive broken wires are noted. (Refer to hoist manufacturer’s handbook, Table
201.)
AFTER FIRST FLIGHT WITH NEW EXHAUST GASKET INSTALLED
369FF/600N
Exhaust bolts should be retorqued after first flight. If bolts are found to be
78−30−00
loose, retorque after every flight until bolts retain torque.
Page 5
05-20-20
Revision 38
CSP-HMI-2
MD Helicopters, Inc.
MAINTENANCE MANUAL
This Page Intentionally Left Blank
Page 6
Revision 36
05-20-20
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
Section
05−50−00
Continued
Airworthiness
MD Helicopters, Inc.
CSP-HMI-2
MAINTENANCE MANUAL
CONTINUED AIRWORTHINESS
CONDITIONAL INSPECTIONS
1. General
It is possible you will need to do more than one
of the inspections or procedures shown in
This section contains the unscheduled or
Table 1 of this section. Do all inspections that
conditional inspections. You must do the
are applicable.
necessary Maintenance Manual specific
inspections and procedures shown in Table 1 to
NOTE: Refer to the applicable Rolls-Royce En
make sure there is continued airworthiness of
gine Operation and Maintenance Manual
the helicopter.
(Ref. Section 01-00-00, Table 201) for de
tailed requirements on inspection of the en
Rotorcraft and components involved in
gine for specific or unique conditions com
accidents or incidents must be inspected
parable to those listed.
and/or tested as required to make sure they
are in a condition of safe operation and
conform to type design. Accident or incident
WARNING
parts are exposed to extreme forces, heat or
immersion that can have a serious effect on
D All components, assemblies, or parts
structural integrity. In some cases, even
that are removed for overhaul or re
though inspection indicates the part is
pair must be identified with the
acceptable, the part must be removed from
cause for removal.
service and scrapped.
D All other components, assemblies, or
Aircraft and component records must be clear
parts that need to be replaced, must
be discarded.
and contain the necessary details to establish
a complete parts history. Without a complete
documented parts history, inspection of a part
2. Hard Landing
per CSP-HMI-2 is not sufficient to determine
if the part is acceptable for installation. This is
A hard landing is an incident or accident in
especially critical for life-limited components,
which the helicopter hits the ground with
flight safety critical aircraft parts (FSCAP)
sufficient force to cause:
and primary load structures.
D main rotor blade to hit the tailboom or upper
Damage from accidents and incidents are
fairings or cowlings.
wide-ranging. The conditional inspection
requirements in CSP-HMI-2, Chapter 05
D permanent deformation of the landing gear
cannot fully relate to the accident or incident
more than permitted limits.
that occurred. If you are not sure what
inspections and/or tests are required to make
D the lower fuselage, lower tailboom surface,
sure the rotorcraft or parts are in a condition
tailrotor, or thruster to touch the ground.
of safe operation and conform to type design,
do the following. Record all information
Use the schedule of inspections in Table 1,
regarding the accident or incident and contact
Conditional Inspections, After Hard Landing if
the MDHI Field Service Department for the
you think a hard landing has occurred.
necessary inspection/tests and maintenance
procedures.
3. Overspeed
If there is an incident with your helicopter not
shown in this section, record all information
Overspeed is an incident in which the rotor
regarding the incident and speak to the Field
speed (NR) is more than the limits shown in
Service Department at MDHI, Mesa, Arizona.
the applicable Rotorcraft Flight Manual. Use
Telephone 1-800-388-3378 or (480) 346-6387.
the schedule of inspections in Table 1, Condi
DATAFAX: (480) 346-6813 for inspections and
tional Inspections, After Main Rotor Over
maintenance procedures you need to do.
speed when an overspeed has occurred.
Page 1
05-50-00
Revision 44
|
||
|
|
|
