BBM OUTLAW XP MODELS ZERO-TURN MOWER. Manual - part 2

PAGE



5

SECTION 2:

MOWER SAFETY GUIDELINES

Never allow untrained people to operate this machine. It is the owner’s responsibility to get training and see to it that anyone who has
permission to use your machine receives the proper training. Do not mow around people. The factory discharge chute is designed
to deflect debris downward, but it could be possible for debris to be thrown in a way that can cause damage to people or property.
Seek additional training when possible to learn more about safety techniques and practices.

This cutting machine is capable of

amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result
in serious injury or death.

GENERAL OPERATION

2.1  Read, understand, and follow all instructions on the machine and in the manual before starting.
2.2  Do not put hands or feet near rotating parts or under the machine. Keep clear of the discharge opening at all times.
2.3  Always remain seated while operating the machine. If the machine is equipped with Roll Over Protection (ROPs), always buckle

your seat belt.

2.4  Only allow responsible adults who are familiar with the instructions to operate this machine.
2.5  Clear the area of objects such as rocks, wire, toys, etc., which could be thrown by the blades.
2.6  Always maintain a safe distance from people and pets just prior to, and during, operation. Stop the machine if anyone enters the area.
2.7  Never carry passengers.
2.8  Do not mow in reverse unless absolutely necessary. Always look down and behind before and while backing.
2.9  Never direct discharged material toward anyone. Avoid discharging material against a wall or obstruction as material may

ricochet back toward the operator. Stop the blades when crossing gravel surfaces.

2.10  Never operate the machine without the discharge chute, grass catcher, or other safety devices correctly in place and functioning

properly.

2.11  Slow down before turning.
2.12  Always disengage blades, place steering controls in neutral, engage parking brake, and remove ignition key when leaving

operators seat. Never leave a running machine unattended.

2.13  Disengage blades when not mowing. Shut off engine and wait for all parts to come to a complete stop before cleaning the

machine, inspecting the machine for damage, removing the grass catcher, or unclogging the discharge guard.

2.14  Always operate machine in daylight or with adequate working lights.
2.15  Do not operate the machine while under the influence of alcohol or drugs.
2.16  Watch for traffic when operating near or crossing roadways.
2.17  Always wear eye protection when operating or servicing the machine.
2.18  Always wear ear protection, such as earplugs, while mowing.
2.19  Use extra care when loading or unloading the machine into a trailer or truck.
2.20  Be alert of surroundings. Watch for rocks, stumps, mounds, depressions, and low hanging limbs or objects that could be

potentially hazardous while mowing.

2.21  Data indicates that operators 60 years of age and above are involved in a large percentage of riding mower related injuries.

These operators should periodically evaluate their ability to operate the riding mower safely enough to protect themselves and
others from serious injury.

PAGE

 6

SLOPE OPERATION

Slopes are a major factor related to loss of control and tip over accidents, which can result in severe injury or death. Operation on all
slopes requires extra caution. If you cannot back up the slope, or you feel uneasy on it, do not mow it.
2.22  Mow up and down slopes, not across.
2.23  Watch for holes, ruts, bumps, rocks, or other hidden objects that tall grass can obscure. Uneven terrain could overturn the machine.
2.24  Choose a low ground

speed when operating the machine on a slope.

2.25  Do not mow on wet grass, the tires may lose traction.
2.26  Do not attempt to coast down a slope in the neutral position.
2.27  Avoid starting, stopping, or turning on a slope. If the tires lose traction, disengage the blades and proceed slowly, straight

down the slope.

2.28  Keep all movement on slopes slow and gradual. Sudden changes in speed or direction could cause the machine to roll over.
2.29  Use extra care while operating machine with grass catchers or other attachments: they can affect the stability of the machine.

Do not use on steep slopes.

2.30  Do not try to stabilize the machine by putting your foot on the ground.
2.31  Do not mow near drop offs, ditches or embankments. The machine could suddenly roll over if a wheel goes over the edge or

the edge caves in.

2.32  Be aware of what is located at the bottom of slopes. For example: rocks water, cliffs, and roadways.

CHILDREN

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the machine and the
mowing activity. NEVER assume that children will remain where you last saw them.
2.33   Keep children out of the mowing area and in the watchful care of a responsible adult other that the operator.
2.34   Maintain alertness and turn machine off if a child enters the area.
2.35   Before and while backing, look behind and down for small children.
2.36   Never carry children, even with the blades shut off. They may fall off and be seriously injured or interfere

with safe machine operation. Children who have been given rides in the past may suddenly appear in the
mowing area for another ride and be run over or backed over by the machine.

2.37   Never allow children to operate the machine.
2.38   Never leave key in the ignition, especially around children.
2.39   Use extreme care when approaching blind corners, shrubs, trees, or other objects that may block your view

of a child.

TOWING

2.40  Tow only with a machine that has a hitch specifically designed for towing. Do not attach towed equipment except at the hitch

point.

2.41  Follow the manufacturer’s recommendation for weight limits for towed equipment and towing on slopes.
2.42  Never allow children or others in or on towed equipment.
2.43  On slopes, the weight of the towed equipment may cause loss of traction and loss of control.
2.44  Travel slowly and allow extra distance to stop.

PAGE



7

SERVICE:

SAFE HANDLING OF GASOLINE
To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors
are explosive.
2.45  Extinguish all cigarettes, cigars, pipes, and all other sources of ignition.
2.46  Use only an approved gasoline container.
2.47  Never remove gas cap or add fuel with the engine running.
2.48  Allow engine to cool before refueling.
2.49  Never fuel the machine indoors.
2.50  Do not store machine near open flame or source of ignition, such as a water heater or furnace.
2.51  Remove gas powered equipment from the truck or trailer and refuel it on the ground. If this is not possible, then refuel such

equipment with a portable container, rather than from a gasoline dispenser nozzle.

2.52  Never fill gasoline containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place containers on the

ground away from your vehicle before filling.

2.53  Keep the nozzle in contact with the rim of the fuel tank or container opening at all times until the fueling is complete. Do not

use a nozzle lock-open device.

2.54  If fuel is spilled on clothing, change clothing immediately.
2.55  Never overfill fuel tank. Replace gas cap and tighten securely.

Tank is full when level reaches bottom of fill tube.

GENERAL SERVICE

2.56  Never operate machine in a closed area where dangerous carbon monoxide fumes can collect.
2.57  Keep all nuts and bolts tight to be sure the equipment is in safe working condition. Never operate a poorly maintained machine.
2.58  Do not touch hot areas of the machine.
2.59  Never interfere with the intended function of a safety device or reduce the protection provided by a safety device. Check their

proper operation regularly.

2.60  Keep the entire machine free of grass, leaves, or other debris build up. Clean up oil or fuel spillage and remove any fuel soaked

debris. Failure to do so can affect the safety and functionality of the machine, as well as increase the danger of a fire due to
contact with the hot surfaces of the machine.

2.61  Allow machine to cool before storing.
2.62  If you strike something with the mower, turn the mower and blades off, engage the parking brake, and inspect the machine for

damage. Repair, if necessary, before resuming.

2.63  Never make any adjustments or repairs with the engine running.
2.64  Check grass catcher components and the discharge guard frequently and replace with manufacturer’s recommended parts,

when necessary.

2.65  Mower blades are sharp. Wrap the blade or wear gloves before servicing them.
2.66  Check parking brake operation frequently. Adjust and service as required.
2.67  Maintain or replace safety and instruction labels, as necessary.
2.68  Do not attempt to mount a tire without the proper equipment and experience to perform the job.

PAGE

8

2.69   Always maintain the correct tire pressure. Do not inflate the tires above the recommended pressure. Never weld or heat a wheel

and tire assembly. The heat can cause an increase in air pressure resulting in a tire explosion. Welding can structurally weaken
or deform the wheel.

2.70   Park machine on level ground. Never allow untrained personnel to service machine. Understand service procedure before

doing work.

SAFETY INTERLOCK SYSTEM

Your Bad Boy mower is equipped with a safety interlock system. This system is designed to prevent serious injury or death to the
operator and other people or property damage. The system consists of an operator presence switch in the seat, the parking brake,
drive lever neutral position, the mower blade engagement switch, and the ignition switch.
These interlocks are vitally important and must be tested frequently. Following are instructions to test these very important safety
precautions.

Note: the operator must be seated properly on the machine during these tests and the engine should

have been previously allowed to warm to operating temperature.
2.71  With the parking brake engaged, bring lever arms to their inward position, then attempt to start the machine (the blade actuator

should be in off position); the engine should not start.

2.72  On a level surface, disengage the parking brake and place lever arms to their outward position, then attempt to start the

machine (the blade actuator should be in off position); the engine should not start.

2.73  Engage parking brake and leave lever arms in outward position, put blade actuator in the on position, then attempt to start the

machine; the engine should not start.

2.74  Next, start the engine as stated in the “Mower Operation Section”, disengage parking brake, and Very Slowly begin to rise from

the seat; the engine should stop.
If any of these tests fail to produce the results indicated and the problem cannot be identified, contact your Bad Boy Mower
dealer or the support contacts in the rear of this manual.

ROLL OVER PROTECTION STRUCTURES (ROPS)

If your machine is equipped with ROPS, it is of utmost importance they are used properly. ROPS, when used correctly, dramatically

decrease the fatality rate in instances when the machine overturns.
2.75  Periodically ensure the bolts that attach the ROPS to the machine are securely fastened.
2.76  Always operated the machine with the ROPS secured in the upright position.
2.77  If the surrounding environment (e.g. low lying limbs, signage, etc.) makes it impossible to mow with the ROPS upright, lower

the ROPS at the hinge point, mow the area, then immediately secure the ROPS upright.

2.78  Upright ROPS are taller than then operators head. Be aware of this and your surrounding environment, as referenced above.

The mower and operator may clear low lying items, but the ROPS may not.

2.79  Always wear the provided seat belt when ROPS are utilized. Failure to use the seat belt severely handicaps the safety benefits

of the ROPS.

2.80  In the event of a roll-over, replace the ROPS before resuming use of the machine.
