BBM OUTLAW XP MODELS ZERO-TURN MOWER. Manual - part 1

ZERO-TURN MOWER

OWNER’S, SERVICE & PARTS MANUAL

For additional information, please see us at

www.badboymowers.com

Bad Boy, Inc.
102 Industrial Drive
Batesville, Arkansas 72501

©201

6  12-1

OUTLAW XP



MODELS

TABLE OF CONTENTS

PAGE  2

Basic Information

Bad Boy Safety Guidelines

Operation

Maintenance

Storage and Transportation

Troubleshooting and FAQ

Controls

Moving In-operable Mower

Instrumentation

Mower Blade Maintenance

Greasing Bearings

How To Choose the Right Blade

Mowing Tips

Service Section

Parts Section

Limited Warranty

Page 4

Page 5

Page 9

Page 10

Page 12

Page 13

Page 14

Page 15

Page 15

Page 16

Page 16

Page 17

Page 18

Page 19

Page

43

Page

66

Section 1

Section 2

Section 3

Section 4

Section 5

Section 6

Section 7

Section 8

Section 9

Section 10

Section 11

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

 . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PAGE



3

COMMONLY USED ITEMS AND PART NUMBERS

Pump Belt

Fuel Filter

20W-50 Motor Oil

 -

 Bad Boy Hydrostatic Oil Recommended;

Approximately 2 quarts per side.

063-8014-00

Inner Air Filter

063-8020-00

Outer Air Filter

063-8019-00

Vanguard 933cc

063-8018-00

015-8000-00

Kawasaki FX 850v

018-8001-00

Yamaha 824cc EFI

015-0056-06

063-6000-00

10W-30 Motor Oil

 -

Bad Boy Synthetic Blend

Motor Oil Recommended

Kawasaki FX 850v

063-8017-00

Yamaha 824cc EFI

015-0053-02

54"

041-0202-00

041-0178-00

041-1650-00

041-8411-00

Vanguard 933cc

038-6090-00

Hi-Lift Fusion

Gator Blade

Wave Blade

038-0001-00

038-0003-00

038-5220-00

Wave Blade

038-7215-00

038-5400-00

038-7230-00

Hi-Lift Fusion

Gator Blade

Wave Blade

Deck Belt

54" Blades

61" Blades

72" Blades

Hi-Lift Fusion

Gator Blade

038-6080-00

038-6081-00

72"

61"

Hydraulic

Filter

Motor Oil

Hydro Oil

Oil Filter

Air Filter

Spark Plug

This manual applies to the following equipment:

Bad Boy Outlaw XP Series

Outlaw XP 5400 54˝ 852cc Kawasaki FX-850

Outlaw XP 6100 61˝ 852cc Kawasaki FX-850

Outlaw XP 7200 72˝ 852cc Kawasaki FX-850

Outlaw XP 6100 61" 824cc Yamaha EFI

Outlaw XP 7200 72" 824cc Yamaha EFI

Outlaw XP 6100 61˝ 993cc Vanguard

Outlaw XP 7200 72˝ 993cc Vanguard

SECTION 1:

BASIC INFORMATION

Congratulations on the purchase of your new Bad Boy Mower! The purpose of this manual is to assist
operators in maintaining and operating their machine. The information and instructions in this manual can
help you attain years of performance from your new Bad Boy. Also, check out our website to learn more

 about the Bad Boy family.
1.1

1.2

1.3
1.4
1.5

All Bad Boy engines use 10W-30 engine oil. For maximum protection, Bad Boy synthetic blend



engine oil is recommended.
All Bad Boy hydraulic systems use 20W-50 engine oil (Conventional or Synthetic). Bad Boy



Hydrostatic oil is recommended.
All Bad Boy Mowers use hi-temp multi-purpose grease. NLGI No. 2 for the grease fittings.



Outlaw models have 12 psi in both front and rear tires.
Most

Yamaha

, Kawasaki, and Vanguard engines hold approximately two (2) quarts of motor oil.

 Be

careful not to over fill engine oil.  Refer to the engine’s service manual.

Warranty Registration

The Warranty Registration form must be completed within 30 days to validate your warranty. As the new
equipment owner, you are expected to see that the form is completed and forwarded to Bad Boy, Inc.,



at time of delivery. Warranty is non transferable.

Warranty registration should be completed by the

selling dealership using the on-line registration site.

Model/Serial Number

Your Outlaw model serial numbers are found on the SIN plate underneath seat.

These numbers can

assist you in the ordering of new parts when replacements become necessary.

Parts/Service

Only Bad Boy replacement parts are to be used on your mower.
Replacement parts are available through your local Bad Boy Mower Dealer. Remember to always provide
the following information when ordering parts:

1. Correct part number
2. Correct serial number

All warranty repair and service must be handled through your authorized Bad Boy Mowers dealer.
To locate the nearest dealer, go to our website and click on Locate a Dealer.

EVAPORATIVE EMISSION CONTROL WARRANTY STATEMENT

Federal Evaporative Emission Control Warranty: Your Warranty Rights and Obligations

The Environmental Protection Agency (EPA), and Bad Boy Inc. are pleased to explain the evaporative emission control system’s warranty
on your

2017

 equipment. New equipment that uses spark ignition engines for off-road use must be meet stringent anti-smog standards.

The evaporative emission control system on your equipment is designed, built, and equipped so it conforms at the time of sale to the
ultimate purchaser with the requirements of 40 CFR 1060. The evaporative emission control system is free from defects in materials and
workmanship that may keep it from meeting said requirements. Bad Boy Inc. must warrant the evaporative emission control system on
your equipment for two years provided there has been no abuse, neglect or improper maintenance. If an evaporative emission control
system component does fail in a manner that would cause the equipment to no longer meet the requirements of 40 CFR 1060 within the
first two years Bad Boy Inc. will replace the defective component. Your evaporative emission control system may include parts such as
fuel tanks, fuel lines, carbon canisters, fuel caps, valves, vapor hoses, clamps, or connectors.

PAGE

4
