Title: Lifting Operations

Doc No: UNIF-HSE-PRO-109-C1

Procedure

Rev No: C1

Page 47 of 49

Dated: July, 2004

Originating Dept: HSE

Examination and Discard Criteria

Slings constructed in man-made fibers are easily damaged and can be sensitive to chemical

attack.

Strength is lost if there are any cuts, tears, abrasion, fraying and burst stitching, therefore

this sling type requires close examination by a competent person for any signs of damage

prior to every lifting operation.

Endless Round Slings are manufactured with an outer protective sheath, which prevents the

ingress of chemicals and dirt, which can lead to the deterioration of the sling fibers in

service. The protective sheath also makes the examination for defects more difficult and

onerous than that of the Flat Webbing Sling.

Man-Made Fibre Endless Round Slings:

Endless Round slings shall only be used for general purpose lifting duties on the site

providing the sling has a current certificate of conformity and there is an approved lifting plan

and risk assessment for the operation. Site Lifting Coordinator shall inspect slings for

suspected or evident damage prior to use. The sling(s) shall be physically removed and

destroyed if any damage is suspected or evident.

Certification for this type of sling is valid for 6 months after which time it will be removed from

service and destroyed.

Man-Made Fibre Flat Webbing Slings:

Flat Webbing Slings shall only be used for special lifts where the component to be lifted can

be damaged by the use of conventional wire rope slings. Flat webbing slings shall be used

for lifting duties on the site providing the sling has a current certificate of conformity and

there is an approved lifting plan and risk assessment for the operation. Site Lifting

Coordinator shall inspect slings for suspected or evident damage prior to use. The sling(s)

shall be physically removed and destroyed if any damage is suspected or evident.

Certification for this type of sling is valid for 6 months after which time it will be removed from

service and destroyed.

The controlled version of this document can be found at: http://baku.bpweb.bp.com/dep/hse/safe/

Next Revision Date: 30/05/2005

Print Date: 24/07/2010

PAPER COPIES ARE UNCONTROLLED. THIS COPY VALID ONLY AT THE TIME OF PRINTING

Title: Lifting Operations

Doc No: UNIF-HSE-PRO-109-C1

Procedure

Rev No: C1

Page 48 of 49

Dated: July, 2004

Originating Dept: HSE

Appendix 9

Wind Force Scale

Wind Force in points

Wind Force, mps

Wind Force, knots

Calm

0-0.5 (0)

0-0.97 (0)

Light air

0.6-1.7 (1)

1.16-3.3 (1.9)

Light breeze

1.8-2.3 (2.1)

3.5-4.5 (4.1)

Gentle breeze

3.4-5.2 (4.5)

6.6-10.1 (8.7)

Moderate breeze

5.3-7.4 (6.5)

10.2-14.4 (12.6)

Fresh wind

7.5-9.8 (8.5)

14.5-19.1 (16.5)

Strong wind

9.9-12.4 (11)

19.2-24.1 (21.4)

High wind

12.5-15.2 (14)

24.2-29.5 (27.2)

Very hard wind

15.3-18.2 (17)

29.7-35.4 (33.04)

Storm

18.3-21.5 (20)

35.5-41.8 (38.8)

Hard storm

21.6-25.1 (23)

41.9-48.8 (44.7)

Heavy storm

25.2-29.0 (27)

48.9-56.4 (52.5)

Tornado

More than 29.0

More than 56.4

The controlled version of this document can be found at: http://baku.bpweb.bp.com/dep/hse/safe/

Next Revision Date: 30/05/2005

Print Date: 24/07/2010

PAPER COPIES ARE UNCONTROLLED. THIS COPY VALID ONLY AT THE TIME OF PRINTING

Title: Lifting Operations

Doc No: UNIF-HSE-PRO-109-C1

Procedure

Rev No: C1

Page 49 of 49

Dated: July, 2004

Originating Dept: HSE

Appendix 10

AzBU Lifting SSOW Coverage

Covered by AzBu Lifting SSOW

Not Covered by AzBU Lifting SSOW

Sangachal Terminal (EOP)

Project Construction activities at SPS,

STEP, ATA, including offshore

construction and installation

Chirag-1, including drilling operations

Sangachal Shore Approach

Supsa Terminal

Offshore Pipe lay

SPS Base (Operations Supply Base)

Zykh Yard

WREP

Dada Gorgud drilling rig

WREP Pump Stations: PS5, PS8, PS11,

Istiglal drilling rig

PS13, PS15, PRS1, PRS2.

WREP Pigging Station: PS2

BTC Construction Project activities

NREP

SCP Construction Project activities

NREP Pump Stations: Sumgait Metering

Port Operations in Baku, Poti & Batumi

Station (BP controlled side), Siyazan

Ports

Injection Station, Shirvanovka Metering

Station.

Eupec pipe coating yard

Third Extension of TISA

NOTE: Once project construction activities cease and facilities and pipelines

are handed over to operations, the AzBU Lifting SSOW will apply on BP

managed sites. BP will also expect equivalent systems to be in place on sites

where it has a material influence, eg Botas International Ltd BTC operational

sites.

The AzBU Lifting SSOW would not apply to contractor operations in countries

other than Azerbaijan and Georgia, including Engineer, Procure and Construct

(EPC) projects.

The controlled version of this document can be found at: http://baku.bpweb.bp.com/dep/hse/safe/

Next Revision Date: 30/05/2005

Print Date: 24/07/2010

PAPER COPIES ARE UNCONTROLLED. THIS COPY VALID ONLY AT THE TIME OF PRINTING

Title: Water Quality Management

Doc No: UNIF-HSE-PRO-110-C1

Procedure

Rev No: C1

Page 2 of 15

Dated: October, 2004

Originating Dept: HSE

TABLE OF CONTENTS

INTRODUCTION

1.1 Document Purpose

1.2 Document Scope

1.3 Definitions

1.4 References

ROLES AND RESPONSIBILITIES

2.1 Site Manager / Offshore Installation Manager

2.2 Procurement

2.3 Marine and Supply Service Providers

2.4 Health Team Leader

WATER QUALITY CRITERIA

3.1 Bacteriological Quality

3.2 Chemical Quality

WATER QUALITY MONITORING

4.1 Water Sampling

4.2 Sample Handling, Packing and Transportation

4.3 Sample Documentation

MAINTENANCE AND MONITORING

5.1 The Requirement for Maintenance and Monitoring

5.2 Potable Water System Maintenance Log

5.3 Emergency Water Systems

LEGIONELLA

6.1 Description and Causes of Legionnaires Disease

6.2 Risk Assessment

6.3 Risk Reduction Strategy

6.4 Screening For Legionella
