ÉÂÔ
Program Directory for
IBM DB2 DataPropagator Q Capture
for VSE
Version 7 Release 4.0
Program Number 5697-F42
for Use with
VSE/ESA
Document Date: September 2004
GI10-5001-02
Contents
Notices
iv
Trademarks and Service Marks
iv
1.0
Introduction
1
2.0
Program Materials
2
2.1
Basic Machine-Readable Material
2
2.2
Optional Machine-Readable Material
3
2.3
Program Publications
3
2.3.1
Basic Program Publications
3
2.3.2
Optional Program Publications
3
2.4
Program Source Materials
3
2.5
Publications Useful During Installation . .
3
3.0
Program Support
5
3.1
Preventive Service Planning
5
3.2
Statement of Support Procedures
5
4.0
Program and Service Level Information
6
4.1
Program Level Information
6
4.2
Service Level Information
6
4.3
Cumulative Service Tape
6
5.0
Installation Requirements and Considerations
7
5.1
Target System Requirements
7
5.1.1
Operating System Requirements
7
5.1.2
Machine Requirements
7
5.1.3
Programming Requirements
7
5.1.4
DASD Storage Requirements
7
5.1.5
Processor Storage Requirements
8
5.2
Program Considerations
9
5.2.1
Operating System Requirements
9
5.2.2
Machine Requirements
9
5.2.3
Programming Considerations
9
5.2.4
System Considerations
9
5.2.5
Special Considerations
9
6.0
Installation Instructions
10
6.1
Allocate DASD for the DProp Q Capture for VSE Distribution Library
10
6.2
Set up the VSE Environment
11
6.3
Define the library to be installed
11
6.3.1
Defining Sublibrary
11
Copyright IBM Corp. 1997, 2004
iii
6.4
Restore the DProp Q Capture for VSE Distribution Library
12
6.5
Define VSAM cluster for message file(s)
13
6.6
Load the DProp Q Capture for VSE message file(s)
14
6.7
Load the DProp Q Capture for VSE package files to a database
14
6.8
Activating DProp Q Capture for VSE
16
6.9
Installation Verification Process
17
6.10
Activating DProp Q Capture for VSE for additional databases
17
7.0
Migration Instructions
18
8.0
Service Instructions
19
8.1
Maintenance Activities
19
8.2
Reloading the DProp Q Capture for VSE package files
19
8.3
Reloading the DProp Q Capture for VSE message file(s)
19
Reader's Comments
21
Figures
1.
Basic Material: Program Tape
2
2.
Program Tape: File Content
2
3.
Basic Material: Unlicensed Publications
3
4.
Publications Useful During Installation
4
5.
PSP Upgrade and Subset ID
5
6.
Component IDs
5
7.
DASD Storage Requirements for ASN740 Sublibrary
8
8.
DASD Storage Requirements for DProp Q Capture language file
8
9.
Defining Sublibrary for DProp Q Capture
11
10. Job ASNQ74AD (Using MSHP to Install DProp Q Capture for VSE)
12
11. Job &asns.ED (Define VSAM cluster for message file)
13
12. Job ASNQ74DD (Load DProp Q Capture Messages)
14
13. Reloading the DProp Q Capture Package
15
14. Job ASNQ74BD (Start DProp Q Capture (ASNQCAP)
16
Contents iv
Notices
References in this document to IBM products, programs, or services do not imply that IBM intends to
make these available in all countries in which IBM operates. Any reference to an IBM product, program,
or service is not intended to state or imply that only IBM's product, program, or service may be used. Any
functionally equivalent product, program, or service that does not infringe on any of IBM's intellectual
property rights may be used instead of the IBM product, program, or service. Evaluation and verification
of operation in conjunction with other products, except those expressly designated by IBM, is the user's
responsibility.
IBM may have patents or pending patent applications covering subject matter in this document. The
furnishing of this document does not give you any license to these patents. You can send license
inquiries, in writing, to the
International Business Machines Corporation
IBM Director of Licensing
North Castle Drive, Armonk, NY
10504-1785, U.S.A.
Trademarks and Service Marks
The following terms, denoted by an asterisk (*), used in this document, are trademarks or service marks of
IBM Corporation in the United States or other countries:
IBM
VSE/ESA
DATABASE 2
DB2 Server for VSE
The following terms, denoted by a double asterisk (**), used in this document, are trademarks of other
companies as follows:
None
Copyright IBM Corp. 1997, 2004
v
1.0
Introduction
This program directory is intended for the system programmer responsible for program installation and
maintenance. It contains information concerning the material and procedures associated with the
installation of DProp Q Capture for VSE. You should read all of this program directory before installing the
program and then keep it for future reference.
The program directory contains the following sections:
¹
2.0, “Program Materials” on page 2 identifies the basic and optional program materials and
documentation for DProp Q Capture for VSE.
¹
3.0, “Program Support” on page 5 describes the IBM support available for DProp Q Capture for VSE.
¹
4.0, “Program and Service Level Information” on page 6 lists the APARs (program level) and PTFs
(service level) incorporated into DProp Q Capture for VSE.
¹
5.0, “Installation Requirements and Considerations” on page 7 identifies the resources and
considerations for installing and using DProp Q Capture for VSE.
¹
6.0, “Installation Instructions” on page 10 provides detailed installation instructions for DProp Q
Capture for VSE.
Before installing DProp Q Capture for VSE, read 3.1, “Preventive Service Planning” on page 5. This
section tells you how to find any updates to the information and procedures in this program directory.
Copyright IBM Corp. 1997, 2004
1
2.0
Program Materials
An IBM program is identified by a program number and a feature code. The program number for DProp Q
Capture for VSE is 5697-F42.
The program announcement material describes the features supported by DProp Q Capture for VSE. Ask
your IBM marketing representative for this information if you have not already received a copy.
The following sections identify:
¹
The basic and optional program materials available with this program
¹
Publications useful during installation
2.1
Basic Machine-Readable Material
The distribution medium for this program is 9-track magnetic tape (written at 6250 BPI), 3480 cartridge,
1/4-inch tape cartridge, or 4mm tape cartridge. The tape or cartridge contains all the programs and data
needed for installation. DProp Q Capture for VSE is installed using Maintain System History Program
(MSHP). See 6.0, “Installation Instructions” on page 10 for more information about how to install the
program. Figure 1 describes the tape or cartridge. Figure 2 describes the file content of the program
tape or cartridge.
Figure 1. Basic Material: Program Tape
Feature Physical
Medium
Number Volume External Label Identification
6250 tape
5821*
1
DProp Q Capture VSE
3480 cart.
5822
1
DProp Q Capture VSE
1/4 inch
5824
1
DProp Q Capture VSE
cart.
4 mm cart.
6016
1
DProp Q Capture VSE
* Not available in Japan
Figure 2. Program Tape: File Content
File
Name
1
DProp Q Capture Copyright Records
2
DProp Q Capture History File
3
DProp Q Capture Product
4
Tape Mark
5
Tape Mark
Copyright IBM Corp. 1997, 2004
2
This tape is intended for processing by the VSE Maintain System History Program or VSE/II. You will
need the following information to download the DProp Q Capture for VSE product:
¹
The tape label for the DProp Q Capture for VSE product is:
ASN/VSE
7.4.0
¹
The library for the product is PRD2.
¹
The sublibrary for the product is ASN740.
2.2
Optional Machine-Readable Material
There are no optional machine-readable materials for DProp Q Capture for VSE.
2.3
Program Publications
The following sections identify the basic and optional publications for DProp Q Capture for VSE.
2.3.1
Basic Program Publications
No publications are included when you order the basic materials for DProp Q Capture for VSE. For your
convenience, the relevant publications are listed below. For additional copies, contact your IBM
representative.
Figure 3. Basic Material: Unlicensed Publications
Publication Title
Form Number
DB2 Replication and Event Publishing Guide and Reference
SC18-7568
DB2 Replication Guide and Reference Supplement for Q Capture VSE/VM
2.3.2
Optional Program Publications
There are no optional publications for DProp Q Capture for VSE.
2.4
Program Source Materials
There are no source materials available for DProp Q Capture for VSE.
2.5
Publications Useful During Installation
The publications listed in Figure 4 may be useful during the installation of DProp Q Capture for VSE. To
order copies, contact your IBM representative.
Program Materials
3
Figure 4. Publications Useful During Installation
Publication Title
Form Number
VSE/ESA System Control Statements
SC33-6713
VSE/ESA System Utilities
SC33-6717
VSE/ESA System Upgrade and Service
SC33-6702
VSE/ESA Messages and Codes
SC33-6799
Program Materials
4
3.0
Program Support
This section describes the IBM support available for DProp Q Capture for VSE.
3.1
Preventive Service Planning
Before installing DProp Q Capture for VSE, check with your IBM Support Center or use either
Information/Access or SoftwareXcel Extended to see whether there is additional Preventive Service
Planning (PSP) information that you should know. To obtain this information, specify the following
UPGRADE and SUBSET values:
Figure 5. PSP Upgrade and Subset ID
UPGRADE
SUBSET
RETAIN Release
DB2VSEVM740
DPRVSE
4NO
If you have received DProp Q Capture for VSE only from IBM Software Distribution, then before installing
DProp Q Capture for VSE, you should also check with your IBM Support Center or use either
Information/Access or SoftwareXcel Extended to see if there is additional PSP information that you should
know.
3.2
Statement of Support Procedures
Report any difficulties you have using this program to your IBM Support Center. If an APAR is required,
the Support Center will provide the address to which any needed documentation can be sent.
Figure 6 identifies the component ID (COMPID) for DProp Q Capture for VSE.
Figure 6. Component IDs
COMP ID
Component Name
CLC
5697F4201
DProp Q Capture for VSE V7
4NO
Copyright IBM Corp. 1997, 2004
5
4.0
Program and Service Level Information
This section identifies the program and any relevant service levels of DProp Q Capture for VSE. The
program level refers to the APAR fixes incorporated into the program. The service level refers to the
PTFs integrated. Information about the cumulative service tape is also provided.
4.1
Program Level Information
All closed APARs from previous versions/releases have been incorporated at the time of the product GA.
4.2
Service Level Information
Check the DB2VSEVM740 PSP bucket for any additional PTFs that should be installed or any additional
install information.
4.3
Cumulative Service Tape
There is no cumulative service tape for DProp Q Capture for VSE.
Copyright IBM Corp. 1997, 2004
6
5.0
Installation Requirements and Considerations
The following sections identify the system requirements for installing and activating DProp Q Capture for
VSE.
5.1
Target System Requirements
This section describes the environment of the target system required to install and use DProp Q Capture
for VSE.
5.1.1
Operating System Requirements
DProp Q Capture for VSE operates under the VSE/ESA Version 2 Release 6 and above operating system.
5.1.2
Machine Requirements
One tape drive supported by VSE/ESA is required for installation.
5.1.3
Programming Requirements
The following Licensed Products are prerequisites for DProp Q Capture for VSE:
¹
DB2 Server for VSE & VM Version 7 Release 4.0 (5697-F42)
¹
DB2 Universal Database Version 8 Release 2
¹
MQSeries for VSE/ESA Version 2 Release 1 Modification 2 plus PTF UQ88412
DProp Q Capture for VSE requires the Language Environment for VSE/ESA (5686-094).
5.1.4
DASD Storage Requirements
The following table lists the target libraries and their attributes required for the installation of DProp Q
Capture for VSE.
The storage requirements of DProp Q Capture for VSE must be added to the storage required by other
programs having data in the same library. See Figure 7 and Figure 8 for estimates of the storage
required.
Copyright IBM Corp. 1997, 2004
7
APPROXIMATE SPACE REQUIREMENT: 910 LIBRARY BLOCKS
DASD
Approximate Sublibrary Space Required
MSHP History File
Device Type
Space Required
3375
17 cylinders
5 tracks
3380
12 cylinders
5 tracks
3390
10 cylinders
5 tracks
9345
13 cylinders
5 tracks
FB-512
9508 blocks
126 blocks
Figure 7. DASD Storage Requirements for ASN740 Sublibrary
Notes for Figure 7:
¹
These allocations include approximately 25 percent free space to allow for maintenance.
¹
Maintain System History Program (MSHP) auxiliary history file sizes are based on suggested values in
the VSE/ESA System Control Statements manual for your VSE operating system.
¹
FB-512 devices include 3370-2, 9332, 9335, and 9336 storage devices.
In addition to the ASN740 Sublibrary, additional VSAM file storage is required for the language files.
Figure 8 lists the sizes for one language file. You will need to adjust this if you decide to install additional
languages.
APPROXIMATE SPACE REQUIREMENT:
DASD
Approximate VSAM File Space Required
Device Type
3375
2 cylinder
3380
2 cylinder
3390
2 cylinder
9345
2 cylinder
FB-512
900 blocks
Figure 8. DASD Storage Requirements for DProp Q Capture language file
5.1.5
Processor Storage Requirements
For ease of installation, choose a virtual partition of at least 8 megabytes for running all of the installation
jobs. After installation, we recommend a virtual partition of at least 10 megabytes for running DProp Q
Capture for VSE. Your installation may require a larger partition based on the activity to be captured by
DProp Q Capture.
Installation Requirements and Considerations
8
5.2
Program Considerations
There are no program, system, or special considerations for DProp Q Capture for VSE.
5.2.1
Operating System Requirements
The VSE/ESA operating system is used to install DProp Q Capture for VSE.
5.2.2
Machine Requirements
There are no special machine requirements for the driving system.
5.2.3
Programming Considerations
There are no programming considerations for DProp Q Capture for VSE.
5.2.4
System Considerations
There are no system considerations for DProp Q Capture for VSE.
5.2.5
Special Considerations
There are no special considerations for DProp Q Capture for VSE.
Installation Requirements and Considerations
9
6.0
Installation Instructions
This chapter describes the installation method and the step-by-step procedures to install and to activate
the functions of DProp Q Capture for VSE.
The following steps must be performed:
1. Allocate DASD for the DProp Q Capture for VSE Distribution Library
2. Set up the VSE Environment
3. Define the library to be installed
4. Restore the DProp Q Capture for VSE Distribution Library
5. Define VSAM cluster for message file(s)
6. Load the DProp Q Capture for VSE message file(s)
7. Load the DProp Q Capture for VSE package files
8. Activating DProp Q Capture for VSE
9. Installation Verification Process
The following step is optional:
1. Activating DProp Q Capture for VSE for additional databases
IBM-Supplied Installation Aids
To help you install the DProp Q Capture for VSE product on a VSE system, sample job control members
are included on the DProp Q Capture for VSE tape. These are distributed as Z-type source members in
the ASN740 sublibrary. You load these members as part of installation, as described in 6.4, “Restore the
DProp Q Capture for VSE Distribution Library” on page 12.
Depending on how you choose to install the DProp Q Capture product, you may have to change some of
the job control members before submitting them for execution. These members and the changes they
need are described in the installation steps. You can punch these members out of the ASN740 sublibrary
into VSE/ICCF or card decks for editing and resubmission. Alternatively, because most of them are short,
you can create them yourself.
6.1
Allocate DASD for the DProp Q Capture for VSE Distribution
Library
Before you can install the DProp Q Capture for VSE product on a VSE system, allocate space for the
distribution library. Figure 7 shows the approximate size of the library on various devices.
Copyright IBM Corp. 1997, 2004
10
6.2
Set up the VSE Environment
Ensure that your VSE system is prepared as follows:
¹
Equip the system with a tape drive for the type of distribution tape ordered.
¹
Choose a suitable partition to run the DProp Q Capture for VSE product during the installation
process. A partition of 2 megabytes or more of storage is the minimum, although 4 megabytes is
recommended.
¹
Be sure that the system files are assigned correctly. During the installation process, input is read from
SYSIPT and source members from the DProp Q Capture for VSE sublibrary. Output is written to the
printer file, SYSLST.
6.3
Define the library to be installed
The IBM-supplied installation procedures and examples assume that DProp Q Capture is being installed in
library PRD2, sublibrary ASN730. If you install it elsewhere, be sure to change the job control statements
as needed in all subsequent procedures and examples.
Library PRD2 should already be defined from your installation of the VSE/ESA operating system. In this
step, you should only need to create the sublibrary, ASN740. First ensure that there is enough space in
the library to contain DProp Q Capture.
(Refer to 6.1, “Allocate DASD for the DProp Q Capture for VSE
Distribution Library” on page 10 to ensure that you have allocated enough library blocks to accommodate
the sublibrary.)
6.3.1
Defining Sublibrary
To define a VSE sublibrary (either BAM or VSAM), use the job shown in Figure 9. For more information
about library definitions, refer to the VSE/ESA System Control Statements manual for your VSE system.
// JOB DEFINE SUBLIBRARY
// EXEC LIBR
DEFINE SUBLIB=PRD2.ASN740 R=Y
/*
/&
Figure 9. Defining Sublibrary for DProp Q Capture
Installation Instructions
11
6.4
Restore the DProp Q Capture for VSE Distribution Library
You can restore the DProp Q Capture for VSE Distribution Library in two ways. We recommend using the
VSE/Interactive Interface, Product Installation Dialog in VSE/ESA. If you use this method, you need to
know that the DProp Q Capture product is shipped on a NON-STACKED V2 FORMAT tape. For
directions on using this method, refer to the Installation manual for your VSE operating system.
Alternatively, you may create the job control member shown in Figure 10 to restore the Distribution
Library. Mount the distribution tape and run your modified job.
// JOB ASNQ74AD
INSTALL DProp Q Capture
// MTC REW,cuu
*-- REWIND TAPE
// ASSGN SYS002,cuu1
*-- AUXILIARY HISTORY FILE
// ASSGN SYS005,UA
*-- NO RESTORE TO DOSRES
// ASSGN SYS006,cuu
*-- DISTRIBUTION TAPE
// OPTION CATAL
// EXEC MSHP
INSTALL PRODUCT FROMTAPE ID='ASN/VSE
7.4.0' - ▌1▐
PROD IN=PRD2.ASN740
▌2▐
DEFINE HISTORY AUX EXTENT=xxx:yyy
/*
// MTC RUN,cuu
/&
Figure 10. Job ASNQ74AD (Using MSHP to Install DProp Q Capture for VSE)
Notes for Figure 10:
Á Before execution, modify the above statements as follows:
cuu Replace with the address of the tape drive.
cuu1 Replace with the address of the disk drive on which the auxiliary history file resides.
xxx Replace with the starting address of the auxiliary history file (in tracks or blocks).
yyy Replace with the size of the auxiliary history file (in tracks or blocks).
Á MSHP message M231D will be encountered when installing the feature using the JCL provided.
Please make sure your target library is different from that of the complimentary product (DB2 Server
for VSE). Then enter KEEP in response to the message to keep both products in the history file.
Á You receive various messages from MSHP. These messages are normal and can be ignored.
▌1▐ 'ASN/VSE
7.4.0' is the actual ID of the tape.
▌2▐ If necessary, replace PRD2.ASN740 with the library and sublibrary names you used in 6.3, “Define
the library to be installed” on page 11.
Installation Instructions
12
6.5
Define VSAM cluster for message file(s)
The messages for DProp Q Capture for VSE are included on the distribution tape and will need to be
loaded into a VSAM file for use by DProp Q Capture. You can create the job control member shown in
Figure 11 to define the VSAM cluster(s).
The following languages are provided on the distribution tape as A-type source members. They were
loaded into the sublibrary in step 6.4, “Restore the DProp Q Capture for VSE Distribution Library.” You
may choose to define clusters for one, several or all of the language files depending on your installation's
requirements. For each language you wish to load, you will need to execute the steps of 6.5, “Define
VSAM cluster for message file(s)” and 6.6, “Load the DProp Q Capture for VSE message file(s).”
ASNQS001 American English
ASNQS002 Upper case English
ASNQS003 French
ASNQS004 German
ASNQD001 Japanese
// JOB ASNQ74ED
DEFINE VSAM CLUSTERS
// EXEC IDCAMS,SIZE=AUTO
DEFINE VSAM CLUSTER
DELETE
(asnqs001.message.file) CLUSTER
- ▌1▐
CAT(user.catalog)
▌1▐
DEFINE
-
CLUSTER(NAME(asnqs001.message.file)
- ▌1▐
VOLUME(volser)
- ▌2▐
CYLINDERS(2 1)
-
RECORDSIZE(512 512)
-
FREESPACE(0 0)
-
KEYS(8 0)
-
CISZ(4096)
-
INDEXED
-
SHAREOPTIONS(1 4)
-
REUSE )
-
DATA (NAME(asnqs001.message.data))
- ▌1▐
INDEX (NAME(asnqs001.message.index))
- ▌1▐
CATALOG (user.catalog)
▌1▐
/*
/&
Figure 11. Job &asns.ED (Define VSAM cluster for message file)
Notes for Figure 11:
▌1▐ The cluster, data, and index names and the catalog names are provided as examples.
Modify them
to conform to your installation's standards.
Installation Instructions
13
▌2▐ Replace volser with the appropriate volume identification information.
6.6
Load the DProp Q Capture for VSE message file(s)
This step will load and unpack the message(s) to the VSAM clusters created in step 6.5, “Define VSAM
cluster for message file(s)” on page 13.
To load the messages, run job control member ASNQ74DD, shown in Figure 12.
// JOB ASNQ74DD
Load DPropR message file(s)
// LIBDEF *,SEARCH=(PRD2.ASN740,prd2.sceebase,prd2.levsebc) ▌1▐
// DLBL usercat,'user.catalog',,VSAM
▌2▐
// DLBL OUTDD,'asnqs001.message.file',,VSAM,CAT=usercat ▌2▐
// EXEC PGM=ASNVSE80,SIZE=ASNVSE80,
X
PARM='membername.A'
▌3▐
/*
/&
Figure 12. Job ASNQ74DD (Load DProp Q Capture Messages)
Notes for Figure 12:
▌1▐ Change prd2.sceebase,prd2.levsebc to the name of your installation's library containing the C
Run-Time Library routines.
▌2▐ Modify these DLBL statements to point to the VSAM catalogs and files you loaded the message file
to in step 6.6, “Load the DProp Q Capture for VSE message file(s).”
▌3▐ Change membername to one of the following:
Membername Description
ASNQS001 American English
ASNQS002
Upper case English
ASNQS003
French
ASNQS004
German
ASNQD001
Japanese
6.7
Load the DProp Q Capture for VSE package files to a database
The DProp Q Capture packages must be loaded to any and all databases with which you are going to run
DProp Q Capture for VSE. To load it, prepare and run the job control statements in Figure 13 on
page 15. The packages are contained in the VSE A-type source members.
Installation Instructions
14
// JOB ASNQ74CD
DPROPR CAPTURE
// LIBDEF *,SEARCH=(PRD2.ASN740,PRD2.DB2740)
// EXEC PGM=ARIDBS,SIZE=AUTO,PARM='DBNAME(dbname)' ▌1▐
CONNECT SQLDBA IDENTIFIED BY currentpw;
▌2▐
RELOAD PROGRAM(SQLDBA.ASNMSGT) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNMSGT.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQADMT) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQADMT.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQCAP) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQCAP.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQINIT) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQINIT.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQMSUB) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
COMMIT WORK;
READ MEMBER ASNQMSUB.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQPRM) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQPRM.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQPRUN) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQPRUN.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQSUBM) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQSUBM.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNSQLCF) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNSQLCF.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQSQL) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
READ MEMBER ASNQSQL.A (NOCONT
COMMIT WORK;
RELOAD PROGRAM(SQLDBA.ASNQSUB) INFILE(SYSIPT BLKSZ(80) PDEV(DASD))
REPLACE;
COMMIT WORK;
/*
/&
Figure 13. Reloading the DProp Q Capture Package
Notes for Figure 13:
Á JCL ASNQ74CD runs the DBS Utility in multiple user mode against the identified database (which is
up and running in multiple user mode).
▌1▐ Supply the appropriate database name for dbname.
Installation Instructions
15
▌2▐ Supply the appropriate password for currentpw.
6.8
Activating DProp Q Capture for VSE
Note!
Prior to activating DProp Q Capture for VSE, DB2 Universal Database must be installed and the
Replication Center administration functions of defining at least one replication source and
subscription must be performed. If this is not done, DProp Q Capture for VSE will not start
successfully and you will be unable to perform the installation verification.
Job control member ASNQ74BD, shown in Figure 14 contains sample JCL to activate DProp Q Capture
for VSE. Detailed steps to get the program into operational status and other parameter descriptions are
defined in DB2 Replication and Event Publishing Guide and Reference, SC18-7568, and its supplement
for Q Capture VSE/VM.
// JOB ASNQ74BD
START DPROPR CAPTURE (ASNQCAP)
// LIBDEF
*,SEARCH=(PRD2.ASN740,PRD2.DB2740,PRD2.MQSERIES,
X ▌1▐
prd2.sceebase,prd2.levsebc)
// EXEC PROC=ARIS74DB
*-- SQL/DS DATABASE ID PROC
▌2▐
// DLBL usercat,'user.catalog',,VSAM
▌3▐
// DLBL MSGS,'asnqs001.message.file',,VSAM,CAT=usercat ▌3▐
// EXEC ASNQCAP,SIZE=ASNQCAP,PARM='STARTMODE=WARMSI USERID=ASN/ASN1
X
CAPTURE_SERVER=dbname'
▌4▐
/*
/&
Figure 14. Job ASNQ74BD (Start DProp Q Capture (ASNQCAP)
Notes for Figure 14:
▌1▐ Change prd2.sceebase,prd2.levsebc to the name of your installation's library containing the C
Run-Time Library routines.
▌2▐ DProp Q Capture for VSE requires access to the VSAM clusters (directory and log) of the database
you are running DProp Q Capture against. For procedure ARIS74DB, you can substitute your own
procedure or job control statements to specify the appropriate DLBL statements for the VSAM
clusters.
▌3▐ Modify these DLBL statements to point to the VSAM catalogs and files you loaded the message file
to in step 6.6, “Load the DProp Q Capture for VSE message file(s)” on page 14.
▌4▐ Sample parameters to be passed to the DProp Q Capture program are given. You should update
this statement to conform to your installation's procedures.
Installation Instructions
16
6.9
Installation Verification Process
Once the DProp Q Capture for VSE is started, you should see an informational message ASN0572I The
program initialized successfully on the system console. It means the DProp Q Capture for VSE has been
able to connect to the DB2 database and is running successfully. Once DProp Q Capture for VSE is
started, it will continue to run until the STOP operator command is issued. At this time, you may also look
at the DProp Q Capture for VSE trace table, IBMQREP_CAPTRACE, to verify that the same message is
logged into the table.
6.10
Activating DProp Q Capture for VSE for additional databases
The DProp Q Capture for VSE program runs in its own partition, capturing changes for one and only one
DB2 Server for VSE database. If there are multiple databases for which you want to capture changes,
you must use additional partitions for running the DProp Q Capture for VSE program. The following steps
must be followed for each additional partitions:
1. Run step 6.7, “Load the DProp Q Capture for VSE package files to a database” on page 14. You will
need to specify the appropriate database name and password.
2. Run step 6.8, “Activating DProp Q Capture for VSE” on page 16. You will need to make the
appropriate changes to the sample job control member, ASNQ74BD, for the additional database.
Installation Instructions
17
7.0
Migration Instructions
The previous versions of Data Propagator Capture for VSE cannot be migrated to Data Propagator Q
Capture. Follow the Installation Instructions, see 6.0, “Installation Instructions” on page 10, to complete
the installation.
Copyright IBM Corp. 1997, 2004
18
8.0
Service Instructions
This section of the Program Directory contains information related to servicing DProp Q Capture for VSE.
MSHP is used to install service for DProp Q Capture for VSE.
To become more familiar with service using MSHP, you should read VSE/ESA System Control
Statements.
8.1
Maintenance Activities
DProp Q Capture for VSE maintenance beyond what MSHP does may include replacing existing
components because of service updates. Some of the same IBM-supplied procedures and source
members used for initial installation will be used for these maintenance activities.
8.2
Reloading the DProp Q Capture for VSE package files
The DProp Q Capture package must be reloaded in all databases if there is a service update to the A-type
source member. To reload it, follow the steps in 6.7, “Load the DProp Q Capture for VSE package files to
a database” on page 14.
Refer to the information supplied with each service update to see if you should take this action.
8.3
Reloading the DProp Q Capture for VSE message file(s)
The DProp Q Capture message files must be reloaded if there is a service update to any of the following
A-type source members:
Membername Description
ASNQS001 American English
ASNQS002
Upper case English
ASNQS003 French
ASNQS004 German
ASNQD001 Japanese
To reload one or all messages, follow the steps in 6.6, “Load the DProp Q Capture for VSE message
file(s)” on page 14.
Refer to the information supplied with each service update to see if you should take this action.
Copyright IBM Corp. 1997, 2004
19
20
Reader's Comments
Program Directory for DataPropagator Q Capture for VSE Version 7 Release 4.0
You may use this form to comment about this document, its organization, or subject matter with the understanding that
IBM may use or distribute whatever information you supply in any way it believes appropriate without incurring any
obligation to you.
For each of the topics below please indicate your satisfaction level by circling your choice from the rating scale.
If a
statement does not apply, please circle N.
RATING SCALE
very
very
not
satisfied
<=====================> dissatisfied applicable
1
2
3
4
5
N
Satisfaction
Ease of product installation
1
2
3
4
5
N
Contents of program directory
1
2
3
4
5
N
Installation Verification Programs
1
2
3
4
5
N
Time to install the product
1
2
3
4
5
N
Readability and organization of program directory tasks
1
2
3
4
5
N
Necessity of all installation tasks
1
2
3
4
5
N
Accuracy of the definition of the installation tasks
1
2
3
4
5
N
Technical level of the installation tasks
1
2
3
4
5
N
Ease of getting the system into production after
1
2
3
4
5
N
installation
Did you order this product as an independent product or as part of a package?
Independent
Package
Is this the first time your organization has installed this product?
Yes
No
Were the people who did the installation experienced with the installation of these products?
Yes
No
Copyright IBM Corp. 1997, 2004
21
If yes, how many years? __
If you have any comments to make about your ratings above, or any other aspect of the product installation, please
list them below:
Please provide the following contact information:
Name and Job Title
Organization
Address
Telephone
Thank you for your participation.
Please send the completed form to (or give to your IBM representative who will forward it to the DataPropagator Q
Capture for VSE Development group):
IBM Canada Ltd.
DB2 Server for VSE & VM
B4/240/8200/MKM
8200 Warden Avenue
Markham, Ontario
L6G 1C7
Canada
Reader's Comments
22
ÉÂÔ
Program Directory for
IBM DB2 DataPropagator Q Capture
for VM
Version 7 Release 4.0
Program Number 5697-F42
for Use with
z/VM
Document Date: September 2004
GI10-5000-02
Contents
Notices
iv
Trademarks and Service Marks
iv
1.0
Introduction
1
1.1
Program Description
1
2.0
Program Materials
3
2.1
Basic Machine-Readable Material
3
2.2
Optional Machine-Readable Material
4
2.3
Program Publications
4
2.3.1
Basic Program Publications
4
2.4
Microfiche Support
4
2.5
Publications Useful During Installation . .
5
3.0
Program Support
6
3.1
Preventive Service Planning
6
3.2
Statement of Support Procedures
6
4.0
Program and Service Level Information
7
4.1
Program Level Information
7
4.2
Service Level Information
7
4.3
Cumulative Service Tape
7
5.0
Installation Requirements and Considerations
8
5.1
Hardware Requirements
8
5.2
Program Considerations
8
5.2.1
Operating System Requirements
8
5.2.2
Other Program Product Requirements
8
5.2.3
Program Installation/Service Considerations
8
5.3
DASD Storage and user ID Requirements
9
6.0
Installation Instructions
11
6.1
VMSES/E Installation Process Overview
11
6.2
Plan Your Installation For DB2 DProp Q Capture for VM V7.4
12
6.3
Allocate Resources for Installing DB2 DProp Q Capture for VM V7.4
15
6.3.1
Installing DB2 DProp Q Capture for VM V7.4 on Minidisk
15
6.3.2
Installing DB2 DProp Q Capture for VM V7.4 in SFS Directories
17
6.4
Install DB2 DProp Q Capture for VM V7.4
19
6.4.1
Update Build Status Table for DB2 DProp Q Capture for VM V7.4
23
6.5
Place DB2 DProp Q Capture for VM V7.4 Into Production
23
6.5.1
Customize the CAPTMACH user ID
23
6.5.2
Copy DB2 DProp Q Capture for VM V7.4 Files Into Production . .
24
Copyright IBM Corp. 1997, 2004
iii
6.5.3
Load the DB2 DProp Q Capture for VM V7.4 Package files to a database
24
6.5.4
Starting DB2 DProp Q Capture for VM V7.4
25
6.5.5
Installation Verification Procedure for DB2 DProp Q Capture for VM V7.4
25
6.6
Post-Installation Considerations (optional)
26
7.0
Migration Instructions
27
8.0
Service Instructions
28
8.1
VMSES/E Service Process Overview
28
8.2
Servicing DB2 DProp Q Capture for VM V7.4
29
8.2.1
Prepare to Receive Service
29
8.2.2
Receive the Service
31
8.2.3
Apply the Service
31
8.2.4
Update the Build Status Table
32
8.2.5
Build Serviced Objects
34
8.3
Place the New DB2 DProp Q Capture for VM V7.4 Service Into Production
34
8.3.1
Copy the New DB2 DProp Q Capture for VM V7.4 Serviced Files Into Production
34
8.3.2
Load the DB2 DProp Q Capture for VM V7.4 Package files to a database
35
Reader's Comments
37
Figures
1.
Basic Material: Program Tape
3
2.
Program Tape: File Content
3
3.
Basic Material: Unlicensed Publications
4
4.
Publications Useful During Installation / Service on VM/ESA Version 4.3
5
5.
PSP Upgrade and Subset ID
6
6.
Component IDs
6
7.
DASD Storage Requirements for Target Minidisks
9
Contents iv
Notices
References in this document to IBM products, programs, or services do not imply that IBM intends to
make these available in all countries in which IBM operates. Any reference to an IBM product, program,
or service is not intended to state or imply that only IBM's product, program, or service may be used. Any
functionally equivalent product, program, or service that does not infringe on any of IBM's intellectual
property rights may be used instead of the IBM product, program, or service. Evaluation and verification
of operation in conjunction with other products, except those expressly designated by IBM, is the user's
responsibility.
IBM may have patents or pending patent applications covering subject matter in this document. The
furnishing of this document does not give you any license to these patents. You can send license
inquiries, in writing, to the
International Business Machines Corporation
IBM Director of Licensing
North Castle Drive, Armonk, NY
10504-1785, U.S.A.
Trademarks and Service Marks
The following terms used in this document, are trademarks or service marks of IBM Corporation in the
United States or other countries or both:
IBM
VM/ESA
z/VM
IBMLink(Service Link)
DATABASE 2
DB2 Server for VM
Copyright IBM Corp. 1997, 2004
v
1.0
Introduction
This program directory is intended for the system programmer responsible for program installation and
maintenance. It contains information concerning the material and procedures associated with the
installation of DB2 DProp Q Capture for VM V7.4. You should read all of this program directory before
installing the program and then keep it for future reference.
The program directory contains the following sections:
¹
2.0, “Program Materials” on page 3 identifies the basic and optional program materials and
documentation for DB2 DProp Q Capture for VM V7.4.
¹
3.0, “Program Support” on page 6 describes the IBM support available for DB2 DProp Q Capture for
VM V7.4.
¹
4.0, “Program and Service Level Information” on page 7 lists the APARs (program level) and PTFs
(service level) incorporated into DB2 DProp Q Capture for VM V7.4.
¹
5.0, “Installation Requirements and Considerations” on page 8 identifies the resources and
considerations for installing and using DB2 DProp Q Capture for VM V7.4.
¹
6.0, “Installation Instructions” on page 11 provides detailed installation instructions for DB2 DProp Q
Capture for VM V7.4.
¹
8.0, “Service Instructions” on page 28 provides detailed servicing instructions for DB2 DProp Q
Capture for VM V7.4.
Before installing DB2 DProp Q Capture for VM V7.4, read 3.1, “Preventive Service Planning” on page 6.
This section tells you how to find any updates to the information and procedures in this program directory.
1.1
Program Description
DataPropagator Q Capture for VM is part of the IBM Replication solution. IBM Replication is a set of
easy-to-use, automated copy tools that replicate relational data from sources to targets. You can use IBM
Replication to define, synchronize, automate, and manage copy operations from a single control point for
data across your enterprise. You can tailor or enhance data as it is copied and deliver detailed, subset,
summarized, or derived data when and where it is needed.
IBM Replication consists of the following tools:
¹
Replication Center
Provides the graphical user interface (GUI) that you use for administration tasks. The Replication
Center is part of DB2 Universal Database.
¹
Capture Program
Copyright IBM Corp. 1997, 2004
1
Captures changes made to data in replication source tables by reading the database log. It places the
captured changes into change data tables. It runs independently of the Replication Center, but uses
control information created by it.
¹
Apply Program
Reads the changed data previously captured and stored in a change data table and applies the
changes to target tables or reads data directly from source tables. Like the Capture program, it runs
independently of the Replication Center, using control information created by it.
Introduction
2
2.0
Program Materials
An IBM program is identified by a program number. The program number for DataPropagator Q Capture
for VM Version 7 is 5697-F42.
The program announcement material describes the features supported by DB2 DProp Q Capture for VM
V7.4. Ask your IBM marketing representative for this information if you have not already received a copy.
The following sections identify:
¹
basic and optional program materials available with this program
¹
publications useful during installation.
2.1
Basic Machine-Readable Material
The distribution medium for this program is 9-track magnetic tape (written at 6250 BPI), 3480 tape
cartridge, 1/4-inch tape cartridge or 4mm tape cartridge. The tape or cartridge contains all the programs
and data needed for installation. See section 6.0, “Installation Instructions” on page 11 for more
information about how to install the program. Figure 1 describes the tape or cartridge. Figure 2
describes the file content of the program tape or cartridge.
Figure 1. Basic Material: Program Tape
Feature
Physical
Number
Medium Volume
Tape Content
External Tape Label
5831*
6250
1
DB2 DProp Q Capture for VM V7.4
DProp Q Capture VM
tape
5832
3480
1
DB2 DProp Q Capture for VM V7.4
DProp Q Capture VM
cart.
5834
1/4 inch
1
DB2 DProp Q Capture for VM V7.4
DProp Q Capture VM
cart.
6017
4mm
1
DB2 DProp Q Capture for VM V7.4
DProp Q Capture VM
cart.
* Not available in Japan
Figure 2 (Page 1 of 2). Program Tape: File Content
Tape
File
Content
1
Tape Header
2
Tape Header
3
Product Header
Copyright IBM Corp. 1997, 2004
3
Figure 2 (Page 2 of 2). Program Tape: File Content
Tape
File
Content
4
Product Memo
5
Service Apply Lists
6
PTFPARTs
7
DB2 DProp Q Capture for VM V7.4 Service
8
DB2 DProp Q Capture for VM V7.4 Service
9
DB2 DProp Q Capture for VM V7.4 Base Code
10
DB2 DProp Q Capture for VM V7.4 Executable Code
2.2
Optional Machine-Readable Material
There are no optional machine-readable materials for DB2 DProp Q Capture for VM V7.4.
2.3
Program Publications
The following sections identify the basic and optional publications for DB2 DProp Q Capture for VM V7.4.
2.3.1
Basic Program Publications
The publications for DB2 DProp Q Capture for VM V7.4 are included with the pre-requisite product, DB2
UDB Universal Database. No publications are included when you order the basic materials for DB2 DProp
Q Capture for VM V7.4. For your convenience, the relevant publications are listed below. For additional
copies, contact your IBM representative.
Figure 3. Basic Material: Unlicensed Publications
Publication Title
Form Number
DB2 Replication and Event Publishing Guide and Event Publishing Guide and Reference
SC18-7568
DB2 Replication Guide and Reference Supplement for Q Capture VSE/VM
2.4
Microfiche Support
There is no microfiche for DB2 DProp Q Capture for VM V7.4.
Program Materials
4
2.5
Publications Useful During Installation
The publications listed in Figure 4 on page 5 may be useful during the installation of DB2 DProp Q
Capture for VM V7.4. To order copies, contact your IBM representative.
Figure 4. Publications Useful During Installation / Service on VM/ESA Version 4.3
Publication Title
Form Number
z/VM V4R3.0 VMSES/E Introduction and Reference
GC24-5994
z/VM V4R3.0 CMS Planning and Administration
SC24-6042
z/VM V4R3.0 CP Planning and Administration
SC24-6043
z/VM V4R3.0 Service Guide
GC24-5993
z/VM V4R3.0 CMS Command and Utility Reference
SC24-6010
z/VM V4R3.0 CP Command and Utility Reference
SC24-6008
z/VM V4R3.0 System Messages and Codes-CP
GC24-6030
z/VM V4R3.0 System Messages and Codes-CMS
GC24-6031
Program Materials
5
3.0
Program Support
This section describes the IBM support available for DB2 DProp Q Capture for VM V7.4.
3.1
Preventive Service Planning
Before installing DB2 DProp Q Capture for VM V7.4, check with your IBM Support Center or use IBMLink
(Service Link) to see whether there is additional Preventive Service Planning (PSP) information. To obtain
this information, specify the following UPGRADE and SUBSET values:
Figure 5. PSP Upgrade and Subset ID
Retain
COMPID
Release
Upgrade
Subset
5697F4201
741
DB2VSEVM740
DPRVM
3.2
Statement of Support Procedures
Report any difficulties you have using this program to your IBM Support Center. If an APAR is required,
the Support Center will provide the address to which any needed documentation can be sent.
Figure 6 identifies the component ID (COMPID), Retain Release and Field Engineering Service Number
(FESN) for DB2 DProp Q Capture for VM V7.4.
Figure 6. Component IDs
Retain
COMPID
Release
Component Name
FESN
5697F4201
741
DB2 DProp Q Capture for VM V7.4
0404450
Copyright IBM Corp. 1997, 2004
6
4.0
Program and Service Level Information
This section identifies the program and any relevant service levels of DB2 DProp Q Capture for VM V7.4.
The program level refers to the APAR fixes incorporated into the program. The service level refers to the
PTFs integrated. Information about the cumulative service tape is also provided.
4.1
Program Level Information
All closed APARs from previous versions/releases have been incorporated at the time of the product GA.
4.2
Service Level Information
Check the DB2VSEVM740 PSP bucket for any additional PTFs that should be installed or any additional
install information.
4.3
Cumulative Service Tape
Cumulative service for DB2 DProp Q Capture for VM V7.4 is available through a monthly corrective
service tape, Expanded Service Option, ESO.
Copyright IBM Corp. 1997, 2004
7
5.0
Installation Requirements and Considerations
The following sections identify the system requirements for installing and activating DB2 DProp Q Capture
for VM V7.4.
5.1
Hardware Requirements
There are no special hardware requirements for DB2 DProp Q Capture for VM V7.4.
5.2
Program Considerations
The following sections list the programming considerations for installing DB2 DProp Q Capture for VM
V7.4 and activating its functions.
5.2.1
Operating System Requirements
DB2 DProp Q Capture for VM V7.4 supports the following VM operating systems:
¹
z/VM Version 4 Release 3, and later.
5.2.2
Other Program Product Requirements
The following Licensed Products are pre-requisites for DB2 DProp Q Capture for VM V7.4:
¹
DB2 Server for VSE & VM Version 7 Release 4.0 (5697-F42)
¹
DB2 UDB Universal Database Version 8 Release 2
¹
MQ Series Client for VM/ESA
DB2 DProp Q Capture for VM V7.4 requires C run-time library support provided by the appropriate level of
the Language Environment for VM (5688-198).
5.2.3
Program Installation/Service Considerations
This section describes items that should be considered before you install or service DB2 DProp Q Capture
for VM V7.4.
¹
VMSES/E is required to install and service this product.
¹
If multiple users install and maintain licensed products on your system, there may be a problem
getting the necessary access to MAINT's 51D disk. If you find that there is contention for write access
to the 51D disk, you can eliminate it by converting the Software Inventory from minidisk to Shared File
System (SFS). See the VMSES/E Introduction and Reference manual, section 'Changing the
Software Inventory to an SFS Directory', for information on how to make this change.
Copyright IBM Corp. 1997, 2004
8
¹
Customers will install and service DB2 DProp Q Capture for VM V7.4 using a new user ID--5697F74B.
This is the IBM suggested user ID name. You are free to change this to any user ID name you wish;
however, a Product Parameter File (PPF) override must be created.
Note: It may be easier to make the above change during the installation procedure 6.2, “Plan Your
Installation For DB2 DProp Q Capture for VM V7.4” step 6 on page 13, than after you have installed
this product.
¹
The DB2 DProp Q Capture for VM V7.4 program runs in its own virtual machine, capturing changes
for one and only one DB2 Server for VM database. If there are multiple databases for which you want
to capture changes, you must define additional virtual machines for running the DB2 DProp Q Capture
for VM V7.4 program. The charts in 5.3, “DASD Storage and user ID Requirements” define an initial
virtual machine, CAPTMACH, to run the DB2 DProp Q Capture for VM V7.4 program. See 6.6,
“Post-Installation Considerations (optional)” on page 26 for information on defining additional virtual
machines.
5.3
DASD Storage and user ID Requirements
Figure 7 lists the user IDs and minidisks that are used to install and service DB2 DProp Q Capture for VM
V7.4.
Important Installation Notes:
¹
User ID(s) and minidisks will be defined in 6.2, “Plan Your Installation For DB2 DProp Q Capture
for VM V7.4” on page 12 and are listed here so that you can get an idea of the resources that you
will need prior to allocating them.
¹
5697F74B is a default user ID and can be changed. If you choose to change the name of the
installation user ID you need to create a Product Parameter File (PPF) Override to reflect this
change. This can be done in 6.2, “Plan Your Installation For DB2 DProp Q Capture for VM V7.4”
step 6 on page 13.
¹
If you choose to install DB2 DProp Q Capture for VM V7.4 on a common user ID, the default
minidisk addresses for DB2 DProp Q Capture for VM V7.4 may already be defined. If any of the
default minidisks required by DB2 DProp Q Capture for VM V7.4 are already in use you will have
to create an override to change the default minidisks for DB2 DProp Q Capture for VM V7.4 so
they are unique.
Installation Requirements and Considerations
9
//////////////////////////////////////////
