DB2 Server for VSE & VM Application Programming (Version 7 Release 5)

Appendix E. Using SQL in PL/I

Using PL/I Sample Programs

384

Using DBCS Characters in PL/I

388

Rules for Using SQL in PL/I

384

Using SQL Statements in PL/I Subroutines . . 389

Placing and Continuing SQL Statements . . . 384

Coding the SIZE Parameter in VSE JCL (DB2

Delimiting SQL Statements

384

Server for VSE)

390

Using the INCLUDE Statement

385

Handling SQL Errors

390

Declaring Static External Variables

385

Handling Program Interrupts

390

Identifying Rules for Case

385

Using Dynamic SQL Statements in PL/I

391

Declaring Host Variables

385

Defining DB2 Server for VSE & VM Data Types for

Using Host Variables in SQL Statements . . . 388

PL/I

393

Using PL/I Variables in SQL: Data Conversion

Using Stored Procedures

394

Considerations

388

383

Using PL/I Sample Programs

ARIS6PLD is a PL/I language sample program for VSE systems that is shipped

with the DB2 Server for VSE product. ARIS6PLC is a PL/I language sample

program for VM systems that is shipped with the DB2 Server for VM product. It

resides on the production disk for the base product. You may find it useful to print

this sample program before going through this appendix as the hard copy will

provide an illustration for many of the topics discussed here.

You can learn most of the rules for using SQL within PL/I just by scanning

through the program. Note, in particular, how the program satisfies the

requirements of the application prolog and epilog. Near the beginning of the

program all the host variables are declared and error handling is defined. Near the

logical end of the program, the database changes are rolled back, to assure the

database remains consistent for each use of the sample program. For your own

applications, of course, you will enter a commit.

The DCL statements for the host variables are determined by referring to Table 43

on page 393. That figure gives the PL/I representation for each of the DB2 Server

for VSE & VM data types. When you are coding your own applications, you will

need to obtain the data types of the columns that your host variables interact with.

This can be done by querying the catalog tables, which are described in the DB2

Server for VSE & VM SQL Reference manual.

Rules for Using SQL in PL/I

Placing and Continuing SQL Statements

All statements in your PL/I program, including SQL statements, must be contained

in columns 2 through 72 of your source deck. Normal PL/I continuation rules

apply.

Continuation of tokens (the basic syntactical units of a language) is allowed from

one line to the next, by coding the first part of the token up to column 72 on the

line to be continued and coding the next part of the token from column 2 on the

continuation line. If either column 72 of the continued line or column 2 of the

continuation line is blank, the token is not continued.

See the DB2 Server for VSE & VM SQL Reference manual for a discussion on tokens.

Delimiting SQL Statements

Delimiters are required on all SQL statements to help the database manager

distinguish them from regular PL/I statements. You must precede each SQL

statement in your program with EXEC SQL, and end each statement with a

semicolon. EXEC and SQL must be on the same line, with only blanks separating

them (no in-line host language or SQL comments).

Within SQL statements, host language and SQL comments are allowed anywhere

that blanks are allowed. However, there should not be any host language or SQL

comments within SQL statements that are dynamically defined and executed.

An SQL statement cannot be followed on the same line by another SQL statement,

a normal PL/I statement, or a host language comment. When you preprocess a

program containing such a combination, the trailing statements or host language

comments are ignored and will not appear in the SYSPRINT listing.

384

Application Programming

Using the INCLUDE Statement

To include external secondary input, specify the following at the point in the

source code where the secondary input is to be included:

EXEC SQL INCLUDE text_file-name;

The text_file-name is the member name of a P-Type source member of a VSE

library or the file name of a CMS file (with a “PLICOPY” file type) located on a

CMS minidisk accessed by the user.

Declaring Static External Variables

A declaration for a variable with the attributes STATIC and EXTERNAL must also

have the attribute INITIAL. If it does not, the declaration generates a common

CSECT, which the database manager cannot handle.

PL/I programming using “DEFAULT RANGE (*) STATIC” gives an error message.

The preprocessor builds control blocks that are incompatible with this statement.

Identifying Rules for Case

The keywords “EXEC SQL” must appear in uppercase in your PL/I program. The

rest of an SQL statement can be in mixed case, but will be interpreted as

uppercase, except for text within quotation marks, which will be left in the original

case.

Declaring Host Variables

You must declare all host variables in an SQL declare section. For a description of

an SQL declare section, refer to “Declaring Variables That Interact with the

Database Manager” on page 8.

Declare host variables in the source file before the first use of the variable in an

SQL statement. You can use the following types of variables in an SQL statement:

v Scalar variables

v Structure variables

v Structure elements

v Array variables

For information on the use of these variables in an SQL statement, refer to “Using

Host Variables” on page 55 and “Using Host Structures” on page 55.

Note: You can declare non-host variables in an SQL declare section; however,

declarations that do not conform to DB2 Server for VSE & VM declaration

rules may return errors.

The declaration of a host variable is subject to the following rules:

v You can use scalar variables and structure elements as main variables. You can

also use them as indicator variables if they are declared with a data type of

short integer.

v The only arrays accepted by the PL/I preprocessor are arrays of short integer

elements. These arrays may be used as indicator arrays only. The following

example is an indicator array:

DCL IND_ARRAY(10) BINARY FIXED(15);

Indicator array elements cannot be used as main or indicator variables.

v A structure variable (which defines a host structure) is any two-level structure

declared in an SQL declare section. The following example is a host structure:

Appendix E. Using SQL in PL/I

385

DCL 01 PROJ_STRCT,

05 PROJNO

CHAR(6),

05 ACTNO

BINARY FIXED(15),

05 ACSTAFF

BINARY FIXED(31),

05 ACSTDATE

CHAR(10),

05 ACENDATE

CHAR(10);

This structure represents the following list of host variables when used in an

SQL statement:

PROJNO, ACTNO, ACSTAFF, ACSTDATE, ACENDATE

In other words, the two following SQL statements are equivalent:

EXEC SQL SELECT PROJNO, ACTNO, ACTSTAFF, ACSTDATE, ACENDATE

INTO

:PROJ_STRCT

FROM PROJ_ACT

WHERE PROJNO = ‘100000’

EXEC SQL SELECT PROJNO, ACTNO, ACSTAFF, ACSTDATE, ACENDATE

INTO :PROJNO, :ACTNO, :ACSTAFF, :ACSTDATE, :ACENDATE

FROM PROJ_ACT

WHERE PROJNO = ‘100000’

A host structure can either be a stand-alone structure or a substructure of a more

complex structure. The following example is a complex structure that contains a

host structure:

DCL 01 EMPLOYEE,

05 EMPNO

CHAR(6),

05 EMPNAME

10 FIRSTNAME

CHAR(12),

10 MIDINIT

CHAR(1),

10 LASTNAME

CHAR(15),

05 WORKDEPT

CHAR(3),

05 PHONENO

CHAR(4);

The structure EMPNAME is a host structure.

You can use the elements of the host structure and the elements of a complex

structure containing a host structure as host variables. In the previous example,

EMPNO, FIRSTNAME, MIDINIT, LASTNAME, WORKDEPT, and PHONENO can all be used

as host variables.

DCL or DECLARE must be the first character sequence on the line, but cannot

start in column 1. You can, however, have a carriage control character in column

1. Otherwise, the line is ignored. (You can place inline host language comments

anywhere after the DECLARE or DCL keyword, and you can continue these

comments over multiple lines.)

DECLARE statements can be continued on additional lines, but you cannot have

more than one DECLARE statement on the same line. All DECLARE statements

must end with a semicolon. Rules for continuation of variable names and PL/I

keywords are the same as those described for SQL statements.

Declare only one host variable per DCL or DECLARE statement. If you declare

multiple variables, only the first variable is recognized; the others are ignored.

For example:

DCL AA FIXED BIN(15) INIT(7),

BB CHAR(7),

BB and CC are ignored.

CC BINARY FLOAT(53);

The next rule provides one exception to this limitation.

v Factoring of scalar variable names, structure element names and indicator array

names is supported. For example, the following declarations are valid:

386

Application Programming

DCL (X,Y,Z) BINARY FIXED(31);

DCL (ARR1(10), ARR2(5), ARR3(6)) BINARY FIXED (15);

DCL 01 STUCT,

05 (FLD1, FLD2, FLD3) CHAR(10),

05 FLD4

CHAR(5);

In addition to the attributes discussed in Table 43 on page 393, the PL/I

preprocessor also supports the following attributes in declarations imbedded in

an SQL declare section:

ALIGNED

UNALIGNED

INTERNAL

EXTERNAL

STATIC

AUTOMATIC

DEFINED

CONTROLLED

CONNECTED

INITIAL

In PL/I, the BASED and LIKE functions are not permitted in host structure

declarations.

You cannot duplicate variable names in a single source file even if they are in

different blocks or functions. The PL/I preprocessor defines a duplicate as any

name that cannot be referenced unambiguously when fully qualified.

You should not declare variables whose names begin with SQL or RDI, because

these names are reserved for database manager use.

The database manager allows host variable names, statement labels, and SQL

descriptor area names of up to 256 characters in length, subject to any PL/I

language restriction mentioned in this appendix.

You can have a label on the “EXEC SQL BEGIN DECLARE SECTION;”, but not on

the “EXEC SQL END DECLARE SECTION;”. If you do place a label on this

statement, the preprocessor does not recognize it and assumes that the SQL declare

section has not ended.

When placing host language comments after either of these statements, make sure

the comment ends on the same line. If it does not, PL/I compiler errors result.

Note: Other program variables can also be declared as usual outside the SQL

declare section. The previous restrictions do not apply to non-SQL

declarations.

In the declaration below, only DATES and PRODUCTS may be used as host structures.

ORDERNO and CUSTNUM may be used as scalar host variables and may be qualified as

CUSTORD.ORDERNO and ORDINFO.CUSTNUM or CUSTORD.ORDINFO.CUSTNUM.

EXEC SQL BEGIN DECLARE SECTION;

DCL 1 CUSTORD,

2 ORDERNO CHAR(10),

2 ORDINFO,

3 CUSTNUM CHAR(10),

3 DATES,

5 ORDDATE CHAR(6),

5 DELIVDTE CHAR(6),

2 PRODUCT,

3 STOCKNO CHAR(10),

Appendix E. Using SQL in PL/I

387

3 QUANTITY CHAR(3);

EXEC SQL END DECLARE SECTION;

EXEC SQL SELECT STOCKNO, QUANTITY

INTO :PRODUCT

FROM ORDER

WHERE STOCKNO = ’1234567890’;

Using Host Variables in SQL Statements

When you reference host variables, host structures, structure fields or indicator

arrays in an SQL statement, you must precede each reference by a colon (:) The

colon distinguishes these variables from SQL identifiers (such as column names).

The colon is not required outside an SQL statement.

Using PL/I Variables in SQL: Data Conversion Considerations

Host variables must be type-compatible with the columns with which they are to

be used. For example, if you want to compare a program variable with the

QONHAND column of the database, and the data type of QONHAND is

INTEGER, you should declare the program variable BIN FIXED(31), BIN

FIXED(15), BIN FLOAT, FLOAT BIN, or FIXED DECIMAL(10). (Refer to

“Assigning Data Types When the Column Is Created” on page 44 for details on the

FLOAT data type.)

The database manager considers the numeric data types compatible, as well as the

character string data types (CHAR, VARCHAR, and LONG VARCHAR, including

strings of different declared lengths), and the graphic string data types (GRAPHIC,

VARGRAPHIC, LONG VARGRAPHIC). Of course, an overflow condition may

result if, for example, you assign a 31-bit integer to a 15-bit integer and the current

value of the 31-bit integer is too large to fit in 15 bits. Truncation also occurs when

a decimal number having a scale greater than zero is assigned to an integer. In

general, overflow occurs when significant digits are lost, and truncation occurs

when nonsignificant digits are lost.

The datetime data types are also considered compatible with character data types

(CHAR, and VARCHAR, but not LONG VARCHAR and VARCHAR > 254).

Refer to “Converting Data” on page 48 for a data conversion summary.

Using DBCS Characters in PL/I

The rules for the format and use of DBCS characters in SQL statements are the

same for PL/I as for other host languages supported by the system. For a

discussion of these rules, see “Using a Double-Byte Character Set (DBCS)” on page

51.

When using the string-constant format of the PREPARE or EXECUTE IMMEDIATE

statement, if the statement in the string-constant contains DBCS characters, you

must append an M to the string-constant. For example:

EXEC SQL PREPARE S13 FROM

'SELECT TRANSLATE(''laabb'') || ''l<▌AB▐>'' FROM SYSTEM.SYSCCSIDS'M;

When coding graphic constants in static SQL statements, use one of the following

PL/I formats of the graphic constant:

388

Application Programming

1. '<▌XXXX▐>'G

<@'▌XXXX▐@'@G>

Note: N is a synonym for G.

When coding graphic constants in dynamically executed SQL statements, use the

SQL format of the graphic constant (that is, G'<▌XXXX▐>'). Refer to “Using Graphic

Constants” on page 58 for a discussion of graphic constants.

Using SQL Statements in PL/I Subroutines

The first SQL statement encountered in a sequential scan of your program by the

PL/I preprocessor that requires an in-line call to the resource adapter results in the

generation of control blocks SQLTIE and RDIEXT, and other declarations

commonly used by internal DB2 Server for VSE & VM code that is associated with

the remaining SQL statements in your program. If your program structure involves

SQL statements in multiple procedures, you must maintain structures so that the

SQLTIE and RDIEXT are addressable by all other SQL statement occurrences in

your program.

Figure 90 represents an incorrect structure.

A: PROC OPTIONS(MAIN);

CALL B;

CALL C;

B: PROC;

EXEC SQL CONNECT

EXEC SQL DECLARE C1 CURSOR

EXEC SQL OPEN C1

END B;

C: PROC;

EXEC SQL DECLARE C2 CURSOR

EXEC SQL OPEN C2

END C;

END A;

Figure 90. Incorrect PL/I Program Structure

SQLTIE and RDIEXT will be generated from the CONNECT in B, but it is not

addressable from C, where other SQL statements appear. This can be solved by

putting the CONNECT statement in A, where it will cause SQLTIE and RDIEXT to

be generated at a place that is addressable by both B and C.

Appendix E. Using SQL in PL/I

389

Coding the SIZE Parameter in VSE JCL (DB2 Server for VSE)

When executing PL/I application programs in VSE single user mode, specify

SIZE=750K, not SIZE=AUTO, in the EXEC job control statement.

Handling SQL Errors

There are two ways to declare the return code structure (called SQLCA):

1. You can write the following statement in your source program:

EXEC SQL INCLUDE SQLCA;

The preprocessor replaces this with the declaration of the SQLCA structure.

2. You may declare the SQLCA structure directly, as shown in Figure 91.

DCL 1 SQLCA,

2 SQLCAID CHAR(8),

2 SQLCABC BIN FIXED(31),

2 SQLCODE BIN FIXED(31),

2 SQLERRM CHAR(70) VAR,

2 SQLERRP CHAR(8),

2 SQLERRD (6) BIN FIXED(31),

2 SQLWARN,

3 SQLWARN0 CHAR(1),

3 SQLWARN1 CHAR(1),

3 SQLWARN2 CHAR(1),

3 SQLWARN3 CHAR(1),

3 SQLWARN4 CHAR(1),

3 SQLWARN5 CHAR(1),

3 SQLWARN6 CHAR(1),

3 SQLWARN7 CHAR(1),

3 SQLWARN8 CHAR(1),

3 SQLWARN9 CHAR(1),

3 SQLWARNA CHAR(1),

2 SQLSTATE CHAR(5);

Figure 91. SQLCA Structure (in PL/I)

The SQLCA must not be declared within the SQL declare section. The meanings of

the fields in the SQLCA are discussed in the DB2 Server for VSE & VM SQL

Reference manual.

You may find that the only variable in the SQLCA you really need is SQLCODE. If

this is the case, declare just the SQLCODE variable, and invoke NOSQLCA support

at preprocessor time.

The number of SQLCODE declarations is not limited by the preprocessor. If a

stand-alone SQLCODE is specified, the code inserted by the preprocessor into the

PL/I code to expand an EXEC SQL statement will refer to the address of that

SQLCODE. The PL/I compiler determines if multiple declarations within a

program section are not acceptable. In addition, the PL/I compiler determines

which region of the code an SQLCODE declaration refers to.

Handling Program Interrupts

If a program interrupt occurs and the database manager is unaware of it, you may

receive unexpected results. To allow the system to process the interrupt, include

the following declaration statement after the “EXEC SQL END DECLARATION

SECTION” statement:

390

Application Programming

DCL PLIXOPT CHAR(20) VAR INIT(’TRAP(OFF)’) STATIC EXTERNAL;

If your PL/I compiler is NOT Language Environment enabled, add the following

statement instead:

DCL PLIXOPT CHAR(20) VAR INIT(’NOSTAE,NOSPIE’) STATIC EXTERNAL;

Using Dynamic SQL Statements in PL/I

You may need to declare an SQLDA structure to execute dynamically defined SQL

statements. You can have the system include the structure automatically by

specifying:

EXEC SQL INCLUDE SQLDA;

in your source code, or by directly coding the structure as shown in Figure 92.

DCL 1 SQLDA BASED(SQLDAPTR),

2 SQLDAID CHAR(8),

2 SQLDABC BIN FIXED(31),

2 SQLN BIN FIXED(15),

2 SQLD BIN FIXED(15),

2 SQLVAR(SQLSIZE REFER(SQLN)),

3 SQLTYPE BIN FIXED(15),

3 SQLLEN BIN FIXED(15),

3 SQLDATA PTR,

3 SQLIND PTR,

3 SQLNAME CHAR(30) VAR;

DCL SQLSIZE BIN FIXED(15);

DCL SQLDAPTR PTR;

Figure 92. SQLDA Structure (in PL/I)

The SQLDA must not be declared within the SQL declare section. See the DB2

Server for VSE & VM SQL Reference manual for more information on the individual

fields within the SQLDA.

In addition to the structure above, you should declare an additional mapping for

the same area. The SQLPRCSN and SQLSCALE fields of the second mapping are

used when decimal data is used. Table 42 shows this mapping.

Table 42. SQLDAX Structure (in PL/I)

DCL 1 SQLDAX BASED(SQLDAPTR),

2 SQLDAIDX CHAR(8),

2 SQLDABCX BIN FIXED(31),

2 SQLNX BIN FIXED(15),

2 SQLDX BIN FIXED(15),

2 SQLVARX(SQLSIZE REFER(SQLNX)),

3 SQLTYPEX BIN FIXED(15),

3 SQLPRCSN format 1 or format 2,

3 SQLSCALE format 1 or format 2,

3 SQLDATAX PTR,

3 SQLINDX PTR,

3 SQLNAMEX CHAR(30) VAR;

The SQLPRCSN and SQLSCALE fields can be declared in one of two formats.

Appendix E. Using SQL in PL/I

391

Table 42. SQLDAX Structure (in PL/I) (continued)

Format 1:

3 SQLPRCSN BIT(8),

3 SQLSCALE BIT(8),

The fields must be set by bit 8 strings. For example, for a precision of 5 and scale of 2, the

following assignments are required:

SQLDAPTR->SQLPRCSN = ’00000101’B

SQLDAPTR->SQLSCALE = ’00000010’B

Format 2:

3 SQLPRCSN CHAR(1),

3 SQLSCALE CHAR(1),

This format requires the declaration of additional variables. These are a CHAR(2) variable

and a BASED FIXED BIN(15) variable for both precision and scale. For example:

DCL PRCSNC CHAR(2);

DCL PRCSNN FIXED BIN(15) BASED (ADDR(PRCSNC));

DCL SCALEC CHAR(2);

DCL SCALEN FIXED BIN(15) BASED (ADDR(SCALEC));

The SQLDAX fields for a precision of 5 and scale of 2 would be:

PRCSNN = 5;

SCALEN = 2;

SQLDAPTR->SQLPRCSN = SUBSTR(PRCSNC,2,1);

SQLDAPTR->SQLSCALE = SUBSTR(SCALEC,2,1);

Format 2, although more complex, allows PL/I manipulation of the precision and scale

fields. For example, the value of the SQLPRCSN field can be determined simply by

reversing the substring operation above. That is:

SUBSTR(PRCSNC,2,1) = SQLDAPTR->SQLPRCSN;

Such an operation cannot be done using format 1.

Because the PL/I SQLDA is declared as a based structure, your program can

dynamically allocate an SQLDA of adequate size for use with each EXECUTE

statement. For example, the code fragment below allocates an SQLDA adequate for

five fields and uses it in an EXECUTE of statement S3:

SQLSIZE=5;

ALLOCATE SQLDA SET(SQLDAPTR);

/* Add code to set values and pointers in the SQLDA */

EXEC SQL EXECUTE S3 USING DESCRIPTOR SQLDA;

The statement SQLSIZE=5 determines the size of the SQLDA to be allocated by

means of the PL/I REFER feature. The ALLOCATE statement allocates an SQLDA

of the size desired, and sets SQLDAPTR to point to it. (Before an EXECUTE

statement is issued using this SQLDA, your program must fill in its contents.)

You can use a similar technique to allocate an SQLDA for use with a DESCRIBE

statement. The following program fragment illustrates the use of SQLDA with

DESCRIBE for three fields and a “prepared” statement S1:

EXEC SQL DECLARE C1 CURSOR FOR S1;

SQLSIZE = 3;

ALLOCATE SQLDA SET(SQLDAPTR);

EXEC SQL DESCRIBE S1 INTO SQLDA;

IF SQLD > SQLN THEN

- get a bigger one;

Set SQLDATA and SQLIND;

EXEC SQL OPEN C1;

EXEC SQL FETCH C1 USING DESCRIPTOR SQLDA;

392

Application Programming

Defining DB2 Server for VSE & VM Data Types for PL/I

Table 43. Data Types for PL/I

DB2 Server for VSE & VM

Description

Keyword

Equivalent PL/I Declaration

A binary integer of 31 bits, plus sign.

INTEGER or INT

BINARY FIXED(31)

A binary integer of 15 bits, plus sign.

SMALLINT

BINARY FIXED(15)

A packed decimal number, precision

DECIMAL[(p[,s])] or DEC[(p[,s])]¹

FIXED DECIMAL(p,s)

p, scale s (1 ≤ p ≤ 31 and 0 ≤ s ≤ p).

In storage the number occupies a

maximum of 16 bytes. Precision is

the total number of digits. Scale is

the number of those digits that are to

the right of the decimal point.

A single-precision (4- byte)

REAL or FLOAT(p), 1 ≤ p ≤ 21

BINARY FLOAT(p) or FLOAT

floating-point number, in short

BINARY(p), 1 ≤ p ≤ 21

DECIMAL

System/390 floating-point format.

FLOAT(p) or FLOAT DECIMAL(p),

1≤p≤7

A double-precision (8- byte)

FLOAT or FLOAT(p), 22 ≤ p ≤ 53

BINARY FLOAT(p) or FLOAT

floating-point number, in long

or DOUBLE PRECISION

BINARY(p), 22 ≤ p ≤ 53

DECIMAL

System/390 floating-point format.

FLOAT(p) or FLOAT DECIMAL(p),

8 ≤ p ≤ 16

A fixed-length character string of

CHARACTER[(n)] or CHAR[(n)]

CHARACTER(n)

length n where 0 < n ≤ 254.

A varying-length character string of

VARCHAR(n)

CHARACTER(n) VARYING

maximum length n. If n > 254 or ≤

32 767, this data type is considered a

long field. See “Using Long Strings”

on page 45 for more information.

A varying-length character string of

LONG VARCHAR

CHARACTER(n) VARYING

maximum length 32,767 bytes.

A fixed-length string of n DBCS

GRAPHIC[(n)]

GRAPHIC(n)

characters where 0 < n ≤ 127.

A varying-length string of n DBCS

VARGRAPHIC(n)

GRAPHIC(n) VARYING

characters. If n > 127 or ≤ 16 383, this

data type is considered a long field.

See “Using Long Strings” on page 45

for more information.

A varying-length string of DBCS

LONG VARGRAPHIC

GRAPHIC(n) VARYING

characters of maximum length 16 383.

A fixed or varying-length character

DATE

CHARACTER(n) or

string representing a date. The

CHARACTER(n) VARYING

minimum and maximum lengths

vary with both the format used and

whether it is an input or output

operation. See the DB2 Server for VSE

& VM SQL Reference manual for more

information.

Appendix E. Using SQL in PL/I

393

Table 43. Data Types for PL/I (continued)

DB2 Server for VSE & VM

Description

Keyword

Equivalent PL/I Declaration

A fixed or varying-length character

TIME

CHARACTER(n) or

string representing a time. The

CHARACTER(n) VARYING

minimum and maximum lengths

vary with both the format used and

whether it is an input or output

operation. See the DB2 Server for VSE

& VM SQL Reference manual for more

information.

A fixed or varying-length character

TIMESTAMP

CHARACTER(n) or

string representing a timestamp. The

CHARACTER(n) VARYING

lengths can vary on input and

output. See the DB2 Server for VSE &

VM SQL Reference manual for more

information.

Notes:

1. NUMERIC is a synonym for DECIMAL and may be used when creating or

altering tables. In such cases, however, the CREATE or ALTER function will

establish the column (or columns) as DECIMAL.

2. The data type can be stated in any way that is acceptable to PL/I; BIN

FIXED(31), BINARY FIXED(31), and FIXED BIN(31) are all equivalent. If several

variables have exactly the same attributes, you can combine them in a single

DCL statement:

DCL (X,Y,Z) BIN FIXED;

Using Stored Procedures

The following example shows how to define the parameters in a stored procedure

that uses the GENERAL linkage convention. The NOEXECOPS procedure option

must be specified.

PLISAMP: PROC(PARM1, PARM2, ...)

OPTIONS(MAIN, NOEXECOPS);

DCL PARM1 ...

/* first parameter */

DCL PARM2 ...

/* second parameter */

Figure 93. Stored Procedure - Using GENERAL Linkage Convention

The following example shows how to define the parameters in a stored procedure

that uses the GENERAL WITH NULLS linkage convention.

394

Application Programming

How to Use the Decision Tables

The DB2 Server for VSE & VM product uses decision tables to determine whether

the owner of a package has the authority or the privilege to execute a given

statement. There are three possible scores for each static statement:

‘G’

Means that the package owner has the necessary authorization or privilege

for this statement such that the owner can receive the RUN privilege.

‘Y’

Means that the package owner has the necessary authorization or privilege

for this statement such that the owner can receive the RUN privilege, but

not the GRANT option on that privilege.

‘D’

Means that the package owner must have DBA authority to execute the

program containing this statement. No entry is made in the authorization

catalog tables.

‘G’ is the highest score, followed by ‘Y’, followed by ‘D’. For example, suppose a

program contains three statements. The package owner receives a ‘G’, on two of

them, but a ‘Y’ on the third (this occurs when the object referenced in the

statement does not exist, or the privileges of the object cannot be resolved). In this

situation, the database manager assigns the package a ‘Y’ (the lower score),

allowing the owner to run the package but not to grant the RUN privilege on the

package to another user. Because the preprocessor does not distinguish between

certain SQL statements that are applied to one application server or to another, you

can compensate by doing one of the following:

v Use dynamic statements that cause RUNAUTH=G on both application servers.

v Create separate packages on each application server. These separate packages

can then be invoked by a mainline program.

v Create dummy tables that have the same user IDs and table names on the other

application server.

Dynamic statements are always given a score of ‘G’.

The next few pages show tables. In these tables:

‘G’, ‘Y’, and ‘D’ have the meanings outlined above.

‘(G)’ and ‘(Y)’ mean that the score for the statement is either ‘G’ or ‘Y’, an error

message is produced when the program is preprocessed, a partial section for

the statement is placed into the package, and the authority for the statement is

checked again at the time the package is run.

‘n/a’ means ‘not applicable’.

package owner is the authorization ID of the person who preprocesses the

program.

398

Application Programming

Decision Tables

ACQUIRE DBSPACE

Dbspace Owner

Pkg Owner's

PRIVATE

Authority

Dbspace Owner

PUBLIC

is Pkg Owner

not Pkg Owner

DBA

RESOURCE

(G)

None of the above

(G)

For cases A2 and B2, the system makes an entry in the SYSUSERAUTH catalog

table with RESOURCEAUTH set to ‘Y’. In addition, the NAME column is set to the

package_id and the AUTHOR column is set to the authorization ID of the person

who preprocessed the program. The entry indicates the program’s dependency.

ALTER DBSPACE

Dbspace Owner

Pkg Owner's

Authority

Dbspace Owner

is Pkg Owner

not Pkg Owner

DBA

non-DBA

(G)

Appendix F. Decision Tables to Grant Privileges on Packages

399

ALTER TABLE

Table Owner

Pkg Owner's

Authority and

Tbl Privilege

Table Owner

Table does not

is Pkg Owner

not Pkg Owner

yet exist

DBA, no ALTER

n/a

ALTER without GRANT

n/a

ALTER with GRANT

n/a

non-DBA , no ALTER

n/a

(G)

For cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the ALTERAUTH columns set to ‘Y’. The entries represent this

package’s dependency on ALTER privilege for the table.

The preprocessor determines which level of RUN privilege to give the owner. For

some SQL statements, privileges are not checked for all objects affected by the

statement. For example, when manipulating primary and foreign keys with the

ALTER TABLE statement, ALTER privilege is only checked for the table_name

following the ALTER TABLE statement rather than all the tables involved.

Additional ALTER and REFERENCES privileges are checked at run time.

COMMENT ON

Table/View Owner

Pkg Owner's

Authority

Table/View Owner

is Pkg Owner

not Pkg Owner

DBA

non-DBA

(G)

400

Application Programming

CREATE INDEX

Table on which INDEX is based

Pkg Owner's

Table Exists and

Table does not yet exist

Authority and

the Table's Owner

and the Table's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no INDEX

non-DBA, INDEX

n/a

without GRANT

non-DBA, INDEX

n/a

with GRANT

non-DBA , no INDEX

n/a

(G)

(Y)

For cases B2, C1, and C2, the system makes an entry in the SYSTABAUTH catalog

table with the INDEXAUTH column set to ‘Y’. The entries represent this package’s

dependency on INDEX authority privilege for the table.

Note: It is possible for the owner of a table to create an index on that table in the

name of another authorization ID. This is true even if the table owner does

not have DBA authority.

CREATE TABLE

Table O wner

Pkg Owner's

Authority

Table O wner

is Pkg Owner

not Pkg Owner

DBA

non-DBA

(G)

DELETE

There are two decision tables that apply to DELETE:

The Table Where the Deletion Is Applied :

Appendix F. Decision Tables to Grant Privileges on Packages

401

Table/View on which DELETE is applied

Pkg Owner's

Table/View Exists and

Table/View does not yet exist

Authority and

the Table/View's Owner

and the Table/View's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no DELETE

non-DBA, DELETE

n/a

without GRANT

non-DBA, DELETE

n/a

with GRANT

non-DBA , no DELETE

n/a

(G)

(Y)

In cases B2, C1, and C2, the application server makes entries in the SYSTABAUTH

catalog table with the DELETEAUTH column set to ‘Y’. The entries represent this

package’s dependency on the DELETE privilege for the table.

Any Tables Referenced in a WHERE Clause :

Note: The authorization checking in the previous decision table precedes the logic

of this table. If the first decision table yields a negative SQLCODE,

processing stops. Otherwise, the system applies the lowest level of

authorization gained from the two decision tables.

Table/Views in WHERE clause

Pkg Owner's

Table/View Exists and

Table/View does not yet exist

Authority and

the Table/View's Owner

and the Table/View's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no SELETE

non-DBA, SELECT

n/a

without GRANT

non-DBA, SELECT

n/a

with GRANT

non-DBA , no SELECT

n/a

(G)

(Y)

Figure 95. Tables/Views in WHERE clause

In cases B2, C1, and C2, the application server makes entries in the SYSTABAUTH

catalog table with the SELECTAUTH column set to ‘Y’. The entries represent this

package’s dependency on SELECT privilege for the table.

402

Application Programming

In case A2, the system makes an entry in the SYSUSERAUTH catalog table to show

this package’s dependency on DBA authority.

GRANT for Authorities Statement

Authority Granted

Authority

of Grantor

CONNECT to

DBA

RESOURCE

another user

CONNECT to self

DBA

Non-DBA

INSERT:

There are two decision tables that apply to INSERT:

The Table Where the Insertion Is Applied :

Table/Views to which INSERT is applied

Pkg Owner's

Table/View Exists and

Table/View does not yet exist

Authority and

the Table/View's Owner

and the Table/View's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no INSERT

non-DBA, INSERT

n/a

without GRANT

non-DBA, INSERT

n/a

with GRANT

non-DBA, no INSERT

n/a

(G)

(Y)

In cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the INSERTAUTH column set to ‘Y’. The entries represent this package’s

dependency on INSERT privilege for the table.

Any Tables Referenced in a WHERE Clause of a Subselect :

Appendix F. Decision Tables to Grant Privileges on Packages

403

Note: The authorization checking in the previous decision table precedes the logic

of this table.

The decision table used here is the same as that used by tables in the WHERE

clause of a DELETE in Figure 95 on page 402.

In cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the SELECTAUTH column set to ‘Y’. The entries represent this

package’s dependency on SELECT privilege for the table.

In case A2, the system makes an entry in the SYSUSERAUTH catalog table to show

this package’s dependency on DBA authority.

REVOKE for Authorities Statement

Authority Revoked

Authority

of Revoker

DBA

RESOURCE

CONNECT

DBA

Non-DBA

SELECT

There are two decision tables that apply to SELECT:

The Tables in the FROM List :

Table/Views in the FROM list

Pkg Owner's

Table/View Exists and

Table/View does not yet exist

Authority and

the Table/View's Owner

and the Table/View's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no SELECT

non-DBA, SELECT

n/a

without GRANT

non-DBA, SELECT

n/a

with GRANT

non-DBA, no SELECT

n/a

(G)

(Y)

In cases B2, C1, and C2, the application server makes entries in the SYSTABAUTH

catalog table with the SELECTAUTH column set to ‘Y’. The entries represent this

package’s dependency on INSERT privilege for the table.

404

Application Programming

In case A2, there are some instances where a ‘Y’ entry is made in the DBAAUTH

column of the SYSUSERAUTH catalog table, showing package dependencies on

DBA authority.

Any Tables Referenced in a WHERE Clause :

Note: The authorization checking in the previous decision table precedes the logic

of this table.

The decision table used here is the same as that used by tables in the WHERE

clause of a DELETE in Figure 95 on page 402.

In cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the SELECTAUTH column set to ‘Y’. The entries represent this

package’s dependency on SELECT privilege for the table.

In case A2, the system makes an entry in the SYSUSERAUTH catalog table to show

this package’s dependency on DBA authority.

The UPDATE Tables

There are two decision tables that apply to UPDATE:

The Table Where the Update Is Applied :

Table/Views to which UPDATE is applied

Pkg Owner's

Table/View Exists and

Table/View does not yet exist

Authority and

the Table/View's Owner

and the Table/View's Owner

Tbl Privilege

is Pkg Owner

not Pkg Owner

is Pkg Owner

not Pkg Owner

n/a

(G)

(Y)

DBA, no UPDATE

non-DBA, UPDATE

n/a

without GRANT

non-DBA, UPDATE

n/a

with GRANT

non-DBA, no UPDATE

n/a

(G)

(Y)

In cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the UPDATEAUTH column set to ‘Y’. The entries represent this

package’s dependency on UPDATE privilege for the table.

Any Tables Referenced in a WHERE Clause :

Note: The authorization checking in the previous decision table precedes the logic

of this table.

Appendix F. Decision Tables to Grant Privileges on Packages

405

The decision table used here is the same as that used by tables in the WHERE

clause of a DELETE in Figure 95 on page 402.

In cases B2, C1, and C2, the system makes entries in the SYSTABAUTH catalog

table with the SELECTAUTH column set to ‘Y’. The entries represent this

package’s dependency on SELECT privilege for the table.

In case A2, the system makes an entry in the SYSUSERAUTH catalog table to show

this package’s dependency on DBA authority.

There are two decision tables that apply to UPDATE:

The LOCK DBSPACE Table

Dbspace Owner

Pkg Owner's

Authority

Dbspace Owner

is Pkg Owner

not Pkg Owner

DBA

non-DBA

(G)

The LOCK TABLE Table

Table Owner

Pkg Owner's

Authority and

Tbl Privilege

Table Owner

Table does not

is Pkg Owner

not Pkg Owner

yet exist

DBA, no SELECT

n/a

SELECT without GRANT

n/a

SELECT with GRANT

n/a

non - DBA , no SELECT

n/a

(G)

For cases B1, B2, and C2, the system makes entries in the SYSTABAUTH catalog

table. The entries have the SELECTAUTH column set to ‘Y’ to show the package’s

dependency.

406

Application Programming

Notices

IBM may not offer the products, services, or features discussed in this document in

all countries. Consult your local IBM representative for information on the

products and services currently available in your area. Any reference to an IBM

product, program, or service is not intended to state or imply that only that IBM

product, program, or service may be used. Any functionally equivalent product,

program, or service that does not infringe any IBM intellectual property right may

be used instead. However, it is the user’s responsibility to evaluate and verify the

operation of any non-IBM product, program, or service.

IBM may have patents or pending patent applications covering subject matter

described in this document. The furnishing of this document does not give you

any license to these patents. You can send license inquiries, in writing, to:

IBM Director of Licensing

IBM Corporation

North Castle Drive

Armonk, NY 10594-1785

U.S.A.

For license inquiries regarding double-byte (DBCS) information, contact the IBM

Intellectual Property Department in your country or send inquiries, in writing, to:

IBM World Trade Asia Corporation

Licensing

2-31 Roppongi 3-chome, Minato-ku

Tokyo 106, Japan

The following paragraph does not apply to the United Kingdom or any other

country where such provisions are inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS

PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or

implied warranties in certain transactions, therefore, this statement may not apply

to you.

This information could include technical inaccuracies or typographical errors.

Changes are periodically made to the information herein; these changes will be

incorporated in new editions of the publication. IBM may make improvements

and/or changes in the product(s) and/or the program(s) described in this

publication at any time without notice.

Any references in this information to non-IBM Web sites are provided for

convenience only and do not in any manner serve as an endorsement of those Web

sites. The materials at those Web sites are not part of the materials for this IBM

product and use of those Web sites is at your own risk.

IBM may use or distribute any of the information you supply in any way it

believes appropriate without incurring any obligation to you.

407

Licensees of this program who wish to have information about it for the purpose

of enabling: (i) the exchange of information between independently created

programs and other programs (including this one) and (ii) the mutual use of the

information which has been exchanged, should contact:

IBM Corporation

Mail Station P300

522 South Road

Poughkeepsie, NY 12601-5400

U.S.A

Such information may be available, subject to appropriate terms and conditions,

including in some cases, payment of a fee.

The licensed program described in this information and all licensed material

available for it are provided by IBM under terms of the IBM Customer Agreement,

IBM International Program License Agreement, or any equivalent agreement

between us.

Any performance data contained herein was determined in a controlled

environment. Therefore, the results obtained in other operating environments may

vary significantly. Some measurements may have been made on development-level

systems and there is no guarantee that these measurements will be the same on

generally available systems. Furthermore, some measurement may have been

estimated through extrapolation. Actual results may vary. Users of this document

should verify the applicable data for their specific environment.

Information concerning non-IBM products was obtained from the suppliers of

those products, their published announcements, or other publicly available sources.

IBM has not tested those products and cannot confirm the accuracy of

performance, compatibility, or any other claims related to non-IBM products.

Questions on the capabilities of non-IBM products should be addressed to the

suppliers of those products.

All statements regarding IBM’s future direction or intent are subject to change or

withdrawal without notice, and represent goals and objectives only.

This information may contain examples of data and reports used in daily business

operations. To illustrate them as completely as possible, the examples include the

names of individuals, companies, brands, and products. All of these names are

fictitious and any similarity to the names and addresses used by an actual business

enterprise is entirely coincidental.

This information may contain sample application programs in source language,

which illustrates programming techniques on various operating platforms. You

may copy, modify, and distribute these sample programs in any form without

payment to IBM, for the purposes of developing, using, marketing, or distributing

application programs conforming to the application programming interface for the

operating platform for which the sample programs are written. These examples

have not been thoroughly tested under all conditions. IBM, therefore, cannot

guarantee or imply reliability, serviceability, or function of these programs.

408

Application Programming

Programming Interface Information

This manual documents intended Programming Interfaces that allow the customer

to write programs to obtain services of DB2 Server for VSE & VM.

Trademarks

The following terms are trademarks of International Business Machines

Corporation in the United States, or other countries, or both:

APL2

CICS

CICS/VSE

DATABASE 2

DataPropagator

DB2

DRDA

IBM

Language Environment

OS/390

QMF

SQL/DS

System/390

VM/ESA

VSE/ESA

Microsoft, Windows, Windows NT, and the Windows logo are trademarks of

Microsoft Corporation in the United States, other countries, or both.

Other company, product, and service names may be trademarks or service marks

of others.

Notices

409

Bibliography

This bibliography lists publications that are

v DB2 Server for VSE System Administration,

referenced in this manual or that may be helpful.

SC09-2981

v DB2 Server for VSE & VM Performance Tuning

DB2 Server for VM Publications

Handbook, GC09-2987

DB2 Server for VSE & VM Application

v DB2 Server for VSE & VM SQL Reference,

Programming, SC09-2889

SC09-2989

DB2 Server for VSE & VM Database

Administration, SC09-2888

Related Publications

DB2 Server for VSE & VM Database Services

v DB2 Server for VSE & VM Data Restore,

Utility, SC09-2983

SC09-2991

DB2 Server for VSE & VM Diagnosis Guide and

v DRDA: Every Manager's Guide, GC26-3195

Reference, LC09-2907

v IBM SQL Reference, Version 2, Volume 1,

DB2 Server for VSE & VM Overivew, GC09-2995

SC26-8416

DB2 Server for VSE & VM Interactive SQL Guide

v IBM SQL Reference, SC26-8415

and Reference, SC09-2990

VM/ESA Publications

DB2 Server for VSE & VM Master Index and

Glossary, SC09-2890

VM/ESA: General Information, GC24-5745

DB2 Server for VM Messages and Codes,

VM/ESA: VMSES/E Introduction and Reference,

GC09-2984

GC24-5837

DB2 Server for VSE & VM Operation, SC09-2986

VM/ESA: Installation Guide, GC24-5836

DB2 Server for VSE & VM Quick Reference,

VM/ESA: Service Guide, GC24-5838

SC09-2988

VM/ESA: Planning and Administration,

DB2 Server for VM System Administration,

SC24-5750

SC09-2980

VM/ESA: CMS File Pool Planning,

DB2 Server for VSE & VM Performance Tuning

Administration, and Operation, SC24-5751

Handbook, GC09-2987

VM/ESA: REXX/EXEC Migration Tool for

DB2 Server for VSE & VM SQL Reference,

VM/ESA, GC24-5752

SC09-2989

VM/ESA: Conversion Guide and Notebook,

GC24-5839

DB2 Server for VSE Publications

VM/ESA: Running Guest Operating Systems,

v DB2 Server for VSE & VM Application

SC24-5755

Programming, SC09-2889

VM/ESA: Connectivity Planning, Administration,

v DB2 Server for VSE & VM Database

and Operation, SC24-5756

Administration, SC09-2888

VM/ESA: Group Control System, SC24-5757

v DB2 Server for VSE & VM Database Services

VM/ESA: System Operation, SC24-5758

Utility, SC09-2983

VM/ESA: Virtual Machine Operation, SC24-5759

v DB2 Server for VSE & VM Diagnosis Guide and

VM/ESA: CP Programming Services, SC24-5760

Reference, LC09-2907

VM/ESA: CMS Application Development Guide,

v DB2 Server for VSE & VM Overivew, GC09-2995

SC24-5761

v DB2 Server for VSE & VM Interactive SQL Guide

VM/ESA: CMS Application Development

and Reference, SC09-2990

Reference, SC24-5762

v DB2 Server for VSE & VM Master Index and

VM/ESA: CMS Application Development Guide for

Glossary, SC09-2890

Assembler, SC24-5763

v DB2 Server for VSE Messages and Codes,

VM/ESA: CMS Application Development Reference

GC09-2985

for Assembler, SC24-5764

v DB2 Server for VSE & VM Operation, SC09-2986

411

VM/ESA: CMS Application Multitasking,

v IBM VSE/ESA Guide to System Functions,

SC24-5766

SC33-6511

VM/ESA: CP Command and Utility Reference,

v IBM VSE/ESA Installation, SC33-6504

SC24-5773

v IBM VSE/ESA Messages & Codes, SC33-6507

VM/ESA: CMS Primer, SC24-5458

v IBM VSE/ESA Networking Support, SC33-6508

VM/ESA: CMS User’s Guide, SC24-5775

v IBM VSE/ESA Operation, SC33-6506

VM/ESA: CMS Command Reference, SC24-5776

v IBM VSE/ESA Planning, SC33-6503

VM/ESA: CMS Pipelines User’s Guide, SC24-5777

v IBM VSE/ESA System Control Statements,

VM/ESA: CMS Pipelines Reference, SC24-5778

SC33-6513

VM/ESA: XEDIT User’s Guide, SC24-5779

v IBM VSE/ESA System Macros User’s Guide,

SC33-6515

VM/ESA: XEDIT Command and Macro Reference,

SC24-5780

v IBM VSE/ESA System Macros Reference,

SC33-6516

VM/ESA: Quick Reference, SX24-5290

v IBM VSE/ESA System Utilities, SC33-6517

VM/ESA: Performance, SC24-5782

v IBM VSE/ESA Unattended Node Support,

VM/ESA: Dump Viewing Facility, GC24-5853

SC33-6512

VM/ESA: System Messages and Codes, GC24-5841

v IBM VSE/ESA Using IBM Workstations,

VM/ESA: Diagnosis Guide, GC24-5854

SC33-6509

VM/ESA: CP Diagnosis Reference, SC24-5855

VM/ESA: CP Diagnosis Reference Summary,

CICS/VSE Publications

SX24-5292

CICS/VSE Application Programming Reference,

VM/ESA: CMS Diagnosis Reference, SC24-5857

SC33-0713

CP and CMS control block information is not

CICS/VSE Application Programming Guide,

provided in book form. This information is

SC33-0712

available on the IBM VM/ESA operating

CICS Application Programming Primer (VS

system home page (http://www.ibm.com/

COBOL II), SC33-0674

s390/vm).

CICS/VSE CICS-Supplied Transactions, SC33-0710

IBM VM/ESA: CP Exit Customization, SC24-5672

CICS/VSE Customization Guide, SC33-0707

VM/ESA REXX/VM User’s Guide, SC24-5465

CICS/VSE Facilities and Planning Guide,

VM/ESA REXX/VM Reference, SC24-5770

SC33-0718

CICS/VSE Intercommunication Guide, SC33-0701

C for VM/ESA Publications

CICS/VSE Performance Guide, SC33-0703

IBM C for VM/ESA Diagnosis Guide, SC09-2149

CICS/VSE Problem Determination Guide,

IBM C for VM/ESA Language Reference,

SC33-0716

SC09-2153

CICS/VSE Recovery and Restart Guide, SC33-0702

IBM C for VM/ESA Compiler and Run-Time

CICS/VSE Release Guide, GC33-1645

Migration Guide, SC09-2147

CICS/VSE Report Controller User’s Guide,

IBM C for VM/ESA Programming Guide,

SC33-0705

SC09-2151

CICS Transaction Server for VSE/ESA V1R1.0

IBM C for VM/ESA User’s Guide, SC09-2152

Resource Definition Guide, SC33-0709

Virtual Storage Extended/Enterprise Systems

CICS/VSE Resource Definition (Online),

Architecture (VSE/ESA) Publications

SC33-0708

v IBM VSE/ESA Administration, SC33-6505

CICS/VSE System Definition and Operations

Guide, SC33-0706

v IBM VSE/ESA Diagnosis Tools, SC33-6514

CICS/VSE System Programming Reference,

v IBM VSE/ESA General Information, GC33-6501

SC33-0711

v IBM VSE/ESA Guide for Solving Problems,

CICS/VSE User’s Handbook, SX33-6079

SC33-6510

CICS/VSE XRF Guide, SC33-0704

412

Application Programming

CICS/ESA Publications

v IBM Distributed Data Management (DDM)

Architecture, Architecture Reference, Level 4,

v CICS/ESA General Information, GC33-0803

SC21-9526

VSE/Virtual Storage Access Method (VSE/VSAM)

v IBM Distributed Data Management (DDM)

Publications

Architecture, Implementation Programmer’s Guide,

SC21-9529

v VSE/VSAM Commands and Macros, SC33-6532

v VM/Directory Maintenance Licensed Program

v VSE/VSAM Introduction, GC33-6531

Specification, GC20-1836

v VSE/VSAM Messages and Codes, SC24-5146

v IBM Distributed Relational Database Architecture

v VSE/VSAM Programmer’s Reference, SC33-6535

Reference, SC26-4651

v IBM Systems Network Architecture, Format and

VSE/Interactive Computing and Control Facility

Protocol Reference, SC30-3112

(VSE/ICCF) Publications

v SNA LU 6.2 Reference: Peer Protocols, SC31-6808

v VSE/ICCF Administration and Operation,

SC33-6562

v Reference Manual: Architecture Logic for LU Type

6.2, SC30-3269

v VSE/ICCF Primer, SC33-6561

v IBM Systems Network Architecture, Logical Unit

v VSE/ICCF User’s Guide, SC33-6563

6.2 Reference: Peer Protocols, SC31-6808

VSE/POWER Publications

v Distributed Data Management (DDM) General

Information, GC21-9527

v VSE/POWER Administration and Operation,

SC33-6571

CCSID Publications

v VSE/POWER Application Programming,

v Character Data Representation Architecture,

SC33-6574

Executive Overview, GC09-2207

v VSE/POWER Networking, SC33-6573

v Character Data Representation Architecture

v VSE/POWER Remote Job Entry, SC33-6572

Reference and Registry, SC09-2190

Distributed Relational Database Architecture

DB2 Server RXSQL Publications

(DRDA) Library

v DB2 REXX SQL for VM/ESA Installation and

v Application Programming Guide, SC26-4773

Reference, SC09-2891

v Architecture Reference, SC26-4651

v Connectivity Guide, SC26-4783

C/370 Publications

v DRDA: Every Manager's Guide, GC26-3195

v IBM C/370 Installation and Customization Guide,

GC09-1387

v Planning for Distributed Relational Database,

SC26-4650

v IBM C/370 Programming Guide, SC09-1384

v Problem Determination Guide, SC26-4782

Communication Server for OS/2 Publications

C/370 for VSE Publications

v Up and Running!, GC31-8189

v IBM C/370 General Information, GC09-1386

v Network Administration and Subsystem

Management Guide, SC31-8181

v IBM C/370 Programming Guide for VSE,

SC09-1399

v Command Reference, SC31-8183

v IBM C/370 Installation and Customization Guide

v Message Reference, SC31-8185

for VSE, GC09-1417

v Problem Determination Guide, SC31-8186

v IBM C/370 Reference Summary for VSE,

SX09-1246

Distributed Database Connection Services

(DDCS) Publications

v IBM C/370 Diagnosis Guide and Reference for

VSE, LY09-1805

v DDCS User’s Guide for Common Servers,

S20H-4793

VSE/REXX Publication

v DDCS for OS/2 Installation and Configuration

v VSE/REXX Reference, SC33-6642

Guide, S20H-4795

Other Distributed Data Publications

VTAM Publications

Bibliography

413

v VTAM Messages and Codes, SC31-6493

v VS COBOL II Application Programming Guide,

SC26-4045

v VTAM Network Implementation Guide, SC31-6494

v VS COBOL II Application Programming

v VTAM Operation, SC31-6495

Debugging, SC26-4049

v VTAM Programming, SC31-6496

v VS COBOL II Installation and Customization for

v VTAM Programming for LU 6.2, SC31-6497

CMS, SC26-4213

v VTAM Resource Definition Reference, SC31-6498

v VS COBOL II Installation and Customization for

v VTAM Resource Definition Samples, SC31-6499

VSE, SC26-4696

v VS COBOL II Application Programming Guide for

CSP/AD and CSP/AE Publications

VSE, SC26-4697

v Developing Applications, SH20-6435

v CSP/AD and CSP/AE Installation Planning Guide,

Data Facility Storage Management

GH20-6764

Subsystem/VM (DFSMS/VM) Publications

v Administering CSP/AD and CSP/AE on VM,

v DFSMS/VM RMS User’s Guide and Reference,

SH20-6766

SC35-0141

v Administering CSP/AD and CSP/AE on VSE,

Systems Network Architecture (SNA)

SH20-6767

Publications

v CSP/AD and CSP/AE Planning, SH20-6770

v SNA Transaction Programmer’s Reference Manual

v Cross System Product General Information,

for LU Type 6.2, GC30-3084

GH23-0500

v SNA Format and Protocol Reference: Architecture

Logic for LU Type 6.2, SC30-3269

Query Management Facility (QMF) Publications

v SNA LU 6.2 Reference: Peer Protocols, SC31-6808

v Introducing QMF, GC27-0714

v SNA Synch Point Services Architecture Reference,

v Installing and Managing QMF for VSE,

SC31-8134

GC27-0721

v QMF Reference, SC27-0715

Miscellaneous Publications

v Installing and Managing QMF for VM,

v IBM 3990 Storage Control Planning, Installation,

GC27-0720

and Storage Administration Guide, GA32-0100

v Developing QMF Applications, SC27-0718

v Dictionary of Computing, ZC20-1699

v QMF Messages and Codes, GC27-0717

v APL2 Programming: Using Structured Query

v Using QMF, SC27-0716

Language, SH21-1056

v ESA/390 Principles of Operation, SA22-7201

Query Management Facility (QMF) for Windows

Publications

Related Feature Publications

v Getting Started with QMF for Windows,

v DB2 for VM Control Center Operations Guide,

SC27-0723

GC09-2993

v Installing and Managing QMF for Windows,

v DB2 for VSE Control Center Operations Guide,

GC27-0722

GC09-2992

v DB2 Replication Guide and Reference, SC26-9920

DL/I DOS/VS Publications

v DL/I DOS/VS Application Programming,

SH24-5009

COBOL Publications

v VS COBOL II Migration Guide for VSE,

GC26-3150

v VS COBOL II Migration Guide for MVS and

CMS, GC26-3151

v VS COBOL II General Information, GC26-4042

v VS COBOL II Language Reference, GC26-4047

414

Application Programming

DB2 Server for VSE & VM Application Programming (Version 7 Release 5) - page 9
