Volvo C70 Convertible (2010 year). Manual

10 Audio

Audio functions

Option/accessory, for more information, see Introduction.

239

Press MENU on the audio system, and
navigate to

AUX Volume

AUX Input

Volume

Turn the volume knob to raise or lower the

AUX Input Volume

until you hear music at

a comfortable level.

If there is distortion, lower your music play-
er's headphone volume until the distortion
goes away.

Finally, exit the menu and adjust the audio
volume to a comfortable level.

Volume

Use the volume dial (1) or the buttons in the
steering wheel keypad to adjust the volume
level. The volume level is also adjusted auto-
matically according to the vehicle's speed, see
page 242 for more information on this func-
tion.

Steering wheel keypad

G026424

Steering wheel keypad

The four buttons on the steering wheel keypad
can be used to control the audio system. The
steering wheel keypad can be used to adjust
volume, shift between preset stations and
change CD tracks. Press one of the two left-
hand buttons briefly to change to the next/pre-
vious preset radio station, or to go to the next/
previous track on a CD. Press and hold down
these buttons to search within a track on a CD.

Daytime/twilight display

In daylight the information is displayed against
a light background. In darkness it is displayed
against a dark background.

USB/iPod

connector*

An auxiliary device, such as an iPod

, MP3

player or a USB flash drive can be connected
to the audio system via the connector in the
center console storage compartment. A stand-
ard cable from an iPod

or MP3 player can be

routed under the cover to the AUX connector
in the storage compartment.

A sound source must be chosen, depending on
the device that has been connected:

Use MODE to select

iPod

USB

. The text

CONNECT DEVICE

will be displayed.

Connect the device to the connector in the
center console storage compartment (see
the illustration).

10 Audio

Audio functions

240

The text

LOADING

will be displayed while the

system loads the files (folder structure) on the
device. This may take a short time.

When information about the files (the folder
structure) on the device has been loaded, the
resulting list includes information on the artist,
genre and song title.

To navigate in the folder structure, press
ENTER and scroll up and down the folders
using the arrow buttons (on the audio system
control panel or on the steering wheel keypad).
Press the right arrow button to select a folder.
Press the left arrow button to go up a level in
the folder structure. Press ENTER to go down
a level in the folder structure.

Tracks can be selected in two ways:

Turn the Tuning knob (no. 4 in the illustra-
tion on page 243) clockwise or counter-
clockwise.

Use the right or left arrow keys on the nav-
igation control (no. 5 in the illustration on
page 243) to select the desired track. The
arrow keys on the steering wheel keypad
can also be used in the same way.

NOTE

The system supports playback of files in the
most common versions of formats such as
mp3, wma, and wav. However, there may be
versions of these formats that the system
does not support.

The system also supports a number of
iPod

models produced in 2005 or later.

iPod

Shuffle is not supported.

USB flash drive

To simplify the use of a USB flash drive, it is
advisable to only store music files on the drive.
It will take considerably longer for the system
to index the files on the drive if it contains any-
thing other than compatible music files.

NOTE

The system supports removable media that
uses the USB 2.0 standard and the FAT32
file system and can index up to 500 folders
and a maximum of 64,000 files. The device
must have at least 256 Mb of memory.

MP3 player

Many MP3 players have a file indexing system
that is not supported by the vehicle's audio
system. In order to use an MP3 player, the sys-
tem must be set to USB Removable device/
Mass Storage Device.

iPod

An iPod

receives current and its battery is

charged through the connecting cord. How-
ever, if the iPod's battery is completely
drained, it should be recharged before the
iPod

is connected to the audio system.

NOTE

When an iPod

is used as a sound source,

the vehicle's audio system has a menu
structure similar to the one in the iPod

. See

the iPod's manual for detailed information.

For further information, refer to the accessory
manual USB/iPod

Music Interface.

Sound settings

Optimal sound reproduction

The audio system is calibrated for optimal
sound reproduction through the use of digital
signal processing. This calibration takes into
account the speakers, amplifier, cabin acous-
tics, the seating position of the listener, etc., for
each combination of vehicle and audio system.
There is also dynamic calibration that takes
into account the setting of the volume control,
radio reception, and the vehicle's speed. The
sound settings described in this manual, such
as

BASS

TREBLE

, and

EQUALIZER

are only

10 Audio

Audio functions

241

intended to enable the user to adapt sound
reproduction to his/her personal preferences.

Press SOUND (5). Press this button
repeatedly until you come to the setting
that you wish to change.

Turn the TUNING dial (4) to make the
desired setting.

The following settings can be made:

BASS

–set the bass level

TREBLE

–set the treble level

BALANCE

–set the left/right sound balance

FADER

–set the front/rear sound balance

SUBWOOFER

(accessory)–set the level for

the subwoofer (bass speaker)

CENTER

–make settings for the center speaker

SURROUND

–make settings for surround

sound

Subwoofer (accessory)

To switch the subwoofer on or off:

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

and press

ENTER.

Select

SUBWOOFER

and press ENTER.

Surround sound

Surround sound settings are used to
balance sound levels throughout the
vehicle. Surround settings for the var-
ious sound sources are made sepa-

rately.

G021216

NOTE

•

Dolby Surround Pro Logic II is only
available on the Premium Sound sys-
tem.

•

When listening to FM radio stations,
Dolby Surround Pro Logic II functions
best in areas with strong reception. If
reception is weak, selecting 2 or 3-
channel stereo may provide better
sound quality.

The Dolby symbol will be appear in the display
when Dolby Pro Logic II is activated.

There are three alternative settings:

•

Pro Logic II

•

3-channel

•

Off (normal 2-channel stereo)

Activating/deactivating Surround sound

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

in the menu and

press ENTER.

Select Surround

FM/AM/CD/AUX

and

press ENTER.

Select

Pro logic II

, 3-channel stereo or

Off

and press ENTER.

Equalizer Front/Rear

This function is used to fine-tune the sound
level for different frequencies separately.

NOTE

This function is only available on certain
sound systems.

To adjust the equalizer settings:

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

in the menu and

press ENTER.

Select

Equalizer Front/Rear

and press

ENTER.

The column in the display indicates the sound
level for the current frequency.

•

Adjust the level with the TUNING dial (4),
or use the Up/Down arrows. Additional fre-
quencies can be selected with the Right/
Left arrows.

•

Save the settings by pressing ENTER or
exit without saving by pressing EXIT.

10 Audio

Audio functions

242

Automatic sound control

The audio system's volume is adjusted auto-
matically according to the speed of the vehicle.
There are three settings available, which deter-
mine the level of volume compensation:

•

Low

•

Medium

•

High

To set the automatic sound level:

Press MENU followed by ENTER.

Select

AUDIO SETTINGS

in the menu and

press ENTER.

Select

AUTO. VOLUME CONTROL

in the

menu and press ENTER.

Select

Low

Medium

, or

High

and press

ENTER.

Default setting.

10 Audio

Radio functions

243

Radio function controls

G026366

AM/FM1/FM2 selection

Station preset buttons

TUNING dial for selecting radio stations

SCAN

MENU NAVIGATION CONTROL–press
the up or down arrow keys to scroll in a
menu, or the keys on the left/right sides of
the control to search for or change radio
stations/CD tracks

EXIT–press to cancel a menu selection or
a selected function

AUTO–search for and store the strongest
radio stations in the area in which you are
driving

Searching for stations

There are two ways to manually tune a radio
station:

Turn the TUNING dial (3) to the desired fre-
quency.

Press the left or right arrow key on the
menu navigation control and hold it down.
The radio scans slowly in the selected
direction and will increase the scanning
speed after a few seconds. Release the
button when the desired frequency
appears in the display.

The frequency can be fine-tuned by short
presses on the left/right arrow keys.

Storing preset stations

Manually storing a station

Tune to the desired station.

Press and hold the preset button under
which the station is to be stored. The audio
system sound will be interrupted for a few
seconds and

STATION STORED

will

appear in the display.

NOTE

A total of 30 stations can be stored; 10 sta-
tions each in AM, FM1 and FM2.

Automatically storing a station

Pressing AUTO (7) automatically searches for
and stores up to ten strong AM or FM stations
in a separate memory. If more than ten stations
are found, the ten strongest ones are stored.
This function is especially useful in areas in
which you are not familiar with radio stations or
their frequencies.

To use the AUTO function:

Select a waveband using the AM/FM but-
ton (1).

Start the search by pressing AUTO until

AUTO STORING

appears in the display.

10 Audio

Radio functions

244

When the search is completed,

AUTO

STORING

will no longer be displayed. If there

are no stations with sufficient signal strength,

NO AST FOUND

is displayed.

The auto-stored stations can be selected using
the preset buttons (2).

Press EXIT (6) to terminate the automatic
storing function.

When the radio is in auto-store mode,

AUTO

shown in the display.

AUTO

disappears when

you return to normal radio mode, which can be
done by briefly pressing AM/FM (1), EXIT (6),
or AUTO (7).

To return to the Auto-store mode, press the
AUTO button briefly and select a stored station
by pressing one of the preset buttons (2).

Saving auto-stored stations in the preset
memory

An auto-stored station can be saved in the
memory for manually preset stations.

Press AUTO (7) briefly.

> Auto is displayed.

Press one of the preset buttons (2) under
which the station is to be stored. Hold

down the button until

STATION

STORED

is displayed.

The radio will then exit auto-store mode and
the stored station can be selected by pressing
the preset button.

Scanning

SCAN (4) automatically searches through the
selected waveband for strong AM or FM sta-
tions. When the radio finds a station, that sta-
tion will be played for approximately 8 sec-
onds, after which scanning resumes.

Activating/deactivating SCAN

Select radio mode using the AM/FM but-
ton (2).

Press SCAN to activate the function.

SCAN

is shown in the display.

Press the SCAN or EXIT button to deacti-
vate the scan function and listen to the
selected station.

Storing a station found with SCAN

A station can be stored as a preset while the
SCAN function is activated.

Press one of the preset buttons (2) under
which the station is to be stored. Hold

down the button until

STATION

STORED

is displayed.

The SCAN function will be deactivated and the
station can be selected by pressing the preset
button.

Radio text

Certain stations broadcast program informa-
tion, which can be shown in the display.

To start this function:

Select

FM1

FM2

and press the MENU

button.

Press ENTER.

Select

RADIOTEXT

in the menu and press

ENTER.

To deactivate this function, select

RADIOTEXT

again and press ENTER.

10 Audio

Radio functions

245

HD Radio

൅

൅reception

(U.S.

models only)

Introduction

Display when the radio is receiving an HD Radio
broadcast

HD radio is a brand name registered by the
Ibiquity digital corporation

. They are the

developer of a broadcasting technology called
IBOC or In Band On Channel, which refers to
the method of transmitting a digital radio
broadcast signal centered on the same fre-
quency as the AM or FM station's present fre-
quency.

The IBOC system is referred to as a "hybrid"
since it is both analogue and digital. During
hybrid operation, receivers still continue to
receive the analogue (non-digital) signal. HD
radio receivers incorporate both modes of
reception, where the receiver will automatically
switch to the analogue signal if the digital signal
cannot be decoded or is lost by the receiver.
When you have tuned to an HD Radio station,
the

symbol will appear in the audio sys-

tem display.

More information about HD radio and IBOC
can be found on Ibiquity's website,
www.hdradio.com and www.ibiquity.com.

Benefits of digital broadcasting

•

Better sound (FM sounds near CD quality
and AM as analogue FM).

•

Some FM frequencies offer a greater num-
ber of listening choices through “multicast-
ing” (consisting of a frequency's main
channel and any sub-channels that may
also be available on that particular fre-
quency. See also the section "Sub-chan-
nels" below).

•

When receiving a digital signal there is no
multipath disturbance or hisses/pops/
crackling due to outside influences.

How HD broadcasting works

HD Radio works similarly to conventional radio
and broadcasts of this type are available in
many areas of the United States. However,
there are a few key differences:

•

Instead of transmitting one analogue sig-
nal, stations send out a bundled signal –
both analogue and digital.

•

An HD radio receiver can receive both dig-
ital and analogue broadcasts. Depending
on the terrain and location of the vehicle
(which will influence the signal strength),
the receiver will determine which signal to
receive.

Limitations

•

Main channel vs. sub-channels (FM
only): The main channel is the only channel
that can receive in hybrid mode (both dig-
ital and analogue). If a frequency has sub-
channels, they are broadcast in digital
mode only. The main FM channel will be
displayed as, for example, 93.9 WNYC
(Volvo uses the symbol > to indicate there
are sub-channels available) The sub-FM

HD Radio(TM) technology is manufactured under license from iBiquity Digital Corp. U.S. and Foreign Patents. HD Radio(TM) and the HD and HD Radio logos are proprietary trademarks of iBiquity
Digital Corp. HD Radio(TM) is only available in vehicles not equipped with the optional integrated CD changer.

10 Audio

Radio functions

246

channels will be displayed as 93.9 – 2
WNYC, 93.9 - 3 WNYC, etc.

•

Reception coverage area: Due to current
IBOC transmitter power limitations, the
reception coverage area in digital mode is
somewhat more limited than the station's
analogue coverage area. Please be aware
that as with any radio broadcast technol-
ogy, terrain, time of day, foliage level and
building location can have positive or neg-
ative effects on radio reception.

•

Analogue to digital/digital to analogue
blending: Analogue to digital blending will
occur as the signal strength reaches a pre-
set threshold in the receiver. This will be
noticeable in fringe areas (areas with weak
reception) and is normal.

NOTE

There may be a noticeable difference in
sound quality when a change from analogue
to digital or digital to analogue occurs, such
as:

•

Volume increase or decrease

•

Equalizer settings, i.e. Bass/ Midrange/
Treble cut or boost

•

Time alignment (Digital program mate-
rial in extreme cases can be as much as
8 seconds behind the analogue). This
will noticeable as a "stuttering" effect.

The above items are dependant on the
broadcaster's equipment settings and do
not indicate a fault in the vehicle's radio
receiver or antenna systems.

Switching HD on or off

The factory setting for HD radio is on. However,
when driving through areas with weak HD sig-
nals (fringe areas), you may experience that the
radio repeatedly switches between analogue/
digital and digital/analogue reception. If this
happens, it may be desirable to switch HD off.
To do so:

Be sure the audio system is switched on
and in AM or FM mode.

Press MENU in the center console control
panel.

Press ENTER to turn HD off (the X will dis-
appear from the box on the display screen).

This will disable the radio's capability to receive
digital broadcasts but it will continue to func-
tion as a conventional (analogue) AM/FM
receiver. Please note that when HD is switched
off, it will not be possible to tune to sub-chan-
nels (see the following section for a more
detailed explanation of sub-channels).

Repeat steps 2 and 3 above to reactivate HD
(an X will appear in the box on the display
screen).

Sub-channels

Example of an HD Radio station with sub-channels

10 Audio

Radio functions

247

In many cases, a main HD Radio station (FM
wavebands only) will also have sub-channels
offering additional types of programming or
music.

In such cases, the “>” symbol will be displayed
to the left of the frequency number and a num-
ber will be displayed to the right of the fre-
quency number indicating that the currently
tuned frequency has at least one sub-channel.
The "2" in the illustration indicates that you are
currently listening to the first sub-channel on
frequency 93.9.

Selecting sub-channels

To listen to a station's sub-channel(s), press
the right arrow key on the center console or on
the steering wheel keypad. To go back to the
main channel, press the left arrow key. To go
to subchannel 2 (if available), press the right
arrow key.

If you are currently tuned to a frequency's main
channel, pressing the left arrow key will tune to
the next lower radio frequency.

NOTE

•

When the radio has gone into HD mode,
it may take several seconds before the
">" symbol (if the current frequency has
any sub-channels) is displayed to the
right of the frequency. Pressing the
arrow keys before the number is dis-
played will cause the radio to tune to the
next available radio station, not to the
current station's sub-channels.

•

When you are no longer in broadcasting
range of the currently tuned sub-chan-
nel,

No HD reception

will be dis-

played. The radio will then be muted
and it will be necessary to tune to or
search for a new radio station.

Sub-channels can also be stored as presets,
see page 243 for information on storing sta-
tions.

If you press a sub-channel's preset button, it
may take up to 6 seconds before the channel
becomes audible. If you press this button while
you are out of digital range of the transmitter,

No HD reception

will be displayed.

Listening to satellite radio

The Sirius satellite system consists of a number
of high elevation satellites in geosynchronous
orbit.

NOTE

•

The digital signals from the Sirius satel-
lites are line-of-sight, which means that
physical obstructions such as bridges,
tunnels, etc, may temporarily interfere
with signal reception.

•

Avoid any obstructions, such as metal-
lic objects transported on roof racks or
in a ski box, or other antennas that may
impede signals from the SIRIUS satel-
lites.

Selecting Sirius radio mode

Press Power to switch on the audio system
(see page 243 for information on the stand-
ard radio functions).

Press the MODE button repeatedly until
Sirius 1 or 2 is displayed.

Activating Sirius radio

Tune to a satellite channel that has no
audio, which means that the channel is
unsubscribed and the text "

Call 888-539-

SIRIUS TO SUBSCRIBE

" is displayed

10 Audio

Radio functions

248

(see also "Selecting a channel" in the right
column).

Call Sirius at 1-888-539-SIRIUS (7474).

When asked for the Sirius ID number press
AUTO to display this number. It is also
possible to retrieve the Sirius ID from the
MENU.

UPDATING SUBSCRIPTION

" will be

displayed while the subscription is being
updated, after which the display will return
to the normal view.

SIRIUS ID

The SIRIUS ID is required when contacting the
Sirius Call Center. It is used to activate your
account and when making any account trans-
actions. The SIRIUS ID is sometimes referred
to as the Electronic Serial Number (ESN).

Selecting a channel category

Select Sirius radio mode as described
above.

Press ENTER.

Use the up/down arrow keys to scroll
through the list of categories.

Press ENTER or the right arrow key to
select a category.

Use the left or right arrow keys to select a
channel in the currently chosen category.

Press ENTER to listen to a channel.

NOTE

•

The category "All" is default, which ena-
bles you to scroll through the entire list
of available satellite channels.

•

The channel categories are automati-
cally updated several times a year. This
takes approximately two minutes and
will interrupt normal broadcasting. A
message will be displayed while updat-
ing is in progress. Information on chan-
nel or feature updates is available at
www.sirius.com.

Selecting a channel

There are three ways of tuning in a channel:

•

Using the left and right arrow keys

•

By turning the tuning control

•

Through direct channel entry

Direct channel entry

The Sirius satellite channels are numbered
consecutively throughout all of the categories.
To access a channel directly:

Press MENU and scroll to "Direct channel
entry."

Use the numerical keypad to enter the
channel's number.

Press ENTER. The radio will tune to this
channel, even if it belongs to a category
other than the currently selected one.

NOTE

•

The numbers of skipped or locked
channels will not be displayed.

•

If a channel is locked, the access code
must be entered before the channel can
be selected. See "Unlocking a channel"
on page 249.

Scanning

NOTE

SCAN automatically searches through the
list of satellite channels, see page 244 for
more detailed information.

Storing a channel

•

A long press on one of the number keys
stores the currently tuned channel on that
key.

•

A short press on a number key while the
radio is in Sirius 1 or 2 mode will tune to the

10 Audio

Radio functions

249

preset satellite channel stored on that but-
ton, regardless of the currently selected
channel category.

Song Seek and Song Memory

The Song Seek and Song Memory functions
provide both audio and visual notification when
Sirius is broadcasting your favorite songs.
Song Seek enables you to store the name of
the song for future advance notification when
that song is being played. The Song Memory
feature makes it possible to view all of the cur-
rent songs that are stored in memory.

Song memory

Up to ten songs can be saved in the system's
memory.

Press MENU.

Scroll to "

Add song to song mem.

" and

follow the instructions shown in the dis-
play.

If a new song is selected when the memory is
full, you will be prompted to press ENTER to
delete the last song on the list.

NOTE

The remaining songs in the list will move
down one position, and the newly added
song will be placed at the top of the list.

Song seek

When a satellite radio channel plays one of the
songs stored in the song memory, the listener
will be alerted by a text message and an audi-
ble signal.

Press ENTER to listen to the song or
EXIT to cancel.

To activate/deactivate the song seek function:

Press MENU

Scroll to "

Song seek

Press ENTER to activate or deactivate the
function.

NOTE

When the song has ended, the radio will
remain tuned to the channel on which the
song was played.

Radio text

The text that is displayed about the song that
is currently playing can be changed. Use the
AUTO button or the menu to display the

Artist,

Title, Composer

, or switch

radio text off

Advanced settings

This menu function enables you to make set-
tings on certain Sirius satellite radio functions.
To access this menu:

Press MENU.

Scroll to Sirius menu.

Select

Advanced Sirius settings

WARNING

Settings should be made when the vehicle
is at a standstill.

The following settings can be made in the Sir-
ius menu.

•

Songs can be added to the song list

•

Channel skip settings can be made

•

Channel lock settings can be made

•

The channel access code can be displayed
or changed

•

Your Sirius ID can be displayed

Skip options

This function is used to remove a channel from
the list of available channels.

Skip current

Select

CHANNEL SKIP LIST

and press

ENTER.

10 Audio

Radio functions

250

Select a category in the list and press
ENTER.

Skip channels in the list presented by
pressing ENTER or right arrow key.

Unskip all channels

This permanently removes all channels from
the skip list and makes them available for
selection.

Temp. unskip all ch.

This function will temporarily unskip all chan-
nels and make them available for selection. The
channels remain on the skip list and will again
be skipped the next time the ignition is
switched on.

Channel lock

Access to specific channels can be restricted
(locked). A locked channel will not provide
audio, song titles, or artist information.

NOTE

All channels are initially unlocked.

Locking a channel

Select "

Sirius ID

" in the menu and select

LOCK OPTIONS

and press ENTER.

Select

CHANNEL LOCK LIST

and press

ENTER

Enter the channel access code and press
ENTER.

Select a category in the list and press
ENTER.

Lock channels in the list presented by
pressing ENTER or right arrow.

The channel is now locked and a checked box
will be displayed to indicate this. It will be nec-
essary to enter the channel access code1 in
order to listen to a locked channel.

Unlocking a channel:

A channel's access code1 is required to unlock
a channel.

Unlock all channels

This permanently removes all channels from
the locked list and makes them available for
selection.

Temp. unlock all ch.

This function will temporarily unlock all chan-
nels and make them available for selection. The
channels remain on the locked list and will
again be locked the next time the ignition is
switched on.

CHANGE CODE

This function makes it possible to change the
channel access code. The default code
is 0000.

To change the code:

Select

CHANGE CODE

and press

ENTER.

Enter the current code and press ENTER.

Enter the code and press ENTER.

Confirm the new code and press ENTER.

If an incorrect code is entered, the text

WRONG CODE!

is displayed.

If you have forgotten the access code:

Select "

SIRIUS ID

" in the Sirius settings

menu and press ENTER.

Press and hold the ENTER button for
2 seconds.

The current code will be displayed.

Your Volvo retailer can also provide you with
assistance.

SIRIUS ID

This function displays the 12-digit Sirius acti-
vation ID.

10 Audio

CD player/CD changer

Option/accessory, for more information, see Introduction.

251

CD function controls

G026367

MENU NAVIGATION CONTROL–press
the up or down arrow keys to scroll in a
menu, or the keys on the left/right sides of
the control to change CD tracks/fast for-
ward/back

Buttons for selecting a disc in the
optional CD changer

CD eject button

CD slot

MODE button

TUNING dial for selecting tracks

Playing a CD

Single CD player

Start the CD player by pressing the MODE but-
ton (5) and inserting a disc in the slot (4). If there
is already a disc inserted, it will begin to play.

NOTE

If a CD is in the slot when the audio system
is in CD mode, the CD will be played auto-
matically.

CD changer*

The CD changer can hold up to six discs.

Start the CD changer by pressing the
MODE button (5).

Select an empty position using the 1 – 6
buttons or the up/down keys on the MENU
NAVIGATION CONTROL. The display
shows which positions are empty.

Insert a disc into the slot (4).

NOTE

•

Ensure that

INSERT DISC

is displayed

before inserting a disc.

•

If a CD position in the changer contain-
ing a disc is selected, and the audio
system is in CD mode when it is
switched on, the CD will play automati-
cally.

CD eject

Eject from Single CD player

Press the eject button (3) to eject the disc.

Eject from CD changer

This function makes it possible to eject a single
disc, or to eject all of the discs in the changer.

Press the eject button (3) briefly to eject the
disc that is currently playing.

A longer press (more than two seconds)
starts the process of ejecting all of the
discs in the changer.

10 Audio

CD player/CD changer

252

NOTE

•

The EJECT ALL function can only be
used while the vehicle is at a standstill
and will be cancelled if the vehicle
begins to move.

•

For reasons of traffic safety, the ejected
CD must be removed within 12 seconds
or it will be automatically drawn back
into the slot and the CD player will enter
pause mode. Press the CD button to
restart the disc.

CD Pause

When the audio system volume is turned off
completely, the CD player will pause and will
resume playing when the volume is turned up
again.

Audio files

In addition to playing normal music CDs, the
CD player/changer can also play discs con-
taining files in mp3 or wma format.

NOTE

Certain discs that are copy protected can-
not be read by the player.

When a disc with audio files is inserted in the
player, the player scans the disc's folders
before it begins playing the files. The length of

time that this takes depends on the quality of
the disc.

Navigating the disc and playing tracks

If a disc with audio files is in the CD player,
press ENTER to display a list of folders on the
disc.

Use the up and down arrows in the navigation
control (see the illustration on page 251) to
move among the folders on the disc. Audio files
have the

symbol and folders containing

these files have the

symbol. Press

ENTER to play a selected folder or a file.

When the music file has been played, the
player will continue to play the rest of the files
in the current folder. When all of the files in the
folder have been played, the player will auto-
matically go to the next folder and play the files
in it.

Press the left or right arrow key on the naviga-
tion control if the entire name of the current
track does not fit in the display.

Changing tracks

Briefly press the left or right arrow keys on the
MENU NAVIGATION CONTROL to skip to the
previous or next track/file.

NOTE

The TUNING dial (6) (turn clockwise to go to
the next track/file, or counterclockwise to
go to the previous track/file) or the steering
wheel keypad can also be used for this pur-
pose.

Fast forward/back

Press and hold down the left or right arrows
keys in the menu navigation control (or the
corresponding keys on the optional steer-
ing wheel keypad) to search within a track/
file or the whole disc. The search continues
for as long as the buttons are held down.

Random play

This function plays the tracks/files on a CD (or
on all of the CDs if the vehicle is equipped with
the optional CD changer) in random order
(shuffle).

Activating/deactivating the random
function-CD player

If a normal CD is being played:

Press MENU followed by ENTER.

Select Random and press ENTER.

If a CD with audio files is being played:

Press MENU followed by ENTER.

Select

Random

and press ENTER.

10 Audio

CD player/CD changer

253

Select

Disc

Folder

and press ENTER.

Activating/deactivating the random
function-CD changer

If a normal CD is being played:

Press MENU followed by ENTER.

Select

Random

and press ENTER.

Select

Single disc

All discs

and press

ENTER.

If a CD with audio files is being played:

Press MENU followed by ENTER.

Select

Random

and press ENTER.

Select

Single disc

Folder

and press

ENTER.

NOTE

CD changer only–you can only select the
next random track/file on the current disc.

Press the EXIT button to stop random play.
The random function is automatically deacti-
vated when another disc is selected.

Disc text (CD changer only)

Certain CDs contain information about the
disc, such as the titles of the tracks, etc. This
information can be shown in the display by
activating the DISC TEXT function.

Press MENU. Select the menu for relevant
sound source and press ENTER.

Select

Disc text

in the menu and press

ENTER.

> If information is stored on the disc, it will

now appear in the display.

To deactivate this function, select

Disc text

the menu and press ENTER.

Scan

This function plays the first 10 seconds of each
track/file on the CD.

Press SCAN.

Press EXIT or SCAN to stop the scan func-
tion and listen to an entire track/file.

CD eject

Single CD player

Press the eject button (3) to eject the disc.

CD changer

This function makes it possible to eject a single
disc, or to eject all of the discs in the changer.

•

Press the eject button (3) briefly to eject the
disc that is currently playing.

•

A longer press (more than two seconds)
starts the process of ejecting all of the
discs in the changer.

NOTE

•

The Eject all function can only be used
while the vehicle is at a standstill and will
be cancelled if the vehicle begins to
move.

•

Compact disc care

Keep the following in mind when playing/han-
dling compact discs

•

Do not put tape or labels on the disc itself.
They could become stuck in the player.

•

CDR discs can cause listening problems
due to the quality of the disc or recording
equipment used.

•

DualDisc: The audio side of a DualDisc
(combined CD/DVD) does not meet CD
specifications and may not play in your
audio system.

•

Keep the discs clean. Wipe them with a
soft, clean, lint-free cloth, working from the
center outward. If necessary, dampen the
cloth with a neutral soap solution. Dry thor-
oughly before using.

10 Audio

CD player/CD changer

254

•

Never use cleaning spray or antistatic liq-
uid. Use only cleaners specifically made for
CDs.

•

Use discs of the correct size only
(3.5" discs should never be used).

•

Volvo does not recommend the use of
plastic outer rings on the disc.

•

Condensation may occur on discs/optical
components of the changer in cold winter
weather. The disc can be dried with a
clean, lint-free cloth. Optical components
in the CD changer may, however, take up
to one hour to dry off.

•

Never attempt to play a damaged CD.

•

When not in use, the discs should be
stored in their covers. Avoid storing discs
in excessive heat, direct sunlight or in
dusty locations.

Volvo C70 Convertible (2010 year). Manual - part 14
