on: 92...97 °C

off: 84...91 °C

2. Speed

on: 99...105 °C

off: 91...98 °C

19. Bracket

z

For bottom of radiator

z

Note installed position

20. Bracket

z

For top of radiator

z

Note installed position

Fig. 1: Identifying Cooling System Components - Body Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLING SYSTEM COMPONENTS - ENGINE SIDE

1. 15 N.m

2. Coolant pump

z

Check for ease of movement

z

Note installed position

z

Removing and installing. See COOLANT PUMP, REMOVING AND INSTALLING

3. O-ring

NOTE:

The following list refers to items in Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



z

Always replace

4. Bypass flap

z

For exhaust gas recirculation radiator

5. Radiator

z

For exhaust gas recirculation

6. To top of expansion tank

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

7. Upper front coolant pipe

z

Installed with cylinder head cover on front side of cylinder head

z

One unit with fuel lines

8. Connection union

9. Seal

z

Check for secure seating

z

Always replace

10. Securing clip

z

Check for secure seating

11. Engine Coolant Temperature (ECT) Sensor -G62-

z

With Engine Coolant Temperature (ECT) Sensor -G2-

12. 10 N.m

13. Heating flange

z

For glow plugs

14. Glow plugs

z

25 N.m

z

Checking. See GLOW PLUGS, CHECKING .

15. Quick-action coupling

16. To heat exchanger

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

17. From heat exchanger

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

18. Distributor

19. To top of radiator

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

20. Coolant pipe

21. 40 N.m

22. To bottom of expansion tank

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

23. Transmission oil cooler



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



24. To bottom of radiator

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

25. Oil cooler

z

Removing and installing. See PART 2: DISASSEMBLING OIL FILTER BRACKET .

26. Connection union

z

For thermostat

27. Thermostat

z

Removing and installing. See THERMOSTAT, REMOVING AND INSTALLING .

z

Observe installed position. See THERMOSTAT, REMOVING AND INSTALLING .

z

Checking: Heat-up thermostat in water

z

Starts to open: approx. 85° C

z

Ends: approx. 105° C

z

Opening stroke: min. 7 mm

Fig. 2: Identifying Cooling System Components - Engine Side
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLANT HOSE CONNECTION DIAGRAM

1. Radiator

2. Oil cooler

3. Thermostat

4. Coolant pump

5. Cylinder block

6. Expansion tank

NOTE:

The following list refers to items in Fig. 3 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



7. Intake manifold

8. Radiator

z

For exhaust gas recirculation

9. Bypass flap

z

For exhaust gas recirculation radiator

10. Connection union

z

To cylinder block

11. Heater unit heat exchanger

12. Quick-action coupling

13. Coolant pipe

14. Transmission oil cooler

15. Distributor

16. Upper front coolant pipe

Fig. 3: Coolant Hose Connection Diagram
Courtesy of VOLKSWAGEN OF AMERICA, INC.

COOLANT, DRAINING AND FILLING

Special tools and equipment

z

T10007 Refractometer

z

V.A.G 1306 Drip tray for VAG1202A

z

VAS 5024 Assembly tool for spring-type clips

Not illustrated:

z

VAS 6096 Coolant system charging unit



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW
