Fig. 13: Removing Thermostat
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



Installation is carried out in the reverse order. Note the following during installation:

z

Moisten new O-ring -3- with coolant.

z

Insert thermostat -4- in connection -2- and turn 1/4 turn (90°) to right.

z

Install thermostat -4- into engine block.

z

Tighten mounting bolt -1- to 15 N.m (11 ft lb).

z

Fill engine with coolant. See COOLING SYSTEM, DRAINING AND FILLING .

NOTE:

The brace on the thermostat must be almost vertical.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - 1.9L 4-Cyl. ALH - New Beetle



1998-2004 ENGINE

Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW

COOLING SYSTEM COMPONENTS, REMOVING AND INSTALLING

Perform cooling system leakage test with cooling system tester V.A.G 1274 and adapters V.A.G 1274/8 and
V.A.G 1274/9.

Cooling system components - body side. See COOLING SYSTEM COMPONENTS - BODY SIDE .

Cooling system components - engine side. See COOLING SYSTEM COMPONENTS - ENGINE SIDE .

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

Draining and filling with coolant. See COOLANT, DRAINING AND FILLING .

Coolant mixing ratios. See COOLANT, DRAINING AND FILLING .

COOLING SYSTEM COMPONENTS - BODY SIDE

1. Radiator

z

Removing and installing. See RADIATOR, REMOVING AND INSTALLING

CAUTION: When performing repair work, especially due to the confined conditions in

the engine compartment, pay attention to the following:

z

Route all types of hoses/lines (e.g. for fuel, hydraulics, EVAP system,
coolant, refrigerant, brake fluid and vacuum) as well as electrical
wiring so that the original positions are restored.

z

Ensure sufficient clearance to all moving or hot components.

NOTE:

z

When the engine is warm, the cooling system is under pressure. If
necessary, release the pressure before beginning repair work.

z

Hoses are secured with spring-type clips. In case of repair, only use
spring-type clips.

z

Assembly tool VAS 5024 or hose clip pliers V.A.G 1921 are recommended
for installing spring-type clips.

z

When installing coolant hoses, route stress-free so that they do not come
into contact with other components (observe markings on coolant
connection and hose).

NOTE:

The following list refers to items in Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Cooling System - New Beetle, 1.9L 4-Cyl. - BEW



z

After replacing, replace entire quantity of coolant

2. O-ring

z

Always replace

3. Upper coolant hose

z

Secured to radiator with retaining clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

4. Connector

5. Cap

z

Check with coolant system tester V.A.G1274 and adapter V.A.G 1274/9

z

Pressure relief valve must open at a pressure of 1.4 to 1.6 bar

6. 2.5 N.m

7. Expansion tank

z

Perform leak test on coolant system with coolant system tester V.A.G 1274 and adapter V.A.G
1274/8

z

Test pressure: 1.4 to 1.6 bar

z

Observe markings. See COOLANT, DRAINING AND FILLING .

8. To coolant pipe

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM

9. Air ducting

10. 5 N.m

11. Supplementary fan

z

Only models with optional equipment

12. Fan ring

z

For additional fan

13. Fan ring

14. Coolant fan

15. Bracket

z

For coolant fan connector.

16. Lower coolant hose

z

Secured to radiator with retaining clip

z

Coolant hose connection diagram. See COOLANT HOSE CONNECTION DIAGRAM .

17. O-ring

z

Always replace

18. Coolant Fan Control (FC) Thermal Switch -F18-, 35 N.m

z

For electric fan

z

Switching temperatures:

1. Speed
