Fig. 154: Identifying VAS 5051 Vehicle Diagnosis, Testing And Information System
Courtesy of VOLKSWAGEN OF AMERICA, INC.

TEST PREREQUISITES FOR OBD

z

The tires installed to all wheels must be of the same (approved) size; tires inflated to prescribed pressure.

z

Mechanical/hydraulic parts of the brake system including brake light switch and brake lights OK.

z

Hydraulic connections and lines are not leaking (visual check of hydraulic module, brake calipers, wheel
cylinders, tandem brake master cylinder).

z

Wheel bearings and wheel bearing play are OK.

z

ABS Control Module (w/EDL) -J104- is correctly bolted to hydraulic unit -N55-.

z

Electrical connection is installed correctly to the ABS Control Module (w/EDL) -J104- (locking device is
engaged correctly).

z

Check electrical connections of ABS components for damage and correct seating.

z

All fuses, according to wiring diagram OK. (remove fuse from holder to check).

z

Supply voltage OK. (at least 10.0 V)

z

Access to the OBD is only possible when the vehicle is stationary and ignition turned on (or engine
running).

z

When checking the ABS system make sure that the vehicle electric system is not affected by
electromagnetic interference, i.e. the vehicle is kept well away from equipment with a high current draw,
e.g. from an electric welding module.

SAFETY PRECAUTIONS



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



SCAN TOOL CONNECTING

All functions which could previously be performed with V.A.G 1551/1552 can also be performed with the new
tester VAS 5051 in the operating mode vehicle OBD.

Connecting VAS 5051

z

With ignition switched off, connect tester VAS 5051 to Data Link Connector using diagnosis cable VAS
5051/1 or VAS 5051/3.

Selecting operating mode:

z

Press button on display for "Vehicle OBD".

Selecting vehicle system:

z

Press "03 - Brake electronics" on display.

WARNING:

z

You must always secure testing and measuring equipment on the
rear seat.

z

When vehicle is being driven, only a second technician operate this
equipment.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 155: Connecting Tester VAS 5051 To Data Link Connector Using Diagnosis Cable VAS 5051/1
or VAS 5051/3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The control module identification and coding are indicated on the display.

Selecting diagnosis function:

All diagnostic functions available are indicated on the display.

z

Press button on display for desired function.

z

Further measures see repair procedures.

V.A.G 1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTION

Special tools and equipment

NOTE:

The following test sequences are for V.A.G 1551 scan tool.

NOTE:

z

All functions that have so far been carried out with V.A.G 1551 can now
also be carried out with the tester VAS 5051.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



z

V.A.G 1551 scan tool

Fig. 156: Identifying V.A.G 1551 Scan Tool
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

V.A.G 1551/3 or 1551/3A adapter cable
