Fig. 151: Locating Warning Lamps For K47, K118 And K155
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ABS WARNING LIGHT -K47-



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 152: Locating ABS Warning Light K47
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

If the ABS warning light -K47- -1- does not go out after switching the ignition on and completion of the
test sequence, the malfunction may be:

-a- Voltage supply is below 10 Volt

-b- There is a malfunction in the ABS

The anti-locking brake system remains switched off with an ABS malfunction -b-, but the brake system
remains fully operational.

Check Diagnostic Trouble Code (DTC) memory, see DIAGNOSTIC TROUBLE CODE (DTC)
MEMORY, CHECKING .

-c- Since the last time the vehicle was started there was a temporary speed sensor malfunction.

In the case of sensor malfunction -c- the ABS warning light -K47- will extinguish after restarting the
engine and attaining a speed of above 20 km/h (approx. 13 mph).

-d- The connection from instrument cluster to ABS Control Module (w/EDL) -J104- is interrupted (open



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



circuit).

-e- Instrument cluster is faulty.

WARNING LIGHTS -K47- AND -K118-

z

If the ABS warning light -K47- -1- goes out but the warning light for brake system -K118- -2- remains
on, then the malfunction may be:

-a- The parking brake is applied.

-b- There is a malfunction in the activation of the warning light for brake system -K118-, see wiring
diagram.

-c- The brake fluid level is too low.

z

If the ABS warning light -K47- -1- and the warning light for brake system -K118- -2- illuminated, the
ABS system is faulty and the EBD (electronic brake pressure distribution) is not functioning.

ESP CONTROL LAMP -K155-

WARNING:

After the ABS warning light -K47- and warning light for brake system -
K118- have illuminated, it is possible that the rear wheels will lock-up
earlier when braking.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES On Board Diagnostic (OBD) - New Beetle



Fig. 153: Locating ESP Control Lamp K155
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

If the ESP Control Lamp -K155- -3- does not go out after the ignition is switched on and test sequence is
completed then the malfunction may be:

Check Diagnostic Trouble Code (DTC) memory, see DIAGNOSTIC TROUBLE CODE (DTC)
MEMORY, CHECKING .

-a- Short to positive in ASR/ESP button -E256-

-b- There is a malfunction in the activation of the ESP Control Lamp -K155-.

-c- The ASR/ESP system has been switched off via ASR/ESP button -E256-.

There is a malfunction present which only affects the safety systems of the ASR/ESP. The ABS/EDL and EBD
safety systems on the vehicle remain fully functional.

If ESP control lamp -K155- flashes while driving, the ASR or ESP system is regulating the system.

ON BOARD DIAGNOSTIC (OBD), PERFORMING

SCAN TOOL, CONNECTING

All functions which could previously be performed with V.A.G 1551/1552 can also be performed with the new
tester VAS 5051 in the operating mode vehicle OBD.

See .

SPECIAL TOOLS AND EQUIPMENT

z

VAS 5051 Vehicle Diagnosis, Testing and Information System

z

Diagnosis cable VAS 5051/1 or VAS 5051/3

NOTE:

This On Board Diagnostic (OBD) is for the ABS MARK 60 system.

NOTE:

z

The ABS function is switched off in the control module during the On
Board Diagnostic (OBD).

z

The Diagnostic Trouble Code (DTC) memory must be erased after a
successfully checking and repair.
