Volkswagen New Beetle. Manual - part 673

Brake pad wear indicator light -K32-

z

If the brake pad wear indicator light -K32- -1- does not go out after ignition is switched on and test
sequence is completed, or it lights up while driving, then the malfunction may be:

-a- The brake pads can be worn out

Check the front and rear brake pads.

See FRONT DISC BRAKE PADS and REAR DISC BRAKE PADS .

-b- There is a malfunction in the activation of the brake pad wear indicator light -K32-.

Fig. 47: Identifying Brake Pad Wear Indicator Light -K32-
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



ABS warning light -K47-

z

If the ABS warning light -K47- -2- does not go out after ignition is switched off and test sequence is
completed, then the malfunction may be:

-a- Voltage supply is below 10 Volt.

-b- There is a malfunction in the ABS.

The anti-lock brake system remains switched off with an ABS malfunction -b-, but the brake system
remains fully operational.

-c- Since the last time the vehicle was started there was a temporary speed sensor malfunction.

In the case of a sensor malfunction -c-, the ABS warning light -K47- will extinguish after restarting the
engine and attaining a speed of above 20 km/h (approx. 13 mph).

-d- The connection of instrument cluster to ABS control module (w/EDL) -J104- is interrupted.

-e- Instrument cluster is faulty.

Fig. 48: Identifying ABS Warning Light -K47-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Warning lamps -K47- and -K118-

z

If the ABS warning light -K47-, -2-, goes out, but the warning light for brake system -K118-, -3-, remains
on, then the malfunction may be:

-a- The parking brake is applied.

-b- The brake fluid level is too low.

-c- There is a malfunction in the activation of the warning light for brake system -K118-.

z

If the ABS warning light -K47- -2- and the warning light for brake system -K118- -3- light up, the ABS



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



system is faulty and the EBD (Electronic brake pressure distribution) is not functioning.

Fig. 49: Identifying Warning Lamps -K47- And -K118-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ASR/ESP control lamp -K155-

z

If the stabilization program ASR/ESP control lamp -K155- -4- does not go out after ignition is switched
off and test sequence is completed then the malfunction may be:

-a- Short to positive in ASR/ESP button -E256-.

-b- There is a malfunction in the activation of the stabilization program ASR/ESP control lamp -K155-.

-c- The ASR/ESP has been switched off via button -E256-.

There is a malfunction present which exclusively affects the safety systems of the ASR/ESP. The
ABS/EDL and EBD safety systems of the vehicle remain fully functional.

If stabilization program ASR/ESP control lamp -K155- flashes while driving, the ASR or ESP
system is regulating the system.

WARNING:

After the ABS warning light - K47- and warning light for brake
system -K118- have lighted up, it is possible that the rear wheels will
lock up earlier.



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle



Fig. 50: Identifying ASR/ESP Control Lamp -K155-
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ABS SYSTEM COMPONENTS ON FRONT AND REAR AXLE

ABS SYSTEM COMPONENTS ON FRONT AXLE, REMOVING AND INSTALLING

1. ABS speed sensor

z

Before inserting sensor, clean mounting hole inner surface and coat with lubricant G 000 650

2. Wheel bearing housing

3. Hex socket head bolt, 8 N.m (71 in lb)

4. Splash plate

5. Hex bolt, 10 N.m (88 in. lb)

6. Wheel bearing

z

Replace each time after removing

z

Pressing out and in

See WHEEL BEARING (WHEEL BEARING HOUSING INSTALLED

7. Phillips-head screw

8. Brake disc

9. Wheel hub with rotor

z

Pressing out and in

NOTE:

Removing and installing ABS system components is identical for FS III and FN 3
brake calipers.

NOTE:

The following list refers to items in Fig. 51 .



2003 Volkswagen New Beetle GLS

1998-2004 BRAKES Anti-Lock Brake System - New Beetle
