Volkswagen New Beetle. Manual - part 584



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 37: Tightening Combi-Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Adjusting side inclination (distance)

z

Remove window slot outer seal.

z

Remove bolts/screws -1-.

NOTE:

The side window must be installed.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle



Fig. 38: Removing Window Bolts/Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosen combi-nuts in assembly opening.

Fig. 39: Loosening Combi-Nuts In Assembly Opening
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Adjust side window distance and inclination at adjuster using an Allen key.

z

Then perform functional check.

z

Tighten combi-nuts.



2003 Volkswagen New Beetle GLS

1998-2004 EQUIPMENT & EQUIPMENT Glass, Window Regulators - New Beetle
