Volkswagen New Beetle. Manual - part 528

Fig. 38: Pressing Connecting Rod Ball Joint Off Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release circlip -1- from pin -2-.

z

Release spring -3- from backrest -4- with a screwdriver.

Fig. 39: Removing Circlip From Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull pin -2- out of backrest -4-, when doing this hold spring -3- with a pair of pliers and pull out.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 40: Pulling Pin Out Of Backrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release button housing -1- -arrow- and take off rear panel -3-.

Fig. 41: Locating Button Housing And Release Rods
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Dismantle release rods -2- and clips -4- from rear panel -3-.

Installing

Install in reverse order of removal.

z

Pin -2-, spring -3- and locking hooks -5- must be inserted together.

NOTE:

The clips -4- can be disassembled from the rear panel, when the spreader
pin is pushed out of the clip. (Remove spreader pin from rear panel ready
for reinstallation).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



z

Engage circlip -1- in pin -2-.

Fig. 42: Installing Right Backrest Locking Device (Two Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tension spring -3-.

z

Perform a functional check after assembling is completed, adjust locking hooks if necessary.

Adjusting locking hooks

z

If part of original equipment, loosen nut -3- and press connecting rod ball joint -1- off locking hooks -2- -
arrow- with a screwdriver

z

Turn ball joint -1- on connecting rod so that the effective length of the connecting rod is increased or
decreased as applicable.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle



Fig. 43: Adjusting Locking Hooks - Right Backrest Locking Device (Two Piece)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

LEFT BACKREST LOCKING DEVICE (TWO PIECE), ASSEMBLY OVERVIEW

1. Release rod

2. Connecting rod

3. Locking hook

4. Pin

5. Rear panel

6. Mounting pin

7. Padding

8. Padding wire

9. Cover

10. Button

z

Must be removed together with cover and padding.

11. Clip

12. Operating rod

13. Release rod

14. Clip

NOTE:

The following list refers to items in Fig. 44 .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
