Volkswagen New Beetle. Manual - part 526

upward on left and right-hand sides out of backrest mounting -3-.

Fig. 25: Pressing Retaining Hooks On Left And Right-Hand Sides Back
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install backrest -2- into backrest mounting -3- and press downward. (Locking lugs -1- will lock when
doing this).

Fig. 26: Installing Backrest Into Backrest Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Install retaining support -2- onto center mounting -3-.

Screw screws -1- into back of backrest. Torque setting: 20 N.m.

2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle

Fig. 27: Installing Retaining Support Onto Center Mounting
Courtesy of VOLKSWAGEN OF AMERICA, INC.

BACKREST LOCKING DEVICE (ONE PIECE), ASSEMBLY OVERVIEW

1. Release rod

2. Locking hook

3. Pin

4. Rear panel

5. Padding

6. Cover

7. Padding wire

8. Button

9. Connecting rod

10. Clip

NOTE:

The following list refers to items in Fig. 28 .

2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle

Fig. 28: Identifying Backrest Locking Device (One Piece) Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.

BACKREST LOCKING DEVICE (ONE PIECE), REMOVING AND INSTALLING

Removing

Remove backrest. See BACKREST (ONE PIECE), REMOVING AND INSTALLING .

Remove padding.

Press left and right-hand connecting rod -1- ball joint off locking hooks -2- with a screwdriver -arrow-.

Fig. 29: Pressing Left And Right-Hand Connecting Rod Ball Joint Off Locking Hooks
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Release circlip -1- from pin -2-. See Fig. 30 .

Release spring -3- from backrest -4- with a screwdriver.

2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle

Fig. 30: Removing Circlip From Pin
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Pull pin -2- out of backrest -4-, when doing this hold spring -3- with a pair of pliers and pull out.

Fig. 31: Pulling Pin Out Of Backrest
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Release button housing -1- -arrow- and take off rear panel -3-.

2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Seats - Frames - New Beetle
